TMTS Virtual Application
Yi Chang Machinery Co., Ltd. who is the maker of Horng Dar brand bench drill press machines and tapping machines, was founded in Dali Dist. Taichung City Taiwan in 1984. We had accumulated a remarkable experience in the territory of making drilling and tapping machines.
To integrate global resources for continuous innovation, to provide a better way of life and a better working environment for mankind, to achieve the goal of continuous operation through practices of professional excellence, working enthusiasm, and enterprise responsibility.
Our founder, Mr. C. F. Chang, established the factory in Taichung City and serviced the metal working industry by one lathe in 1968. Since 1973, we began made the lathe and named as " CHIN HO Machinery Factory ". In 1980, we moved the factory to Ta - Ya, Taichung country and reorganized as CHIN HUNG MACHINERY CO.,LTD. In order to expand the product, we built the new factory for CNC lathe in 1996 and installed next year. We buy the new land located the Taichung Precision Machinery Technological Park and began to build the new modern factory since the end of year 2010 in order to expand the product line to meet the requirement from the customer.
Since its establishment, SIGMA CNC Technology Machinery holds the fundamental concept of “EXPERTISE, INNOVATION, and PERFORMANCE”. Led by President Humor Chuang, the efficiently co-operated teams are running the company’s daily operations. Under the leadership of our President, constant efforts, renovations are made to meet eve changing market challenges.
The high-precision CNC 5-Axis indexing table of HOSEA meets the most stringent standards in the European market. The products are widely used and favored in Europe, and are well-known by global machine tool manufacturers.
JEENXI Technology Co., Ltd. was established by Mr. S. C. Chen in 2000. Specializing in Machine Tools for R&D and production technology, our main products are high precision and quality 3-axis and 5-axis machining centers. The Machining Centers from Sunmill offer numerous customer-friendly features and comprehensive processing sizes to meet diversified customer’s needs. Customized specifications are also available.
CNC Cutting Tool Solutions Supporting our Partners
Your cutting tools are the key step in your metal cutting process, so choosing the right long term manufacturing partner as your CNC cutting tools solutions provider will be key to your success and profitability.
Established in Taichung City, Taiwan in 2004, by Dr. Pu Hong-Yen, YIDA’s core business scope includes R&D and manufacturing of machine tools. YIDA is currently one of the few machine tool companies in Taiwan with product lines covering horizontal lathes, vertical machining centers and horizontal machining centers. Adopting customer-oriented service principle and strategy, YIDA is well-known for the ability to come up with automation solutions and customized machine tools that best satisfy its customers’ needs.
Founded in 1954, YCM (Yeong Chin Machinery Industries Co. Ltd.) specializes in machine tool manufacturing. YCM machine tools have been recognized worldwide for superior precision, outstanding rigidity and exceptional reliability. Today there are more than 70 makes and models fulfilling the industry’s diverse requirements. With over 60 years of machine tool manufacturing experience, YCM has established a strong foundation in the field of machinery.
Founded in 1994 Matrix Precision Co., Ltd. started the production of gear cutting tools at Hsin-Chu Science-Based Industrial Park, Taiwan. The key members who came from the Industrial Technology Research Institute (ITRI) had hand-on experiences on high technology and high precision machinery to produce aircraft gears and components.
Honor Seiki was founded in 1987 and has more than 35 years of experience in VTL machine design and manufacturing.
We mainly focus on the production of Vertical lathes and strive for excellence.
With around 200 employees, HONOR SEIKI is the most professional, leading brand, machine tool provider which has international quality certificate in the field of Turnkey solution in Taiwan.
Established in 1983, UNITIDE INDUSTRIAL CO., LTD. is a leader in adhesives. It has been more than 30 years since its establishment and it has served more than 20,000 customers. From the early stage of being agent of German brand industrial adhesives as the main business, there are also high-quality product lines such as adhesives for industrial electronics, special lubricating greases, adhesive injecting dispenser, UV curing equipment, maintenance series and Big Foot floor non-slip coating introduced... So far, it has expanded its business to solve the problems of adhesive using for customers, and at the same time to provide bicycle lubricants, bicycle rubber equipment and manufacturing processes to increase production capacity, reduce costs, and find innovative solutions for customers. The company has earned the ISO 9001 certification since 2005, and has established multiple service locations in Taiwan and China, namely Taichung and Taoyuan in Taiwan and Guangzhou and Shanghai in China to make the services solid and reliable.
Accuway Machinery Corporation is one of the leading machine tool builder of vertical machining centers and CNC lathes for various industrial applications. Founded in 1986 by supplying mold and die for semi-conductor industries, it has accumulated abundant precision machining experience and technologies by continuous improvement and innovation.
Having been a special-purpose machine developer since 1977, we are keenly aware of the importance of motor spindles, and started to develop a series of motor-built-in spindles from 1998. Prioritizing "Quality First" enables us to be a reliable supplier to help enhance machinery operation.
