TMTS Virtual Application
Our founder, Mr. C. F. Chang, established the factory in Taichung City and serviced the metal working industry by one lathe in 1968. Since 1973, we began made the lathe and named as " CHIN HO Machinery Factory ". In 1980, we moved the factory to Ta - Ya, Taichung country and reorganized as CHIN HUNG MACHINERY CO.,LTD. In order to expand the product, we built the new factory for CNC lathe in 1996.
Since its establishment, SIGMA CNC Technology Machinery holds the fundamental concept of “EXPERTISE, INNOVATION, and PERFORMANCE”. Led by President Humor Chuang, the efficiently co-operated teams are running the company’s daily operations. Under the leadership of our President, constant efforts, renovations are made to meet eve changing market challenges.
The high-precision CNC 5-Axis indexing table of HOSEA meets the most stringent standards in the European market. The products are widely used and favored in Europe, and are well-known by global machine tool manufacturers.
JEENXI Technology Co., Ltd. was established by Mr. S. C. Chen in 2000. Specializing in Machine Tools for R&D and production technology, our main products are high precision and quality 3-axis and 5-axis machining centers. The Machining Centers from Sunmill offer numerous customer-friendly features and comprehensive processing sizes to meet diversified customer’s needs. Customized specifications are also available.
Chain Headway, founded in 1992, specializes in developing and producing cutting tools and accessories for CNC machining centers. Over the years, we have established a stable production environment with advanced R&D and manufacturing capabilities. Our commitment to innovation enables us to deliver cutting-edge products and efficient material processing solutions for intelligent manufacturing.
Established in Taichung City, Taiwan in 2004, by Dr. Pu Hong-Yen, YIDA’s core business scope includes R&D and manufacturing of machine tools. YIDA is currently one of the few machine tool companies in Taiwan with product lines covering horizontal lathes, vertical machining centers and horizontal machining centers. Adopting customer-oriented service principle and strategy, YIDA is well-known for the ability to come up with automation solutions and customized machine tools that best satisfy its customers’ needs.
Founded in 1954, YCM (Yeong Chin Machinery Industries Co. Ltd.) specializes in machine tool manufacturing. YCM machine tools have been recognized worldwide for superior precision, outstanding rigidity and exceptional reliability. Today there are more than 70 makes and models fulfilling the industry’s diverse requirements. With over 70 years of machine tool manufacturing experience, YCM has establi
Founded in 1994 Matrix Precision Co., Ltd. started the production of gear cutting tools at Hsin-Chu Science-Based Industrial Park, Taiwan. The key members who came from the Industrial Technology Research Institute (ITRI) had hand-on experiences on high technology and high precision machinery to produce aircraft gears and components.
Honor Seiki was founded in 1987 and has more than 35 years of experience in VTL machine design and manufacturing.
We mainly focus on the production of Vertical lathes and strive for excellence.
With around 200 employees, HONOR SEIKI is the most professional, leading brand, machine tool provider which has international quality certificate in the field of Turnkey solution in Taiwan.
Accuway Machinery Corporation is one of the leading machine tool builder of vertical machining centers and CNC lathes for various industrial applications. Founded in 1986 by supplying mold and die for semi-conductor industries, it has accumulated abundant precision machining experience and technologies by continuous improvement and innovation.
It's the Pao Fong people who have our commitment alive. They extend quality idea to every aspect of our business activities-form the machine design, manufacturing. Running test, and after sale service, that stress the total value of every Pao Fong milling machine.
POJU International has been committed to the high-precision machine tool industry for 25 years since its establishment. The Group is at the forefront of promoting the development of precision machining and manufacturing, from planning production solution and production automation to key components manufacturing of machine tools. The operating focus of POJU International is the production of machine tool spindles and tool magazines.
MAINTECH PRECISION CO.,LTD. was established in 2017.Due to the rise of industrial 4.0 and artificial intelligence, we recognize that once again the new industry revolution was coming. And for that reason, it is necessary to recruit industry elite and committed to automation and artificial intelligence research and development by focusing on developing the complex spindle head for high end CNC machine.
Established in 1984, Ring Sun Machinery is the home of chip conveyor experts. With more than 30 years of experience and technical know-how in the field, Ring Sun has become a leading chip conveyors manufacturer in Taiwan. Ring Sun specializes in providing customized chip conveyors for a variety of applications.
TOP-ONE Machinery delivers technical excellence, custom solutions, and a commitment to quality. Dedicated to environmental awareness and long-term collaborations, we offer unparalleled service advantages for your business growth. Explore our renowned OEM/ODM machining centers services for tailored product solutions.
Victor Taichung machinery works co. ltd, one of Taiwan’s biggest machine tool manufacturers, has specialized in CNC lathes, multi-tasking turning machines, machining centers, plastic injection molding machines, casting, sheet metal, etc. While Industry 4.0 has become a hot topic in global manufacturing, Victor Taichung further expanded a brand new smart factory with eight Victor Smart Production (
Establised in 1969 and was listed on stock since 2003 in Taiwan. Tongtai locates in Kaohsiung and our business was started from special purpose machine manufacturing. Now, we are a leading machine tool manufacturer in Taiwan and having diverse machine types. We are very experienced and capable of turnkey solutions and whole plant exports.
Jea Sheng has professional casting experience for over 35 years and advanced casting and testing equipment. We have stable and fast delivery. The casting capacity is 2500 tons per month with 0.02mm machining precision.
Established in 1978, TMT has enjoyed over 40 years of successful business experiences.
TMT have complete production line for customers including CNC Lathes, Vertical Machining centers, Tapping Centers, Column Moving Gantry Type Machining Centers and five-axis machines to satisfy the processing and production needs from different industrial fields.
TMT, good choice and partner for you!
Founded in 1976 and based in Taichung, Taiwan, Pinnacle Machine Tool Co., Ltd. specializes in manufacturing various CNC machining centers. The company offers a wide range of products including 5-axis, gantry, vertical, and horizontal machining centers. With advanced technology and a commitment to quality, Pinnacle has become a preferred supplier for customers worldwide.
To fulfill customers' needs, Taiwan Takisawa establishes Application Center. This center is in charge of demand planning, training and customization. Through technology exchange, Application Center has affirmed customers' loyalty all around the world. This is a key factor why Taiwan Takisawa plays an important role in this field.
Campro established since 2003 in Taiwan provides high-end CNC machine tools to the high precision applications requested user. As a manufacturer to the industry, we provide all phases of CNC machinery, from market analysis to production. Campro also develops at least 2 series of CNC machines every year to help customer improving their factory into the next level.
QUASER MACHINE TOOLS, INC. was established in 1991.
Quaser and Winbro joined hands in 2019 to provide customers with a perfect solution in the process of innovation.
Whether in the aerospace industry/semiconductor processing/fuel cell/medical industry, Quaser Group can provide different professional planning technologies and solutions for different industries.
PALMARY Machinery Co., Ltd. was founded in Taichung, Taiwan since 1998. Two production bases with 20,000 square meters space, we produce kinds of centerless grinders, cylindrical grinders, internal grinders, vertical grinders & surface grinders. As a leading manufacturer of grinders in the world, we customize cutting edge grinders for our clients worldwide at reasonable cost.
PERFECT Surface Grinders Help Customers Stay Ahead
Under the company’s policy of “Quality. Innovation. Service.”, PERFECT constantly enhances R&D and presents new models to meet market demands. Meanwhile, we are committed to producing the most dependable and valuable machines to serve our customers worldwide.
JINN FA Machine industrial Co., Ltd. was established in 1976 as a Precision Metal Lathes Machine Tool Manufacturer. JINN FA designs and manufactures a wide range of auto lathes, cnc lathe machines, CNC machining centers and special purpose machines.
AWEA Mechantronic Co., LTD, established in 1986, is now one of Taiwan's largest professional CNC machine manufacturers. The machine travel range spans from 510 mm all the way to 20,000 mm. Product line includes 5-axis, five-sided, vertical, horizontal, and other types of CNC machines. Especially for the large-scale bridge type machines, they are widely recognized by the global market and enjoy the
PARKSON enthusiastically develops our innovative researches and productive technologies for cooperating with clients to respond to the quick changing demands in industry and designs the rotary tables with digital control that comply with the demands by clients, demonstrating the capabilities of PARKSON in terms of research, innovation, and production.
Our aim is to be the best partner with the highest quality EDM machines for the mold and non-contact machining industry.
We focus on the development and innovation in the EDM sector, offering an integrated service before and after your purchase. Our professional and comprehensive product inventory provides customization services for users with full fledged EDM solutions.
Topwork founded in 1980 located in Taichung, Taiwan, with a factory 6000 sequare meter. The 4 axex or 5 axes CNC are Topwork main products. Major customers for these machines include those who are involves in tool production and resharpening all over the world. Topwork and products meet ISO9001:2000, CE certificate, also with NUMROTOR software to provide the complete solution for customers.
KAIFENG MACHINERY CO., LTD. was founded in 2002, and the company is located in Taichung Industrial Park, which is the biggest industrial park in the area. Our business covers Greater China, Asia, Europe and North America. “Quality, Precision, Stability, and Practicality” is the foundation of the company.
Founded in 1954. With the help of Industrial Development Bureau, Ministry of Economic Affairs in 1995, Supertec successfully built up the Taiwan’s very first CNC Angular Cylindrical Grinding Machine. In 2003, Supertec received the ISO 9001~2000 certificates. Close-Loop Linear Motor CNC Profile Grinder and Electronic system producing equipment are on the process of researching.
USync Inc. has over 40 years of experience in factory automation and manufacturing in the machinery and electronics industries. We have established long-term relationship with multi-national corporations such as Mitsubishi Electric Corporation of Japan, Renishaw Plc. of the United Kingdom, Balance Systems S.r.l. of Italy … etc.
Our Vision:
Applying Technologies for Increasing Productivity.
LEADWELL was established in 1980. Currently have two manufacturing bases located in Taichung and Hangzhou. In 1990 we are the one of largest machine tool manufacturers in Taiwan which also a great team full of competitiveness and cohesion. Our mission is to constantly search for excellence and gain respect in the industry and provide high-quality and high-efficiency products.
Also, we looking forw
It is a great pleasure to introduce us as a professional CNC VERTICAL MACHINING CENTER & DOUBLE COLUMN MACHINING CENTER manufacturer in Taiwan since 1997 for 25 years. The managing team has more than 50 years experience in manufacturing CNC Vertical Machining Center. We are proud of our top quality products and superb after sales service that is competitive with the top quality CNC Machining Cent
HEIDNHAIN products are primarily used in high-accuracy machine tools as well as manufacturing and processing systems for electronic components. Thanks to its extensive expertise in developing and manufacturing encoders and controls, HEIDENHAIN is in an excellent position supplying critical and innovative industries, including machine tools, electronics, robotics, medical, elevators, & metrology.
Fair Friend Group (FFG) was established in 1979 with the founding principles of reliability, growth,continuous advancement,best in quality,and strive for excellence. FFG consists of three major divisions of businesses: (1) Machine Tool Division, (2) Industry Equipment Division and (3) Green Energy Division.
Since the establishment in 1968, KAFO (KAO FONG MACHINERY CO., LTD) keeps growth step by step along with the development of machinery industry in Taiwan based on its solid foundation of superior technology. It is not accidental that it becomes the leading brand of mold processing industry as well as faithful business partner. The key to KAFO’s success is intensifying the know-hows, continuously im
FEMCO was established in 1949, Originated in Chiayi, Taiwan. As a comprehensive steel manufacturing enterprise. Providing a wide range of products and services to a diverse international clientele, the business scope includes pipes and tubes, engineering and construction, machine tools, and golf shafts.
FATEK is a machine tool manufacturer of FEMCO Group in Taiwan.
GENTIGER is established in 1995, GENTIGER has specialized in the manufacturing of High Speed, High Accuracy CNC Milling Machines and Bad Saw machines.
“Perfection, Efficiency, Specialization” that is the spirit our company adheres to in all aspects of its endeavors, and over the past decade, these ideals have helped mold us to be one of the leaders in our field.
With over 40 years experience, You Ji has obtained customers' support in design and quality of machine. There are many machines to meet customers' different needs. Table diameter from Ø200 to Ø8000mm. You Ji is the first machine manufacturer to have passed CE and EMC and to have begun sales in the European market, and is the biggest vertical lathe and floor borer manufacturer in Taiwan.
Chung Sing Machinery Co., LTD was established in 1988 & located in Taichung City, Taiwan. We have more than 30 years experience in design, development and manufacturing of Boring Mills and Milling Machines under the brand name “FORTWORTH”. All our boring and milling machines are designed and manufactured with the finest craftsmanship for maximum accuracy,stability and processing.
JARNG YEONG ENTERPRISE CO., LTD. was founded in 1978, is a Taiwan-based professional manufacturer specializing in the production of CNC lathes and cam automatic lathes. Since company’s establishment, all the personnel adhere to professionalism, service enthusiasm, integrity, and attentive attitude as the core values, while attentively listening to the customers' needs.
The Manford group owns four companies in Taiwan, including Manford, Avemax, Automac Smartauto and Manford Guarding Co. Ltd.
Our product range is wide. We produce 5 axis machining centers, Double column, Vertical machining centers, Horizontal machining centers, Tapping center, CNC lathe.
A multi-talented R&D team is able to integrate advanced design into products, as well as supplying mac
JAINNHER MACHINE owns more than 40 years extensive experiences in grinding filed and develop completely machine series which can fulfill various demand. The great quality, precise accuracy and good service made our good reputation. We have consisted of 130 employees with full energy and ambitious to satisfy various customer’s requirement. We are capable to be your trustworthy solution partner!
Established in 1978, Falcon Machine Tools Co., Ltd. is an innovative, Taiwan-based CNC machine manufacturer with facilities in the United States (Chevalier Machinery Inc.) and agents in Europe, the Middle East, Mainland China and South America.
The company is publicly traded on the Taiwan Stock Exchange.
Since our company was founded in December 1986, thanks to the support of Taiwan machine tool industry and manufacturing industry, our business can develop smoothly. We would like to express our deep gratitude.
Taiwan FANUC Corporation has worked devotedly to provide customers with the best services as the goal, and hope that you will continue to support.
Apart from selling FA products, CNC syste
OSCARMAX has had 30 years of history since being established in 1985. Over many years, OSCAMRAX has been totally dedicated to design and manufacturing of electrical discharge machines. Our objective is to subvert the general impression of low machining speed of EDMs. Therefore, we have spent great efforts in developing high speed EDM machining technology, where to create the best results in speed,
Seedtec established in 1984 year, specializes in manufacturing of precision surface grinders for Manual/Semi-Auto, NC/CNC series surface grinder, also rotary type and cylindrical grinder, the innovative technologies of the companies SEEDTEC are used in a wide range of industries such as automotive, mold making, heavy industry, precision machine, electronic/optical industry and IC packaging.
Kenturn has been designing, manufacturing, fabricating and marketing machine tool spindles of all kinds since 1983.
The company prides itself on intensively studying spindle design and producing innovative technology.
It is always improving design and manufacturing teamwork. Kenturn's innovation and initiative guide its planning.
Vision Wide’s core value is based on customer demand-oriented to realize social values. Through the manufacture of products, we continue thinking how to provide customers with more valuable products and services. So we define customer satisfaction, value contribution and social responsibility as our direction.
Future Life has been specializing in cnc accessories design & manufacturing.
Joen Lih Machinery Co., Ltd. is an experienced specialized maker of high-precision and CNC (computerized numerically controlled) surface grinding machines.
Wire Cut EDM Manufacturer | AccuteX
"TECHNOLOGY", "EXCELLENCE", "INTEGRITY"
AccuteX CNC Wire Cut EDM - AccuteX has been playing a EDM machines leading role in machine tool, AccuteX-industry since it was established many years ago. Under AccuteX motto of Customer is always right, AccuteX machine tool is the best !
AKIRA SEIKI was founded in 1985, specializing in the production of machine tools, and established a production factory in Taiwan in 2005.
AKIRA SEIKI has expanded our market to over 50 countries worldwide.
EQUIPTOP company product brand recognition EQUIPTOP, meaning TOP EQUIPMENT top-level equipment intended. From the manual molding grinding machine, the three-axis automatic grinding machine, the NC surface grinding machine, the CNC surface grinding machine, to the CNC computer drilling and tapping center machine and the vertical comprehensive processing Center machine, all products have been carefu
PROTH Industrial Co., Ltd., a highly reputed manufacturer of precision surface grinders in Taiwan, provides a whole line of surface grinders.
Since 1980, we have been dedicated to researching and developing the most comprehensive ranges of surface grinders. Our mission is to exceed the needs of our customers by creating new and innovative designs through continuous development.
Hypermax Machinery Co., Ltd, with over 40 years of experience in manufacturing grinding machines, cultivating expertise in grinding processes and investing in the latest technologies. We continuously improving our research team’s competitiveness to provide customers with more choices and services.
CASTEK Mechatron IND. Co., LTD is established at 1987,
expertise in manufacturing EDM drilling machines. Our main clients are from wire-cutting molds, lubricant holes of heat treatment parts (with angles), special small holes for electronics and spare parts processing, ex：spinneret, spraying nozzle… Base on stable and excellent generator, machine performances, our strong team and customers’ trust,
Senday Enterprise Co., Ltd., is a professional lathe manufacturer established in 1975. With quality, technology and after-sales service as core values, our industry-leading technology and commitment to excellence our products have won the trust of local as well as international customers and distributors. By letting our quality speak for our r
GSA TECHNOLOGY CO., LTD. established in 1978, from time to time, our growing of devotion work stable, keeping in mind of honesty, faith, profession and innovation, nonstop communication and promotion of critical quality procedure, ensure every products could meet high quality of duration and precision.
L&L Machinery Industry Co., Ltd. has been specializing in the manufacturing of CNC lathes in Taiwan for over 40 years. We produce both conventional and CNC lathes capable of handling a variety of processes such as turning milling, boring, milling turning, drilling, grinding, cutting, and polishing. Our high-quality machines are fully customizable to meet your specific demands.
The Company was established in 1991, We specialize in manufacturing precision machine vise, hydraulic vise, Drill Re-Sharpening Machine and Machine tool accessories.
We insist the Principle "A workman wants to do his work well must first sharpen his tools " to Make a product, Our equipments: CNC machine center, milling machine, grinding machine etc. Those precision machines and the Perfect Proces
Established since 2006 AVEREX Automation has become Taiwan’s premier precision horizontal machining center manufacturer.
AVEREX specializes in high rigidity, high speed, high precision flexible HMC with field expandable pallet and tool changers.
500+ HMC global sales record attest to our wealth of experiences in proven design, production and services.
Buffalo Machinery supplies a wide range of products, divided in two brands. MICROCUT, the original brand since 1983, covers most of the product lines and aims to deliver quality machines at competitive prices focusing on the relationship with the dealer and the end-user. AXILE, the high-end brand was launched in 2017, is conceived to cover the premium market of 3X and 5X high-tech machining center
Maple was founded in 1989 by a man that wanted to find better way to produce parts that can be more cost effective and a faster way then the current method that is being used. Today, Maple builds not only cnc machine tools but also provide added value solutions to help advance every individual customer production needs.
We are a professional manufacturer specialized in producing Milling accessories since 1978. Our product range covers various kinds of machine tools- CNC workholding equipments: Five-axis Vises, Multi-Power Mechanical Vises for CNC machining Centers, Permanent Magnetic Vises, Pneumatic Vises, Tooling Columns (Tombstones), Precision Index Tables, Rotary Table, Dividing Head, Super Divider, etc.
WELE is a professional CNC machine builder in Taiwan. We provide total solution to satisfy customers' demands. Wider range of product line and its X axis stroke range from 0.5meter to 20meter. More detail information shows in our official website.
Jar Hon provide wide range of tapping & drilling solutions for many industries and other special needs.The quality of machines is guaranteed and its durability is unquestionable. The after-sales service provided in order to adhere the concept of "keeping quality" and "doing still better".
Best Manufacturer for Surface Grinding Machines
DOWELL® follows our company philosophy "Keeping & Improving" forever.
With customers' demands, we continue R&D and innovation to provide various accurate level grinding machines. And we accumulate the deepest manufacturing experiences with practical as foundation, simple and easy to operate it for the principle.
We are a professional manufacturning fixture & jiigs factory.
We are offering more than hundred product to satisfied your CNC clamping operation. We can also customize your request for the fixture.
MYLAS was established in 1985. Headquartered in Taichung, the company started from the Auto Lathe Series which has sold more than 65thousand machines worldwide. In 1999, the Jiangsu branch was established to target the market in China. In order to satisfy the skyrocketing demand, the Shengang branch was founded in 2004. We offers simple lathe, dual spindles, double turret types CNC machines.
JIH-I Machinery Co., Ltd was founded in 1971. Since 1995, in order to meet the market demands, we have introduced the high-speed cut-off saw, NC fully automatic high production saw, CNC machining center, 45 degree double-saw angle cut saw, NC 45 degree cut-off saw, hydraulic press, copy milling machine, and material processing machines.
Taicin is a Taiwan oil hydraulic valves and pumps manufacturer for more than 30 years.
Our products are used in plastic injection machines, CNC lathe, machine center, machine tools etc.
Our core value is to provide high quality, durable and also environmental social governance products to clients.
Established in 1984, Axisco Precision Machinery Co., Ltd. built its name by helping customers in more than thirty countries with broaching turnkey solutions. The solutions include electrical-mechanical table-up broaching machines, CNC helical broaching machines, hydraulic internal broaching machines, hydraulic surface broaching machines, broach tools, fixtures, training, etc.
Holer Cutting Tool Co., Ltd is specializing in designing and manufacturing various cutting tool. Under the policy of constant breakthrough and innovation, we have dedicated to pursuing new level of technology, quality, and management. With the combination of theorem and practical experience and outstanding knowledge in material characteristics, we always strive in research for cutting technology.
Established in 2001, YIDA Precision Tools Co., LTD is located in the central of Taiwan, Taichung City, where we are surrounded by abundant industrial resources. Founded with the ideal that each step in the process of creating our products should be pursued with innovative ideas and technologies, YIDA is committed to manufacturing carbide tools.
TJR Precision Technology co., Ltd. is a professional manufacturer of CNC rotary tables (the 4th and 5th axis). The main products are CNC rotary table, CNC index table, Auto Pallet Changer, and other accessories with high precision and stability.
Due to the strictest quality control, the products are mainly applied in automobile parts manufacturing, and other mechanical industries.
The Largest Professional Rotary Table Manufacturer
detron is committed to designing and engineering the highest quality NC rotary table products, through the experience, dedication and innovation of our International R & D team. Our mission is to understand and support our customer's needs with advanced application technology, with a wide range of products, providing optimum performance. Through
ECOM Founded in 1976, specializes in machine tool manufacturing. ECOM machine tools have been recognized worldwide for superior precision, outstanding rigidity, and exceptional reliability. ECOM product covers CNC Vertical Machining Center, Horizontal Machining Center, Tapping Center, and Bridge Type Machining Center. We dedicated to provide our customer with reliable machines and best services.
Established on November 6, 2000, OCEAN TECHNOLOGIES CO., LTD a manufacturer of high-tech EDM machines, known for its excellent R&D and management capabilities, commitment to quality, and spirit of continuous innovation. With a global localization strategy, OCEAN has marketed its products in over 35 countries, mainly in high-tech countries such as Germany, the US, and Japan.
FORCE ONE Machinery, founded in 1997, specializes in high-performance CNC lathes. With 27 years of company experience and 40+ years of chief engineer expertise, it leads in designing efficient, quality machines. Through innovation and R&D, FORCE ONE has become a respected manufacturer of multi-tasking CNC lathes in Taiwan.
Starting in 1990 making machine tool components, Ying Han Technologoy has accumulated sufficient experiences and know-how in designing and manufacturing high precision components.
The concept of building quality machines stems from the long term supplying relationship with known companies in the field of machining center manufacturing.
“To create a performance and create a win-win situation”. Kai Hung was founded in 1991, and specializes in the design and manufacturing of CNC multi-spindles trunnion/ horizontal rotary transfer machine, automatic assembly stream line, customized equipment of valve/sanitary/gas parts processing, automation production line for automobile parts.Kaihung insists on
GRINTIMATE PRECISION INDUSTRY CO., LTD is a world-leading designer and specialized manufacturer of high-precision grinders. We have developed exclusive technologies for hydrostatic spindles, hydrostatic rotary worktables, and hydrostatic guideway modules that could widely used in machine tools for a wide variety of applications
Founded in 1976, staffed by over 150, Cosen is one of the world’s leading band saw manufacturers with a broad product line and a global sales network including Cosen USA and Cosen Europe. Cosen offers 140 models including vertical, horizontal, miter-cutting, NC & CNC automatic and customized band saws. Capacity ranges from 200 to 3200 mm.
As Taiwan's industrial landscape rapidly transforms, Century Trade continues to provide industrial products ranging from CNC machine tools and injection molding machines to automation robots, along with peripheral products that complement these machines. Under the guiding principles of "Solution, Integration, and Service," Century Trade strives to offer comprehensive one-stop solution.
Yih Kuan Enterprises is a professional manufacturer of milling heads, dedicated to providing high-quality milling head products to serve various industrial sectors globally. Our product range includes turret milling heads, gantry milling heads, CNC milling heads, angle heads, and customized milling heads. We are customer-oriented, providing comprehensive pre-sales, sales, and after-sales services.
ANCA is a market leading manufacturer of CNC grinding machines. It was founded in 1974 in Melbourne, Australia where the company still has its global headquarters. ANCA has offices in the UK, Germany, China, Thailand, India, Japan, Brazil and the USA as well as a comprehensive network of representatives and agents worldwide.
ANCA CNC grinders are used for manufacturing precision cutting tools and
Syntec Technology, a leading provider of CNC controllers in Asia, boasts a global presence across Europe, the Americas, and Asia. Devoted to continual advancements in software and hardware technology for machine tool controllers, Syntec offers key products including CNC systems, servo drives, and servo motors. Collaborating with its subsidiary, Leantec, the company focuses on industrial robotics,
The Production Site of a Tier 1 Factory, Waysia Industrial Co., Ltd. was established at Ming Hsiung Industrial Area, Chiayi, Taiwan in 1991. It is a wholly owned subsidiary of Meita Group.
