There are two types of gantry milling machine, CNC computer type and non-NC computer type (traditional manual type). It is a milling machine with a portal frame and a horizontal long bed. Gantry milling machines are suitable for machining flat and inclined surfaces of large workpieces in batch and mass production. CNC gantry milling machines can also process space curved surfaces and some special parts.

In recent years, the usage habits and processing conditions of gantry milling machines are different, so gantry milling heads have also successively introduced milling heads in different directions for use in machine tools (vertical/horizontal milling heads), and also widely load angle heads/horizontal milling heads. So that the processing range of the gantry milling machine is wider to meet the more difficult processing requirements.

Mention traditional gantry milling head, how to choose the correct one to install on a gantry machine?

There are two options：

- Machine body, according to the connection plate on the gantry milling machine, confirm which type of milling head the connection hole matches.

- Application, according to the user's processing conditions.

(Such as: processing material, processing efficiency, cutting amount...etc.)

Traditional gantry milling heads can generally be distinguished from the size of the motor, gear speed, processing travel and the connection hole position behind the milling head:

-Size of motor: 10HP/12.5HP/15HP/20HP/other

-Gear speed: 2 stages/6 stages/9 stages/other

- Processing travel: 320mm~700mm/other

Besides, it can also as a match basis through the connection holes on the back of the milling head (if the user needs to modify or replace the milling head).

In necessary, you need to customize a special gantry milling head to match the special body.

(Such as: super large gantry milling machine, gantry milling machine with special processing conditions.)

The CNC (Computer Numerical Control) milling machine is a typical machine tool in the machinery sector. It is a common kind of CNC that can execute repeated drilling and turning activities that were previously performed by humans.

Ø Classification of CNC milling machines

The total number on a CNC machine determines its classification. For horizontal movement, axes are designated x and y, while for vertical movement, axes are labeled z. You will be able to call these as milling heads. Milling Head Z, Table Z, Table Y, and Table X are the four axes of this machine. The number of axes it possesses is often represented in a variety of ways. Out of these, milling heads are the most important, as they play a major role than other axes.

There is a five-axis machine, for example. The additional 5th axis comes in the form of a vertical pivot for the mill head, which ensures outstanding machining flexibility by allowing the end mill to follow the table at an angle. It's commonly programmed using a set of standard instructions known as G-codes, which are used to express particular CNC jobs in alpha-numeric form.

Ø Important features to note in CNC milling machines

This machine comes in a variety of sizes, depending on the purpose and area of use, and the material that need to be cut.

Aside from that, the capacity of the motor has an impact on the speed with which the materials are sliced. Plastic or wood are often the simplest materials to cut, but steel requires a more powerful milling machine and more time. You should focus on the specifics before you buy a milling machine. Then you will never regret about the machine that you purchase to get work done.

The stiffness of milling may be used to assess its performance. For instance, the stiffer a mill is the more accurately it drills or cuts. In comparison to manual mills, CNC mills often feature superior and harder engines for increased stiffness.

Ø What are the benefits that you can get out of a milling machine

In comparison to manual operation, we can increase the speed of cut using a CNC milling machine. When the rigor of the findings rose, it also lowered rejection. As a result, in the long term, it'll save a lot of money and time since there will be less waste.

Another advantage of using a cut via CNC milling machine with such a computerized numerical control machine is the precision. It is critical in a manufacturing line that all pieces be made identically. Nothing, however, is perfect. Because a mill may cut with precise accuracy as near as.0001 of an inch, the operator of a CNC milling machine is at fault.

Many milling machines also feature beds that can move at various angles for easier cutting activities, variable angled cuts, and more complex drilling operations. It is one of the advantages of a CNC mill over a manual mill. By spraying and blasting hot metal and even tooling using specially designed coolant, it is possible to retain the quality raw material using controlled cooling systems.

Final words

Now you have a good understanding of the different features that milling machines are capable of offering. As you go ahead and buy a milling machine, you need to focus on these features. Then you can determine what the best feature that you should be spending your money on is. Upon the discovery of that perfect milling machine, you can simply stick to it and get your work done.

If you're searching for a CNC Milling Head, the chances are that you will need a lot of help deciding which one is best for your needs. When you are on a mission to buy the best CNC milling machine, not just any device will do.

You have a lot of things to consider and lots of things to think about. If you don't do ample research ahead of time, you may make a purchase that is not worthwhile. Don't let yourself make an impulsive buying decision.

You may already know the basics about CNC Milling, but you are still looking for a specific guide or comparison chart that breaks down all the specs and whatnot into a more straightforward, digestible form. If this is the case, you have come to the right place!

Top 9 Tips for Buying Best CNC Milling Head

The CNC milling head is the essential part of a CNC mill. It is the heart of a CNC milling machine, which can make the machines work or not work. Therefore, it is indispensable to choose a good one.

1.Choose the Right Spindle

The spindle is an essential part of the CNC milling head, which determines the performance and accuracy of your CNC milling machine. Choosing the wrong spindle will affect your workpiece's accuracy and quality and your machine's performance and life span.

Therefore, choosing a high-quality spindle with high rigidity, high precision, and long service life for your CNC milling machine is extremely important.

2.Make Sure Your Machine Is Plug-and-Play

Another thing to consider when buying a CNC milling head is whether it's plug-and-play or not. If it isn't, then this means that there will be some setup required for everything to work correctly together before you can use it.

When this happens, there might be issues with alignment and calibration (among other things), which could cause problems down the road if they aren't fixed right away.