It's the Pao Fong people who have our commitment alive. They extend quality idea to every aspect of our business activities-form the machine design, manufacturing. Running test, and after sale service, that stress the total value of every Pao Fong milling machine.
Taiwan's leading manufacturer of spray washing machine - YAW SHENG MACHINERY CO., LTD. In order to meet the rising global environmental awareness and expanding market demand, YAW SHENG has expanded its two new modern plants, an Environmental Technology plant and a Sand Core Technology plant, and has entered the trial operation stage. It is expected that Q3 will be fully operational. Including: mechanical assembly, metal parts processing, shell mold core manufacturing, metal forging and casting workpiece sandblasting, burr grinding, polishing, primer coating and other post-process processing. The successful one-stop vertical integration, YAW SHENG has been established for nearly 45 years. At this time, it demonstrates the maximization of industrial advantages, and also lays a strong cornerstone for the global layout and second-generation succession.
POJU International has been committed to the high-precision machine tool industry for 25 years since its establishment. The Group is at the forefront of promoting the development of precision machining and manufacturing, from planning production solution and production automation to key components manufacturing of machine tools. The operating focus of POJU International is the production of machine tool spindles and tool magazines.
MAINTECH PRECISION CO.,LTD. was established in 2017.Due to the rise of industrial 4.0 and artificial intelligence, we recognize that once again the new industry revolution was coming. And for that reason, it is necessary to recruit industry elite and committed to automation and artificial intelligence research and development by focusing on developing the complex spindle head for high end CNC machine.
Established in 2013, Da Shiang Automation (DSA) is located in Guishan industrial park, Taoyuan Taiwan. With the Business philosophy of Innovation, Technical, Scientific Spirit to service customer, DSA has been growing continuously. We has over 10 years of experience at the automatic solution. Now, we even complete the whole solution by integrating industrial 4.0 with the automatic system.
Mission：
1.to Facilitate the Development of Taiwan Machine Tool Industry
2.Governmental Assignments
3.to Assist in Developing Overseas Market
4.Industry Statistics and Market Research
5.Members Communications
6.to Organize the Taiwan International Machine Tool Show (TMTS)
We are committed to the production of milling collets, chuck holders, and collets to solve all customer problems, and produce cutting tools that create value for customers.
Established in 1984, Ring Sun Machinery is the home of chip conveyor experts. With more than 30 years of experience and technical know-how in the field, Ring Sun has become a leading chip conveyors manufacturer in Taiwan. Ring Sun specializes in providing customized chip conveyors for a variety of applications.
To provide a better way of life and a better working environment for mankind, to achieve the goal of continuous operation through practices of professional excellence, working enthusiasm, and enterprise responsibility.
HANN KUEN was found in 1985 and have extended its expertise in developing & manufacturing special purpose machine units, such as drilling head, tapping head, boring and milling head, servo driven facing head, built-in motor spindle unit, spindle with auto unclamping cylinder, servo and hydraulic slide tables.
Establised in 1969 and was listed on stock since 2003 in Taiwan. Tongtai locates in Kaohsiung and our business was started from special purpose machine manufacturing. Now, we are a leading machine tool manufacturer in Taiwan and having diverse machine types. We are very experienced and capable of turnkey solutions and whole plant exports.
Jea Sheng has professional casting experience for over 35 years and advanced casting and testing equipment. We have stable and fast delivery. The casting capacity is 2500 tons per month with 0.02mm machining precision.
Established in 1978, TMT has enjoyed over 40 years of successful business experiences.
TMT have complete production line for customers including CNC Lathes, Vertical Machining centers, Tapping Centers, Column Moving Gantry Type Machining Centers and five-axis machines to satisfy the processing and production needs from different industrial fields.
TMT, good choice and partner for you!
Founded in 1987, Stanny Machine Tools Co., Ltd. specializes in making accessories for machine tools as grinders and milling machines, including precision vises and borers, which are recognized for quality. In 1996, we introduced two boring systems that can be assembled to handle different bore sizes and depths. One is a coarse-boring system, which has a tool-setting gauge to enable stable, precise
To fulfill customers' needs, Taiwan Takisawa establishes Application Center. This center is in charge of demand planning, training and customization. Through technology exchange, Application Center has affirmed customers' loyalty all around the world. This is a key factor why Taiwan Takisawa plays an important role in this field.
Campro established since 2003 in Taiwan provides high-end CNC machine tools to the high precision applications requested user. As a manufacturer to the industry, we provide all phases of CNC machinery, from market analysis to production. Campro also develops at least 2 series of CNC machines every year to help customer improving their factory into the next level.
KOMPASS Kang Baishi. Asada Enterprise Group, dedicated to hydraulic system Planning, design and manufacturing, with the best technical experience for more than 40 years so far And uphold the team's experience, we also master the intelligent machinery manufacturing and The key technology of the Internet of Things, our integrity will become you in the future
Indispensable best partner.