At the beginning stage of its establishment, the company was engaged in the design and manufacturing of special tools, jigs, and fixtures, metal cutting machines and special-purpose machines.
“High Speed Cutting, High Quality, Express Service, and Customer First” has made SISTER a trusted cutting partner since the founding of SISTER Machine Technology Co., Ltd. in October of 2006.
LH TOOL is a CNC carbide cutting tools manufacturer, with 30 years of production experience. We can provide excellent after-sales service and technical support.
Our main products include carbide end mills for machining difficult-to-cut materials such as stainless steel, titanium alloys, and nickel-based alloys, as well as micro tools as small as 0.1mm, 3D-40D carbide coolant-through drills.
YING SHUN is a professional milling machine manufacture and has a professional team, management skills & production efficiency.
The complete product range includes Knee type, Vertical & Horizontal, Bed type, CNC milling machines.
Over the years of milling machine tool manufacturing experience, we established a strong foundation in the field of machinery.
Nano-Mill Technology Co., Ltd has been established since year 2000. Nano produce a wide range of high quality Carbide cutting tools. The production is specializing in high hard, high speed and soft metal cutting Solid Carbide End Mill. We supplied end mill made of the best material from Germany and manifested by modern CNC grinding machines from Switzerland ‘Rollomatic’ and Schneeberger.
Microdrilling, a brand of Honge Precision Industries Corp., has been a leading designer and seller of industrial deep hole drilling machines in Taiwan since 2003. With a wide range of models available, our deep hole drilling machines are suitable for various industrial parts' deep hole drilling, making them an ideal solution for a wide range of applications.
Microdrilling is committed to deliveri
WELLTECH Machinery Co., Ltd. was established in 1996, specializing in the machining/manufacturing/sales/rental of CNC machine tools. Vertical lathe, vertical turning and milling compound processing machine.
The main customer groups are precision machining industry, automobile and motorcycle parts industry, electronic communication industry, aviation parts industry, ship parts industry, etc
Shinzawa Precision Machinery Co., Ltd. is a professional CNC machining center manufacturer. Ever since our company's establishment, the pursuit of continuous progress and total customer satisfaction is the driving power of our company's success. We strive for "perfection without compromise"
Wei Fong Precision is a professional supplier of mechanical components and high accuracy transmission parts in Taiwan.
With over 35 years of experience, our products have been applied in multiple industries, such as CNC machine, woodworking machine, sports equipment, 3D printer, storage facilitate …etc.
PROMPT is a young, dynamic and professional manufacturer of machine tool, our sales network has extended to over 30 countries around the world.
With complete structure of software and hardware, we conduct strict quality control to achieve maximum working efficiency.
We put great efforts on creating mutual benefit. In 21 century, it is expectable to see more improvement
& development of PROMPT.
HC FENG CO., LTD. has provided advanced purification and filtration solutions for the CNC machining industries.
Our mission is to assist the global manufacturing industry in achieving and facilitating environmental, social, and governance (ESG) goals.
TOTAL SOLUTIONS:
BEST-1 (Cutting Coolant Purification Equipment)
FOODIE (Chip/Sludge Removal Machine)
FOODIE II (Centrifugal Magnetic Filter)
Providence Technology Co., LTD was founded in 2006. “ High quality, High stability, High accuracy," is our purpose. To maintain the best quality is on our main thinking for sustainable management.
We took a serious attitude about quality control. The serious thinking "better than better” is the basic requirement for our products and employees.
「AGILE WING SMART MANUFACTURING CO.,LTD」Founded in January 2019, the original intention of the establishment: to build an unmanned lighthouse factory for customers, move towards Industry 4.0, and take a big step for the industry!
DIN-KO MACHINERY CO. LTD was founded on April 12th, 2012. With the eager of keeping abreast of time, innovation is embedded into our company philosophy. Starting from building the first 3-roller vertical flow forming machine in Taiwan to the formation of a complete production cell with turn-key solution.
VERNAL is proud to present our new product line, VERNALCO, which specializes in driven tool holders for Swiss type CNC machine. Our exceptional capabilities enable us to design and fabricate such holders to meet the demands of high-precision machining. Vernalco is prepared to deal with a broader range of machining requirements.
Hantop Intelligence Tech.’s ultrasonic machining module can retrofit in CNC machines to improve milling, drilling, and grinding process of advanced materials, including ceramics, optical glass, quartz, Si/SiC, heat-resistant alloy (titanium/nickel alloy), tungsten carbide, carbon steel, and stainless steel. The system helps enhance efficiency, workpiece quality, and tool life.
Asia Machine Group is a Taiwanese manufacturer of high-quality, durable, and affordable CNC Cutting and Drilling Machine. Our products can be custom made to any size needed, from small standalone units to large extendable units that can be built up to 12m wide. Since 1995, AMG has installed over 3,500 units in over 60 countries worldwide.
We believe that a product’s quality is the testament to th
Special for Difficult-to-Cut Materials processing, Titanium Alloy processing etc.
Features:
High-Rigidity structure design. Mechanical-type Simultaneous Two-Axis rotary spindle. Warm and gear transmission for B and C axes. With self-made heavy-cutting two-stage gearbox design (Gear Ratio by 1:1.75 and 1:7). Maximum Torque: 1155 N-m.
Unique patented design of the Z-axis spindle rail structure - vibration restrain in machining. It can largely reduce the vibration in machining hard-to-cut material, enhance the machining efficiency, reduce the surface roughness, and prolong the tool’s life. (Model S5A-HH exclusive)
Fully Splash Guarding design. Super large and wide working door design. Fashionable aesthetic and ergonomic safety design.
Specific design of safety guardrail upon the cross column. Convenient for machine maintenance.
Height-adjustable manipulation control box. Suitable for people of different height.
1.採用德國高剛性徑軸向軸承，足承受各方向荷重。<br />2.直接裝角度編碼器，提高分度定位及重複性精度。<br />3.可選配直驅DD扭力馬達，無背隙、其轉速可達120rpm，可應用於銑車複合。<br />4.配合工作母機設計，提供最小占地面積。<br />
Chain Headway offers high-precision PCD (Polycrystalline Diamond) and PCBN (Polycrystalline Cubic Boron Nitride) inserts, specifically designed for machining non-ferrous metals and hard-to-cut materials. These inserts are known for their exceptional wear resistance and cutting efficiency, making them ideal for various high-demand precision machining applications, such as automotive parts, aerospace, and electronics industries.
1. PCD Inserts:
(a) Suitable Materials: Aluminum alloys, copper alloys, carbon fiber reinforced plastics (CFRP), composite materials, etc.
(b) Advantages: Excellent surface finish and outstanding wear resistance.
(c) Applications: Used for high-efficiency mirror cutting, deep hole boring, and slotting operations.
2. PCBN Inserts:
(a) Suitable Materials: Hardened steel, gray cast iron, powder metallurgy materials, etc.
(b) Advantages: Provides stable cutting performance and long tool life in high-hardness materials.
(c) Applications: Suitable for precision turning, milling, and machining of wear-resistant components.
In addition to standard inserts, Chain Headway also offers customized PCD and PCBN inserts tailored to meet specific customer requirements. Whether it is insert shape, size, or edge design, our products can be customized according to different machining conditions to achieve higher machining efficiency and optimal cutting performance.
Working Table Dimensions : 400 x 400 mm
Max. Loading Capacity : 400 kg
B Minimum Indexing : STD: 0.001° ; OPT: 1°
Pallet Capacity : 2 pcs
Max. Diameter of Workpiece : Ø550
Max. Height of Workpiece : 800 mm
Max. Travel of X/Y/Z-axis : 550 / 510 / 630 mm
Distance from Spindle Nose to Table Center : 70-700 mm
Spindle Taper : ISO No. 40
Spindle Speeds : STD: 10,000 rpm (belt-driven)
OPT: 12,000 rpm (belt-driven)
Tool Capacity STD: 40 pcs
OPT: 60 /120 pcs
Wide Applicability, Modular Design, High Scalability
Central chip removal system avoids thermo focus on working area
High rigidity bed body with X axis high/low guide way design
Click the link below for more information:
https://www.yidacnc.com/product_d.php?lang=en&tb=1&id=322
PF-8S1500CNC Bed type 4-axis vertical Bedtype milling machine developed by PAOFONG.Table size: 1730 x 400 mm ) Travel: X = 1500 mm Y = 500 mm Z = 550mmSpindle Taper: NST#40 Machine.It is mainly used for machining of largeCentroid 4 Axes CNC Table and heavy-duty chip removal capacity. This large machine bed is developed for large-sized 4th Rotarl Table.Table design It is built with premium cast-iron .
￭ Large delta machining column and base for ensuring the highest stability during machining.
￭ Wide span of axial guideways
￭ Wide ball screws and high precision roller type guideways on all axes, weighing up to 700 kg 1,543 lb
￭ X-axis adopts a six-slider design, providing a 50% increase in rigidity compared to the previous fourslider.
￭ The unique IDD spindle design offers smooth reliability at high speed.
￭ Enhance mechanical structure design
￭ Optimize VFD techniques of electrical control variable frequency technology
￭ Implement smart manufacturing solutions
￭ ISO 14955-1/2/3 Certifi cation
NFX400A is designed especially for small, complex high-quality parts mainly for aerospace, automotive, medical, job shop and die & mold applications￭ Extra wide column and base design to ensure best support and cutting rigidity.￭ Increased tool life by cutting with belly and edge of the tool￭ Reduce fixture error and improve workpiece loading and uploading time￭ Greatly reduced non-cutting or setup waiting time￭ Saves manufacturing cost with reduced fixture and electrode costs.
High rigidity and high accuracy NH500A provides the best solution for automotive, precise and mechanical parts industries.￭ High rigidity T-base foundation with rib construction￭ One-piece casting spindle headstock and dual-wall column design￭ Powerful Built-in spindle with Micro oil-air lubrication for angular ceramic ball bearings prolongs spindle life￭ High precision roller type guideways on all axes￭ High precision pallet indexing system.
THW-2080/3080 is designed and developed based on Matrix’s experience of many years in gear cutting tool manufacturing. THW-2080 is built on a base of a highly rigid, high quality cast iron to perform with pin point accuracy. THW-2080/3080 applies the most advanced technologies available around the globe. With Fanuc CNC controller, a direct drive motor, a linear motor and servo motors, THW-2080/3080 is able to deliver the accuracy, reliability and precision for double lead grinding, tapper thread grinding, single flank grinding, dual pressure angle grinding, plug thread gage, rolling die, crusher roller, etc.Matrix has developed its own Windows-based software program for THW-2080/3080. Using an advanced Windows-based, user-oriented interface, THW-2080/3080 can generate and archive practically infinite number of different profiles and grind/ dressing cycles easily by data input. The flexible dresser can profile the grinding wheels for standard worms, as well as profile the multi-rib grinding wheels for thread grinding with tip and root modifications. THW-2080/3080 can also grind pump rotors. We highly recommend THW-2080/3080 for your worm and thread grinding applications.
GHP-3540 is designed and developed based on Matrix’s experience of many years in gear cutting tool manufacturing. GHP-3540 is built on a base of highly rigid, high quality cast iron to perform with pin point accuracy. GHP-3540 applies the most advanced technologies available around the globe. With FANUC CNC controller, a direct drive motor, a linear motor and servo motors, GHP-3540 is able to deliver the accuracy, reliability and precision a gear expert is looking for.Matrix has developed its own Windows-based software program for GHP-3540. Using an advanced Windows-based, user-oriented interface, this software requires only the final gear data and all other CNC data is calculated automatically. GHP-3540 is a highly technical and highly precise gear grinder that gear grade of DIN 4 (AGMA 14 or JIS 0) can be achieved for standard gear profile at ease.
The GVP-8040 is built with some of the most modern technology available, such as an advanced 8-axis CNC controller with a closed loop servo control system, integrated with an industry computer, and a direct drive motor, all of which Matrix utilizes to achieve very high precision over long periods of use. The GVP-8040 includes Matrix’s most technologically advanced smart Windows-based and user-oriented interface to date. This software provides the user the ability of design flexibility for modifying gear profiles and specifying grinding conditions. Matrix has developed this software so that the operator just needs to key in the required gear data in an easy step-by-step process on our Windows-based user-oriented interface. No other numerical control programming knowledge is required since the entire program is generated automatically within the software.
The ZHS-3040 is an extremely versatile machine. With Matrix’s available software and fixtures, the ZHS-3040 can sharpen straight or helical gashed hobs, shaper cutters and can even grind gears achieving AGMA class 14 (DIN 4) accuracy. The ZHS-3040’s base is constructed of a highly rigid, high quality cast iron. Matrix manufactures every machine to perform with pin point accuracy and it all starts with a very stable base. Matrix builds the ZHS-3040 using the finest technology in the world. With seven axes, a CNC Fanuc controller, a personal computer, direct drive motors, servo motors and a linear motor, Matrix is able to deliver the accuracy, reliability and precision a gear expert is looking for.Matrix has developed its own Windows-based software programs for the 3040. Using an advanced Windows-based, user-oriented interface, this software requires only the final hob, shaper cutter dimensions and all other CNC data is calculated automatically by Matrix’s smart grinding software program.Matrix’s ZHS-3040 CNC hob sharpening machine is a highly technical, highly precise hob sharpener with the option of becoming an impressive shaper sharpener
Spindle housing diameter ： 120mmTool interface ： Quill D22/38 M22XP2.0Maximum speed ： 42,000 RPMLubrication ： Oil-AirMotor power ： 11.5/17 Kw
Spindle housing diameter ： 100mmTool interface ： HSK-E32Maximum speed (rpm) ： 30,000 RPMLubrication ： GreaseMotor power ： 3.5/5.5 Kw
Spindle housing diameter ： 210mmTool interface ： HSK-A63Maximum speed (rpm) ： 20,000 RPMLubrication ： Oil-AirMotor power ： 18/22.5 KW
Spindle housing diameter ： 170mmTool interface ： HSK-A63Maximum speed (rpm) ： 24,000 RPMLubrication ： Oil-AirMotor power ： 18/23 KW
Spindle housing diameter ： 45mmTool interface ： SD6Maximum speed (rpm) ： 50000 RPMLubrication ： GreaseMotor power ： 0.45/0.54 Kw
￭ Robust roller linear guideways applied on 3 axes.
￭ Rigid dual-wall castings on saddle and 6 blocks design on X-axis can easily support workpieces weighing up to 1,500 kg.
￭ 4-linear guideways on Y-axis with superior large span ensures the best dynamic balance.
￭ Large-diameter ball screws on X/Y/Z-axis directlydriven by servomotor, providing rapid feedrate up to 50 m/min.￭ 6 slide blocks on X-axis￭ High torque A/C-axis rotary table can holds a max. workpiece size of ø650 x 400 mm with 300 kg weight.￭ Complete thermal solutions against thermal
-Strong structure design of spindle: cross roller bearing is used as exclusive design of bearing for vertical lathes
-High rigidity column: Once piece column with wide span box structure design provide more stability and reduce vibration
-Excellent machining performance: Honor patented powerful clamping system - "Solid Lock" provides high accuracy for heavy-duty cutting and reduces tool vibration, and machine productivity as well
-For more information, please contact us.
honor@honorseiki.com
-Multiple turret types to fulfill various application
-High-Reliability Spindle: 100% spindle balancing process offers high durability. All spindles are made and tested by HONOR SEKEI and feature a precise one-to-one fit
-Excellent machining performance: High rigidity column with box in box machine bed design supports great stability during processing
-For more information, please contact:
honor@honorseiki.com
High Rigid and High Precision Machine Structure
Add 4th & 5th rotary table to increase efficiency and productivity
．X / Y / Z axis linear guideway
．Arm type tool magazine : 24 tools (STD.) ; 30 tools (OPT.)
．X / Y / Z travel: 1050 x 600 x 610 mm
Click the link below for more information:
https://www.yidacnc.com/product_d.php?lang=en&tb=1&id=178
Product Description
1. Size: BT30 BT40 BT50 - ER8 ER16 ER20 ER25 ER32 ER40
3. Standard: JIS (MAS 403)
Product Name
CNC milling BT ER collet chuck tool holder Taiwan made
Standard JIS (MAS 403)
Controller：FANUC 0i-T
Max. turning lengthSwing over bed：660mm
Swing over saddle：620mm
Max. Turning Diameter：300mm(UZ-1500T2Y) / 310mm(UA-1500T2Y)
Max. turning length：480mm(UZ-1500T2Y) / 500mm(UA-1500T2Y)
Guide way type：Linear + Box
X-axis Travel：X1/X2 : 200mm(UZ-1500T2Y)/185mm(UA-1500T2Y)
Z-axis Travel：Z1/Z2 : 600mm
Y-axis Travel：±50mm
B-axis Travel：700mm(UZ-1500T2Y)/600mm(UA-1500T2Y)
>click here to see more specifications<
Controller：FANUC 0i-M
Spindle speed：12000 /15000 rpm
Spindle nose taper：BT40
Bearing inner diameter：70mm
Drive system：Direct
X-axis travel：500mm
Y-axis travel：400mm
Z-axis travel：550mm
A-axis travel：-30 / +120 degree
C-axis travel：360 degree
>click here to see more specifications<
High Rigidity, High Precision, High Speed
Perfect for processing polyhedrons and curved parts
Five-axis simultaneous movement finishes complex processing with single setup.
Click the link below for more information:
https://www.yidacnc.com/product_d.php?lang=en&tb=1&id=142
ML-560 series is one of Yida's most popular models.
With high-precision, heavy-duty roller type linear guideways on X, Y & Z axes, allowing the axes to move at high rapid traverse rates with high positioning accuracy due to low stickslip and low coefficient of friction.
． High stability
． High Speed
． High Process Reliability
． Slant Bed Design
． Various turrets available
． CS-axis function applicable
． Automation equipment available
Click the link below for more information:
https://www.yidacnc.com/product_d.php?lang=en&tb=1&id=94
Controller： FANUC 0i-T
Swing over bed：660mm
Swing over saddle：620mm
Max. Turning Diameter (SP1)：320mm
Max. Turning Diameter (SP2)：320mm
Max. turning length：790mm
Guide way type：線軌+硬軌
X-axis Travel：X1/X2 : 210mm
Z-axis Travel：Z1/Z2 : 840mm
Y-axis Travel：-40/+60mm
B-axis Travel：920mm
>click here to see more specifications<
Controller：FANUC 0i-T
Swing over bed：380mm
Swing over saddle：320mm
Max. turning diameter：180mm
Max. turning length：175mm
Guide way type：Box
X-axis Travel：120mm
Z-axis Travel：230mm
>click here to see more specifications<
Controller：FANUC 0i-T
Swing over bed：505mm
Swing over saddle：318mm
Max. turning diameter：300mm(JT-150)；230mm(JT-150M)
Max. turning length：310mm(JT-150)；200mm(JT-150M)
Guide way type：Linear
X-axis Travel：195mm
Z-axis Travel：350mm
>click here to see more specifications<
Controller：FANUC 0i-T
Swing over bed：455mm
Swing over saddle：260mm
Max. turning diameter：280mm(UL-20)；180mm(UL-20M)
Max. turning length：600mm(UL-20)；500mm(UL-20M)
Guide way type：Box Way
X-axis travel：175mm
Z-axis travel：625mm
>click here to see more specifications<
Controller：FANUC 0i-T
Swing over bed：680mm
Swing over saddle：485mm
Max. turning diameter：240mm(UT-200Y)；155mm(UA-200Y)
Max. turning length：440 mm/ 365mm(UT-200Y)；500mm/425mm(UA-200Y)
Guide way type：Box Way
X-axis Travel：220mm
Z-axis Travel：600mm
Y-axis Travel ：±50mm
>click here to see more specifications<
Controller：FANUC 0i-T
Swing over bed： 850mm
Max. turning diameter： 750mm
Max. turning length： 700mm
Guide way type： Linear (Box way)
X-axis Travel：420mm
Z-axis Travel：800mm
>Click here to see more specifications<
The pressure is clamped,which is beneficial to the use
of any CNC machine .
X/Y/Z travel : 1000(Opt.800)/400/470 mm
Spindle taper : NT40(Ø105)
Spindle motor : 5HP(Opt.7.5)
X/Y/Z travel : 1000(Opt.800)/400/440 mm
Spindle taper : NT40(Ø110)
Spindle motor : 5HP(Opt.7.5)
X/Y/Z travel : 1000(Opt. 1200,1400)/550/600 mm
Spindle taper : NT40
Spindle motor : 5HP (Opt.7.5HP)
X/Y/Z servo motor
X/Y/Z axis ball screw
X/Y/Z travel : 1000(Opt. 1200,1400) /550/600 mm
Spindle taper : NT40
Spindle motor : 5HP(Opt.7.5HP)
Controller system
Performance. Precision. Reliability. Affordability.These are the driving forces behind the design of our new Traveling Column High-Efficiency Profile Grinding Machine. They’re the standards required by the medical, automotive, mining, semiconductor, aerospace and job shop industries in order to meet current grinding demands and pave the way to smart manufacturing.Chevalier achieved greater precision by placing the high waist traveling column on the same level as the spindle, creating a solid, rigid machine structure that minimizes vibration, movement, and displacement. Axial movements are programmable in increments of 0.001 mm (0.0001") with little effort.Our grinding machines are designed to be user friendly. Now, our exclusive next generation SMART iControl incorporates production efficiency, which simplifies operation procedures and greatly enhances the performance of Chevalier CNC grinders. Combined with TaskLink, it allows operators to create their own programs for generating complex grinding tasks in a single cycle—without an engineering degree.
X/Y/Z travel : 800 (Opt.1000)/400/420mm
Spindle taper : NT40
Spindle motor : 5HP(Opt.7.5)
Hardened ground-X/Y/Z
Square way-Y/Z
1. The base is fabricated from heavy gauge steel plates and scientifically reinforced, allowing for solid support for the column and work pieces.
2. Travelling column design features increased machining efficiency and accuracy.
3. The oversized box-type column is manufactured from high quality cast iron.
4. Large diameter ball screw on x-axis is firmly supported to eliminate self-deflection problems.
5. 3 axis adopt 45 mm P class high precision linear guide ways; X axis features 8 blocks, Y and Z axis are 6 blocks.
6. Automatic lubricator delivers lubrication oil to all linear ways and ball screws.
7. 3 axis ball screws are direct coupled with drive motors, featuring no backlash, high transmission efficiency and high accuracy.
2. Travelling column design features increased machining efficiency and accuracy.
3. The oversized box-type column is manufactured from high quality cast iron.
4. Large diameter ball screw on x-axis is firmly supported to eliminate self-deflection problems.
5. 3 axis adopt 45 mm P class high precision linear guide ways; X axis features 8 blocks, Y and Z axis are 6 blocks.
6. Automatic lubricator delivers lubrication oil to all linear ways and ball screws.
7. 3 axis ball screws are direct coupled with drive motors, featuring no backlash, high transmission efficiency and high accuracy.
Intelligent. Dynamic. Affordable.These words describe the driving forces behind the new design of our SMART-IV CNC surface grinders. These are the benchmarks required by the medical, energy, semiconductor, aerospace, mold and processing industries in order to meet current and future market demands.This series is capable of producing complicated shapes for highly accurate workpieces along with finer finishes. The heavy-duty slide rails, one-piece base casting and hardened wheelhead guideways create a solid, rigid machine structure that minimizes vibration, movement and displacement.Our grinding machines are designed to be user friendly. Now, our exclusive next generation SMART iControl incorporates production efficiency, which simplifies operation procedures and greatly enhances the performance of Chevalier CNC grinders. Combined with TaskLink, it allows operators to create their own programs for generating complex grinding tasks in a single cycle—without anengineering degree.
The UNi5X-400 five-axis vertical machining center can provide the required stability, speed and accuracy when machining complex workpieces. The machine’s high rigidity achieves the best stability, and the BIG-PLUS double-sided restraint spindle design can achieve excellent speed and accuracy.This machine type can be widely used in aerospace, automotive, medical treatment, mold, pneumatic and hydraulic components, electronics, semiconductor, and job shop industries.Our exclusive iMachine Communications System™ (iMCS) software includes remote machine monitoring, data analysis, alarm history and maintenance updates to improve overall equipment efficiency (OEE) and is the equipment required for the construction of smart factories.
Chevalier’s FSG-ADIV Series of surface grinders have several design features to shorten your processing and non-processing preparation while delivering high-precision workpieces year after year—functions you might not expect on such affordable machines: iSurface control, variable speed spindle, constant surface speed, smart grinding path and in-machine manual dynamic balancing.FSG-ADIV Series grinders also feature tools to secure Big Data with Chevalier’s exclusive iMachine Communications System TM (iMCS). This software package, combined with data analysis, enhances machine efficiency in the factory while enabling remote monitoring and diagnostics to track machine performance and identify potential problems before they begin.
【ASER-WP】
--The double direction coolant hole toward the cutting edge.
【ASER-NA】
--The upper coolant hole toward the cutting edge.
--It's specialized for CNC automatic lathes.
Feature:
(1)Shorten processing time by high cutting speed.
(2)30 to 150% longer tool life for different kind of materials.
(3)Improved chip breaking, particularly at pressures above 40 bar.
(4)Simple locking structure is solid, easy to assemble and operate that makes insert quickly change.
(5)Unique high pressure water outlet design, aiming the tip of insert for cooling down and chip removal.
Chevalier’s new FSG-2048ADIV and FSG-2064ADIV machines join our ADIV Series of surface grinders offering two additional machine sizes, along with several newly designed features, including: a traveling column structure to further reduce vibration and achieve higher accuracy, a spindle that can withstand heavy load grinding and a double-V guideway for smooth, stable longitudinal movements.
