AccuteX — Wire Cut EDM Automation Solution ﹝Industry 4.0- Intelligent Manufacturing System﹞

Industry 4.0- Intelligent Manufacturing System

The whole system combined "Automatic final core removing function", "Probing function","CIMFORCE Intelligent Manufacturing System"

and R obotics to achieve untended multi-workpiece production. It provides End-to-End solutions that start from project management,

mold design, process processing to molding quality testing. It provides a solution for Industry 4.0.

(*) Performed by AP-4030A-0.1μm Linear scale

(*) The cutting conditions must follow AccuteX's provisions.

Features

1. Real-time communication with the machines via common APPs-Line, no more software expense.

2. Monitoring the cutting status remotely by your existing Line account.

3. Push notification to a specific account or group.

Accutex Rotary Table Package is leading ahead of other WEDM manufacturers by years in R&D which can be applied to

submerged operation.

The Built-in Type Motorized Spindle features ultra-high resolution 720,000 pulses each revolution,

free of backlash problems.

Standard 120RPM spindle speed, optional 1,000RPM high-speed spindle for Turn & Burn application.

Core Remove Module (*Optional)

During Wire Cut EDM machining, by using the new-generation flushing nozzle to remove

the core automatically can reduce human operation and increase productivity.

1.Patented technology to remove core.  Patent ( No.I676513)

2.Core Remove Module can fit together with existing machine.

3.Final core collection box can setup easily on multi-positions.

4.Integrated with CIMFORCE intelligent manuacturing system and robot to increase productivity.
