●Machine designed with finite element analysis to
ensure the high rigidity and best structural
optimization, also provided with high precision
machining performance and stability.
●Three axes are roller type linear guide way
(35/35/45 mm); the Z axis has no counter weight
needed in order to enhance the machine stability.
●Direct drive spindle with the speed of 15000rpm –
BBT.
●Automatic pneumatic magazine door, linear
guideway, precise and stable feed and prevents
coolant going into the magazine.
●Automatic lubrication on three axes ball screws,
effectively prevent oil deterioration, and reduce the
heat generation and thermal expansion during high
speed machining to achieve high speed and high
precision.
●Three axes federate can reach the maximum of
1.0G.
●Equipped linear scales in three axes, which can
make compensation for the thermal displacement
during high speed operation, effectively improving
the accuracy of three axes.