PALMARY Machinery Co., Ltd. was founded in Taichung, Taiwan since 1998. Two production bases with 20,000 square meters space, we produce kinds of centerless grinders, cylindrical grinders, internal grinders, vertical grinders & surface grinders. As a leading manufacturer of grinders in the world, we customize cutting edge grinders for our clients worldwide at reasonable cost.
PERFECT Surface Grinders Help Customers Stay Ahead
Under the company’s policy of “Quality. Innovation. Service.”, PERFECT constantly enhances R&D and presents new models to meet market demands. Meanwhile, we are committed to producing the most dependable and valuable machines to serve our customers worldwide.
JINN FA Machine industrial Co., Ltd. was established in 1976 as a Precision Metal Lathes Machine Tool Manufacturer. JINN FA designs and manufactures a wide range of auto lathes, cnc lathe machines, CNC machining centers and special purpose machines.
Keyarrow implemented KAPS (Keyarrow Production System) based on “5S+TPM”, and TPS spirit (Toyota Production System). Aim for “Deliver high quality product to customer’s production line on time.”, keep improving ourselves towards zero defects and zero customer inventories.
We are, and we shall, be your most reliable and most faithful cooperating partner.
AWEA Mechantronic Co., LTD, established in 1986, is now one of Taiwan's largest professional CNC machine manufacturers. The machine travel range spans from 510 mm all the way to 20,000 mm. Product line includes 5-axis, five-sided, vertical, horizontal, and other types of CNC machines. Especially for the large-scale bridge type machines, they are widely recognized by the global market and enjoy the
Habor, located in Taichung Taiwan, was founded since 1981 with main business of design, manufacturing and sales in high-accuracy & constant temperature control cooling units specified for industrial machinery. For more than 30 years, we have done the effort in new development and technology innovation of temperature control system and cooling units, we provide reliable and high-quality products be
PRAISE PRECISION IND.CO., LTD. founded in since 1976.
We are specialized in Carbide boring bars、Tool holders、Cutting tools、Grooving tools、Fine boring bars and machine tools series…etc with own brand “7-HERO”.
Lately, we promote new product, Knurling tools with new brand: “ADONAI”.
Over 40 years, our R&D Group is experienced in innovation and improvement to provide High precision quality products.
KAIFENG MACHINERY CO., LTD. was founded in 2002, and the company is located in Taichung Industrial Park, which is the biggest industrial park in the area. Our business covers Greater China, Asia, Europe and North America. “Quality, Precision, Stability, and Practicality” is the foundation of the company.
USync Inc. has over 40 years of experience in factory automation and manufacturing in the machinery and electronics industries. We have established long-term relationship with multi-national corporations such as Mitsubishi Electric Corporation of Japan, Renishaw Plc. of the United Kingdom, Balance Systems S.r.l. of Italy … etc.
Our Vision:
Applying Technologies for Increasing Productivity.
LEADWELL was established in 1980. Currently have two manufacturing bases located in Taichung and Hangzhou. In 1990 we are the one of largest machine tool manufacturers in Taiwan which also a great team full of competitiveness and cohesion. Our mission is to constantly search for excellence and gain respect in the industry and provide high-quality and high-efficiency products.
Also, we looking forw
Speed Tiger Precision Technology Co., Ltd. was founded in 1998. Our main target is to create a long lasting partnerships based on high quality service and top performance carbide endmill. We will become a "supplier of technical knowledge in the cutting field", and provide outstanding service to various fields, in order to meet the needs of customers around the world.
HEIDNHAIN products are primarily used in high-accuracy machine tools as well as manufacturing and processing systems for electronic components. Thanks to its extensive expertise in developing and manufacturing encoders and controls, HEIDENHAIN is in an excellent position supplying critical and innovative industries, including machine tools, electronics, robotics, medical, elevators, & metrology.
Fair Friend Group (FFG) was established in 1979 with the founding principles of reliability, growth,continuous advancement,best in quality,and strive for excellence. FFG consists of three major divisions of businesses: (1) Machine Tool Division, (2) Industry Equipment Division and (3) Green Energy Division.
With over 40 years experience, You Ji has obtained customers' support in design and quality of machine. There are many machines to meet customers' different needs. Table diameter from Ø200 to Ø8000mm. You Ji is the first machine manufacturer to have passed CE and EMC and to have begun sales in the European market, and is the biggest vertical lathe and floor borer manufacturer in Taiwan.
The Manford group owns five companies in Taiwan, including Manford, Winford, Avemax, Automac Smartauto and Manford Guarding Co. Ltd.
Our product range is wide. We produce 5 axis machining centers, Double column, Vertical machining centers, Horizontal machining centers, Tapping center, CNC lathe.
A multi-talented R&D team is able to integrate advanced design into products, as well as supplying mac
JAINNHER MACHINE owns nearly 40 years extensive experiences in grinding filed and develop completely machine series which can fulfill various demand. The great quality, precise accuracy and good service made our good reputation. We have consisted of 130 employees with full energy and ambitious to satisfy various customer’s requirement. We are capable to be your trustworthy solution partner!