3.Choose the Right Tooling

The second step is to choose the proper tooling for your application. The most common type of tooling is called "tool holders," which are mounted directly to the spindle and allow you to change out different bits.

Other options include collets (which grip round objects like drill bits), end mills (which cut on one side only), or slot drills (which can cut slots as well as round holes). Slot drills are beneficial if your part requires multiple holes that align perfectly with one another.

4.Fix Your Requirements

Before searching for the best CNC milling head, you need to know what you want from it. The first thing to consider is your budget. You should never buy a product that is beyond your budget.

You also need to consider what kind of work you will be doing with this machine tool. Any CNC milling head will do if you are a hobbyist who just wants to make small projects or have fun.

However, if you are an experienced engineer who needs to make complex parts for big projects, you should buy a high-end product with additional features.

5.Find Out About the Manufacturer

The next thing you need to do before buying any product is to find out about its manufacturer to know whether they produce high-quality products or not.

You should look at their history and determine how many satisfied customers they have served in the past year or two.

Suppose they have been producing high-quality products for many years. In that case, this means that they take customer satisfaction seriously and will provide good service and after-sales service if required by their customers in the future.

6.Consider Your Budget

Budget is another crucial factor that needs to be considered before buying any product. You don't need to accept the most expensive product, but you must purchase something within your budget range.

If the cost of a product is too high, then there are chances that it might not satisfy all your requirements. If a product falls under your budget range and has all the features you want in a CNC machine, then this could be one of the best options for you!

7.Make Sure That the Spindle Fits Your Machine Perfectly

Before buying any CNC milling head, make sure that the spindle size fits your machine perfectly. The most common mistake is to choose the wrong spindle, which will cause damage.

If you have a giant machine, then make sure that you get one that can handle the more extensive tooling and heavier cutting materials. On the other hand, if you have a smaller machine, get one that can take smaller tools and lighter materials.

8.Pay Attention to the Tool Length

Make sure that you pay attention to the tool length when choosing a CNC milling head to fit your workpiece correctly without causing any damage while working on it.

You may also need to pay attention to what kind of tooling works best with whatever material you might be using to get maximum efficiency out of your new CNC milling head purchase!

9.Look For the Brand

Choosing the right brand can be tricky as many brands claim to offer high-quality CNC milling heads, but in reality, they don't.

The best way to choose a good brand is by looking at the reviews and ratings of other customers who have already purchased their products.

Summing Up!

CNC Milling Machine is one of the most devoted machines in the engineering environment. It can help you perform best on your project within a short period.

If you are looking for the top 9 tips for buying the best CNC milling heads, read this article because we have provided you with some excellent ways to make the perfect purchase without hassles.

The best way to ensure that the product you buy will suit your needs is to ask as many questions as possible about it. If the shop selling it does not have good answers, you are well within your rights to choose another provider.

Getting 5-Axis milling machining services

CNC machining solutions are quite significant, and you may select from a variety of them based on the project and demands that you have for your items. A manufacturing business may provide you with 5-axis services, for example. The machining type in question contains three linear axes and two rotary axes along with an angle head, which might be in the form of a rotary table or rotary axes just on crank shaft and headstock. 5-axis milling is a sophisticated solution, particularly for complex components that demand great accuracy. The precision is substantially greater since all characteristics are done in one setup.

◆What are the benefits of 5-Axis milling machine services

The 5-axis technique makes it relatively easy to create complicated forms in a single step, significantly decreasing machining time, mistakes, and tool costs for the work at hand. As a consequence, you'll get quicker, more accurate, and more inexpensive outcomes for your production job.

Because the head may be lowered and the cutter directed to the surface, this form of machining allows for the use of smaller cutting tools. As a consequence, a greater cutting speed is reached, as well as a significant reduction in tool vibration, all of which contribute to attaining the best outcomes, regardless of the work at hand.

CNC machining is capable of handling exceedingly complicated pieces made from solids that would normally need casting. High-temperature alloys such as tool stainless steel, brass, titanium, Alloy, tungsten, copper, sterling silver, carbon steel, and bronze may all be milled with the five axis milling. It can also handle polycarbonate, acetal, PP, ABS, and nylon, among other materials.

When it concerns to drilling holes, machining saves time. When drilling a sequence of holes with compound angles, it takes a long time, but with the machine, it's simple to automatically position the head along the appropriate axis for each hole. As a result, hole drilling has been simplified and may be accomplished more quickly utilizing 5-axis machining or machining.

◆Things to consider before you go ahead with 5-Axis CNC machine services

When looking for machining services, look for a company that has been in business for a long time. Keep in mind that machining service expertise may have a significant impact on the quality of work and turnaround time. For the finest experience, choose a dependable and trustworthy manufacturer.

The factory's five-axis CNC milling equipment are also extremely crucial to consider. The greater the machine's quality, the better the consistency with which your product outcomes are delivered. The equipment should be in good working order so that you can get the results you want in a short amount of time.

Affordability of the service should also be examined. The costs should correspond to the final product quality. Keep in mind that the service price is determined on the raw materials utilized. Before deciding on the finest you can afford, consider what materials the manufacturer can handle and your demands.

◆Starting your own business to offer CNC machine services

Since there is a high demand for 5-Axis CNC machining, you may think about starting your own business around it as well. This is where you should think about getting the best quality milling machine available out there. Then you can offer an impressive service to your customers and get them to buy what you offer. Make sure that you pay special attention to specific features such as the angle head, as they can contribute a lot towards the overall functionality that you can get out of the machine.