These two new sizes, along with the entire ADIV Series, offer several design features to shorten processing and non-processing preparation while delivering high-precision workpieces: iSurface control, variable speed spindle, constant surface speed, smart grinding path and in-machine manual dynamic balancing.
The driving forces behind this series pave the way to smart manufacturing by meeting the current grinding demands and standards required by the automotive, electric vehicle, mining, aerospace and job shop industries.
This series of grinders also features tools to secure Big Data with Chevalier’s exclusive iMachine Communications SystemTM (iMCS).
Combined with data analysis, this software package enhances machine efficiency in the factory while enabling remote monitoring and diagnostics to track machine performance and identify potential problems before they begin.
Equipped with the latest technology, Chevalier’s FDG-700 is loaded with features that make the innovative double-sided grinder the ideal machine for a variety of flat, hard and brittle materials.The FDG-700 is perfect for mass production of small- and medium-sized workpieces that demand high-precision and high efficiency with an eight-stage pressure control. This fine grinding process offers several advantages in flatness, parallelism, surface finish and size tolerances.The FDG-700 features Chevalier's iSurfaceDS, a PC-based control that makes it possible to intuitively operate the grinder entirely by conversational graphic control.The machine features a high-precision, digitally controlled pneumatic system that automatically adjusts according to the selected pressure. The high-precision, contact-measuring system includes grinding height control and dressing monitoring.
Our highly efficient Intelligent Gantry-Type Automatic Production Line is designed to make sure each machine meets customers’ expectations for design, features, precision, quality and reliable performance for years to come.
This automatic production line, developed and tested by our R&D department and application team, includes vertical lathes and vertical machine centers along with automatic loading and unloading systems, workpiece identifying, positioning, flipping, cleaning and in-process measuring systems.
We significantly increased the system’s production efficiency by using high-speed, double-jaw robot arm movements, vertical direction at 60 m/min and horizontal direction at 80 m/min.
As a result, our professional team can study customers’ requirements and design a complete integrated production line—including an automatic loading and unloading system—to meet their specifications.
．Max. Swing: Φ540 mm
．Max. Machining Diameter: Φ350 mm
．Max. Machining Length: 700 mm
．Powerful 20hp Spindle Motor
．5,000 rpm Max. Spindle Speed
．6", 8" or 10" Chuck System
．Orthogonal Moving Column Structure
．Linear Guideway
．±110° B-axis Design
．Multi-Tasking Table
Click the link below for more information:
https://www.yidacnc.com/product_d.php?lang=en&tb=1&id=394
The FVL-8, 12, 20 and 24 Series meets the need to integrate automation or cell manufacturing into the market. This series is widely used in the automotive parts, engines and compressor industries by using a simplified fixture design and is excellent for turning irregular shaped workpieces. The automotive industry's lightweight and environmental restrictions and the popularity of alternative energy vehicles are driving a substantial increase in the demand of forged aluminum wheels.With our steel-inlaid guideway technology, this series adopts the dual-turret dual-system configuration that simultaneously handles the inner and outer diameter of the aluminum wheels. The machining range can reach 26" aluminum wheels, which greatly reduces machining time. The 6+6 turret provides additional flexibly for tool selection.Our exclusive iMachine Communications System™ (iMCS) software includes remote machine monitoring, data analysis, alarm history and maintenance updates to improve overall equipment efficiency (OEE). Working with Chevalier’s software, an operator easily controls the machine with simple procedures to increase productivity.
．X / Y / Z axis linear guideway (MV-1500)
．X / Y / Z axis box guideway (BMV-1500)
．Arm type tool magazine: 24 tools (STD.) ; 30 tools (OPT.)
．X / Y / Z travel: 1,500 x 680 x 680 mm
Click the link below for more information:
https://www.yidacnc.com/product_d.php?lang=en&tb=1&id=460
．X / Y / Z axis linear guideway (MV-1100)
．X / Y / Z axis box guideway (BMV-1100)
．Arm type tool magazine: 24 tools (STD.) ; 30 tools (OPT.)
．X / Y / Z travel: 1,100 x 650 x 620 mm
Click the link below for more information:
https://www.yidacnc.com/product_d.php?lang=en&tb=1&id=436
．X / Y / Z axis linear guideway (MV-1300)
．X / Y / Z axis box guideway (BMV-1300)
．Arm type tool magazine: 24 tools (STD.) ; 30 tools (OPT.)
．X / Y / Z travel: 1,300 x 680 x 680 mm
Click the link below for more information:
https://www.yidacnc.com/product_d.php?lang=en&tb=1&id=448
‧ X / Y / Z axis linear guideway
‧ Arm type tool magazine: 24 tools (STD.) ; 30 tools (OPT.)
‧ X/Y/Z travel: 860 x 600 x 610 mm
Click the link below for more information:
https://www.yidacnc.com/product_d.php?lang=en&tb=1&id=418
· X / Y / Z axis linear guideway
· Automatic pallet changer
· Arm type tool magazine: 24 tools (STD.) ; 30 tools (OPT.)
· X / Y / Z travel: 860 x 500 x 500 mm
Click the link below for more information:
https://www.yidacnc.com/product_d.php?lang=en&tb=1&id=424
．Max. Machining diameter: Φ360 mm
．Max. Machining length: 300 mm
．X-axis Travels: 195 (175+20) mm
．Z-axis Travels: 330 mm
．Spindle Nose: A2-5
．Chuck diameter: 6"
Click the link below for more information:
https://www.yidacnc.com/product_d.php?lang=en&tb=1&id=526
BML-560S
．Max. Machining diameter: Φ320 mm
．Max. Machining length: 320 mm
．X-axis Travels: 190 (160+30) mm
．Z-axis Travels: 360 mm
．Spindle Nose: A2-6 (STD.) ; A2-5 (OPT.)
．Chuck Diameter: 8" (STD.) ; 6" (OPT.)
．CS- axis function
BML-560M
．Max. Machining diameter: Φ320 mm
．Max. Machining length: 570 mm
．X-axis Travels: 190 (160+30) mm
．Z-axis Travels: 610mm
．Spindle Nose: A2-6 (STD.) ; A2-5 (OPT.)
．Chuck Diameter: 8" (STD.) ; 6" (OPT.)
．CS- axis function
Click the link below for more information:
https://www.yidacnc.com/product_d.php?lang=en&tb=1&id=538
BML-600L
．Max. Machining diameter: Φ420 mm
．Max. Machining length: (STD.) 1,280 mm (10")；(OPT.) 1,260 mm (12")
．X-axis Travels: 230 (210+20) mm
．Z-axis Travels: 1,330 mm (10") ; 1,320 mm (12")
．Spindle Nose: A2-8 (STD.)
．Chuck Diameter: Φ10" (STD.) ; Φ12" (OPT.)
．CS- axis function (OPT.)
Click the link below for more information:
https://www.yidacnc.com/product_d.php?lang=en&tb=1&id=562
BML-600M
．Max. Machining diameter: Φ420 mm
．Max. Machining length: (STD.) 780 mm (10")；(OPT.) 760 mm (12")
．X-axis Travels: 230 (210+20) mm
．Z-axis Travels: 830 mm (10") ; 820 mm (12")
．Spindle Nose: A2-8 (STD.)
．Chuck Diameter: Φ10" (STD.) ; Φ12" (OPT.)
．CS- axis function (OPT.)
Click the link below for more information:
https://www.yidacnc.com/product_d.php?lang=en&tb=1&id=550
BML-600S
．Max. Machining diameter: Φ420 mm
．Max. Machining length:(STD.) 560 mm (8")；(OPT.) 540 mm (10")
．X-axis Travels: 230 (210+20) mm
．Z-axis Travels: 590 mm (10") ; 600 mm (8")
．Spindle Nose: A2-6 (STD.) ; A2-8 (OPT.)
．Chuck Diameter: 8" (STD.) ; 10" (OPT.)
．CS- axis function (OPT.)
Click the link below for more information:
https://www.yidacnc.com/product_d.php?lang=en&tb=1&id=538
Working Table Dimensions: (STD): 500 x 500 mm, OPT: 400 x 400 mm
Max. Loading Capacity: STD: 500kg
OPT: 400 kg
B Minimum Indexing: STD: 0.001°
OPT: 1°
Pallet Capacity: 2 pcs
Max. Diameter of Workpiece: Ø570
Max. Height of Workpiece: 640 mm
Max. Travel of X/Y/Z-axis: 610 / 510 / 680 mm
Distance from Spindle Nose to Table Center: 140-820 mm
Spindle Taper: ISO No. 40
Spindle Speeds: STD: 10,000 rpm (belt-driven)
OPT: 12,000 rpm (belt-driven)
Tool Capacity: STD: 40 pcs
OPT: 60 pcs
Click the link below for more information:
https://www.yidacnc.com/product_d.php?lang=en&tb=1&id=196
Working Table Dimensions: 500 x 500 mm
Max. Loading Capacity: 500kg
B Minimum Indexing: STD: 0.001°
OPT: 1°
Max. Speed of B-axis: STD: 35 rpm (0.001°)
OPT: 25 rpm (1°)
Pallet Capacity: 2 pcs
Max. Diameter of Workpiece: Ø780
Max. Height of Workpiece: 750 mm
Max. Travel of X/Y/Z-axis : 800 / 650 / 800 mm
Distance from Spindle Nose to Table Center: 150-950 mm
Spindle Taper: ISO No. 50
Spindle Speeds: STD: 10,000 rpm (direct-drive)
OPT: 12,000 rpm (direct-drive)
15,000 rpm (direct-drive)
Tool Capacity: STD: 40 pcs
OPT: 60, 120, 180 pcs
Click the link below for more information:
https://www.yidacnc.com/product_d.php?lang=en&tb=1&id=310
．Tool Magazine: 60 Tools; 120, 180 Tools (OPT.)
．Tool Change Time (T-T): 3.5 sec.
．Pallet Change Time (P-P): 16 sec.
．Box-in-Box solid structure
．BT50 direct driven spindle: 10,000 rpm
．Dual ball screw (X/Z axis) and dual motor design
．Fanuc/ Heidenhain / Siemens controllers
Click the link below for more information :
https://www.yidacnc.com/product_d.php?lang=en&tb=1&id=298
．Tool Magazine: 40 Tools
．Tool Change Time (T-T): 2.1 sec.
．Pallet Change Time (P-P): 10 sec.
．BT40 Spindle: 12,000 rpm direct driven
．Acceleration: 1 G
．Central Removal System
Click the link below for more information:
https://www.yidacnc.com/product_d.php?lang=en&tb=1&id=130
．Max. Machining diameter: Φ360 mm
．Max. Machining length: (STD.) 470 mm (A2-6)；(OPT.) 460 mm (A2-8)
．X-axis Travels: 215 (180+35) mm
．Z-axis Travels: 500 mm (8") ; 500 mm (10")
．Spindle Nose: A2-6 (STD.) ; A2-8 (OPT.)
．Chuck Diameter: 8" (STD.) ; 10" (OPT.)
．CS- axis function (OPT.)
Click the link below for more information:
https://www.yidacnc.com/product_d.php?lang=en&tb=1&id=382
ML-600S
．Max. Machining diameter: Φ420 mm
．Max. Machining length:(STD.) 560 mm (8")；(OPT.) 540 mm (10")
．X-axis Travels: 230 (210+20) mm
．Z-axis Travels: 600 mm (8") ; 590 mm (10")
．Spindle Nose: A2-6 (STD.) ; A2-8 (OPT.)
．Chuck Diameter: Φ8" (STD.) ; Φ10" (OPT.)
．CS- axis function (OPT.)
ML-600M
．Max. Machining diameter: Φ420 mm
．Max. Machining length: (STD.) 780 mm (10")；(OPT.) 720 mm (12")
．X-axis Travels: 230 (210+20) mm
．Z-axis Travels: 830 mm (10") ; 820 mm (12")
．Spindle Nose: A2-8 (STD.)
．Chuck Diameter: Φ10" (STD.) ; Φ12" (OPT.)
．CS- axis function (OPT.)
ML-600L
．Max. Machining diameter: Φ420 mm
．Max. Machining length: (STD.) 1,280 mm (10")；(OPT.) 1,260 mm (12")
．X-axis Travels: 230 (210+20) mm
．Z-axis Travels: 1,330 mm (10") ; 1,320 mm (12")
．Spindle Nose: A2-8 (STD.)
．Chuck Diameter: Φ10" (STD.) ; Φ12" (OPT.)
．CS- axis function (OPT.)
Click the link below for more information:
https://www.yidacnc.com/product_d.php?lang=en&tb=1&id=238
ML-430
．Max. Machining diameter: Φ430 mm
．Max. Machining length: 240 mm
．X-axis Travels: 350 mm
．Z-axis Travels: 320 mm
．Spindle Nose: A2-5
．Chuck Diameter: 8"
．CS- axis function (OPT.)
Click the link below for more information:
https://www.yidacnc.com/product_d.php?lang=en&tb=1&id=250
VISE CAN SIDE-LOCK TO WORK
1.Pressure Constant. Clamping force can presetting, repeat use the same clamping force.
2.Vise body is made of ductile iron FCD-60.
3.Vise bed hardened to HRC45° and maintain accuracy for long.
4.Vise bed height-size and the guide block side are all made with full control, can 2, 3, or 4 vises to perform a job at a time.
5.The length of vise body is very short, but the clamping range is very big. It works with every kind of milling machine, CNC machine center.
IK-N90 characteristics
1. It uses precision grinding gears made in Japan. It can be used machining with high speed.(2000 RMP)
2. It is always linked to traditional plano milling machine, gantry type machine, CNC machine center and special functions milling machine…etc.
3. It is a processing accessory for machinery manufacturing, molds, aerospace, energy, automobiles, motorcycles and other industries.
4. 90 degree processing angle heads is suitable for all types of milling heads and it can change the processing angle and direction. It help you save equipment investment costs.
5. There are 2 models in 90 degree processing IK Angle Head series. (the other one is IK-A90)
Besides these characteristics.IK-N90 could be used with IK-N95 semi-automatic hydraulic table.IK-N90+IK-N95 are applied for auto-rotating multi-angle machining.
(Accessory Milling Head / Semi-Automatic Angular Head)
IK-U90 characteristics
1. It uses precision grinding gears made in Taiwan. It can be used machining with high torque.(800 RPM)
2. It is always linked to traditional plano milling machine, gantry type machine, CNC milling machine and special functions milling machine…etc. The universal milling head is a commonly used accessory of machine tools, and one of the most core parts of machine tools with the highest technical content.
3. It is widely used in high-speed processing in mold manufacturing, aviation industry…
etc.
4. Universal milling head refers to a milling head whose output axis of the machine tool can rotate in both horizontal and vertical planes.
5. There are 2 models in 90 degree processing IK Angle Head series.(the other one is IK-N90)
IK-E93A 2000 characteristics
1. Extend head, its function is to extend spindle and increase rigidity. The working stroke is increase.
2. Extend head is used to extend machining process 305mm.
3. Used on gantry milling machine, special machine, CNC milling machine, it need to be combined with flange.(Flange is optional)
4. It is used for mold, like aluminum for light cutting and drilling.
IK-E95A 2000 characteristics
1. Extend head is used to provide longer machining range. If you don't want to move or raise the workpiece, you can choose to use an extended milling head.
2. Extend head is used to extend machining process 505mm.
3. It is always linked to gantry milling machine, CNC machine center, boring and special machine. It need to combined with customize flange.(Customize flange is optional)
4. It is used for mold, like aluminum for light cutting and drilling.
Features :
1. IK milling heads can help you upgrade or replacement your original machine body, milling machine or special purpose machine.
2. This product uses for gear type structure can bring the powerful and high-quality cutting benefits for machine.
3. This product can be configured in CNC horizontal milling machine or special machine for milling machine.
4. This products didn't offer servo motor and servo controller.
5. There are 3 models in IK CNC Milling Machine Head Series.
Features :
1. IK milling heads can help you upgrade or replacement your original machine body, milling machine or special purpose machine.
2. This product uses for gear type structure can bring the powerful and high-quality cutting benefits for machine.
3. This product can be configured in CNC vertical milling machine or special machine for milling machine.
4. This products didn't offer servo motor and servo controller.
5. There are 3 models in IK CNC Milling Machine Head Series.
6. Offer IK-N90 and IK-N90+N95 milling head accessory for you to optional.
Features :
1. IK milling heads can help you upgrade or replacement your original machine body, milling machine or special purpose machine.
2. This product uses for gear type structure can bring the powerful and high-quality cutting benefits for machine.
3. Spindle speed change has high and low two stage.
4. This product can be configured in CNC vertical milling machine or special machine for milling machine.
5. This products didn't offer servo motor and servo controller.
6. There are 3 models in IK CNC Milling Machine Head Series.
-Worktable diameter Ø125, Ø170, Ø210, Ø255
-Exclusive patented dual pneumatic piston braking system.(P.19)
-Higher rotation speed.
-Equipped with high precision cross roller.
-Full gear depth transmitted by dual lead worm drive, resulting in higher efficiency and lower backlash.(P.20)
-Worktable diameter Ø255, Ø320, Ø400.
-Big spindle bore allow the more complex parts clamping and fixture.
-Ultra high clamping force by drum brake system.(P.19)
-Consolidated spindle with radial-Axial bearing built-in. (P.18)
-Full gear depth transmitted by dual lead worm drive,resulting in higher efficiency and lower backlash.(P.20)
Controller：FANUC 0i-T
Swing over bed：455mm
Swing over saddle：260mm
Max. turning diameter：280mm(UL-15)；180mm(UL-15M)
Max. turning length：300mm(UL-15)；210mm(UL-15M)
Guide way type：Box Way
X-axis travel：175mm
Z-axis travel：350mm
>click here to see more specifications<
Controller：FANUC 0i-T
Max. Turning Diameter(SP1)：70mm
Max. Turning Diameter(SP2)：70mm
Max. Turning Length：mm 55
Guide way type：Linear
X-axis Travel： 160(145+15)mm
Z-axis Travel： 310(±155)mm
>click here to see more specifications<
Controller：FANUC 0i-T
Swing over bed：660mm
Swing over saddle：620mm
Max. Turning Diameter：340mm
Max. turning length：510mm(UA-2000T2M) / 400mm(UA-2000T2MB)
Guide way type：Linear + Box
X-axis Travel：X1/X2: 210mm
Z-axis Travel：Z1/Z2: 550mm(UA-2000T2M)/Z1/Z2: 450mm(UA-2000T2MB)
B-axis Travel：1400mm(UA-2000T2M) /1200mm(UA-2000T2MB)
>click here to see more specifications<
Controller：FANUC 0i-M
Spindle speed：10000/12000rpm
Spindle nose taper：BT40
Bearing inner diameter：70mm
Drive system：Belt/Direct
X-axis travel：1100mm
Y-axis travel：550mm
Z-axis travel：550mm
Spindle nose to table：150~700mm
>click here to see more specifications<
With a highly experienced design and manufacturing background in centerless grinders, PALMARY present the new bearing type CNC centerless grinder.
Differ from PALMARY traditional model, PCB, bearing type to meet the awareness of eco-friendly, there’s no oil tank for spindle lubrication. Both wheel head spindle filled with oil grease which can do oil mist auto lubrication while needed. Maintenance is much easier. G.W. is hold by bearing in single side which is convenient for replacement. R.W. is hold by bearing at double side to reduce backlash.
The model has had great performance on automobile industry, take hydraulic spool for instance. Roundness can be controlled under 1 um.
To maintain such stable result, the dressing attachment is also key point. It is equipped with cylinder to avoid backlash. Besides, in addition to single point diamond dresser, roller dresser is optional for customer for better durability.
Automation design is always available with the machine. Gantry type loader is equipped on GW side which is easier to do grinding adjustment.
In addition to that, the graphic interface integrates auto loader and unloader as well as measuring data, which is much easier to take necessary action while notice the change.
The base structure is upgraded with square slide with roller bearing and shorten the machine layout at the same time.
Super rigid structure, stable without deformation. Double support grinding wheel spindle design features high speed operation to boost grinding performance. The double support bearing type spindles offer even grinding force on the contact surface. During grinding process, the stress is even on both ends of spindle to avoid taper shaped workpieces.
The one "V" & one flat feeding slide design reinforces the feeding stability. The entire feeding slide is hand scrapped to reduce friction and to increase accuracy of jog movement. Computer numerical control from 1 ~ 6 axes satisfy requests for customized specification. Fitted with wider wheel, suitable for efficient mass production.
CNC Cylindrical Grinder, Plunge grinding with wpecial wider grinding wheel series, the machine structure is strengthened with same design of heavy duty cylindrical grinder. The enlarge hydrostatic wheel spindle construction could equip max. 125 mm width grinding wheel for plunge grinding application.The enlarge hydrostatic wheel spindle construction could equip max. 125 mm width grinding wheel for plunge grinding application. The variable frequency grinding wheel speed control could reach max. 60 M/s cutting speed. The large fully splash guard is designed for more interior space use. All the slides are hydrostatic designed for smooth move while grinding process. The taper fine adjustment tailstock is standard accessory and easy to adjust the taper if required. The CNC conversational controller is ease of operation. The optional accessories such as O.D. measuring system is possible to equip for clients use.
CNC cylindrical grinder special designed for spindle grinding. The advanced machine structure with a special grinding wheel spindle design, enhances the whole rigidity of the machine, and makes the grinding workpiece of spindle faster, more accurate and more stable. High precision and high rigidity machine structure design.
Advance the machine design structure. The lower center of gravity of the bed reinforces the machine rigidity.
The rigidity of the grinding wheel spindle is comprehensively improved. Fully enhance the cutting force and grinding efficiency.
(a) The grinding wheel spindle with hydro-static bearing. No friction between metals, maximum wear resistance and enhance the lifetime.
(b) Enlarge the spindle pitch and grinding wheel motor, enhance the grinding efficiency and shorten cycle time.
Fully-closed hydrostatic slide advances the loading capacity.
The slide is widened and thickened designed with fully-closed hydrostatic. The maximum loading weight of the workpiece is 500KGS.
The stroke of each axis is increased to meet the requirement of large-angle grinding.
(a) The X&Z axis strokes are increased to improve the grinding efficiency of the wheel.
(b) The swiveling angle of the worktable is enlarged, providing the operator with their diversified processing demands.
The new and miniaturized CNC internal Grinding Machine from PALMARY features build-in spindles design, man-made mineral machine bed for more stability, minimize its space, and an elegant appearance combined with advanced CNC control and interactive screen operation. The all new series will bring internal grinding technology into a new era.
The high rigidity and stable man-made mineral machine bed could provide the smooth machining requirement and being the basic of accuracy.
The clients’ factory land capacity was increased for the machine has small machine bed design which only same as B1 paper size. Further, it’s easy to equip the automatic loading system.
The high efficiency bearing built-in spindles are used on both grinding wheel spindle & work spindle which offer the high accuracies grinding performance.
Both X & Z axes equip with linear servo motors which provide high-speed grinding activity and shorten the cycle time. Further, the digital readouts put on both axes for high-speed precision efficiency.
The new CNC internal Grinding Machine from PALMARY features optimal structural design, and an elegant appearance combined with advanced CNC control. The all new series will bring internal grinding technology into a new era.
The structural parts of the machine are manufactured from high quality cast iron for deformation-free performance year after year. The entire machine is precision built throughout to guarantee the best possible grinding accuracy you can find anywhere.
Two internal wheel spindles model for your different application requirement. It's capable of grinding internal hole, end face and outer diameter at one time setting. To meet mass production requirements, automatic loading and unloading equipment is available to provide a fully automatic operation. The slides move on roller type linear guideways for increasing smoothness & stable movement. The feed axis is equipped with optical scale to upgrade positioning accuracy.
Based on PALMARY's tradition of "Pursuing Quality Perfection", combined with human engineering design and peak performance concepts, each machine fully reflects PALMARY's unmatched design and technique.
Honeycomb type machine structure assures the best possible rigidity and stability. The machine bed is manufactured from high-quality Meehanite cast iron, heat treated and stress relieved for outstanding stability and without deformaiton. The design of honeycomb Tubular type machine bed and cross guideway structure for improving the higher rigidity and stability. For end face grinding application, the wheel spindle can swivel to 22.5 degrees for easy grinding.
Auto. tool change system (ATC). Equipped with max. 6 no. grinding wheels for different diameter or accuracy requirement. The coolant flow has an isolation design from the machine bed and can reduce the heat deformation and dirt contamination on the bed.
Based on PALMARY's tradition of "Pursuing Quality Perfection", combined with human engineering design and peak performance concepts, each machine fully reflects PALMARY's unmatched design and technique. Honeycomb type machine structure assures the best possible rigidity and stability. The machine bed is manufactured from high-quality Meehanite cast iron, heat treated and stress relieved for outstanding stability and without deformaiton. The design of honeycomb Tubular type machine bed and cross guideway structure for improving the higher rigidity and stability. For end face grinding application, the wheel spindle can swivel to 22.5 degrees for easy grinding. Auto. tool change system (ATC). Equipped with max. 6 no. grinding wheels for different diameter or accuracy requirement. The coolant flow has an isolation design from the machine bed and can reduce the heat deformation and dirt contamination on the bed.
Contact Information
www.palmary.com
No. 77, Gongye Rd., Dali Dist., Taichung City 412037, Taiwan
+886-4-24929799
+886-4-24929499
![Products|OCD-32100CAM - CNC Cylindrical Grinding Machine [CAM series] - special shaped workpiece]( https://www.mtb2b.tw/storage/customer/330f9c32862e.jpg )
For various eccentric circle or non-round shape workpieces grinding purpose, PALMARY develop CNC Cylindrical Grinder Cam Type with CAD/CAM software for easily transfer from workpiece drawing to grinding program. The workhead could offer precise angle control upto 0.1 micron resolution due to the C axis has accurate angle encoder. The infeed axis is driven by linear motor with linear guideway & close loop linear scale, it could avoid the backlash in order to reach high machining precision. Also, it could prevent the reaction force causing by linear motor under the large acceleration and deceleration motion, it could stabilize the grinding process.This machine has high-speed algorithm controller execute under PC Based + Windows XP, allowing the 3rd party application and Flash Drive for prompt transfer, its single section processing time could be ≦ 1ms.