It’s highly involved in manufacturing of ballscrews, precision ball screw spline, linear guideway, ball spline and actuator, which is the critical component of precision machinery and mainly applied to Machine Tool, Electric Discharging Machine, Cutting Wire Machine, Plastics Injection Machine, Semi-conductor Equipment, Precision Orientation Equipment and other equipments and machines.
Theta Precision Co., LTD was established on 21 September 2005, our factory is in No.12, Ln. 191, Sec. 1, Minsheng Rd., Daya Dist., Taichung City 428, Taiwan (R.O.C.). We are professional factory for high speed, high precision, and high quality of spindles. We could offer customers the special size of spindles and technical support and integrated plan of machines. We also set up maintenance departm
Established in 1978, Falcon Machine Tools Co., Ltd. is an innovative, Taiwan-based CNC machine manufacturer with facilities in the United States (Chevalier Machinery Inc.) and agents in Europe, the Middle East, Mainland China and South America.
The company is publicly traded on the Taiwan Stock Exchange.
Since our company was founded in December 1986, thanks to the support of Taiwan machine tool industry and manufacturing industry, our business can develop smoothly. We would like to express our deep gratitude.
Taiwan FANUC Corporation has worked devotedly to provide customers with the best services as the goal, and hope that you will continue to support.
Apart from selling FA products, CNC syste
OSCARMAX has had 30 years of history since being established in 1985. Over many years, OSCAMRAX has been totally dedicated to design and manufacturing of electrical discharge machines. Our objective is to subvert the general impression of low machining speed of EDMs. Therefore, we have spent great efforts in developing high speed EDM machining technology, where to create the best results in speed,
Kenturn has been designing, manufacturing, fabricating and marketing machine tool spindles of all kinds since 1983.
The company prides itself on intensively studying spindle design and producing innovative technology.
It is always improving design and manufacturing teamwork. Kenturn's innovation and initiative guide its planning.
EVERISING has been specializing in mid to large size band saws and circular saws since 1982. Our R&D innovations have yielded constant break-through over the years. With two factories in Taichung, Taiwan, and another in Kunshan, China, yearly output is in excess of 2000 units. In Taiwan, sales offices are established in Taipei, Taichung, Tainan, and Kaohsiung. China has over ten branch offices and service centers throughout, providing complete pre-sales and after-sales services with full-scale sawing technology. Everising has more than forty sales distributors around the world, and our equipment can be found in over sixty countries worldwide.
Vision Wide’s core value is based on customer demand-oriented to realize social values. Through the manufacture of products, we continue thinking how to provide customers with more valuable products and services. So we define customer satisfaction, value contribution and social responsibility as our direction.
Established in 1981, Chien Wei takes “steady on sincerity, attentive to management and devoted to perfection” as : “technique innovation, pursuing excellence in quality, and customers satisfaction” to approach the “prompt delivery and zero-defection.” Under the managements stratum and the hard work of its employees.
Wire Cut EDM Manufacturer | AccuteX
"TECHNOLOGY", "EXCELLENCE", "INTEGRITY"
AccuteX CNC Wire Cut EDM - AccuteX has been playing a EDM machines leading role in machine tool, AccuteX-industry since it was established many years ago. Under AccuteX motto of Customer is always right, AccuteX machine tool is the best !
AKIRA SEIKI was founded in 1985, specializing in the production of machine tools, and established a production factory in Taiwan in 2005.
AKIRA SEIKI has expanded our market to over 50 countries worldwide.
Acrow Machinery is a specialized manufacturer of precision toolholders; has been working in this industry for more than 30 years.
In recent years, Acrow have developed ultrasonic toolholder which is widely used in various industries, applicable industry including: Ceramic, Sapphire, Tempered glass, Composite materials, Semiconductors, and other special precision machining.
CASTEK Mechatron IND. Co., LTD is established at 1987,
expertise in manufacturing EDM drilling machines. Our main clients are from wire-cutting molds, lubricant holes of heat treatment parts (with angles), special small holes for electronics and spare parts processing, ex：spinneret, spraying nozzle… Base on stable and excellent generator, machine performances, our strong team and customers’ trust,
LI-HSUN INDUSTRIAL CO., LTD. was founded in 1978 and moved into the Taichung Industrial Park in October 2003 with 1,682 meters of factory and company premise. We always adhere to the operational principle of "Looking for high quality, utility and innovation" to provide our customers with the best product service.
Winson Machinery Co., Ltd. was established in 1980, and it has been a leading company in foundry over 30 years in Taiwan. We are specialized in large machine tool castings, ductile iron and grey iron castings. In 2013, we expanded our factory floor area to 39600m2 and increased our production capability up to 4000 tons monthly.
