Swing over bed: 660mm / 900mm / 1150mm / 1500mm
Swing over cross slide: 370mm / 520mm / 700mm / 900mm
Width of bed: 460mm / 560mm / 725mm / 1000mm
Distance between centers: 1055~4285mm / 1015~6330mm / 1020~7020mm / 2075~6075mm
Spindle bore & speed (CL-38): 120mm (6-1600rpm), 186mm (3-1000rpm)
Spindle bore & speed (CL-58): 120mm (6-1600rpm), 186mm (3-1000rpm), 258mm (6~600rpm), 375mm (4~400rpm)
Spindle bore & speed (CL-68/CL-78): 181mm (6-650rpm), 255mm (6~600rpm), 375mm (4~400rpm), 530mm (2~300rpm)
Spindle motor(CL-38): 30HP
Spindle motor(CL-58): 30HP, 40HP
Spindle motor(CL-68/CL-78): 60HP
Turret: V8, H4, H6