The Internal Grinder for bearing inner dia. and groove is specially applied for bearing grinding. The workpiece loading, unloading and the workhead movement could operate at the same time in order to shorten the time for setting & adjustment. Machine could equip with vibration feeder or workpiece arranging device in order to have auto loading control.
Machine equipped with Palmary developed conversational control panel (Mitsubishi PLC) for easy operation. The customer could choose to use CNC controller as optional.
Machine with magnetic workhead centerless support device which allows the loading and unloading workpiece process move quickly and increase work efficiency.
Machine supplied the high precision roller type dressing device to make sure the dressing accuracy.
The customer could use optional accessory CBN grinding wheel for having better grinding results.
According to the workpiece accuracies required, it's optional to add the digital linear or in-process ID measuring device.
5 AXES SIMULTANEOUS CONTROL CNC MACHINING CENTER
Features:
-Moving column construction
-X/Y/Z box ways or X/Z Linear ways+Y box way
-X,Y,Z-axis are equipped with linear scales
-Gear-drivn type spindle head is excellent for heavy cutting
-0,001-degree servo-driven rotary table
-Table rotation is transmitted through double worm/ double worm gear units to eliminate gear-backlash problem
-W axis extension is free of deformation
-Go tools chain type magazine
-During machine assembly, all foundation bolts have been locked into the foundation to ensure the consistency of leveling accuracy
Features:
-30 degree slant bed design for easy operation and easy chip removal
-Cast iron bed with optimally designed ribs with integral stiffness provides an very strong rigidity
-Big diameter bearing provides high rigidity
-High-resolution encoder mounted on spindle to provide accurate C axis positioning
-C axis with continuous indexing
-Double supported ball screws direct-driven servo motors are used for axial movements
-Servo turret or hydraulic turret is offered for users as an alternative choice
-Large disc is equipped for easy tool set up
-Special spindle motor location design reduces machine floor space
-One-piece structure on the machine structure to provide massive rigidity
-Programmable tailstock available as an option
-Large coolant tank
-Internal coolant supply through turret disc
-High pressure pump
-PLC controlled chip conveyor
￭One-piece 30° slant bed design made from high quality MEEHANITE® cast iron to reduce the effects of vibration and
minimize thermal deformation.￭The spindle driven by a 35 kW 47 HP motor can generate rotation speed up to 3,500 rpm which is well-suited for heavy duty
machining.￭Packed with sub spindle, Y-axis, live tool turret and C-axis, these turn-mill features allow complex finished parts machining in
just one setup, while also improving efficiency and accuracy.￭The BMT65 turret ensures a fast and stable rotation.
1. The grinding wheel head spindle is equipped with a self-made hydrostatic spindle, which has excellent characteristics such as high precision, high rigidity, high shock resistance, high bearing capacity and long life.
2. High rigidity hydrostatic rotary table, static rigidity>400kgf/μm, Ø600 worktable load can reach 10000kg
3. The base of the bed adopts an integrated cast iron design, which not only increases the structural strength, but also makes the center of gravity of the machine more stable, and provides the best support and ensures the bearing rigidity of the machine.
4. Equipped with CNC Mitsubishi controller, graphical dialogue human-machine interactive interface, and visual application.
* There are 4 Stations, 1 station is for loading/ unloading; the other 3 stations can machine the parts at the same time.
* Each station equips with spindle, ATC and B axis.
Process program is separated, in other words, one machine is equivalent three horizontal milling machines.
* Max. rotary speed of built-in spindle can reach to 16,000RPM, and rated torque is 55N.m.
* It can equip BT40 or HSK63A ATC, the capacity of ATC is 24 tools.
* The stroke of sliding table is X:400; Y:350; Z:400
* Design of B axis is used toothed clutch.
Depends on customer's request, one indexing can be set up for 1∘or 5∘, Repeatability is within 4”.
* Machine is suitable for processing special shape part, e.g. drilling, tapping, and milling
Description
▶Reliable ▶Diversity ▶Customization ▶Cost-effective
1. European DELEM multi-axial controller.
2. The ram repeat accuracy is guaranteed by 2 sets of linear scales.
3. The controller stores up to 999 programs, each contains 17 bend. All programs can be interconnected.
Description
▶Reliable ▶Diversity ▶Customization ▶Cost-effective
1. European DELEM multi-axial controller.
2. The ram repeat accuracy is guaranteed by 2 sets of linear scales.
3. The controller stores up to 999 programs, each contains 17 bend. All programs can be interconnected.
4. Graphic display of punch and die. Data about die sets up to 2 MB can be stored.
5. Multi=language controller, with English, Japanese, Korean, Chinese (traditional & simplified) available.
6. Basic functions of windows.
1. Grinding wheel has been carried out, and one-time feed is adopted in a straight-forward mode, which greatly improves the overall processing efficiency and stability.2. The maximum width of the grinding wheel can reach 300mm, and the grinding of workpieces with 15 steps can be completed by one-time operation.3. Equipped with hydrostatic spindle, it has excellent features such as high precision, high rigidity, high shock resistance, high bearing capacity and long life.4. The headstock and tailstock are driven by dual servo motors, which can avoid the interference problem of traditional driving rings.
Description
▶Reliable ▶Diversity ▶Customization ▶Cost-effective
1. After planning the V slots on sheets, it can use small tonnage hydraulic press brake to bend the sheet.
2. Processing length depends on working piece length. Planer tool's stroke is adjustable. Planer working speed is stable and fast.
3. CNC 3 axes control, with semi-auto/auto processing function.
4. Be able to clamp and hold the working piece in semi-auto/auto function. All operation can be done in once.
5. The distance between planer tool and pressing plate is very small (3mm). The planned V slots are even.
1. The grinding wheel head seat is equipped with a hydrostatic spindle, which has the characteristics of high precision, high rigidity, high shock resistance, high bearing capacity and long life, and the spindle rotation accuracy can reach within 1.0μm.
2. The tailstock is designed with high rigidity. The telescopic sleeve is controlled by hydraulic pressure, which is convenient for fixing and replacing the workpiece.
3. The workpiece headstock is equipped with a servo motor with automatic speed regulation function to maintain the machining accuracy and efficiency during the grinding process.
4.4. Graphical dialogue human-machine interface, visualization application.
1. The grinding wheel head seat is equipped with a hydrostatic spindle, which has the characteristics of high precision, high rigidity, high shock resistance, high bearing capacity and long life, and the spindle rotation accuracy can reach within 1.0μm.
2. Graphical dialogue human-machine interface, visualization application.
3. Stable mechanical structure, special grinding wheel spindle design, suitable for grinding outer surface, tapered surface, forming outer surface, radius, groove and end surface, with excellent precision.
4.The X-axis feed slideway adopts double V design, which presents the best balanced support and stable leveling accuracy. When grinding, the feed accuracy can reach μm level.
CONTINUOUS OPTIMIZATION OF PRODUCTION LINE NARROW FACE WIDTH. FLEXIBLE LAYOUT. YOUR BEST PARTNER IN INTELLIGENT MANUFACTURING.
- 1000mm supper narrow face width
- Flexible Layout to Suit Various Production Requirements.
- Patented Complex Tool Turret.
- Automatic Workpiece Changer (optional)
- Intelligent Production through Human-Machine Interface.
The WVT series CNC Vertical Lath features highly rigid structure. The series of machine is designed specifically for extra hard workpiece machining, and exhibits outstanding stability and dependability.
One-piece-formed base: The base is made as 60-degree one-piece-formed, which decreases the negative influence from the casting combination and also ameliorates the chip transferring.
Customized turret: The specialized turret, designed from MYLAS and SAUTER, mainly reduces the interference of each turret while triple system movement.
High-level end controller: For simultaneous machining, all three programs can be monitored in one shot, which maximizes the convenience of the tool control.
Multi-axes linear guideway: For better accuracy and speed, X and Z-axis are equipped with linear guideways.
Boxy way on dual Y axes: The machine is equipped double BMT-55 turret that increases the loading of each Y-axis. To meliorate the stability and rigid, double Y axes design with boxy way.
●Significantly upgrade CNC 5-Axis Machines
●Special 45° dovetail structure with teeth
●The patented calibration system can regulate clamping center easily and rapidly
1) Vise body is made of High quality Steel (S50C) and its slideways gone through high-frequency hardening to achieve HRC50, which makes the whole part durable.
2) Detachable jaws are made of High quality Tool Steel (SCM440) and gone through carburizing to achieve HRC55. Since both sides are fixed size and able to be used as a datum, users can reverse them to increase clamping range.
3) The vise's clamping force can achieve 1300KG, the repeatability positioning precision of its clamping center is within 0.015mm.
4) Users can calibrate the clamping center of vise by adjusting the screws on both ends.
5) The 45° dovetail structure with teeth on the upper jaw ensures the bottom of the workpiece to be firmly clamped.
●Shortest Length with Big Jaw Opening
●Extremely High Accuracy and Repeatability
●Special MULTI-POWER design enhances clamping force of 5000KG
●Suitable for CNC 5-Axis Machining Centers, horizontal and vertical CNC Machining Centers
1) Compact design with big jaw opening, which enhances machine space utilization.
2) Vise jaws are made of High quality Tool Steel (SCM440) and Hardened to achieve HRC 55, which makes vise clamp the workpieces easily and firmly.
3) Vise body is made of Ductile lron above FCD 60 grade and its slideways are hardened to HRC 52 , which makes the vise tensile strength with high precision accuracy.
4) The patented MULTI-POWER SYSTEM is built of high grade BEARING STEEL which doubles the clamping force. Adjustable clamping force 5000kg. With this special patented system the pressure is more consistent and eliminates oil leakage and maintenance problems associated with Hydraulic Vises.
5) Special Leadscrew Covers protect Leadscrew from swarf and avoid any possible damage to internal parts.
●Electro-Permanent Magnetic Chuck structure design, use the natures of different permanent magnetic materials, through electronic control system control and convert the distibution of internal magnetic circuit, magnetic disk (i.e. in tight clamping state), and demagnetize (i.e. in loosing state).
●Magnetization and demagneticzation time is only 3-12 seconds. After completion, it does not need to continuously supply power to produce safe and strong magnetic force. It does not have the problem with temperature rise. It can last for a long time. The maintenance is easy. It is both economic and environment friendly.
●Shorten workpiece installation time, fast mold change, save work time, increase productivity.
●Strong and stable magnetic force, assure tight fastening of workpiece, high processing precision.
●Use and Applicable Areas:
General cutting and processing for all kinds of iron parts, rapid mold change, suitable for CNC vertical computer milling machine and horizontal computer milling machine, general milling machine precision machining; the Electro-Permanent Magnetic Chuck is highly mobile, suitable for any machine.
Workpiece thickness requirement
ECMC-A Series: above 15mm
ECMC-B Series: above 25mm
ECMC-C Series: above 40mm
ECMC-D Series: above 50mm
●As workpiece is clamped, strongest magnetic force is achieved when the contact is from more than 4 magnetic poles.
●Magnetic pole dimensions 50x50 mm, suitable for general cutting and processing for small and medium workpiece.
●Magnetic pole dimensions 70x70 mm, suitable for general cutting and processing for medium and large workpiece.
●Work with various magnetic soft jaws and movable spring pads, flexible adjustment and configuration according to processing needs.
1) Suitable for the magnetic material processing
2) Quick clamping the workpiece and provide five-sided processing
3) Work with various magnetic Soft jaws, flexible adjustment and configuration according to processing needs
Use and Applicable Areas:
●Milling, Grinding, Turning, Drilling, Automation, etc.
●Suitable for medium and large size of workpiece machining on milling machine and CNC machining center
●Users can array several magnetic vises in one set-up on a working table or a tooling tombstones to custom their own workholding solutions
●Mechanical vise (powerful clamping)
●Shortest Length with Big Jaw Opening
●Extremely High Accuracy and Repeatability
●Special MULTI-POWER design enhances clamping force of 0~8000KG (adjustable)
●Suitable for Gantry-Type machining centers
1.Vise Fixed Jaw is made of high quality steel and HARDENED to HRC 55. Vise body is made of Ductile Iron above FCD 60 grade for high precision and durability. With a force of 4500kg, the shape will deflect less than 0.005mm.
2.Slide ways are HARDENED to HRC 50 to further increase durability and maintain positioning height over long use.
3.The Special ANGLE-LOCK SYSTEM with compact design and high-grade iron of over FCD 60 grade for high rigidity automatically pulls the work-piece down to the accurate position of within 0.005mm under 4500kg of pressure. This vise is most suitable for precision mould making on Machining Centers.
4.Vise can be mounted horizontally or vertically.
5.The patented MULTI-POWER SYSTEM built of HIGH GRADE BEARING STEEL doubles the clamping force.
The pressure is more consistent and eliminates all leakage and maintenance problems associated with Hydraulic Vices.
With the first half a turn the vise will clamp with 2500kg pressure. With a second half turn it will apply 4500kg of clamping force.
This special patented system makes the clamping force constant.
6.Adjusting stop ring: This simple and effective presetting device enables to preset each desired clamping force and it guarantees to repeat each clamping operation at the same clamping force.
Mechanical Vise
Shortest Length with Big Jaw Opening
Extremely High Accuracy and Repeatability
Special MULTI-POWER design enhances clamping force of 0~6000KG
1.The patented MULTI-POWER SYSTEM is built of HIGH GRADE BEARING STEEL which doubles the clamping force. Adjustable clamping force of 0~6000kg. With this special patented system the pressure is more consistent and eliminates oil leakage and maintenance problems associated with Hydraulic Vices.
2.Slide ways are HARDENED to HRC 50º to further increase durability and maintain positioning height over long use.
3.Using high-grade iron of over FCD 60 grade for high rigidity and also ANGLE-LOCK SYSTEM, which automatically pulls the work-piece down to the accurate position of within 0.01mm under 4500kg of pressure, this vise is most suitable for precision mould making on Machining Centers.
4.Vise body is made of Ductile lron above FCD 60 grade for high precision and durability.
It is made in one solid piece and has very high rigidity with a force of 4500kg, the shape will deflect less than 0.01mm.
5.Vise can be mounted horizontally or vertically.
6.Adjusting stop ring: this simple and effective presetting device enables to preset each desired clamping force and it guarantees to repeat each clamping operation at the same clamping force.
1.Feature:
options of centering Microscope, CCD camera, Laser and other projection system depends on the different workpiece. Further application, manual, motorized with joystick or the CNC model can be optional by your demands.
2.Application:
IC electronics, Lead Frame and the related manufacturers in the fields of LCD, Semiconductor, PCB Screen printing WireCut. E.D.M. Rubber.Plastic, Precise Mold & Dies and other 2D workpiece machining.
3.Measuring Functions:
The multi-function MSU 3DPRO effects the 2D geometric measurement of Point, Line, Circle, Arc, Angle, Distance, Pitching, Alignment, and is accompanied with RS232 port.
ASM is the first 5-axis CNC turning and milling machining center of Vision Wide, and it is particularly designed for delicate cylindrical components machining featuring high acceleration, rapid feed-rate and synchronized axes machining, especially for aerospace components, tire molds, turbine blades and aluminum parts.
ASM accessorizes with 5-axis universal head and rotary shafts built-in D.D motor. Through topology analysis, ASM realizes the best distance between tool center point and B-axis transmission
NF series machines, with typical VW products features of rigid structure and high precision, are designed with 5-face function of multi-angle cutting and X-Y roller ways structure. It speeds up 3 axes rapid traverse and increases the machine’s efficiency of utilization.
UC Series, ultrasonic machining center, is mainly designed for aerospace honeycomb structure processing and it can efficiently perform honeycomb structure cutting with different inclinations, and output various structural shapes that meet customer needs.
● Composite paper honeycomb angle processing – triangle cutter processing and disc cutter processing
● With lightweight and dynamic column structure, combined with precision gears and racks, the movement is fast, ensuring the best feed speed.
● Oil-free pollution processing of advanced materials, and the three-axis slide rail adopts full grease lubrication device.
● Using European standard precision gear transmission on feeding axis to be provided with high feed rigidity position accuracy.
● Feeding axis with high accuracy linear scale feedback to use low thermal deformation coefficient to control positioning accuracy on linear scale.
● Feeding axes are using roller type linear guideway to keep accuracy for a long term.
● Vacuum chuck is clamping device under vacuum table to make workpiece adsorb stably on table.
● Two axis head self-monitoring protection system.
Spindle cooling system.
● Auto workpiece coordinate measurement / Contacting auto tool length measurement / Triangular tool angle deviation measurement.
Bed swing diameter: 450mm (17.7")
Saddle swing diameter: 280mm (11.0")
Maximum turning diameter: 260mm (10.2")
Maximum turning length: 300mm (11.8")
Bar capacity: 42mm (1.7")
Power chuck diameter: 6"
Spindle motor power: 7.5/11kw
Spindle speed: 5000rpm
Spindle nose taper: A2-5
X-axis travel: 125+20mm (4.9"+0.8")
Z-axis travel: 300mm (11.8")
X-axis rapid feed rate: 24m/min
Z-axis rapid feed rate: 30m/min
Slide way type: Linear
Tool capacity: 8T
Floor space: 2790x1542x1713mm
Machine weight: 3300kg
www.keepwaycnc.com
Bed swing diameter: 450mm (17.7")
Saddle swing diameter: 280mm (11.0")
Maximum turning diameter: 260mm (10.2")
Maximum turning length: 300mm (11.8")
Bar capacity: 52mm (2.0")
Power chuck diameter: 8T
Spindle motor power: 7.5/11kw
Spindle speed: 5000rpm
Spindle nose taper: A2-6
X-axis travel: 125+20mm (4.9"+0.8")
Z-axis travel: 300mm (11.81")
X-axis rapid feed rate: 24m/min
Z-axis rapid feed rate: 30m/min
Slide way type: Linear
Tool capacity: 8T
Floor space: 2790x1542x1713mm
Machine weight: 3300kg
Bed swing diameter: 530mm (20.9")
Saddle swing diameter: 380mm (15.0")
Maximum turning diameter: 360mm (14.2")
Maximum turning length: 500mm / 750mm (19.7" / 29.5" )
Bar capacity: 52mm (2.0") (OPT: 65mm)
Power chuck diameter: 8"
Spindle motor power: 11/15kw
Spindle speed: 4500rpm
Spindle nose taper: A2-6
X-axis travel: 180+20mm (7.1"+0.8")
Z-axis travel: 500mm (19.7")
X-axis rapid feed rate: 24m/min
Z-axis rapid feed rat: 24m/min
Slide way type: Linear
Tool capacity: 8T
Floor space: 3318x1675x1727mm / 4070x1705x1844mm
Machine weight: 4000kg / 5000kg
Bed swing diameter: 530mm (20.9")
Saddle swing diameter: 380mm (15.0")
Maximum turning diamteter: 360mm (14.2")
Maximum turning length: 500mm / 750mm (19.7" / 29.5")
Bar capacity: 75mm (3.0")
Power chuck diameter: 10"
Spindle motor power: 15/18.5kw
Spindle speed: 3500rpm
Spindle nose taper: A2-8
X-axis travel: 180+30mm (7.1+1.2")
Z-axis travel: 500mm / 750mm (19.7" / 29.5")
X-axis rapid feed rate: 20m/min
Z-axis rapid feed rate: 20m/min
Slide way type: Box
Tool capacity: 10T
Floor space: 3508x1658x1854mm / 4070x1705x1844mm
Machine weight: 4500kg / 5200kg
Bed swing diameter: 600mm (23.6")
Saddle swing diameter: 400mm (15.7")
Maximum turning diameter: 500mm (19.7")
Maximum turning length: 750mm (29.5")
Bar capacity: 85mm (3.3")
Power chuck diameter: 12"
Spindle motor power: 15/18.5kw
Spindle speed: 3000rpm
Spindle nose taper: A2-8
X-axis travel: 250+25mm (9.8+1.0")
Z-axis travel: 750mm (29.5")
X-axis rapid feed rate: 20m/min
Z-axis rapid feed rate: 20m/min
Slide way type: Box
Tool capacity: 10T
Floor space: 4307x1770x1942mm
Machine weight: 5700kg
Bed swing diameter: 600mm (23.6'')
Saddle swing diameter: 400mm (15.7")
Maximum turning diameter: 500mm (19.7")
Maximum turning length: 1200mm / 1600mm (47.2" / 63.0")
Bar capacity: 85mm (3.3")
Power chuck diameter: 12"
Spindle motor power: 15/18.5kw
Spindle speed: 3000rpm
Spindle nose taper: A2-8
X-axis travel: 250+25mm (9.8+1.0")
Z-axis travel: 1200mm / 1600mm (47.2" / 63.0")
X-axis rapid feed rate: 20m/min
Z-axis rapid feed rate: 20m/min
Slide way type: Box
Tool capacity: 10T
Floor space: 4786x1932x1941mm
Machine weight: 5900mm
WEB IoT Software for CNC Machines
●Machine monitoring
●Machine Activation rate (visualization)
●Employee work performance KPI
●System function
The VM25 is a modular fully programmable system designed for high performances
applications in grinding machines. It is able to provide solutions for:
- Automatic balancing of the grinding spindle on 1 and 2 plane
- Touch detection to control the contact grinding wheel-work piece and grinding
wheel-dresser, by using acoustic emission and/or power sensors
- In-process and post-process gauging (absolute or comparative)
Any imagination of processing can be achieved by GMT-2000 series• Looking for advanced processing equipment, with both high productivity and processing capacity for complex workpieces, as well as excellent cost performance. The seemingly impossible task will be fully achieved by GOODWAY GMT-2000 series.• The GMT-2000 series integrates the functional characteristics of turning centers and machining centers into one. It has the highest 9-axis control and 5-axis simultaneous machining capabilities. It can not only efficiently complete various complex shapes of workpieces, but also easily overcome the need for heavy cutting. This is a versatile model that can be used in all industries.• In addition, the optional G.LINC smart operating system and various automation equipment can further improve production efficiency, reduce manufacturing costs, and fully meet all your processing needs today and tomorrow.
Packed with the latest machine tools technology and high precision turning capabilities, the Goodway GV-500 series high speed vertical CNC turning center combines a high rigidity structure and precision linear guideways with a servo indexing turret and powerful spindle ( max. torque up to 883 N-m ). These series features a compact machine size with heavy duty turning capabilities. In addition to the GV-500 series, the GV-500X series twin spindles & turrets equipped with loading & unloading systems can complete disk-shape work pieces that need multi-processing in one single setup which saves a great amount of time and increases production efficiency to meet your needs of today and tomorrow.
• Fully enclosed splashguard keep chips and coolant contained for a safe clean working environment.
• The low center of gravity design with 90 degree rotatable control panel provides easy access to load & unload parts and a user friendly operating interface.
• Super compact machine size ( 3.3m ) equipped with rear discharge chip conveyor increases factory space usage while providing you with a convenient conveyor system planning.
With the latest machine tools technology and high quality components, GOODWAY brings you the new GLS-2800 / GLS-3300 series high speed CNC turning center. This series is based on high precise linear guide ways and featured big bore, high power, fast cut and more to provide you machining solution with high efficiency cutting power. Besides, The GLS-2800 / GLS-3300 series equipped with an optional live tooling turret, C-axis, Y-axis and sub-spindle, G.LINC 350 intelligent control system and various automation equipment to reach a complete series and easily meet your machining needs of today and tomorrow.
Equipped with an optional live tooling turret, C-axis, Y-axis and sub-spindle and other advanced features allows GLS-2800/3300 can work on turning, milling, drilling, tapping and off-center milling tasks. The machining capability equals the integration of turning center and machining center, which significantly lowers machining cycle time and manpower, and also prevent accuracy error of switching work-piece to another machine.
he spindle and gears of the right angle milling head (90o milling head, angle head) are made of chrome molybdenum alloy steel and heat treated (carburization). Thus, the milling head is rigid and durable. Its quality is reliable. Such a milling head is suitable for conventional gantry milling machines, CNC gantry milling machines, single arm milling machines, special purpose machines and machining centers. The main body of bidirectional milling type right angle milling head is formed in one piece, so its machining precision is more accurate and stable. Besides, the V-shaped oil seal not only seals the hole tightly, but also has waterproof and dust proof functions. The bidirectional milling saves re-correction time, and enhances work efficiency. This type of milling head, you can select 800RPM (heavy duty cutting type), 2000RPM (moderate cutting type) or 3000RPM (light cutting type) for using depending on the nature of the work and machine spindle speeds. And can mill five sides of the work piece if they work together with our boring-milling heads.
The spindle and gears of the right angle milling head (90 degree milling head, angle head) are made of chrome molybdenum alloy steel and heat treated (carburization). Thus, the milling head is rigid and durable. Its quality is reliable.
Such a milling head is suitable for conventional gantry milling machines, CNC gantry milling machines, single arm milling machines, special purpose machines and machining centers.
The model N75-HSK is a special milling head for motorized spindle, you can select 2000RPM (moderate cutting type) or 3000RPM (light cutting type) for using depending on the nature of the work and machine spindle speeds.
The spindle and gears of the right angle milling head (90 degree milling head, angle head) are made of chrome molybdenum alloy steel and heat treated (carburization). Thus, the milling head is rigid and durable. Its quality is reliable.
Such a milling head is suitable for conventional gantry milling machines, CNC gantry milling machines, single arm milling machines, special purpose machines and machining centers.
The model N75-CV use curvic coupling, which can be positioned quickly, customer can select inside curvic coupling type or outside curvic coupling type for using according the adapter size. Also can select 2000RPM(moderate cutting type) or 3000RPM(light cutting type) for using depending on the nature of the work and machine spindle speeds.
1. This milling head is one of our CNC boring-milling head series, and most suitable for installing to gantry milling machine, single arm milling machine and special purpose machine as heavy milling.
2. The inner wall is thicker. The main body is rigid.
3. The spindle of the milling head is made of Japan material and NSK bearings. The inner driving system has passed strict quality inspection, and is sturdy and durable. It functions very well.