Moreover, we not only continuously improve our casting quality, but
Senday Enterprise Co., Ltd., is a professional lathe manufacturer established in 1975. With quality, technology and after-sales service as core values, our industry-leading technology and commitment to excellence our products have won the trust of local as well as international customers and distributors. By letting our quality speak for our r
Established in 2000, Win Ho Technology Industrial Co. has been providing supreme quality Lathe Machines for local Taiwanese customers and also for clients from Germany, Netherlands, Italy, USA, Canada, Australia, New Zealand, Vietnam,Singapore and Indonesia and many other customers across the globe. As a leading manufacturer of Machine Tools in Taiwan, Win Ho offers the largest selection of Lathe.
CHUMPOWER was established in 1981, nearly 41 years in the chuck industry, our customers are famous dealers of machine tools and metal manufacturers around five continents. Our products are all made in Taiwan, produced by ourselves. Including drill chuck, tap chuck , spindle system , tool holder , pull stud, collets, milling cutter…and so on. No matter what you need , we are the best choice.
Hardinge is a global leader in the design, manufacture, and distribution of precise, advanced metal-cutting machine tool solutions. We work tirelessly to help make today’s manufacturers and job shops more productive and more profitable. As manufacturing demands increase, so do we. Bringing innovation, precision, and accuracy to the most demanding applications.
With locations, employees, channel pa
The Company was established in 1991, We specialize in manufacturing precision machine vise, hydraulic vise, Drill Re-Sharpening Machine and Machine tool accessories.
We insist the Principle "A workman wants to do his work well must first sharpen his tools " to Make a product, Our equipments: CNC machine center, milling machine, grinding machine etc. Those precision machines and the Perfect Proces
SEYI is a leading brand of middle and large servo presses with a global presence. Our main customers are spread across various industries, including automotive, aerospace, medical equipment, home appliances, consumer electronics, and hardware manufacturing. With cutting-edge innovation and advanced technical know-how, SEYI creates compelling niche value for all its customers.
Etablished Tao Chen Industrial Enterprise in 1972 and changed the company name into existing Toa Dr Enterprise Co., Ltd. in 1983, converting his business from processing services to a product-making plant. With 49 years of continuing progressing, the company has now become increasingly specialized in the manufacturing of metal slitting machines and relevant whole-plant sale in Taiwan.
Buffalo Machinery supplies a wide range of products, divided in two brands. MICROCUT, the original brand since 1983, covers most of the product lines and aims to deliver quality machines at competitive prices focusing on the relationship with the dealer and the end-user. AXILE, the high-end brand was launched in 2017, is conceived to cover the premium market of 3X and 5X high-tech machining center
Maple was founded in 1989 by a man that wanted to find better way to produce parts that can be more cost effective and a faster way then the current method that is being used. Today, Maple builds not only cnc machine tools but also provide added value solutions to help advance every individual customer production needs.
We are a professional manufacturer specialized in producing Milling accessories since 1978. Our product range covers various kinds of machine tools- CNC workholding equipments: Five-axis Vises, Multi-Power Mechanical Vises for CNC machining Centers, Permanent Magnetic Vises, Pneumatic Vises, Tooling Columns (Tombstones), Precision Index Tables, Rotary Table, Dividing Head, Super Divider, etc.
WELE is a professional CNC machine builder in Taiwan. We provide total solution to satisfy customers' demands. Wider range of product line and its X axis stroke range from 0.5meter to 20meter. More detail information shows in our official website.
Maho Enterprise Co., Ltd. was established in 1984, and accompanies with the trade marks TRADE MAX to all over the world. To construct long-term cooperation relationship with our clients, Maho got reputation from the tapping field that had many exclusive monopolies.
Maho was specialized in Pneumatic tapping machine, Hydraulic tapping machine, Electric tapping machine and relative accessories.
Jar Hon provide wide range of tapping & drilling solutions for many industries and other special needs.The quality of machines is guaranteed and its durability is unquestionable. The after-sales service provided in order to adhere the concept of "keeping quality" and "doing still better".
Shung Dar Industrial Co., LTD., since 1982, is a steel coil stamping processing equipment manufacturer based in Taiwan. CE, SGS & ISO 9001 certified, blanking Line system technical partnership with Japanese press manufacturer AIDA, and German press manufacturer Heilbronn, Shung Dar's machinery is sold in over 30 countries with solid reputation.
Based on industry 4.0, Shungdar‘s press equipment is
MYLAS was established in 1985. Headquartered in Taichung, the company started from the Auto Lathe Series which has sold more than 65thousand machines worldwide. In 1999, the Jiangsu branch was established to target the market in China. In order to satisfy the skyrocketing demand, the Shengang branch was founded in 2004. We offers simple lathe, dual spindles, double turret types CNC machines.
JIH-I Machinery Co., Ltd was founded in 1971. Since 1995, in order to meet the market demands, we have introduced the high-speed cut-off saw, NC fully automatic high production saw, CNC machining center, 45 degree double-saw angle cut saw, NC 45 degree cut-off saw, hydraulic press, copy milling machine, and material processing machines.