4. Travel: 600mm
5. It can work together with our Φ250 right angle milling head (angle head) to
proceed with five-side milling.
6. Temperature rises slowly.
1. This milling head is one of our CNC boring-milling head series, and most suitable for installing to gantry milling machine, single arm milling machine and special purpose machine as heavy milling.
2. The whole machine uses Japan NSK bearings to ensure smooth operation and long service life.
3. 12-step speed satisfies a variety of machining needs.
4. Four hydraulic locks reduce vibration during heavy cutting, and make the
machining more stable.
5. 22kw permanent magnet synchronous motor or servo motor is employed to ensure big horse power, stable and smooth operation.
The spindle and gears of the right angle milling head (90o milling head, angle head) are made of chrome molybdenum alloy steel and heat treated (carburization). Thus, the milling head is rigid and durable. Its quality is reliable. Such a milling head is suitable for conventional gantry milling machines, CNC gantry milling machines, single arm milling machines, special purpose machines and machining centers. Oh Young right angle milling heads provide customers with many choices depending on machine spindle speeds and the nature of the work. The super heavy duty type right angle milling heads with heavy load bearings are suitable for super heavy duty cutting. And can mill five sides of the work piece if they work together with our boring-milling heads.
The spindle and gears of the right angle milling head (90o milling head, angle head) are made of chrome molybdenum alloy steel and heat treated (carburization). Thus, the milling head is rigid and durable. Its quality is reliable. Such a milling head is suitable for conventional gantry milling machines, CNC gantry milling machines, single arm milling machines, special purpose machines and machining centers. Oh Young right angle milling heads provide customers with many choices depending on machine spindle speeds and the nature of the work. The heavy duty type right angle milling heads with heavy load bearings are suitable for heavy duty cutting at low speeds(0-800RPM), finish milling, drilling, boring at high speeds(800-1500RPM). And can mill five sides of the work piece if they work together with our boring-milling heads. We also welcome customer-made orders.
The spindle and gears of the right angle milling head (90o milling head, angle head) are made of chrome molybdenum alloy steel and heat treated (carburization). Thus, the milling head is rigid and durable. Its quality is reliable. Such a milling head is suitable for conventional gantry milling machines, CNC gantry milling machines, single arm milling machines, special purpose machines and machining centers. Oh Young right angle milling heads provide customers with many choices depending on machine spindle speeds and the nature of the work. The light cutting type right angle milling heads with angular contact ball bearings are suitable for light cutting at low speeds(0-800RPM), finish milling at high speeds(800-3000RPM). And can mill five sides of the work piece if they work together with our boring-milling heads. We also welcome customer-made orders.
The spindle and gears of the right angle milling head (90o milling head, angle head) are made of chrome molybdenum alloy steel and heat treated (carburization). Thus, the milling head is rigid and durable. Its quality is reliable. Such a milling head is suitable for conventional gantry milling machines, CNC gantry milling machines, single arm milling machines, special purpose machines and machining centers. Oh Young right angle milling heads provide customers with many choices depending on machine spindle speeds and the nature of the work. The moderate cutting type right angle milling heads with angular contact ball bearings are suitable for moderate cutting at low speeds(0-800RPM), finish milling, drilling, boring at high speeds(800-2000RPM). And can mill five sides of the work piece if they work together with our boring-milling heads.
The spindle and gears of the right angle milling head (90 degree milling head, angle head) are made of chrome molybdenum alloy steel and heat treated (carburization). Thus, the milling head is rigid and durable. Its quality is reliable.
Such a milling head is suitable for conventional gantry milling machines, CNC gantry milling machines, single arm milling machines, special purpose machines and machining centers.
The model XR10 with unclamping cylinder, which can change the tool quickly, and the OTT pull stud type clamping units, make the tool clamping force strong and long service life.
Customer can select 2000RPM(moderate cutting type) or 3000RPM(light cutting type) for using depending on the nature of the work and machine spindle speeds.
The spindle and gears of the right angle milling head (90 degree milling head, angle head) are made of chrome molybdenum alloy steel and heat treated (carburization). Thus, the milling head is rigid and durable. Its quality is reliable.
Such a milling head is suitable for conventional gantry milling machines, CNC gantry milling machines, single arm milling machines, special purpose machines and machining centers. Adopting enlarged square main body can bear greater torque. It is also suitable for vertical lathe, large gantry milling machine.
The model XR10 with unclamping cylinder, which can change the tool quickly, and the OTT pull stud type clamping units, make the tool clamping force strong and long service life.
Customer can select 2000RPM(moderate cutting type) or 3000RPM(light cutting type) for using depending on the nature of the work and machine spindle speeds.
Optional accessories coolant through spindle for deep holes drilling.
Customized is available, please contact us.
The spindle and gears of the right angle milling head (90o milling head, angle head) are made of chrome molybdenum alloy steel and heat treated (carburization). Thus, the milling head is rigid and durable. Its quality is reliable.
Such a milling head is suitable for conventional gantry milling machines, CNC gantry milling machines, single arm milling machines, special purpose machines and machining centers.
This milling head is suitable for deep hole machining, and you can select 800RPM (heavy duty cutting type), 2000RPM (moderate cutting type) or 3000RPM (light cutting type) for using depending on the nature of the work and machine spindle speeds.
• GRU Series／Plunge CNC Cylindrical Grinder
• GRA Series／Angular CNC Cylindrical Grinder
• GRW Series／Traveling Head CNC Cylindrical Grinder
• GRC Series／Center Hole CNC Cylindrical Grinder
●HRV- Vise In-Row is a kind of multiple vise. Full set of this vise is made of Tool Steel with heat treatment more than HRC 60º of Hardness and then multiple viseground precisely to ensure durability. It enlarges clamping range. No matter what shape of working piece, such as square, round, cylindrical or any irregular shapes, it can be positioned quickly. Precision gear locating datum plate is adjustable so workpieces can be fixed easily.
●This vise is suitable for horizontal, vertical and 4-Axis CNC Machining Centers and Surface Grinder, ...etc.
1.Vise body is made of Ductile lron above FCD 60 grade for high precision and durability and is made in one solid piece. It has very high rigidity and with a force of 4500kg, the shape will deflect less than 0.01mm
2.Slide ways are HARDENED to HRC 50° to further increase durability and maintain positioning height over long use.
3.Using high-grade iron of over FCD 60 grade for high rigidity and also ANGLE -LOCK SYSTEM which automatically pulls the work-piece down to the accurate position of within 0.01mm under 4500kg of pressure, this vise is most suitable for precision mould making on Machining Centers.
4.Vise can be mounted horizontally or vertically.
5.The patented MULTI-POWER SYSTEM built of HIGH GRADE BEARING STEEL doubles the clamping force.
The pressure is more consistent and eliminates oil leakage and maintenance problems associated with Hydraulic Vices.
With the first half a turn the vise will clamp with 2500kg pressure.
With a second half turn it will apply 4500kg of clamping force.
This special patented system makes the clamping force constant.
6.Adjusting stop ring: this simple and effective presetting device enables to preset each desired clamping force and it guarantees to repeat each clamping operation at the same clamping force
1.Vise body is made of Ductile lron above FCD 60 grade for high precision and durability and is made in one solid piece.
2.Slide ways are HARDENED to HRC 50° to further increase durability and maintain positioning height over long use.
3.Using high-grade iron of over FCD 60 grade for high rigidity and also ANGLE -LOCK SYSTEM which automatically pulls the work-piece down to the accurate position of within 0.01mm, this vise is most suitable for precision mould making on Machining Centers.
4.Vise can be mounted horizontally or vertically.
1. A special SPRING DEVICE allows an extra tolerance of up to 5mm in workpiece sizes, which enables automatically quick positioning and clamping.
2. The vise can hold 2 workpieces of different sizes with max. difference of 25mm.
3. The Special ANGLE-LOCK SYSTEM with compact design and high-grade iron of over FCD 60 grade for high rigidity automatically pulls the workpiece down to its accurate position.
4. Fixed Height, so several vises can be used together.
5. Double Leadscrew Covers protect Leadscrew from swarf.
6. The patented MULTI-POWER SYSTEM built of HIGH GRADE BEARING STEEL doubles the clamping force.
The pressure is more consistent and eliminates all leakage and maintenance problems associated with Hydraulic Vices.
With the first half a turn the vise will clamp with 2500kg pressure.
With a second half turn it will apply 4500kg of clamping force.
This special patented system makes the clamping force constant.
●Increases the workholding capacity of CNC ●Machining Centers by holding 2 pieces in each vise.
●This vise is compact which allowing several vices to be fitted to the worktable at one set up.
●The special SPRING DEVICE allows an extra tolerance of up to 5mm in two workpiece sizes and enables quick positioning and clamping.
If the tolerance of two workpieces is more than 5mm, please adjust this screw.
●Heat treated (Normalized)
●Application: Good for horizontal M/C
●Heat treated (Normalized)
●Application: Good for horizontal M/C
●It's ergonomics for easy reach, thus saves time and prevents back strain
●Mechanical vise
●Shortest Length with Big Jaw Opening
●High Accuracy and Repeatability
●Special MULTI-POWER design enhances clamping force of 0~6000KG
●Suitable for Gantry-Type machining centers
●It possesses all features of HPAQ-Type
● It's ergonomics for easy reach, thus saves time and prevents back strain
● Mechanical vise
● Shortest Length with Big Jaw Opening
● High Accuracy and Repeatability
● Special MULTI-POWER design enhances
● clamping force of 0~5000KG
● Suitable for Gantry-Type machining centers
● It possesses all features of HPAQ-Type
● Mechanical Vise
● Special MULTI-POWER design enhances
● clamping force of 0~6000kg
● It’s ergonomics is for easy reach, thus saves time and prevents back strain.
● The HPAC-160F possesses all features of HPAC-Type.
SSD06 spindle unit is designed servo feeding with ball screw grade C5 and servo motor, the accuracy of spindle nose is strictly under 0.003mm and maximum drilling capacity up to 20mm (S45C).
CNC Spindle allows to perform all types of machining applications such as drilling, tapping, chamfering, reaming and countersinking.
Controller： FANUC 0i-T
Swing over bed：850mm
Max. turning diameter： 750mm
Max. turning length：800mm
Guide way type： Linear/Box way
Tool Spindle taper：BT50
X-axis Travel：650mm
Z-axis Travel：800mm
>click here to see more specifications<
Controller FANUC 0i-T
Swing over bed mm 750
Max. turning diameter mm 550
Max. turning length mm 550
Guide way type Linear
X-axis Travel mm 295
Z-axis Travel mm 550
>click here to see more specifications<
Controller：FANUC 0i-T
Swing over bed：1100mm
Max. turning diameter：720/950mm
Max. turning length：700mm
Guide way type：Box way
X-axis Travel：410mm
Z-axis Travel：750mm
>click here to see more specifications<
Controller：FANUC 0i-T
Swing over bed：1100mm
Max. turning diameter：720/950mm
Max. turning length：700mm
Guide way type：Box way
X-axis Travel：410mm
Z-axis Travel：750mm
>click here to see more specifications<
Series 0i-F Plus
Easier to use the World Standard CNC from FANUC Series 30i/31i/32i-B Plus FANUC's high-end CNC with extremely polished machining performance
CNC and SERVO technologies for cycle time reduction
Controller：FANUC 0i-T
Swing over bed：380mm
Swing over saddle：320mm
Max. turning diameter：180mm(UT-100E)；100mm(UT-100EM)
Max. turning length：175mm(UT-100E)；140mm(UT-100EM)
Guide way type：Box way
X-axis Travel：120mm
Z-axis Travel：230mm
>click here to see more specifications<
Controller：FANUC 0i-T
Swing over bed：505mm
Swing over saddle：318mm
Max. turning diameter：300mm (JT-200)；230mm (JT-200M)
Max. turning length：560mm (JT-200)；450mm (JT-200M)
Guide way type：Linear
X-axis Travel：195mm
Z-axis Travel：600mm
>點此看更多詳細規格<
Controller：FANUC 0i-T
Swing over bed：505mm
Swing over saddle：318mm
Max. turning diameter：300mm (UT-200)；260mm (UT-200M)
Max. turning length：550/470(UT-200)；450/370mm(UT-200M)
Guide way type：Box Way
X-axis Travel：220mm
Z-axis Travel：600mm
>click here to see more specifications<
Controller：FANUC 0i-T
Swing over bed：505mm
Swing over saddle：318mm
Max. turning diameter：300mm；260mm
Max. turning length：1000mm/920mm(UT-200L)；900mm/820mm(UT-200LM)
Guide way type：Box Way
X-axis Travel：220mm
Z-axis Travel：1050mm
>click here to see more specifications<
Controller：FANUC 0i-T
Swing over bed：505 mm
Swing over saddle：135 mm
Max. turning diameter：135 mm
Max. turning length：200 mm
Guide way type：Box
Working table：350x190 mm
X-axis Travel：320 mm
Z-axis Travel：600 mm
>click here to see more specifications<
Controller：FANUC 0i-T
Swing over bed：612mm
Swing over saddle：400mm
Max. turning diameter：500mm (UT-300)；420mm (UT-300M)
Max. turning length：680mm/600mm (UT-300)；540mm/460mm (UT-300M)
Guide way type：Box Way
X-axis Travel：300mm
Z-axis Travel：750mm
>click here to see more specifications<
Controller：FANUC 0i-T
Swing over bed：612mm
Swing over saddle：400mm
Max. turning diameter：500mm(UT-300L)；420mm(UT-300LM)
Max. turning length：1180mm/1100mm(UT-300L)；1040mm/960mm(UT-300LM)
Guide way type：Box Way
X-axis Travel：300mm
Z-axis Travel：1250mm
>click here to see more specifications<
Controller：FANUC 0i-T
Swing over bed：910mm
Swing over saddle：720mm
Max. turning diameter：420mm
Max. turning length：540mm / 470mm
Guide way type：Box Way
X-axis Travel：275mm
Z-axis Travel：750mm
Y-axis Travel：±50mm
>click here to see more specifications<
Controller：FANUC 0i-T
Swing over bed：910mm
Swing over saddle：720mm
Max. turning diameter：420mm
Max. turning length：1540mm/1470mm
Guide way type：Box Way
X-axis Travel：275mm
Z-axis Travel：1750mm
Y-axis Travel：±50mm
>click here to see more specifications<
Controller：FANUC 0i-T
Swing over bed：612mm
Swing over saddle：400mm
Max. turning diameter：500mm
Max. turning length：1680mm / 1600mm
Guide way type：Box Way
X-axis Travel：300mm
Z-axis Travel：1750mm
>click here to see more specifications<
Controller：FANUC 0i-T
Swing over bed：612mm
Swing over saddle：400mm
Max. turning diameter：500mm
Max. turning length：2180mm / 2100mm
Guide way type：Box Way
X-axis Travel：300mm
Z-axis Travel：2250mm
>click here to see more specifications<
Controller：FANUC 0i-T
Swing over bed：910mm
Swing over saddle：720mm
Max. turning diameter：470mm
Max. turning length：2040mm / 1970mm
Guide way type：Box Way
X-axis Travel：275mm
Z-axis Travel：2150mm
Y-axis Travel：±50mm
>click here to see more specifications<
Controller：FANUC 0i-T
Swing over bed：612mm
Swing over saddle：400mm
Max. turning diameter：500mm
Max. turning length：3100mm / 3030mm
Guide way type：Box Way
X-axis Travel：300mm
Z-axis Travel：3182mm
>click here to see more specifications<
Controller：FANUC 0i-T
Swing over bed：750mm
Swing over saddle：600mm
Max. turning diameter：540mm
Max. turning length：630mm / 550mm
Guide way type：軌道
X-axis Travel：305mm
Z-axis Travel：750mm
>click here to see more specifications<
Controller：FANUC 0i-T
Swing over bed：750mm
Swing over saddle：600mm
Max. turning diameter：540mm
Max. turning length：1130mm / 1050mm；1040mm / 960mm
Guide way type：Box Way
X-axis Travel：305mm305mm
Z-axis Travel：1250mm1250mm
>click here to see more specifications<
Controller：FANUC 0i-T
Swing over bed：750mm
Swing over saddle：600mm
Max. turning diameter：540mm
Max. turning length：1630mm/1550mm
Guide way type：Box Way
X-axis Travel：305mm
Z-axis Travel：1750mm
>click here to see more specifications<
Controller：FANUC 0i-T
Swing over bed：750mm
Swing over saddle：600mm
Max. turning diameter：540mm
Max. turning length：2130mm / 2050mm
Guide way type：Box Way
X-axis Travel：305mm
Z-axis Travel：2250mm
>click here to see more specifications<
Controller：FANUC 0i-T
Swing over bed：750mm
Swing over saddle：600mm
Max. turning diameter：540mm
Max. turning length：3062mm / 2982mm
Guide way type：Box Way
X-axis Travel：305mm
Z-axis Travel：3182mm
>click here to see more specifications<
Controller：FANUC 0i-T
Swing over bed：850mm
Swing over saddle：700mm
Max. turning diameter：680mm
Max. turning length：630mm / 550mm / 490mm
Guide way type：Box Way
X-axis Travel：370mm
Z-axis Travel：750mm
>click here to see more specifications<
Controller：FANUC 0i-T
Swing over bed：850mm
Swing over saddle：700mm
Max. turning diameter：680mm
Max. turning length：1130mm/1050mm/990mm
Guide way type：Box Way
X-axis Travel：370mm
Z-axis Travel：1250mm
>click here to see more specifications<
Controller：FANUC 0i-T
Swing over bed：850mm
Swing over saddle：700mm
Max. turning diameter：680mm
Max. turning length：1630mm/1550mm/1490mm
Guide way type：硬軌
X-axis Travel：370mm
Z-axis Travel：1750mm
>click here to see more specifications<
Controller：FANUC 0i-T
Swing over bed：850mm
Swing over saddle：700mm
Max. turning diameter：680mm
Max. turning length：2130mm/2050mm/1990mm
Guide way type：Box Way
X-axis Travel：370mm
Z-axis Travel：2250mm
>click here to see more specifications<
Controller：FANUC 0i-T
Swing over bed：850mm
Swing over saddle：700mm
Max. turning diameter：680mm
Max. turning length：3062mm/2982mm/2922mm
Guide way type：Box Way
X-axis Travel：370mm
Z-axis Travel：3182mm
>click here to see more specifications<
Controller：FANUC 0i-T
Swing over bed：900mm
Swing over saddle：745mm
Max. turning diameter：700mm
Max. turning length：1380mm
Guide way type：Box Way
X-axis Travel：380mm
Z-axis Travel：1500mm
>click here to see more specifications<
Controller：FANUC 0i-T
Swing over bed：900mm
Swing over saddle：745mm
Max. turning diameter：700mm
Max. turning length：2080mm
Guide way type：Box Way
X-axis Travel：380mm
Z-axis Travel：2200mm
>click here to see more specifications<
Controller：FANUC 0i-T
Swing over bed：900mm
Swing over saddle：745mm
Max. turning diameter：700mm
Max. turning length：2980mm
Guide way type：Box Way
X-axis Travel：380mm
Z-axis Travel：3100mm
>click here to see more specifications<
Controller：FANUC 0i-T
Swing over bed：900mm
Swing over saddle：745mm
Max. turning diameter：700mm
Max. turning length：3980mm
Guide way type：Box Way
X-axis Travel：380mm
Z-axis Travel：4100mm
>click here to see more specifications<
Controller：FANUC 0i-T
Swing over bed：1200mm
Swing over saddle：1040mm
Max. turning diameter：700mm
Max. turning length：3900mm
Guide way type：Box Way
X-axis Travel：380mm
Z-axis Travel：4100mm
Y-axis Travel：±75mm
>click here to see more specifications<
Controller：FANUC 0i-T
Swing over bed：1030mm
Swing over saddle：950mm
Max. turning diameter：900mm
Max. turning length：1300mm
Guide way type：Box Way
X-axis Travel：495mm
Z-axis Travel：1500mm
>click here to see more specifications<
Controller：FANUC 0i-T
Swing over bed：1030mm
Swing over saddle：950mm
Max. turning diameter：900mm
Max. turning length：1900mm
Guide way type：Box Way
X-axis Travel：495mm
Z-axis Travel：2100mm
>click here to see more specifications<
Controller：FANUC 0i-T
Swing over bed：1030mm
Swing over saddle：950mm
Max. turning diameter：900mm
Max. turning length：2900mm
Guide way type：Box Way
X-axis Travel：495mm
Z-axis Travel：3100mm
>click here to see more specifications<
Controller：FANUC 0i-T
Swing over bed：1030mm
Swing over saddle：950mm
Max. turning diameter：900mm
Max. turning length：3950mm
Guide way type：Box Way
X-axis Travel：470mm
Z-axis Travel：4100mm
>click here to see more specifications<
Controller：FANUC 0i-T
Swing over bed：450
Swing over saddle：330
Max. turning diameter：110
Max. turning length：170
Guide way type：Box Way
X-axis Travel：80
Z-axis Travel：220
Y-axis Travel：±25
>click here to see more specifications<
Controller：FANUC 0i-T
Swing over bed：380mm
Swing over saddle：320mm
Max. turning diameter：100mm
Max. turning length：130mm
Guide way type：Box Way
X-axis Travel：120mm
Z-axis Travel：230mm
>click here to see more specifications<
Controller：FANUC 0i-T
Swing over bed：380mm
Swing over saddle：320mm
Max. turning diameter：220mm
Max. turning length：155mm
Guide way type：Box Way
X-axis Travel：120mm
Z-axis Travel：230mm
>click here to see more specifications<
Controller：FANUC 0i-T
Max. Turning Diameter(SP1)：50mm
Max. Turning Diameter(SP2)：50mm
Max. Turning Length：60mm
Guide way type：Linear Way
X-axis Travel：210mm
Z-axis Travel：310(±155)mm
Tooling system：Gang Type
>click here to see more specifications<
Controller：FANUC 0i-T
Swing over bed：660mm
Swing over saddle：620mm
Max. Turning Diameter ：320mm
Max. turning length ：790mm
Guide way type：Linear + Box
X-axis Travel：X1/X2 : 210mm
Z-axis Travel：Z1/Z2 : 840mm
>click here to see more specifications<
Controller：FANUC 0i-T
Swing over bed：600mm
Swing over saddle：260mm
Max. Turning Diameter：220mm
Max. turning length (SP1)：240mm
Max. turning length (SP2)：350mm
Guide way type：Box Way
X-axis Travel：X1/X2 : 220mm
Z-axis Travel：Z1/Z2 : 350mm
B-axis Travel：850mm
>click here to see more specifications<
Controller：FANUC 0i-T
Swing over bed：700mm
Swing over saddle：600mm
Max. Turning Diameter：360mm
Max. turning length：290mm
Guide way type：Box Way
X-axis Travel：X1/X2: 190mm
Z-axis Travel：Z1/Z2: 500mm
B-axis Travel：1050mm
>
click here to see more specifications<
Controller：FANUC 0i-T
Swing over bed：660mm
Swing over saddle：620mm
Max. Turning Diameter：320mm
Max. turning length ：790mm
Guide way type：Linear + Box
X-axis Travel：X1/X2 : 210mm
Z-axis Travel：Z1/Z2 : 840mm
B-axis Travel：920mm
>click here to see more specifications<
Controller：FANUC 0i-T
Swing over bed：660mm
Swing over saddle：620mm
Max. Turning Diameter：320mm
Max. turning length：790mm
Guide way type：Linear + Box
X-axis Travel：X1/X2 : 210mm
Z-axis Travel：Z1/Z2 : 840mm
Y-axis Travel：-40/+60mm
B-axis Travel：920mm
>click here to see more specifications<
Controller：FANUC 0i-T
Swing over bed：460mm
Swing over saddle：400mm
Max. Turning Diameter：200mm
Max. turning length：500mm
Guide way type：Linear + Box
X-axis Travel：X1/X2:160.5mm
Z-axis Travel：Z1/Z2:565mm
Y-axis Travel：Y1: ±50mm/Y2:±35mm
B-axis Travel：650mm
>click here to see more specifications<
Controller：FANUC 0i-T
Swing over bed：910mm
Swing over saddle：720mm
Max. turning diameter(SP1)：420mm
Max. turning diameter(SP2)：375mm
Max. turning length：1040mm / 970mm
Guide way type：Box Way
X-axis Travel：275mm
Z-axis Travel：1250mm
Y-axis Travel：±50mm
B-axis Travel：1200mm
>click here to see more specifications<
This modular assembly gives you CNC adjustable feeding rate and fast reversing control for heavy duty machining. Roller type linear blocks are implemented and enhanced the assembly rigidity for your machining applications.
Controller：FANUC 0i-T
Swing over bed：612mm(UT-300LS)/700mm(UT-300LSM)
Swing over saddle：400mm(UT-300LS)/500mm(UT-300LSM)
Max. turning diameter(SP1)：500mm(UT-300LS)/480mm(UT-300LSM)
Max. turning diameter(SP2)：400mm(UT-300LS)/375mm(UT-300LSM)
Max. turning length：1110mm/1040mm(UT-300LS)；1040mm/970mm(UT-300LSM)
Guide way type：Box Way
X-axis Travel：300mm(UT-300LS)/275mm(UT-300LSM)
Z-axis Travel：1250mm(UT-300LS)/1250mm(UT-300LSM)
B-axis Travel：1200mm
>click here to see more specifications<
Controller：FANUC 0i-T
Swing over bed：910mm
Swing over saddle：720mm
Max. turning diameter(SP1)：420mm
Max. turning diameter(SP2)：375mm
Max. turning length：540mm/470mm
Guide way type：Box Way
X-axis Travel：275mm
Z-axis Travel：750mm
B-axis Travel：700mm
>click here to see more specifications<
Controller：FANUC 0i-T
Swing over bed：612mm(UT-300S)；700mm(UT-300SM)
Swing over saddle：400mm(UT-300S)；500mm(UT-300SM)
Max. turning diameter(SP1)：500mm(UT-300S)；480mm(UT-300SM)
Max. turning diameter(SP2)：400mm(UT-300S)；375mm(UT-300SM)
Max. turning length：610mm/540mm(UT-300S)；540mm(UT-300SM)/470mm(UT-300SM)
Guide way type：Box Way
X-axis Travel：300mm(UT-300S)/280mm(UT-300SM)
Z-axis Travel：750mm(UT-300S)
B-axis Travel：700mm(UT-300S)
>click here to see more specifications<
Controller：FANUC 0i-T
Swing over bed：680mm
Swing over saddle：485mm
Max. turning diameter(SP1)：240mm
Max. turning diameter(SP2)：200mm
Max. turning length：440mm360mm
Guide way type：Box Way
X-axis Travel：220mm
Z-axis Travel：600mm
Y-axis Travel：±50mm
B-axis Travel：585mm
>click here to see more specifications<
Controller：FANUC 0i-T
Swing over bed：505mm(UT-200S)；570mm(UT-200SM)
Swing over saddle：318mm(UT-200S)；378mm(UT-200SM)
Max. turning diameter(SP1)：250mm
Max. turning diameter(SP2)：220mm
Max. turning length：mm480mm/400mm(UT-200S)；440mm/370mm(UT-200SM)
Guide way type：Box Way
X-axis Travel：220mm(UT-200S)；220mm(UT-200SM)
Z-axis Travel：600mm(UT-200S)；600mm(UT-200SM)
B-axis Travel：585mm(UT-200S)；585mm(UT-200SM)
>click here to see more specifications<
Controller：FANUC 0i-M
Spindle speed：10000(12000)rpm
Spindle nose taper：BT40
Bearing inner diameter：70mm
Drive system：Belt (Direct)
X-axis travel：600mm
Y-axis travel：520mm
Z-axis travel：540mm
Spindle nose to table：150~690mm
>click here to see more specifications<
Controller：FANUC 0i-M
Spindle speed：10000 (12000)rpm
Spindle nose taper：BT40
Bearing inner diameter：70mm
Drive system：Belt (Direct)
X-axis travel：750mm
Y-axis travel：520mm
Z-axis travel：540mm
Spindle nose to table：150~690mm
>click here to see more specifications<
Controller：FANUC 0i-M
Spindle speed：10000 (12000)rpm
Spindle nose taper：BT40
Bearing inner diameter：70mm
Drive system：Belt (Direct)
X-axis travel：850mm
Y-axis travel：550mm
Z-axis travel：550mm
Spindle nose to table：150~700mm
>click here to see more specifications<
Controller：FANUC 0i-M
Spindle speed：12000(15000)rpm
Spindle nose taper：BT40
Bearing inner diameter：70mm
Drive system：Direct
X-axis travel：850mm
Y-axis travel：550mm
Z-axis travel：550mm
Spindle nose to table：150~700mm
>click here to see more specifications<
Controller：FANUC 0i-M
Spindle speed：12000(15000)rpm
Spindle nose taper：BT40
Bearing inner diameter：70mm
Drive system：Direct
X-axis travel：1100mm
Y-axis travel：550mm
Z-axis travel：550mm
Spindle nose to table：150~700mm
>click here to see more specifications<
ontroller：FANUC 0i-M
Spindle speed：10000(12000)rpm
Spindle nose taper：BT40
Bearing inner diameter：70mm
Drive system：Belt (Direct)
X-axis travel：1200mm
Y-axis travel：650mm
Z-axis travel：600mm
Spindle nose to table：125~725mm
>click here to see more specifications<
Controller：FANUC 0i-M
Spindle speed：10000(12000)rpm
Spindle nose taper：BT40
Bearing inner diameter：70mm
Drive system：Belt(Direct)
X-axis travel：1200mm
Y-axis travel：650mm
Z-axis travel：600mm
Spindle nose to table：150~750mm
>click here to see more specifications<
Controller：FANUC 0i-M
Spindle speed：10000(12000)rpm
Spindle nose taper：BT40
Bearing inner diameter：70mm
Drive system：Belt (Direct)
X-axis travel：1300mm
Y-axis travel：650mm
Z-axis travel：550mm
Spindle nose to table：150~700mm
>click here to see more specifications<
Controller：FANUC 0i-M
Spindle speed：10000(12000)rpm
Spindle nose taper：BT40
Bearing inner diameter：70mm
Drive system：Belt (Direct)
X-axis travel：1500mm
Y-axis travel：750mm
Z-axis travel：550mm
Spindle nose to table：150~700mm
>click here to see more specifications<
Controller：FANUC 0i-M
Spindle speed：10000(12000)rpm
Spindle nose taper：BT40
Bearing inner diameter：70mm
Drive system：Belt (Direct)
X-axis travel：1600mm
Y-axis travel：850mm
Z-axis travel：850mm
Spindle nose to table：150~1000mm
>click here to see more specifications<
Controller：FANUC 0i-M
Spindle speed：6000rpm
Spindle nose taper：BT50
Bearing inner diameter：90mm
Drive system：Belt
X-axis travel：1100mm
Y-axis travel：550mm
Z-axis travel：550mm
Spindle nose to table：155~705mm
>click here to see more specifications<
Controller：FANUC 0i-M
Spindle speed：6000rpm
Spindle nose taper：BT50
Bearing inner diameter：90mm
Drive system：Belt
X-axis travel：1200mm
Y-axis travel：650mm
Z-axis travel：600mm
Spindle nose to table：150~750mm
>click here to see more specifications<
● Heat treated (Normalized)
● Application: Good for horizontal M/C
It is a kind of double angled tombstone for mounting clamping devices from two sides.
Free to finish an actual required hole pattern or your special jig.
Suitable for all horizontal machining centers to improve manufacturing efficiency.
● Heat treated (Normalized)
● Application: Good for horizontal M/C
● It is a kind of double angled tombstone for mounting clamping devices from two sides.
● Suitble for all horizontal machining centers to improve manufacturing efficiency.
Locked by MTP locating holes.
Using the assorted, rationalized jig component, you can quickly build up to meet requirement jig.
Controller：FANUC 0i-M
Spindle speed：6000rpm
Spindle nose taper：BT50
Bearing inner diameter：90mm
Drive system：Belt
X-axis travel：1300mm
Y-axis travel：650mm
Z-axis travel：550mm
Spindle nose to table：155~705mm
>click here to see more specifications<
Controller：FANUC 0i-M
Spindle speed：6000rpm
Spindle nose taper：BT50
Bearing inner diameter：90mm
Drive system：Belt
X-axis travel：1500mm
Y-axis travel：750mm
Z-axis travel：550mm
Spindle nose to table：150~700mm
>click here to see more specifications<
Controller：FANUC 0i-M
Spindle speed：6000rpm
Spindle nose taper：BT50
Bearing inner diameter：90mm
Drive system：2-step gearbox
X-axis travel：1600mm
Y-axis travel：850mm
Z-axis travel：850mm
Spindle nose to table：150~1000mm
>click here to see more specifications<
Controller：FANUC 0i-M
Spindle speed：6000rpm
Spindle nose taper：BT50
Bearing inner diameter：90mm
Drive system：2-step gearbox
X-axis travel：2100mm
Y-axis travel：850mm
Z-axis travel：850mm
Spindle nose to table：150~1000mm
>click here to see more specifications<
● 熱處理(標準化)
● 適用於各種臥式電腦加工機台
● 材質:高精密FCD 50石墨鑄鐵 / 鋁合金A356
(可依不同加工需求，自行客製化其表面設計)
● Heat treated (Normalized)
● Application: Good for horizontal M/C
● It is a kind of double angled tombstone for mounting clamping devices from two sides.
● Suitable for all horizontal machining centers to improve manufacturing efficiency.
● Locked by T-slot.
● Using the assorted, rationalized jig component, you can quickly build up to meet requirement jig.
● Significantly upgrade CNC 5-Axis Machines
● Special 45° dovetail structure with teeth
● The patented calibration system can regulate clamping center easily and rapidly
1.Vise body is made of High quality Steel (S50C) and its slideways gone through high-frequency hardening to achieve HRC50, which makes the whole part durable.
2.Detachable jaws are made of High quality Tool Steel (SCM440) and gone through carburizing to achieve HRC55. Since both sides are fixed size and able to be used as a datum, users can reverse them to increase clamping range.
3.The vise's clamping force can achieve 1300KG, the repeatability positioning precision of its clamping center is within 0.015mm.
4.Users can calibrate the clamping center of vise by adjusting the screws on both ends.
5.The 45° dovetail structure with teeth on the upper jaw ensures the bottom of the workpiece to be firmly clamped.
● Designed with special device to hold 2 workpieces in different sizes (max. tolerance of 1.5mm) at the same time
● The combinations of jaws enable different clamping tasks, center fixed jaw can be removed for clamping larger work piece
● Modular vise with fixed height, can be used vertically or horizontally
● Especially suitable for small CNC machining centers, several vises can be used on a machine table
● Specially designed for 5-axis & CNC machining centers
● Both sides of Vice Jaws are available for multiple clamping
● Modular vice with fixed height, can be used vertically or horizontally
● Super-Big Jaw Opening
● Special ANGLE-LOCK SYSTEM ensures to pull the work-piece down to the accurate position
● Fixed Height, so several vises can be used together
● Suitable for any kind of CNC manufacturing and general milling machines
● Big Jaw Opening of 150mm.
● Vise Jaws are made of high quality Tool Steel with heat treatment to HRC 56º, and ground precisely to ensure the durability and high accuracy.
● Fixed Height, suitable for high speed CNC machining centers, tapping centers ... etc.
JHC-20S-CNC8 centerless machine equipped with auto loading / unloading device. Aesthetics Splash Guard and high strength one-piece fabricated base . Semi-hydraulic float spindle is protected by an oil membrane which results in minimal contact friction. Regulating wheel drive by servo motor variable speed from 10～250RPM. Automatic wheel dressing. Automatic compensation function and no need to do the extra editing on the program. The range of grinding diameter is from 1~ 100mm. Machine equipped with “Dual System”, it’s convenient for technician to control the movement of axes and loading/unloading devices only by one controller.
The second tool system is equipped with 14 tools included 3 cross live tool, 3 face live tool, 3 O.D. tool, 5 I.D. tools. To machine complex application and better accuracy, Y axis is assembled linear guideway.
Whole machine is used with boxway to enhance smooth and fast precision movement and ensure dynamic rigidity and heavy-duty cutting ability.
Capabilities: This multi-tasking turning center is an advanced machine designed for precision complex parts processed in one setup.Power & Versatility: It has Double Spindles and Turrets with back machining provided by an 8-station sub-turret and sub-spindle with a total tool capacity of up to 32 tools. This solution is a powerful combination of power, precision and versatility.Front Machining: BMT45 12-Stations, Up to 24 tools, 7.5/11 kW Spindle Power, 55 mm Through Hole.Back Machining: VDI 25 8-Stations Sub-Turret, 3.7/5.5 kW Spindle Power, 48 mm Through Hole.
Capabilities: This heavy duty multi-tasking turning center is an advanced and economical solution designed to process precision complex parts with fast cycle times.
Power & Versatility: It has Double Spindles, a BMT 12 station turret and 4 gang tools for economical machining. Coupled with superimposed cutting it’s a powerful solution for precision complex workpieces with extremely fast cycle times.
Front Machining: BMT 45, 12 Stations, Up to 24 Tools, 7.5/11 kW Spindle Power, 55 mm Through Hole
Back Machining: GT42: 4 x 20 mm ID Tools, GT52: 4 x 16 mm ID Tools, Or 3x 20 mm ID Tools, Or 3x 25 mm ID Tools
SIGMA CNC – 2016 New Development
Automatic Swing Divided Angle Head - A、C-axis Auto Indexing Divided 5ﾟ(1ﾟ)
SDV-H series, Direct-Drive Spindle max. 10000rpm collocate with 2-steps Planetary Gearbox, Spindle Motor 35/30HP, Torque Max. 907 / 770Nm, Heavy Cutting & High Spindle Speed in one machine. Besides, it could choose Auto Attachment Heads Change System, Extension Head, 90ﾟAngular Head, 35ﾟ&45ﾟHead, Swing Divided Angle Head are self-made by SIGMA CNC.
In the beginning of 2016, SIGMA CNC developed a new Automatic Swing Divided Angle Head, BT-50, max. 3000rpm, C-axis ±270ﾟ auto indexing minimum 5ﾟ(1ﾟ) by gear coupling, A-axis ±90ﾟauto indexing minimum 5ﾟ(1ﾟ) by gear coupling, Material Remove Rate max. 640cc/min. It is very useful for the molds processing in the Automotive field & Aerospace field etc.
SIGMA CNC has been established over 15 years, and innovated over 15 mechanism patents of machine tools and use them into our products. To enhance greater differences with our competitors. SIGMA CNC always cares about the Quality, Accuracy, Service, Reliability & New Innovation for our products that could give customers more functional applications and helping customers to obtain greater profits.
VU-620 offers high speed, high accuracy and more reliable quality. Twin door design with wide open space is easy for loading workpiece. Movable column C-shape provides superior rigidity. Rotary table with one-piece iron casting provides excellent ductility an dgreater anti-vibration.
Axis motors are direct coupled with ball screws, featuring highly efficient motion control, high response and low noise. And the box way series mach9ining centers are all Finite Element Analysis (FEA) designed. The machine structure is optimized for maximum mechanical rigidity but with minimum cast iron material used.
8 axes. Equipped with sub-spindle for front and back machining. The maximum processing diameter is 20mm.
X/Y/Z travel : 800(Opt.1000)/400/400mm
Spindle taper : NT40
Spindle motor : 5HP (Opt.7.5HP)
Controller system
You Ji VTL series is designed for high-efficiency heavy-duty cutting, column adopts a symmetrical design to increase 50% more rigidity.
Wide span X-axis box guideway design brings high stability during the long cutting time, suitable for the aerospace industry, wind power industry,
the shipbuilding industry, energy industry, pumps & valves, motor industry...etc.,VTL series can also be used for machining engine case, bearings, engines, mechanical parts, ring parts, motor housing, and various heavy equipment.
The YOU JI independently develops HMI (human-machine interface), which is developed according to customer needs and can achieve virtual and real integration and visualized management.
With Marposs intelligent monitoring system, it can achieve tool monitoring, processing process monitoring, processing optimization (vibration and load detection), machine maintenance prediction, machine protection (collision protection), and other intelligent machinery elements that comply with Industry 4.0.
With twin spindle and twin turret structure, finite element analysis is used on a 45-degree slant bed design to support the rigid base for spindle and turret.
Leadwell itself power turret not only magnifies all appropriate configurations to satisfy all machining requirements but also ensures machine quality and
utuilization with intelligent function.
This multi-tasking turning machine equipped with FANUC controller is composed of the main spindle, BMT-45 power turret, and Y-axis with an overall width of only 1815mm. And, with narrow width, small floor space, and rear chip disposal design, this machine still has a large turning diameter of 300mm and can accomplish the production line layout requirement for full line production. Furthermore, 12 tools turret can specify the automatic processing required for a variety of workpieces. And with an optional auto-loading gantry robot, it can fulfill diverse and large quantity automatic processing requirements.
LEADSKY-SMES delivery and set up the machining program, issued start command. The machine follow command, start the processing automatically, and reply the number of workpiece has been completed. If the production list finishes, it will reply the message and finish the production. If the next production list ready, LEADSKY-SMES will delivery and set up another machining program, also issue the production command again.
The 5 axes simultaneous processing, can reduce the times of workpiece unloading and the requirement of the jigs, shorten the processing time and improve performance. C-axis table using the DD motor provides (Turning Speed 800rpm/min) high torque and rigidity, and solve the traditional worm gear backlash and worn problems. High torque and efficiency of the spindle with a complete high-rigidity structure applied results in roughing to finishing can be completed on the same machine, suitable for machining hard materials and non-ferrous materials processing.
This is designed to meet high accuracy, high speed and high efficiency machining requirements. 2. This machine allows the operator to set up workpieces while the machine is performing cutting, to increase efficiency.
1) There are 6 linear blocks for Z axis. 2) MVL-HS series uses Mitsubishi controller M830 (15” colors LCD). 3) MVL-HS series adopts BBT40 dual contact tool holder system. The bearings of spindle adopt oil-mist type lubrication system. The cooling system of spindle by microcomputer temperature control system. 4) Chassis flush sheet metal made of SUS. 5) Cutting coolant system
1) 3 axes adopt high precision linear guideway, suitable for the needs of high-speed precision machining. 2) Spindle with ring sprinkler design, to improve cooling needed during cutting. 3)Option: MLC series (X/Y-Linear ways； Z-Box way)
1)Table surface and c-axis center at the same level, to improve the accuracy of machining datum point (program reference point).
2)Table can be reserved 2 holes (OPT) with 6-8 bars to install jigs.
3)4/5 axis rotary table adopts two section worm shaft and worm wheel.
4)To connect the base of 4/5 axis with X axis linear way and ballscrew can makes the interference of Z axis travel decrease effectively to maintain high rigidity of machine.
1. The moving column and fast feeding design
2. Rapid table exchange (Change time: 7 sec)
1.MAX series is suitable for use in aerospace industry, electronics industry, automotive industry, medical industry and mold industry. This MAX series can help user to reduce preprocessed time for fixing working-pieces.
2.The design of B/C structure with twin arms is for support and stability. Then when you do machining in C axis, the accuracy is precision.
The 3 axes box ways is focusing for heavy cutting. The machining position with special design is in the center of machining center to increase the stability of dynamic machining.
DMH series is with the high-speed and high-precision mechanical design concept. It is installed three axes ball linear ways and built-in spindle. It also has high-rigidity frame structure for high stability during machining process. It is designed for mold making.
■ PJ-saving system (Patented high-performance & less consumables filtration system.)
■ Innovative intelligent HMI touch panel:
→ Provides instant message and alarm historic records.
→ Setting multi pressure by touch panel.
→ Auto maintenance reminder.
■ Outlet pressure detect, to avoid waterless.
■ Energy saving more than 40%.
■ Compact size, to save space.
The NT-208SM is Campro’s highly flexible and profitable twin spindle CNC lathe which is an intelligent CNC multi-tasking machine, has high rigidity structure design by CAE analysis with quality engineering that has been considered the geometry and the physical properties of the design to increase reliability and material removal rate (MRR) effectively. The boxway type one-piece 30∘slant bed offers perfect stiffness and lower vibration to deliver much heavier cutting with a smaller footprint. Through synchronized control of 8” Main spindle / 6” Sub-spindle to complete the greatest amount of primary and secondary turning possible in one compact platform. The NT-208SM not only equip twin spindle but also adopt living turret and C-axis control which enables machine to perform milling functions, the hardened precision box guideways and optimal structure provide excellent performance for heavy-duty cutting. CAMPRO IIoT Smart Manufacturing Technology offers extremely good digital tools. Meanwhile Campro NT-208SM can adopt auto production system, bar feeder, or parts catcher to fulfilling the needs of 4.0 in the shop floor.
【HK series】
Feature：
◎Prevent deterioration of liquid.
◎Open coil type heat exchanger can prevent the obstruction problem of liquid circulating system.
◎Advance the speed of process.
◎Maintain the stability of dielectric fluid, advance the process quality.
◎Avoid fire risk cause by temperature rise and accumulating of dielectric fluid, advance the working safety.
◎Reduce the wastage of electrode.
◎Prevent the spreading of foul odor air, reduce the air pollution.
◎Easy operation and low noise.
◎Made of anticorrosive material.
Applications：
Spindle, Linear Motor, Ball Screw, Grinding Liquid, CNC Cutting System, CNC Lathe, Other Machining Center
----------------------------------------------------
【HJ series】
Feature：
◎Prevent deterioration of liquid.
◎Open coil type heat exchanger can prevent the obstruction problem of liquid circulating system.
◎Advance the speed of process.
◎Maintain the stability of dielectric fluid, advance the process quality.
◎Avoid fire risk cause by temperature rise and accumulating of dielectric fluid, advance the working safety.
◎Reduce the wastage of electrode.
◎Prevent the spreading of foul odor air, reduce the air pollution.
◎Easy operation and low noise.
◎Made of anticorrosive material.
Applications：
Grinding Liquid、CNC Cutting System、CNC Lathe、Other Machining Center
Applications：
◎CNC Machining Center、CNC Grinding machine、Broaching machine、CNC Wood-working Machine、CNC Mechanical Press、CNC Lathe、High Speed Lathe
◎Hydraulic Unit
◎High Speed Spindle
Feature：
◎Prevent temperature increasing of spindle, improve working precision of machine.
◎Prevent deviation of spindle center line or heat deformation of machine.
◎Extend the lifetime of the machine.
◎Stabilize oil pressure, prevent oil vibration.
◎Easy operation, low noise.
Feature：
◎Precisely control temperature of industrial machines, improve production efficiency and reduce cost.
◎Use stainless steel for water circuit.
◎Multi-safety devices are equipped to secure the safety of operator and machine.
◎No need for cooling water tower【HWV, HWK, HWH】. No heat exhaust【HEW, RW】.
Applications：
Spindle、Linear Motor、Hydraulic Unit、CNC Cutting System、Laser Machine、Other Machining Center、 CNC Wire Cutter、PCB Drilling Machine、Injection Machine、Semi Con Industrial Machine、Medical Equipment、Printing Equipment【HWV、HWK、HWH】
Vertical With Tank【HEW，RW】
Air cooler【HA series (Wall mounting type)】
Feature：
◎Two separated air circulation to prevent damage from intrusion of ambient air with scrap, dust, moisture or any corrosive elements.
◎Saving the cost due to controller down time.
◎Installed with compressor, functioned dehumidify and temperature control.
◎Extend the lifetime of the control cabinet.
Applications：
Air cooler, CNC Cutting System, Laser Machine, CNC Lathe, Other Machining Center, CNC Wire Cutter, PCB Drilling Machine, Injection Machine, Electronic or Electric Cabinets, Tele-communication Equipment, CNC Control Equipment
------------------------------------------------------------------
Heat Pipe Heat Exchanger【HPW / HPC series】
Feature：
◎Using heat pipe with high heat conductivity to ensure excellent heat exchange.
◎Enclosed design to assure isolation of internal and ambient air.
◎Compact design with light weight for easy transportation and installation.
◎Dew proof from over-cooling.
◎Easy to maintain and inspect.
Applications：
Heat Exchanger, CNC Cutting System, Laser Machine, CNC Lathe, Other Machining Center, CNC Wire Cutter, PCB Drilling Machine, Injection Machine, Electronic or Electric Cabinets, Tele-communication Equipment, CNC Control Equipment
C / Y-axis with living turret & Sub-spindle
CPL-3010SY is optimized with sub-spindle which allows automatic part transfer of workpiece from main spindle to sub-spindle, it could save manpower and reduce cycle time. The front and back-end turning applications may be completed in one single machine.
Inheriting the outstanding machine rigidity from TB series, the TD series is the brand new multi-tasking turning center with single power turret which standard equipped with 12 tool stations and linear Y axis to process milling function. In addition, for customer’s needs, the 16 tool stations turret and sub-spindle is also available for more complex machining process, it helps to reduce labor costs and increase floor utility.
- VTX-II high torque type not only provides the machining torque equal to a medium-sized machining center, but also keeps its originally outstanding rapid traverse performance.
- VTX-II high efficiency type has outstanding spindle acceleration/deceleration performance, which provides fast spindle orientation to the tool changing point and dramatically saves cycle time.
1. Center shaft is made of alloy steel and hardened through vacuum heat treatment to provide higher rigidity HRC60°±1°
2. Center is fitted with dual ball bearing, thrust bearing and needle roller bearing assembly, the waterproof is maze type.
3. The tailstock pressure of lathe adjusts to five to eight kilograms. (for reference)
※ Applicable to high speed lathes and CNC lathes with heavy loads.
1. Center shaft is made of alloy steel and hardened through vacuum heat treatment to provide higher rigidity HRC60°±1°
2. Center is fitted with dual ball bearing, thrust bearing and needle roller bearing assembly, the waterproof is maze type.
3. The tailstock pressure of lathe adjusts to five to eight kilograms. (for reference)
※ Applicable to high speed lathes and CNC lathes with heavy loads.
1. The shaft is made of alloy steel and through vacuum heat treatment (HRC60°±1°). It possesses great rigidity and high durability.
2. Front end is fitted with angular contact ball bearing & thrust bearing. Middle & Rear needle bearing and the waterproof is maze type.
3. The tailstock pressure of lathe adjusts to five to eight kilograms. (for reference)
※ NCF-B Type : Long nose live centers are suitable for small workpieces.
1. Front end is fitted with angular contact ball bearing, thrust bearing and needle bearing.
2. Suitable for CNC lathes at high-speed and medium-load. The waterproof is maze type.
3. The tailstock pressure of lathe adjusts to five to eight kilograms. (for reference)
※ NC-B Type : Long nose live centers are suitable for small workpieces.
1. The shaft is made of alloy steel and through vacuum heat treatment (HRC60°±1°). It possesses great rigidity and high durability.
2. Front end is fitted with angular contact ball bearing & thrust bearing. Middle & Rear needle bearing and the waterproof is maze type.
3. The tailstock pressure of lathe adjusts to five to eight kilograms. (for reference)
1. Front end is fitted with angular contact ball bearing, thrust bearing and needle bearing.
2. Suitable for CNC lathes at high-speed and medium-load. The waterproof is maze type.
3. The tailstock pressure of lathe adjusts to five to eight kilograms. (for reference)
1. The shaft uses alloy steel and hardened through vacuum heat treatment to (HRC60°±1°).
2. Uses the combination of taper roller bearing, thrust bearing and needle bearing.
3. Applicable to medium and heavy loads.
4. The tailstock pressure of lathe adjusts to five to eight kilograms. (for reference)
5. Adjustable to reach original loading capacity after using for a long period of time.
※ NCR-B Type : Long nose live centers are suitable for small workpieces.