Established in 1984, Axisco Precision Machinery Co., Ltd. built its name by helping customers in more than thirty countries with broaching turnkey solutions. The solutions include electrical-mechanical table-up broaching machines, CNC helical broaching machines, hydraulic internal broaching machines, hydraulic surface broaching machines, broach tools, fixtures, training, etc.
Shin-Yain Industrial Co., Ltd. specializes in manufacturing precision tool holders, collets, angel head holders, boring heads and cutting tools. SYIC is certified to ISO9001 and ISO14001 and has over 300 pieces of patents worldwide. With the core value “Quality creates reputation; reputation ensures quality,” SYIC will launch more precise and premium products to customers.
We are the largest specialized bronze and stainless casting and manufactures factory in Taiwan. Our main products are casting bronze alloy for machine tool industry and stainless steel. Over last thirty year, assuring our clients of high and stable quality, we constantly introduced high quality equipment, advanced technology and precision inspection instruments into our company.
The Largest Professional Rotary Table Manufacturer
detron is committed to designing and engineering the highest quality NC rotary table products, through the experience, dedication and innovation of our International R & D team. Our mission is to understand and support our customer's needs with advanced application technology, with a wide range of products, providing optimum performance. Through
ECOM Founded in 1976, specializes in machine tool manufacturing. ECOM machine tools have been recognized worldwide for superior precision, outstanding rigidity, and exceptional reliability. ECOM product covers CNC Vertical Machining Center, Horizontal Machining Center, Tapping Center, and Bridge Type Machining Center. We dedicated to provide our customer with reliable machines and best services.
TOYO Established in 2000,we have over 20 years of experience specializing in the development
of professional miniature robots.In the last few years, we have been engaging
to invest resources to the industrial circles,intent to connect with the ambitious mission of industry 4.0.
Toyo Automation Co., Ltd has a fully intergraded manufacturing process, include Linear actuator module,Servo Cylinders,
“To create a performance and create a win-win situation”. Kai Hung was founded in 1991, and specializes in the design and manufacturing of CNC multi-spindles trunnion/ horizontal rotary transfer machine, automatic assembly stream line, customized equipment of valve/sanitary/gas parts processing, automation production line for automobile parts.Kaihung insists on
GRINTIMATE PRECISION INDUSTRY CO., LTD is a world-leading designer and specialized manufacturer of high-precision grinders. We have developed exclusive technologies for hydrostatic spindles, hydrostatic rotary worktables, and hydrostatic guideway modules that could widely used in machine tools for a wide variety of applications
Golden Asia is a professional manufacturer of cylinder tube, hydraulic pipe tubing, seamless carbon steel, hydraulic tubing, seamless tube, cylinder chrome rod, hard chrome bar, hydraulic piston rod, hydraulic shaft, piston shaft, hard chrome plated steel bar, induction hardened chromed shaft and precision stainless tube/rod for heavy machinery, the industry of hydraulics, mining and agricultural
Yih Kuan Ent Co., Ltd., it was established from 1977. At first, the company name is “Hung Yih Machinery Factory”. We are the first milling head company that get ISO9001 quality management certification and CE production quality certification. Now we are the leader of the milling head manufacturers in Taiwan.
YIH KUAN dedicated to make Gantry,CNC,Turret,Angle milling heads.
The Production Site of a Tier 1 Factory, Waysia Industrial Co., Ltd. was established at Ming Hsiung Industrial Area, Chiayi, Taiwan in 1991. It is a wholly owned subsidiary of Meita Group.
At the beginning stage of its establishment, the company was engaged in the design and manufacturing of special tools, jigs, and fixtures, metal cutting machines and special-purpose machines.
YING SHUN is a professional milling machine manufacture and has a professional team, management skills & production efficiency.
The complete product range includes Knee type, Vertical & Horizontal, Bed type, CNC milling machines.
Over the years of milling machine tool manufacturing experience, we established a strong foundation in the field of machinery.
“Pursuit for outstanding quality and continuous improvement. Upgrade competitive advantage for everlasting business” has been the entrepreneurial spirit of Yeh Chiun Industrial Company since our inception in 1984.
Rich Rewards Interprise was established in Taichung since 2005, with more than 30 years of experience in export sales of machine tools, mechanical standard parts, molding and clamping system equipment. Possess a wealth of professional knowledge of machine tools, specializing in providing customers with excellent and reliable products; familiar with Taiwanese machinery manufacturers and maintaining
LIS Automatics was established in 1979 in Taichung, the very heart of Taiwanese machine tool industries. In the past 40 years, LIS already became the sole designer and manufacturer of many machine tool builders at home in Taiwan and abroad. We keep expanding and innovating our product lines to meet the constantly changing demand of metal cutting, forging, and plastic injection machine tools.
J&M Media Corporation adheres to the concept of "pursuing innovation, serving with heart" and the spirit of dedicated service. We offer the customized integrated marketing plans, provide website, visual design and CIS, public relations activities planning. To effectively promote product marketing and build your own image are what we do.