※ Waterproof design
1. Shaft uses alloy steel and hardened through vacuum heat treatment to( HRC60°～62°).
2. Applicable to heavy duty loads.
3. The tailstock pressure of lathe adjusts to five to twelve kilograms. (for reference)
※ Waterproof design
1. The tip of bull nose center uses Cr-Mo steel and hardened to (HRC60°±1°).
2. Uses a combination of taper roller bearing and ball bearing.
3. Applicable to pipes turning.
4. The tailstock pressure of lathe adjusts to six to ten kilograms. (for reference)
1. Suitable for the asperities of the workpieces. The auto adjustable transmission center with 5T and 6T design on end surface is able to adjust the stress point so that the workpieces will be done easily.
2. The inside structure of the center is comprised of PU. It is nearly free of break-down and is durable and easy to fix.
3. Accuracy : 0.008mm
※ Suitable for LATHE & CNC LATHE
Honor provides comprehensive solutions in many industries, from wind mill, to aerospace, precision bearing, valve, automotive and so on.
VL-160CM is a large, high precision, heavy duty turning center with an extra wide dual vertical column and base composed of meehanite casting. This heavily ribbed structure reduces thermal distortion and vibrations during Heavy cutting.
A patented Solid Lock clamping system provides over 8 tons clamping force reduces tool vibration, increases tool life which is suitable for heavy duty processing in different industry.
In aerospace, VL-100CA is your best choice for processing. To explore more, please visit our booth and website.
Spindle Taper：BT30
Outer Diameter：100 mm
Max. Speed：15,000 rpm
Bearing size：Ø45
Bearing Lubrication：Grease
Clamping pull-force：2 KN
1. Specified Hydro-static bearing offered heaviest loaded on the index table. 2. Powerful and rigid gear driven spindle design provide the Max. torque as 2177Nm.
Compactly constructed with minimal apporach.
Extremely smooth machining motions, and can be equipped with carious tooling system.
Including gang type table, V8 hydraulic turret, Polygon milling turret.
Equip a 6" hollow 3-jaw hydraulic chuck or a collet chuck.
Max. swing: 320mm (CL-10/CL-12)
Max. swing: 420mm (CL-100/CL-120)
Swing over cross slide: 100mm (CL-10/CL-12)
Swing over cross slide: 170mm (CL-100/CL-120)
Standard turning diameter: 150mm (CL-10/CL-12)
Standard turning diameter: 350mm (CL-100/CL-120)
Max. turning length: 100mm (CL-10/CL-12)
Max. turning length: 200mm (CL-100/CL-120)
Spindle speed: 80~4000rpm (CL-10/CL-100)
Spindle speed: 60~3000rpm (CL-12/CL-120)
Bar capacity: 45mm (CL-10/CL-100)
Bar capacity: 65mm (CL-12/CL-120)
*Range of grinding diameter : Ø6～50mm
*Maximum grinding depth：150mm
*Maximum holding length ：200mm
*Roundness ≦ 0.002mm
*Can equip with automatic loading / unloading devices to shorten processing time and saving the labor cost
*Design according to the workpiece characteristics to fit accuracy demand
*Applications：Aerospace and transportation industry / Energy industry / Machine tool precision parts / Gear motor parts / Pumps industry
The You Ji VMT Vertical Turn /Mill Center Series combines 3-axis 5-face machining with vertical turning capabilities. The machines provide 5-sided or 4+1 axis milling and turning of medium size workpieces, producing complete parts in a single set-up. A full C-axis allows for 4-axis simultaneous milling, making the machines ideal for aerospace and energy industry applications.
X/Y/Z travel : 700(Opt.800)/400/420mm
Spindle taper : NT40(Ø110)
Spindle motor : 5HP (Opt.7.5HP)
Controller system
X/Y/Z travel : 1600(Opt.1800.2000)/550/500mm
Spindle taper : BT40 (Opt.BT50)
Spindle motor : 7.5/11kw (Opt.11/15kw)
Spindle driven : Belt (Opt.Direct)
APPLICATION
■ CNC internal and external diameter machine
■ CNC cutting machine
■ CNC lathe, grinding and milling machine
■ Production for auto parts industry
■ CNC vertical & horizontal machine center
FEATURE
■ It is designed for turning and cutting machine. No impurities or metal clog interference.
■ Stainless steel coil tubes are high heat exchange efficiency to ensure no corrosion problem.
■ It is easy to install and space-saving, easy to clean and maintain.
■ Filling high-efficiency environmental refrigerant, without pollution.
APPLICATION
■ Oil hydraulic equipment
■ CNC lathe and high-speed lathe
■ CNC grinding , broaching and pressing machine
■ CNC machine center (5-axis)
■ CNC wood carving and oil hydraulic machine
■ CNC vertical & horizontal machine center
FEATURE
■ Maintained the constant oil temperature in order to prevent process-ing precision-losing.
■ Kept oil viscosity and avoid oil deterioration to stable spindle working.
■ With the temperature control panel to avoid thermal expansion.
■ Built-in failure-detection system that connects to control panel in order to warn users and prevent further damage to machine.
■ Filling high-efficiency environmental refrigerant, without pollution.
APPLICATION
■ CNC grinding, broaching and punching machine
■ CNC machine center (5axis)
■ All kinds of oil hydraulic equipment
■ CNC vertical & horizontal machine center
FEATURE
■Single refrigerant circuit is with multiple oil circuits, and it provides independent flow rate and pressure precisely.
■ Different liquids can be controlled temperature at the same time,and it can be customized.
■ Temperature control of Dual-PCB for each of plural circuits and it can adjust temperature individually.
■ It has temperature compensation and preheated function.
■ Temperature control precision is +0.5~1.5 ㆍC. (It can be customized of other temperature control precision.)
■ Saving about 50% of floor space.
■ Using high-efficiency environmental refrigerant and without pollution.
■ Up-to 95% materials of machine are recyclable and eco-friendly.
APPLICATION■ CNC grinding machine■ CNC double column grinding and milling machine■ CNC machine center (5-axis)■ CNC vertical & horizontal machine center■ Industries and high-precision spindles with high-speed precision requirementFEATURE■ Full series of inverter compressors are smooth start. There is no-start instantaneous high current and saving power more than 33%.■ Unique design of multi-function LCD panel and it's provides -0.10°C temperature control stabilization.■ There are 15 malfunction protection to ensure normal operation of cooler.■ When low heating load is happend,the cooler will operate in low load mode and combined accurate temperature control and energy saving.■ Groove recessed panel design is reducing oil mist infiltration into electrical control unit.■ Using high-efficiency heat exchanger to enhance cooling efficiency.■ Using high-efficiency environmental refrigerant and without pollution.■ Up-to 95% materials of machine are recyclable and eco-friendly.
APPLICATION
■ CNC lathe
■ CNC instrument box
■ CNC wire cutting machine
■ CNC special made machine
■ Electrical control panel for base station
■ CNC double column grinding and milling machine
■ CNC vertical& horizontal machine center
FEATURE
■ Heat exchanger with high efficiency. Closed design could be ensured no exchange of internal and ambient air.
■ Dust, oil and moisture from getting into electric control panel.
■ Heat pipe heat exchanger is an energy saving and highly efficient heat conductor. It is heat conductor. Heat conductivity is 1,600 times as cooper and extremely safe.
■ Easy to install and maintain due to the simple design.
■ Some models are used RoHS lightweight casing design, and overall appearance is more industrial aesthetic style.
Coolant Purification Systems
Floating Oil Skimmer (Tramp Oil Separator) Ultra 360
Based on the principle of not changing the cutting fluid concentration and base oil, the main leakage (oil slick) is effectively removed, anaerobic bacteria formation and acidification of the cutting fluid are prevented.
It improved the water tanks of the die-casting plant and screwing machine, electroplating plant, cleaning machine, milling machine ,CNC lathes, drilling machines, grinders, cutting machines and other machine which be corroded and leaking, and it can also improve the odor problem, the instability of PH, and the cost derived from the Labor、Maintenance.
The Oil skimmer of Green Eco Pro would maintain the original concentration of the cutting fluid and it is differentthe with general Oil skimmer,as steel belt type, disc type, chain type oil skimmer on the priciple to remove the oil. The waste oil collected after separation has a high concentration and can be recycled at a price.
Built-in oil storage barrel, patented STPM module, patented floating skimmer
No consumables, small size, continuous circulation
Pneumatic pump, safe and no leakage concerns
Purify and process waste water-based cutting fluid to improve annoying odor
Consumables for removing waste oil and making oil mist recovery machine for using longer
Extend tool life, reduce tool wear and replacement costs of machine tools
Chip Vacuum Removal System
Chip Vacuum Removal-FC Series
The impact of the chip not being removed and cleaned in time: The chip conveyor will take away the chips when the cutting fluid is processed, but some of the uncarried waste debris will be left at the bottom of the water tank, which will generate anaerobic bacteria 、cause the release of odor 、 the acidification of the cutting fluid and the drop of Ph value make the cutting fluid deteriorate; it also reduces the effective volume of the water tank, resulting in insufficient water supply.
The FC series chip vacuum machine uses the principle of negative pressure vacuum in exchange for a large suction volume, and then achieves continuous filtration to intercept impurities and suspended particles. Whether it is all oily cutting fluid or water-based cutting fluid, it can intercept iron filings, aluminum mud, aluminum filings , Copper powder, aluminum powder, tungsten steel powder, stone mill... etc. And there is no cost of consumables. It can save the time and labor cost of the clean water tank. It is a high CP value chip suction machine.
Widely used in lathes, milling machines, grinders, drilling machines, CNC, boring machines, planers, sawing machines, broaching machines and other machine tools to effectively remove impurities in the water tank.
Continuous processing/non-batch processing/no need to worry about running out of water in the tank
No need to use electric/pneumatic pump/high safety
No downtime/increased capacity
Dehydrate/reduce water content
No consumables/stainless steel filter basket can be cleaned
Save cutting fluid consumption
Increase the effective volume of the water tank
Increase production utilization rate
Oil mist recovery machine for oily cutting fluid and water-based cutting fluid. The GEP series adopts vortex impeller, upright design, high-precision filter material, which effectively solves the problems of atomization and oil fume; the optional filter tube can effectively intercept oil fume and mist up to 1μm.
Due to the special design of the vortex impeller, the atomized cutting fluid is effectively recovered to save the loss of cutting fluid.
The vertical design is designed to draw air first and then filter, so the wind is relatively large, while the horizontal type has three layers of filtration, so that the wind is relatively weak when the motor is exhausted; in terms of the vibration rate, the vertical vibration is relative to the horizontal, the low vibration of the built-in type makes CNC machining more accurate.
Therefore, the vertical design of the GEP series creates large air volume, low vibration, high interception of oil mist return to flow, and professional processing and recycling of CNC lathes, milling machines and other machine tools due to processing time The generated oil fume, oil gas, oil mist and fine suspended particles and other waste oil fume can effectively reach the standard value range of PM2.5.
Imported mechanical aesthetic design, high-performance models on the market
Low vibration, quiet, does not affect processing accuracy
Original two-dimensional turbine blade and CE certification
Smart LED flashing to alert the filter tube saturation, see the alert clearly
A full range of oil mist collector machines, using IE3 ultra-high-performance motors, saving electricity, reducing carbon emissions, and high performance
Tapping Machine, Drilling Machine, Special Purpose Machine
X/Y/Z travel : 700(Opt.800)/400/100mm
Vertical travel (M./A.) : 450mm
Spindle taper : NT40(Ø105)
Spindle motor : 3.7KW-Inverter (Opt.3.7-5.5KW-servo)
Controller system
✔5 memory sets of sparking parameters ( Optional 10 sets )
✔EDP Function : Point sparking ( Surface sparking )
✔Display mode : DSP, Wear , Depth , End, Pn
✔Automatic / Manual work piece surface sensing
✔Automatic / Manual electrode compensation
✔Metric / Inch conversion
✔The sparking drilling is use of digital control mechanism, which can effectively enhance the small size drilling and speed by stability.
✔With HP1 plus high-speed circuit to enhance drilling speed.
✔The sparking drilling is use of digital control mechanism, which can effectively enhance the small size drilling and speed by stability.
✔With HP1+(plus) high-speed circuit to enhance drilling speed.
✔Compact with Friendly Operations
✔High performance Ocean Technology Controller
✔High Efficient linear guide ways
✔Simple and Convenient.
✔All axes use linear ways.
✔Auto Tool Change is optional. (12 tools)
✔Ideal for irregular-shape Drilling for Automotive Parts.
✔Gantry type constrution assures outstanding rigidity and stability.
✔All axes use linear ways.
✔Available to equip with 5th or 6th axis machining irregular-shape workpiece.
✔Employs industrial grade P.C. with DOS or windows(opt.) operation system for powerful control functions and ease operation.
✔Auto electrode change, Auto guide change is optional.
✔COMPACT HARDWARE AND HIGH QUALITY HUMAN-MACHINE INTERFACT
▸Industrial Class Computer(Pentium 266 CPU,32M RAM)
▸12.1"TFT LCD Display Panel
▸Display Power and External Keyboard Inte-rface
▸I/O Operator's Panel
▸4 Axes Closed-loop Motion control Card
▸I/O Control Card
✔AUTOMATIC TOOL CHANGE, AUTO GUIDE CHANGE AND INTELLIGENT TOOL COMPENSATION
▸Auto Tool Change control.
▸Auto guide change.
▸Auto compensation of replacement new electrodes while machining electrode is run out.
▸Once the machining depth is reached, the electrode automatically returns to a fixed height above the workpiece.
▸Variable deepness control of machining.
▸Simulation and working path display.
▸Many condition files - each file input has -100 discharge variables.
▸100 sets of drilling deepness
✔USER FRIENDLY AND COMPATIBLE
▸Dialogue Programming
▸G/M Code Programming
▸Background Editing
▸Special Modular Machining (Circle, Rectan-gle Patterns)
▸Auto Edging. Centre of Two Points. Center of Circle Contains Electrode.
▸Radius Compensation.
✔FLEXIBLE AND MAINTAINBLE
▸Self-Diagnostic System Display
▸Hardware Status Display
▸Alarm History Management
▸RS232 Trans Function
▸Chinese/English/German/Japanese Conversion
✔AUTOMATIC TOOL CHANGE AUTO GUIDE CHANGE COMPONENTS
Power chucks are commonly used in automated lathes and milling machines to securely hold and clamp workpieces during machining operations. They are operated using a hydraulic cylinder or pneumatic cylinder connected to a rotating mechanism.
Power chucks are available in various configurations, including 2-jaw, 3-jaw, and 4-jaw chucks, depending on the shape of the workpiece being held. The H-2 second-generation design mentioned offers certain advantages over industry-standard chucks. It has a larger through-hole diameter, allowing for the clamping of circular through-hole workpieces with greater efficiency. Additionally, the clamping force of the H-2 chuck is increased by approximately 10% compared to standard chucks, enhancing the overall grip and stability.
The product structure of your power chucks is optimized using finite element method (FEM) design, resulting in increased rigidity. This improved rigidity contributes to higher precision, stability, and durability during machining operations. By using your power chucks, customers can expect enhanced efficiency and productivity in their machining processes while remaining cost-effective.
Overall, power chucks offer high rigidity, precise clamping, and stable performance, enabling customers to achieve improved operational outcomes in terms of productivity and cost-efficiency.
The indexing operation is performed during the spindle running, which can quickly switch between multiple working axes. Indexing angle: 90°*4 or 45°*8 with unique indexing system and hydraulic system, chuck with pressure detection mechanism, high reliability. Internal parts are hardened and ground for high durability. AUTOGRIP is a professional indexing chuck manufacturer.
-High rigid structure.
-Humanized operation control technology.
-Variable frequency adjustable step-less variable speed drive, precise feed, reduce wear and improve the life of the saw.
-One-piece roller frame with a special vise to improve the smoothness of sawing.
-The double-column gantry arch is matched with the roller-type line rail slider, which ensures the fineness of the sawing material surface.
-The rotary encoder on the side of the driving wheel feeds back real-time control and compensation, making the transmission of cutting force more stable and reliable.
-Application of QR CODE for sawing processing to improve production efficiency.
JL-3080CNC slide block grinding machine is suitable for standard-size block.
JL-1000HR with hydrostatic rotary table, through accurately control hydraulic pressure, there is no friction be generated between table and bearing, which provides high accuracy and damping effect. That is why JL-1000HR can qualify high precision grinding demand.
JL-52CNC-B's table travels on double V guideways, coated with low friction Turcite-B, makes the table moves smoothly on guideways. With ball screw and servomotor, which allows workpieces to have superior accuracy after processing.
JL-20200CNC rail grinding machines are suitable for standard-sized and miniature linear guides. With two vertical spindles and one horizon spindle,this machines can fulfill three-surface profile grinding of linear guides at the same time.
JOENLIH Surface & CNC Profile Grinding Machine - Column series fulfilled with all kinds of working table size from 500 x 1000 (mm) to 700 x 4000 (mm). X and Z Axis slideways are designed with double "V" ways and coated with scraped Turite-B. All these features made our machine works stability and produces high precision outcome. Last but not less, client can choose their familiar controller to go with the machine.
Three axes servo | Three axes linear guildeways | Accurate and fast positioning | Quiet and energy-saving | ESG sustainable development | Versatility: PSGC-50100E can be combined with the fourth axis/ measuring system/tool holder. | Applicable: surface grinding, concave, convex, stepped, grooved.|
1.Flow control regulator is used in longitudinal way for easy operation.
2.With auto down feed , auto dresser dressing and to compensation.
3.Vertical axis are driven by high efficiency serve motor.
4.Equipped with PLC controller and MPG.
5.The surfaces of longitudinal table ways are all hand scraped to getting perfect contact pattern and to ensure very high accuracy.
1.The surfaces of longitudinal table ways are all hand scraped to getting perfect contact pattern and to ensure very high accuracy.
2.Longitudinal table ways are designed to have slide surfaces longer than that of the working surface and equal to the table length to keep the table free from torsion and deflection.
1. Cross Slideway: The Linear Guideway has the high rigidity and very high load capacities that improve working precision.
2. Also has the characteristics of low noise , high load capacity.
3. The hydraulic type drive system of the working table.
4. Table is driven by two hydraulic cylinders.Use high rigidity high precision spindle is of a cartridge type design and anti-friction bearing.
1.Setting of “Spark-out” grinding is up to 10 passes.
2. Selectable wheelhead retract clearance at job completion for convenient workpiece loading.
3.After program end, select:(1)All powers are turned off automatically.OR
(2)Turn off grinding wheel automatically .OR(3)Turn off hydrualic automatically.
4. 7" touch panel and use dark colors to increase the user's visual comfort.
5.Use of graphical and text format is more convenient for operation.
Max. swing: 590mm
Swing over cross slide: 380mm
Max. turning diameter: 450mm (V10)
Max. turning diameter: 340mm (VDI)
Max. turning diameter: 420mm (BMT)
Distance between centers: 580mm (CL-220/CL-250)
Distance between centers: 1180mm (CL-280)
Spindle speed: 3200rpm (CL-220)
Spindle speed: 2200rpm (CL-250 / CL-280)
Spindle motor: 25HP
Chuck & Bar capacity: 8", 52mm (CL-220)
Chuck & Bar capacity: 10", 80mm (CL-250)
Chuck & Bar capacity: 10", 12", 80mm (CL-280)
Turret: Vertical 10-station servo turret
Turret: Live tool vertical 12-station turret (VDI 30/BMT 55)
Swing over bed: 660mm / 900mm / 1150mm / 1500mm
Swing over cross slide: 370mm / 520mm / 700mm / 900mm
Width of bed: 460mm / 560mm / 725mm / 1000mm
Distance between centers: 1055~4285mm / 1015~6330mm / 1020~7020mm / 2075~6075mm
Spindle bore & speed (CL-38): 120mm (6-1600rpm), 186mm (3-1000rpm)
Spindle bore & speed (CL-58): 120mm (6-1600rpm), 186mm (3-1000rpm), 258mm (6~600rpm), 375mm (4~400rpm)
Spindle bore & speed (CL-68/CL-78): 181mm (6-650rpm), 255mm (6~600rpm), 375mm (4~400rpm), 530mm (2~300rpm)
Spindle motor(CL-38): 30HP
Spindle motor(CL-58): 30HP, 40HP
Spindle motor(CL-68/CL-78): 60HP
Turret: V8, H4, H6
- Built-in FANUC TURN Mate i conversation software, no writing of NC programs required. The operator only needs to input machining parameters according to the graphic guidance before performing machining.
- The manual four-way tool holder rotation emplys a curvic coupling for upgrading the positioning accuracy of the tool holder.
Max. swing: 530mm
Swing over carriage: 285mm
Width of bed: 346mm
Distance between centers: 1067mm, 1667mm
Spindle bore: 78mm
Spindle speed: 3~1650rpm
Spindle motor: 10HP
．Turning & Milling in one set-up
．Y-axis travel 260 mm (10.2")
．Max. turning dimension Ø500 x 1075 mm
．Turning spindle 4200 rpm / 15 KW with 8” chuck for Vmt-X200, or 3500 rpm / 22 kW with 10” chuck for Vmt-X260
．Milling spindle 12000 rpm / 22 kW
．with HSK-T63 / A63 tooling
．ATC-40 tools
★ Multiple output type for many CNC controllers
★Multiple output types compatible with different CNC
control systems
★Optional enable micor switches for application
★Meet customers’various demands
★Optional Emergency Stop switch
★Magnetic back cover
★Dust & Water proof (IP65)
★Optimal solution
★Provide reverse polarity protection
★Easy to handle
-Support Yaskawa serial bus communication
-Lower the distributon power cost
-Space saver
-Higher cost performance
★ Rotary switch steps 1-12axis
★High performance offers 2 function
openings and 1 emergency stop opening
★Magnetic back cover
★Dust & Water proof (IP65)
★Optimal solution
★Multiple output types compatible with different CNC control systems
1. The shaft is made of alloy steel and through vacuum heat treatment HRC60°±1°. It processes great rigidity and high durability.
2. The center uses the combination of roller bearings, thrust ball bearing, the tailstock pressure of lathe adjusts to five to eight kilograms (for reference).
※ NCK-B type: Long nose live centers are suitable for small workpieces.
1. The universal tool & cutter grinder Model EH-832 is versatile in operation without requiring special skills. All milling cutters, endmills, shell endmills,staggered tooth cutters, rough endmills, countersinks (2 flutes, 4 flutes) and the angle of endmill helix can sharpen 2, 3, 4, 5, 6 flutes.
2. The Model EH-832 is designed to sharpen HSS and carbide toolings in small and medium quantities.
3. In one chucking operation, the machine can perform the grinding of the rake angle of the flute, clearance angle on the periphery and the end of the tool.
4. A few seconds set up time for helix angle.
5. Due to the backlash free operation, spiral toothed, solid carbide or carbide tipped milling cutters can be ground with high accuracy thus far only achieved by CNC grinders.
6. The heavy duty compound slides and one piece cast-iron base provide extra rigidity and minimize vibration.
1. The main-shaft is of integrated type, which is much more superior than the traditional design.
2. Extremely rigid construction tolerances can be reduced to a minimum, since the traditional mechanism requiring and arbor to connect the drill chucks which will generate the accumulative tolerances.
3. Prevent the drill chucks from falling out.
4. Extremely safe in operation
1. Special design & manufacture against for super heavy torque (Clamping capacity) use.
2. Owing to inspecting strictly & with excellent RUN-OUT accuracy and quality guaranteed the gripping power is double than the general brands.
3. Avoid the drill dropped when used in instantaneous change of direction and equipped with spanner for tightening perfect safety.
4. Especially suitable for CNC machining center & milling machine use.
♦ Well-applied in CNC Milling, Drilling, and Grinding processes
♦ Cost-Effective Solution for Advanced-Material Machining
1. High rotation speed up to 30,000rpm for high precision advanced-material machining.
2. Plug-and-play installation with convenience and flexibility.
3. High-efficiency and high-quality performance with the use of HIT ultrasonic technology.
4. Reduction in cutting force brings longer tool life.
5. Intelligent frequency tracking system for all kinds of tools used in advanced-material machining.
♦ Well-applied in CNC Milling, Drilling, and Grinding processes
♦ Cost-Effective Solution for Advanced-Material Machining
1. High rotation speed up to 24,000rpm for high precision advanced-material machining.
2. Plug-and-play installation with convenience and flexibility.
3. High-efficiency and high-quality performance with the use of HIT ultrasonic technology.
4. Reduction in cutting force brings longer tool life.
5. Intelligent frequency tracking system for all kinds of tools used in advanced-material machining.
♦ Well-applied in CNC Milling, Drilling, and Grinding processes
♦ Cost-Effective Solution for Advanced-Material Machining
1. High rotation speed up to 24,000rpm for high precision advanced-material machining.
2. Plug-and-play installation with convenience and flexibility.
3. High-efficiency and high-quality performance with the use of HIT ultrasonic technology.
4. Reduction in cutting force brings longer tool life.
5. Intelligent frequency tracking system for all kinds of tools used in advanced-material machining.
♦ The world-smallest ultrasonic toolholder
♦ Well-applied in CNC Micro-drilling process
♦ Cost-Effective Solution for Advanced-Material Machining
1. High rotation speed up to 48,000rpm for high precision advanced-material machining.
2. Plug-and-play installation with convenience and flexibility.
3. High-efficiency and high-quality performance with the use of HIT ultrasonic technology.
4. Reduction in cutting force brings longer tool life.
5. Intelligent frequency tracking system for all kinds of tools used in advanced-material machining.
♦ Well-applied in CNC Milling, Drilling, and Grinding processes
♦ Cost-Effective Solution for Advanced-Material Machining
1. High rotation speed up to 38,000rpm for high precision advanced-material machining.
2. Plug-and-play installation with convenience and flexibility.
3. High-efficiency and high-quality performance with the use of HIT ultrasonic technology.
4. Reduction in cutting force brings longer tool life.
5. Intelligent frequency tracking system for all kinds of tools used in advanced-material machining.
♦ Well-applied in CNC Milling, Drilling, and Grinding processes
♦ Cost-Effective Solution for Advanced-Material Machining
1. High rotation speed up to 30,000rpm for high precision advanced-material machining.
2. Plug-and-play installation with convenience and flexibility.
3. High-efficiency and high-quality performance with the use of HIT ultrasonic technology.
4. Reduction in cutting force brings longer tool life.
5. Intelligent frequency tracking system for all kinds of tools used in advanced-material machining.
♦ Well-applied in CNC Milling, Drilling, and Grinding processes
♦ Cost-Effective Solution for Advanced-Material Machining
1. High rotation speed up to 24,000rpm for high precision advanced-material machining.
2. Plug-and-play installation with convenience and flexibility.
3. High-efficiency and high-quality performance with the use of HIT ultrasonic technology.
4. Reduction in cutting force brings longer tool life.
5. Intelligent frequency tracking system for all kinds of tools used in advanced-material machining.
*It can process various chips created by complex machining.
*The patented design enables the steel belt to discharge both
coarse and fine chips, eliminating troublesome selection.
*Equipped with a filter system for processing cutting fluid with
0.5mm filtrating accuracy. The roller filter screen features a
self-cleaning function to ensure the dependability of filtration.
*No chips will accumulate between the top and bottom steel
belts, increasing the service life of steel belts.
*Compact design with less space occupied. Easy to clean and
maintain.
*Equipped with an industry-leading overload protection device
that extends the parts service life of the chip conveyor.
Winbro’s High-Speed Electrical Discharge Machining provides substantially faster drilling times than the conventional oil dielectric process.
EDM SYSTEM
A compact, high-speed single point EDM system that delivers high productivity and meets the strictest standards for drilling turbine components and semiconductor process equipment.
HIGH SPEED EDM WITH DI
Winbro machines use deionized water as the medium for the Electrical Discharge Machining process. This allows for a high speed drilling without the need to change oil based solutions.
DESIGNED FOR PRECISION
Our machines are designed from the ground up to maximize precision through out the process. We offer multiple solutions to help monitor the EDM process to ensure high quality throughput.
UNMATCHED TECHNOLOGY
Our EDM technology delivers functionality that has yet to be matched. Our advanced features include electrode probing and Electrical Discharge Machining milling where we use a cutter path to create 3D geometries similar to milling.
EXPLORING THE CORE ELEMENTS OF ELECTRICAL DISCHARGE MACHINING
Explore the sophisticated components integral to Electrical Discharge Machining (EDM), illuminating the fundamental elements pivotal for its precision and effectiveness. From the spark generator to the intricacies of the dielectric fluid system, each facet orchestrates the controlled electrical discharges, crafting intricate shapes with exceptional accuracy
• Power Supply: Provides the necessary electrical energy to generate the electrical discharge between the electrode (tool) and the workpiece. The power supply delivers controlled pulses of electrical energy to create sparks.
• Workpiece:The material being machined. It could be any conductive material, such as steel, titanium, copper, nickel alloy, etc.
• Electrode: Also known as the tool, the electrode is usually made of a conductive material (like copper, graphite, or tungsten) and is shaped according to the desired form to be machined into the workpiece. Typically the electrodes are tubes that allow dielectric fluid through and increase the processing speed.
• Dielectric Fluid: EDM typically operates in a dielectric fluid, which acts as a medium to facilitate the electrical discharge and helps in cooling the workpiece and flushing away the debris. Typically Winbro used deionized water with fine filtration to keep the fluid as clean as possible.
• Control System: The control unit regulates various parameters of the machining process, such as pulse duration, frequency, current, voltage, and servo movements in the case of EDM.
• Filtration System: In EDM, a filtration system removes debris and particles from the dielectric fluid, ensuring it remains clean and suitable for use in the machining process.
• Automatic Tool Changer (ATC): A tool changer in EDM allows for the guide assembly (also known as quill or guides) to be changed automatically in the machine allowing multiple tool types and guides to be used without operator intervention.
• Automatic Electrode Changer (AEC): Electrode changers also eliminate the need for operator intervention by disposing of electrodes and loading a new electrode to continue processing. Winbro’s machines can hold up to 700 electrodes for high volume production.
• Rotary magnetic chuck dia：600mm
• Meehanite Class FC30 casting with slide way provides high
stiffness and wear resistance maintaining the accuracy of the
machine.
• Spindle lateral design creates stability during heavy cutting.
• Base and column main castings use Meehanite Class FC30 and aged naturally through time allowing longtime structural
stability.
• Vertical feeding uses 2 high stiffness and rigidity linear roller
guides, RG45(Block x6), RG65(Block x6) allowing smoothly
vertical feeding whilst maintaining high stiffness.
• Small workpiece suction is accomplished by fine electrical
magnetic chuck.
• Rotary magnetic chuck dia：500mm
• Meehanite Class FC30 casting with slide way provides high stiffness and wear resistance maintaining the accuracy of the machine.
• Vertical Y axis uses Class 1 ball screw Ø50 provides high stability during feeding.
• Vertical and longitudinal feeding uses high stiffness and rigidity linear roller guides made in Japan (slide block x6) provides smooth feeding but still maintain high stiffness.
• Vertical spindle Y axis uses peumatic counterweigh to reduce ball screw and servo motor loading to make movement more smoothly and extend the use of life.
• Horizontal Spindle uses six high precision ball bearing for heavy grinding.
• Rotary magnetic chuck dia：800mm
• Meehanite Class FC30 casting with slide way provides high stiffness and wear resistance maintaining the accuracy of the machine.
• Spindle lateral design creates stability during heavy cutting.
• V3 grade spindle motor with good water proof and moisture resistant design.
• Vertical feeding uses 2 high stiffness and rigidity linear roller guides, RG45(Blocks x6),RG65(Block x6) allowing smoothly vertical feeding whilst maintaining high stiffness.
• Small workpiece suction is accomplished by fine electrical magnetic chuck.
• Rotary magnetic chuck dia：350mm
• Spindle motor adopts V3 Grade provides good water resistance and resist high humidity.
• X、Z axis feeding uses high stiffness and rigidity linear roller guides allowing smoothly X.Z feeding whilst maintaining high stiffness.
• Machine equips fine pole electrical magnetic chuck provides bigger holding power and able to attract small workpiece firmly.
• Table size(LxW)：1200x2000mm.
• Meehanite Class FC30 casting with slide way provides high stiffness and wear resistance maintaining the accuracy of the machine.
• The large spindle is support by CP6 precision angular contact ball bearing. 20HP(V3) motor ensures powerful accurate cutting.
• All slide ways are coated with TURCITE-B and then hand scraped for precision operation and longevity.
• The table speed is controlled infinitely by proportional valve, which is adjusted from the knob on the control panel.
• The automatic lubrication system is furnished as standard to provide ample lubrication on all slide ways and ball screws whenever the hydraulic is under the power, thus assuring smooth table movement.
• Y-axis ball screw(C3) and high precision reducer, by AC servo motors driver.
• Table size(LxW)：750x2000mm.
• Machine structure is manufactured from high quality Meehanite class FC cast iron
• Spindle motor select high stability Siemens motor
• X and Z axis guide way use double V design
• The large spindle use CP6 precision angular contact ball bearing (Front 4 and Rear 2) ensure heavy grinding ability.
• Y and Z axis use precision ball screw
• Y axis use AC servo motor and go with MPG reach high feeding accuracy
• Cross stroke adjusting function get rid of inconvenience of traditional sensor and increase grinding efficiency. All guide way and ball screw use automatic lubrication system for forced cycle lubrication (with alarm for oil detective)
• Table size(LxW)：1500x600mm
• “MEEHANITE” casting.
• Machine base fully supported design creating high rigidity structure.
• 3 axis uses high precision ball screw AC servo motor drive.
• X axis use double V guide way design and driven by hydraulic.
• Y 、Z axis uses high stiffness and rigidity linear roller guideways.
• High precision spindle.
• Closure type water-proof guard.
• Table size(WxL)：500x1000mm
• Precision grinding machine.
• Automatic Trim Compensation.
• On line spindle vibration monitor.
• Machine base fully supported design creating high rigidity structure.
• Table size(LxW)：400x4000mm
• Vertical feeding use high stiffness box ways、precisely scraped，and Ø50mm ball screw.
• X axis use high stiffness and rigidity linear roller guideway(RG65) and block x6.
• X axis use high precision rack and pinion system for high rapid and smooth movement.
Comply with TUV CE comformity, both safety and desired design with easy operation.
Power slider door design to save installation space and light operation.
●High Precision
Smart Corner Control, Stable Discharge processing, Super Finish Circuit (SFC) provide more accuracy.
●Efficiency
DPM module, Precision mark control, Electrolysis Free(EF) generator system.
●Cost effective
Intelligent access control, Reduce Wire Consumption, Economic concerned price.
●Intelligent Networking
Remote monitor management, Controller connector, Portable device monitor.
●Automation
High speed Auto Wire Threading, Robo-arm transfer of Workpiece, Probe Auto Measurement and Correction
[NP400L Energy-Saving Strategies]
A. GS High-Speed Energy-Saving Discharge Circuit (Patent No. I839195):
The new GS high-speed energy-saving discharge circuit features an innovative active discharge energy recovery module. During the machining process, excess discharge energy is recovered synchronously (redirecting surplus capacitor energy back to the power supply instead of dissipating it through resistors). This significantly reduces power consumption in high-speed machining, saving up to 33% of energy compared to the previous-generation system. Additionally, the discharge energy waveform is optimized (from triangular to T-shaped), increasing thermal accumulation area and improving high-speed machining efficiency by 25%, achieving a cutting speed of up to 320 mm²/min, on par with leading Japanese competitors.
B. Enhanced Water Cooling System:
Cooling Unit: Upgraded from a fixed-frequency cooling unit to a DC inverter cooling unit, reducing hourly energy consumption by 75%.
Water System:
Previous Approach: The filtration pump operated continuously, filtering water even when the clean water tank was full, causing energy and filter waste as excess water overflowed back to the wastewater tank.
Improved Method: A water level monitoring device is added to the clean water tank. The filtration pump activates only when the clean water tank's water level is low, reducing hourly energy consumption by 44%.
C. Intelligent Energy-Saving Modes:
New standby and warm-up modes optimize the operation of pumps, cooling units, fans, and LED lights. In standby mode, power consumption is reduced by 95%.
These three energy-saving technologies enable our wire-cutting machine to lead the industry in speed while achieving outstanding energy efficiency (44% energy savings during machining). This helps users significantly reduce production costs. Simulating a customer's annual production scenario, the machine saves 10,961 kWh annually, reducing carbon emissions by 5,425 kg CO2e.
Multiple-Axis Mill-Turn Machining Center
MT-900 has a 5-axis milling head, two turrets, a tool magazine and twin spindles. The design layout allows to maintain a large work envelope for both lathe operations--turning and milling. All 6 sides of a art can be machined.
-最大旋徑/Swing over bed Ø500 mm
-最大加工直徑/Max. machining dia. Ø300 mm
-最大加工長度/Max. machining length 922 mm
行程 Travels
X-軸/X-axis 420 mm
Y-軸/Y-axis ±150 mm
Z-軸/Z-axis 900 mm
B-軸/B-axis ±150˚
C1-軸/C1-axis 360 (S1=3,000rpm)˚
C2-軸/C2-axis 360 (S2=3,000rpm)˚
W-軸/W-axis 968 mm
A-軸/A-axis 360 (1°)
Click the link below for more information:
https://www.yidacnc.com/product_d.php?lang=en&tb=1&id=636
．Max. Machining diameter: Φ800 mm
．Max. Machining length: 1,342 mm
．X-axis Travels: 340(310+30) mm
．Z-axis Travels: 1,150 mm
．Spindle Nose: A2-11 (STD.) ; A2-8/ A2-15 (OPT.)
．Chuck Diameter: 15" (STD.) ; 12" (OPT.)
．CS- axis function
Click the link below for more information:
https://www.yidacnc.com/product_d.php?lang=en&tb=1&id=662
Main feature /
■ Accuracy
Table surface guaranty (Testing grinding piece*6, thickness difference) : 5μ
Downfeed(minimum unit) : 1μ
■ Spindle & motor
Vertical driven by AC servo motor.
15HP V3 grade low vibration spindle motor.
Direct drive spindle, ABEC Class 7 (P4) bearings, 0.003m/m TIR.
4 angular contact ball bearings at front, 2 angular contact ball bearings at rear side of spindle.
■ Cross and Longitudinal
Cross feed driven by simplified AC servo motor, it's more precise when intermittent feed.(TS)
Cross feed driven by AC servo motor. (P)
Double hydraulic cylinders drive with variable speed regulator for longitudinal.
Longitudinal by advanced table hydraulic design, feed range from 0.5m/min to 25m/min, it provides easy operation and vibration-free reversing motion and controlled by the proximity sensor built-in design for safety.
■ Base & slide ways
Linear guide ways for vertical and cross axes with extra large block.
Longitudinal double V, and TURCITE B coated with hand scraped
One-piece T shape casting base and slide way.
All main castings are made of "Meehanite GC275" and have been annealed stress for long lasting and accuracy.
(1) NTC is the new modulized lathe series design we have, can be selected with different spec. for different customers' machining demand.
(2) NTC is very suitable for complex parts machining for the electronics, 2 and 4 wheels automotive, and mechanical parts industry need.
(3) 6" or 8" spindle chuck size can be chosen. With big spindle bore design, 8" chuck can have dia. 65 mm bar, 6" chuck can have dia. 51 mm bar.
(4) Turret can select standard turret, live turret, or turret with Y axis which is 90 angle design to get more turning capability. And based on different coolant pump the different pressure can be operated.
(5) About tailstock, manual or hydraulic, or programmable type can be selected, and also sub spindle is an option.
(6) High rigid one piece slant bed design with X/Z axis box way design can highly increse the machine's rigidity.
(7) With bar feeder, sub spindle workpiece push system, parts catcher system...etc. an easy cell of automation can be applied.
Suitable Materials: Steel, Stainless Steel, Cast Iron
Special Blade Chip-Breaking Design:
• Reduces machining resistance and increases chip-breaking efficiency.
• Adaptable to larger cutting depths with an enlarged chip groove design to enhance chip evacuation efficiency.
• Specially designed chip-breaking groove effectively cuts and removes iron chips, improving cutting efficiency.
• Unequal spiral angle design of 35°/38° is advantageous for high-speed machining and crack resistance.
• Unequal division design is beneficial for high feed machining, improving anti-vibration and surface finish better than rough end mills, reducing machine load.
Excellent Internal Diameter Machining
Tool Materials:
Solid Tungsten Carbide
High-Speed Steel
Tool Steel SKD61
Crafting Precision in Every Cut, Rough Milling Tools Leading Efficient Machining, Mastering Material Control for Impeccable Workpieces!
SPGX Series
Indexable Rapid Drill
Dual-helical coolant hole
Better cooling and lubrication
Wider range of drilling depths
Good insert mounting angle
Small vibration during cutting
Better drilling accuracy and surface quality
More space for chips
Good flushing angle, make the chip removal smoother
High torsional resistance and new surface treatment
strong drill body
Higher feeds can be tolerated for greater efficiency
General Drilling、Half Cylindrical、Ramping Drilling、Broach、Intersect Drilling
Applicable material: Alloy Steel、Stainless Steel、Cast Iron
Feature of Rotary Series Ball Screw / Spline
TBI motion rotary ball screw / spline is designed to enable the application to move linearly, rotationally and spirally in one assembly, with symmetrical orientation design between the outer and inner ball screw nut. Both rotary and spiral movement can be achieved simultaneously.
1.No backlash, high position accuracy.
2.High speed, smooth operating.
3.Low noise.
4.Easy assembling, space-saving.
Application
SCARA, Industrial robot, Laser milling, Pick & Go application etc.
From CNC center and etc.
BT-30 / BT-40 Grinding Wheel Toolholder Series
♦ Applied in CNC grinding process, especially for the making of ring-shaped components (i.e. quartz/focus ring, SiC wafer carrier/susceptor) used in semiconductor manufacturing equipment
♦ Higher Machining Efficiency and Material Removal Rate (MRR)
♦ Balance Quality Grade G2.5
♦ High Precision Runout <5 μm
♦ Double-sided Restraint Taper
♦ Thread Locking Tool Interface
The Ultimate in Heavy and Precision Cutting Capability
Maximizing Machining Efficiency Through Quality Features
-The slant bad is a massive structure for minimized vibration and higher structural length
-Box ways on X, Z-axis exhibit outstanding stability for heavy cutting
-Draw tube dia= 65mm (2.56 inch)
-45° base
-Box way Tailstock
【PRODUCTS➢BMC SERIES】
Horizontal Boring & Milling Machine
BMC-110R1/R2/R3
⟡All primary structural compoents are composed of high quality cast iron.
⟡4+1 axis and 4 axis simultaneous
⟡B axis design integrates two worm gears to minimize backlash; incorporates high precision encoder (rotary scale) for 0.001 degee precision table rotation.
⟡FANUC(standard), Heidenhain, Siemens(option)
【PRODUCTS➢ WHL SERIES】
Rofessional model for mirror like wheels
⟡SP series adopt C1 class ball screw which makes its scraping precision within Ra0.2.
【PRODUCTS➢HL SERIES】
HORIZONTAL LATHE
HL-25N
⟡The smallest footprint in its class.
【PRODUCTS➢VL SERIES】
⟡Double column VL-12 VL-25 VL-25M
⟡Double column VL-25
STEP 1
Place the alloy wheel blank on the feed-in conveyor, the robot will clamp it into the production line. The whole process is mainly operated by robot arms in order to fulfill automated manufacturing.
STEP 2
First process for wheel internal process Includes rough/fine machining. Main Measuring items: CHD, Surface flatness.
STEP 3
Drilling Process : Main measuring items are PCD holes and Air Valves.
STEP 4
Final process for wheel OD (rough/fine machining). Main Measuring items: wheel O.D. and Cap Dia.
STEP 5
Before the material is discharged, the robot will send the wheels to laser maker to print ID codes, enabling material traceability during the production process and after discharge.
【PRODUCTS➢ WHL SERIES】
CNC Vertical Wheel Turning Lathe WVL-T24/F24
⟡Dual Turrets Design
【PRODUCTS➢ WHL SERIES】
Comprehensive drilling lathe
⟡All-Size Processing Capacity (13''~26'').
⟡Simultaneous processing weight loss holes and PCD rear boring.
◆Features：high speed, high precision, enhancing the productivity and quality.
◆It can machine workpieces all day continuously to save manpower.
◆Dual-spindle adopts servo control, with superiority in high speed and high precision for single blank workpiece loading.
◆It can work with different types of feeder station based on customer’s feeding requirement on blank materials.
◆Gantry Loader uses remote control interface, owing professional hand –held touchscreen with clear interface, fool-proof design, and guide with teaching.
◆Gantry Loader is on top of machine. The design can extend lifetime of auto loading /unloading system and decrease the consumption cost.
◆Various possibilities for production line lineage according to process plan.
◆We, GREENWAY can also provide the relative assistance if customer has remote monitoring requirement.
◆ Suitable for turning (drilling /tapping) screw-type shaft tails ends.
◆ Suitable workpiece feeding length: about 100~190mm
◆ The maximum outer diameter of turning is φ18mm.
◆ The way of loading / unloading material: from the back-side of spindle.
◆ The slide way of parts catcher is equipped with a safety detection system to prevent material jamming issues.
The XL-A type drill gun machines are ideal choices designed specifically for the production of small-diameter and deep hole drilling parts, shafts, and core rods. These CNC deep hole drilling machines feature a uniquely designed spindle with a maximum speed of 10,000rpm to 15,000rpm, providing extremely low noise and vibration, creating a quieter and more stable working environment. To provide a better performance, we have specially designed vibration dampeners that allow for the use of shorter drill bits, effectively preventing drilling from causing bending. With the advanced technology of our CNC deep hole drilling machine, you can easily adjust various parameters to achieve higher precision and quality in your drilling process.
XL-A type drill gun machines are suitable for the production of small diameter & deep hole drilling components, shafts & mandrels.
The specially designed and direct spindle produces low noise and vibration.
Specially designed vibratory dampers (PAT. M444890-Taiwan & ZL200920168114.2-China ) support the gun drills which allow it to use a shorter length of gun drills and prevent curving of drilling holes.
Suspending type of operation panel and MPG(Hand wheel) for easier setting and operation
An automatic lubrication pump is provided as a standard accessory to ensure all the bearing surfaces and screws are well-lubricated.
CE packages are available for special requirements.
The XE model gundrilling machines have the capability of multi-axis machining, allowing for the simultaneous design of 1 to 4 axes, providing greater flexibility and efficiency in machining. It is an ideal choice designed specifically for the production of small and medium-sized parts, shafts, and core rods. Servo motors and ball screws are used as the feeding mechanism, ensuring smooth and convenient feed speed adjustments, guaranteeing precision and efficiency in the drilling process.
XE type machines are suitable for the production of small & medium components shafts, mandrels
The Servo motor and Ball screw are used for the feed mechanism to insure smooth and convenient feed rate adjustment.
Hardened and ground Main slide ways to hardness HRC 60. The opposite ways and gibs are all Turcite-B plated with the hand-scraped bearing surface
Suspending type operate panel and MPG(Hand wheel) for easier setting and operation.
An automatic lubrication pump is provided as a standard accessory to ensure all the bearing surfaces and screws are well-lubricated.
The machine could be controlled by CNC or a conventional model with a PLC & man-machine interface.
CE marks are available for special requirements.
The XT deep hole gun drilling machines feature a sturdy bed-type structure design for both its worktable and machine base. Compared to knee-type machines, the worktable of Microdrilling’s XT model deep hole gun drilling machine can withstand three times the weight. This ensures precise positioning accuracy and drilling process accuracy even during full-speed operation or large-scale production. Additionally, Microdrilling offers a variety of controller brands to choose from, including Fanuc, Mitsubishi, or Syntec CNC controllers. Our deep hole gun drilling machines come standard with an automatic lubrication pump and oil injection reminder function, ensuring sufficient lubrication for all bearing surfaces and screws.
XT-600/1000 CNC /Drilling capacity and Max. depth of drilling: Ø 3~25mm × 600~1000mm
The following brands of controllers can be chosen for bed-type deep hole drilling machines: Fanuc, Mitsubishi, or Syntec CNC controls.
The worktable and machine base of the gun drilling machine is designed to come with bed-type installation. Its worktable can bear three times the weight that can be born by the worktable of the knee type of machine, ensuring its positioning accuracy during its movement or its drilling process when the machine is in full operation or mass production. It is suitable for chilling small plastic molds, glass extrusion molds, heat exchangers, water cooling holes, workpieces with off-center holes, and PCD deep hole drilling.
An automatic lubrication pump is provided as a standard accessory to ensure all the bearing surfaces and screws are well-lubricated.
To ensure accuracy in drilling, X, Y, and Z axes are equipped with precision ball screws.
The XT-1200 gun drill lathe is suitable for deep hole drilling of coolant water holes and ejector pin sleeves in medium to large plastic molds and other workpieces. Various CNC controllers such as FANUC and MITSUBISHI are available to meet your specific needs. Microdrilling's XY model gun drill lathe stands out with its second axis, which can be used for milling, tapping, and other purposes.
XT-1200 CNC /Drilling capacity and Max. depth of drilling: Ø 3~30mm × 1200mm
Table type deep hole drilling machine controlled by CNC, Max. loading 5000 kgs.
Suitable for drilling waterlines and ejector pin holes of large-type injection molds.
CNC could be selected with FANUC or MITSUBISHI etc.
Hardened and hand-scrapped box way slide design provides rigidity for heavy cutting.
P-grade linear guideway for Z and A axes.
CE marks are available for special requirements.
The XT-1500/1800 (CNC) gun drilling equipment features a column-type design with CNC control, allowing the option to choose brands like FANUC or MITSUBISHI according to specific requirements. Microdrilling's gun drilling equipment is specifically designed for drilling water lines and ejector pin holes in large injection molds. The machine's spindle is supported by angular contact bearings and achieves full lubrication throughout the running components of the main unit. The robust honeycomb-shaped column structure ensures a stable cutting environment.
Type: Bed Type Deep Hole Drilling Machine
The column-type deep hole drilling machine with CNC control is designed for drilling waterlines and ejector pin holes of large-type injection molds.
The spindle is supported by angular contact bearings well-lubricated to all running points in the head.
The rigid honeycomb walled column gives a stable cutting condition. FC-32 castings have been stress-relieved and annealed.
Hardened and ground double V-ways for worktable X-axis main slide to hardness HRC 60. The opposite ways and gibs are all Turcite-B plated with hand-scraped bearing surfaces.
A huge wide and long worktable allows heavy work pieces. An extra wide saddle gives a much heavier loading capacity.
An automatic lubrication pump is provided as a standard accessory to ensure all the bearing surfaces and screws are well-lubricated.
Spindle feed Z-axis and A-axis, feature P-grade linear motion guideway and provides stable cutting capacity.
CNC could be selected with Fanuc or Mitsubishi brands.
CE marks are available for special requirements.
The XL-3000/4000/5000/6000 (CNC) gundrill machines offer drilling capabilities with a maximum depth ranging from 3000mm to 6000mm. They are professionally designed and manufactured to fully leverage the performance of gundrilling tools, achieving excellent results in drilling extremely deep and precise holes in various materials. Our professional gun drill machine integrates powerful technologies such as tool support, cutting oil pressure, and machine power, providing accurate and efficient solutions for deep hole gun drilling applications.
Based on mature technology, Microdrilling gun drill machines exhibit a high level of flexibility, allowing for customized configurations based on the size and shape of the workpiece, desired production rate, and accuracy specifications. This configuration enables outstanding adaptability of the gundrill machine in various application scenarios, delivering excellent operability and performance.
Chain Headway offers a comprehensive range of chamfering tools, professionally designed and developed to cater to diverse processing needs and application scenarios. Our precise manufacturing process ensures that each chamfering tool achieves high surface quality and accuracy in various machining environments, ultimately enhancing processing efficiency and stability.
1. AAC Adjustable Chamfering Tool:
(a) The AAC series features a flexible, a