Nano-Mill Technology Co., Ltd has been established since year 2000. Nano produce a wide range of high quality Carbide cutting tools. The production is specializing in high hard, high speed and soft metal cutting Solid Carbide End Mill. We supplied end mill made of the best material from Germany and manifested by modern CNC grinding machines from Switzerland ‘Rollomatic’ and Schneeberger.
Hai Ju is dedicated to introducing international advanced fasteners and assembly systems.
We are the authorized agent of world-renowned German Bollhoff Group, including the leading brand Helicoil© thread inserts.
We also offer various worldwide innovative high-precision products, such as US ACME、US E-Z LOK、HjtCoil to meet customers’ different needs .
WORLDMAX started making woodworking machines in 1954 and started manufacturing metal sanders in 1980.
We provide quick and safe processing equipment for surface treatment, especially for burr or welded marks generated from laser cut, waterjet, plasma cut, welding and punching. Metal sanders have wet-grind and dry-grind types.
Selica International Co., Ltd. is a company including active and professional teams who offer a large variety of machine tools in Taiwan. Our team have great experience on manufacturing and exporting and also have great relationship with its suppliers which can offer high quality machines with competitive price to meet customer’s demand.
Since the founding, Tung Cherng committed to provision of fine quality, sensible pricing and swift services to the clients has been thriving, so it is our anticipation to meet the clients’ demand for high-quality mechanical tools made in Taiwan with our experiences and techniques over the years.
WELLTECH Machinery Co., Ltd. was established in 1996, specializing in the machining/manufacturing/sales/rental of CNC machine tools. Vertical lathe, vertical turning and milling compound processing machine.
The main customer groups are precision machining industry, automobile and motorcycle parts industry, electronic communication industry, aviation parts industry, ship parts industry, etc
Wei Fong Precision is a professional supplier of mechanical components and high accuracy transmission parts in Taiwan.
With over 35 years of experience, our products have been applied in multiple industries, such as CNC machine, woodworking machine, sports equipment, 3D printer, storage facilitate …etc.
Leadrank Co., Ltd. established in 1990, specializes in grinding, polishing, cutting, drilling, and deburring tools, is a professional manufacturer of diamond grinding wheel, CBN wheel and Aluminum oxide and Silicon Carbide wheel.
We welcome the mutual cooperation.
For more detailed information, kindly visit another website below：
https://diamondtool.en.taiwantrade.com
Jigs manufacturer
PROMPT is a young, dynamic and professional manufacturer of machine tool, our sales network has extended to over 30 countries around the world.
With complete structure of software and hardware, we conduct strict quality control to achieve maximum working efficiency.
We put great efforts on creating mutual benefit. In 21 century, it is expectable to see more improvement
& development of PROMPT.
Xin Gong Yang was set up in 2017. This company consisted of a group of outstanding technicians from Gong Yang Machinery Company which was a time-honored manufacturer on milling heads. Oh Yang is specializing in the manufacture of right angle milling heads and boring milling heads as the accessories for gantry milling machines, single arm milling machines and special purpose machines.
Sharp One Co.Ltd, has a team of dedicated engineers with more than 10 year's experience in designing,develoment,manufacturing and marketing of drill bit grinding machines.
We studied end users requirements from around the world and the advantages and disadvantages of each brand to develop our own state of the art multi-purpose drill bit sharpening machine-As a result the all new simple to
Our company specializes in encoder sales for more than ten years,And distributed encoder products for several years,For the application of the encoder, installation design, refurbishment machine installation, and accuracy verification are all provided with related services.Can help customers improve product competitiveness, reduce costs, save installation space, improve positioning accuracy .
Providence Technology Co., LTD was founded in 2006. “ High quality, High stability, High accuracy," is our purpose. To maintain the best quality is on our main thinking for sustainable management.
We took a serious attitude about quality control. The serious thinking "better than better” is the basic requirement for our products and employees.
「AGILE WING SMART MANUFACTURING CO.,LTD」Founded in January 2019, the original intention of the establishment: to build an unmanned lighthouse factory for customers, move towards Industry 4.0, and take a big step for the industry!
TANGRAM CO., Ltd combine IT,OT engineers and telecommunications talents in various fields to create the unique TANGRAM and launch a series of relevant IoT products, hoping to solve the integration issues faced by machine tools used across different fields.
Special for Difficult-to-Cut Materials processing, Titanium Alloy processing etc.
Features:
High-Rigidity structure design. Mechanical-type Simultaneous Two-Axis rotary spindle. Warm and gear transmission for B and C axes. With self-made heavy-cutting two-stage gearbox design (Gear Ratio by 1:1.75 and 1:7). Maximum Torque: 1155 N-m.
Unique patented design of the Z-axis spindle rail structure - vibration restrain in machining. It can largely reduce the vibration in machining hard-to-cut material, enhance the machining efficiency, reduce the surface roughness, and prolong the tool’s life. (Model S5A-HH exclusive)
Fully Splash Guarding design. Super large and wide working door design. Fashionable aesthetic and ergonomic safety design.
Specific design of safety guardrail upon the cross column. Convenient for machine maintenance.
Height-adjustable manipulation control box. Suitable for people of different height.
本公司生產之鑽床鑽孔機油壓自動HD-POM750，具有下列特點:1. 益彰公司所生產之宏達牌自動鑽床鑽孔機(油壓自動進刀)，系列機型分為2型: (1) A型 : 多段退屑型-針對鑽深孔。 (2) B型 : 單段進刀型。2. 本系列機型擁有台灣及大陸兩地專利肯定。3. 可無段變速進刀，操作靈活方便。4. 快速進刀時穩定性高，確保優良工作品質。5. 深孔作業時，可無限次退屑，鑽頭不易扭斷（A型）。6. 退屑後可快速歸位，大幅節工作省時間，提高生產量。7. 本系列機種擁有定點延時退刀裝置，深度精準。8. 可配置腳踏控制器，提供使用者多樣的操控選擇。9. 冷卻系統為選配。10. 產品100%台灣製造。更多操作影片請連結 : https://goo.gl/uQZZOJ
本公司生產之多軸鑽孔攻牙器-QU/QNU型，具有下列特點:1. 最長銷機種，業界唯一使用日製萬向接頭，操作方便使用壽命長。2. 接受特殊規格訂製。3. 產品100%台灣製造。更多操作影片請連結 : https://goo.gl/uQZZOJ
本公司生產之攻牙機齒輪式自動HD-AT12/HD-AT19，具有下列特點:1. 益彰公司所生產之宏達牌自動攻牙機已獲台灣及大陸兩地專利肯定。2. 本機以齒輪制動，可精確設定攻牙深度。3. 牙距齒輪採墮輪式設計，更換方便迅速。4. 針對量產考量，主軸皮帶輪採特殊設計，大幅減少馬達正反轉所產生之過熱現象。5. 機體結構上採特別強化設計，攻牙精準穩定，可將螺絲攻之耗損降至最低。6. 操作簡單、維護方便，可確保生產線之正常運作。7. 產品100%台灣製造。更多操作影片請連結 : https://goo.gl/uQZZOJ
Wide Applicability, Modular Design, High Scalability
Central chip removal system avoids thermo focus on working area
High rigidity bed body with X axis high/low guide way design
．Tool Magazine: 40 Tools (STD.) ; 60, 120 Tools (OPT.)
．Tool Change Time (T-T): 3.7 sec.
．Pallet Change Time (P-P): 10 sec.
．BT40 Spindle: 10,000 rpm belt driven
．Acceleration: 0.6 G
．Central Removal System
Click the link below for more information:
https://www.yidacnc.com/product_d.php?lang=en&tb=1&id=322
PF-8S1500CNC Bed type 4-axis vertical Bedtype milling machine developed by PAOFONG.Table size: 1730 x 400 mm ) Travel: X = 1500 mm Y = 500 mm Z = 550mmSpindle Taper: NST#40 Machine.It is mainly used for machining of largeCentroid 4 Axes CNC Table and heavy-duty chip removal capacity. This large machine bed is developed for large-sized 4th Rotarl Table.Table design It is built with premium cast-iron .
Most Popular High Performance NSV106AS is well suited for superior surface finishing works, specially in automotive, job shop and electronics industries. ￭ Large delta machine column and base ensure the highest stability during high speed movement￭ High precision roller type guideways on all 3 axes￭ High precision linear guideway with 6 slide blocks on X-axis￭ High performance YCM in-house designed spindle with low vibration to achieve excellent finish
NFX400A is designed especially for small, complex high-quality parts mainly for aerospace, automotive, medical, job shop and die & mold applications￭ Extra wide column and base design to ensure best support and cutting rigidity.￭ Increased tool life by cutting with belly and edge of the tool￭ Reduce fixture error and improve workpiece loading and uploading time￭ Greatly reduced non-cutting or setup waiting time￭ Saves manufacturing cost with reduced fixture and electrode costs.
High rigidity and high accuracy NH500A provides the best solution for automotive, precise and mechanical parts industries.￭ High rigidity T-base foundation with rib construction￭ One-piece casting spindle headstock and dual-wall column design￭ Powerful Built-in spindle with Micro oil-air lubrication for angular ceramic ball bearings prolongs spindle life￭ High precision roller type guideways on all axes￭ High precision pallet indexing system.
THW-2080/3080 is designed and developed based on Matrix’s experience of many years in gear cutting tool manufacturing. THW-2080 is built on a base of a highly rigid, high quality cast iron to perform with pin point accuracy. THW-2080/3080 applies the most advanced technologies available around the globe. With Fanuc CNC controller, a direct drive motor, a linear motor and servo motors, THW-2080/3080 is able to deliver the accuracy, reliability and precision for double lead grinding, tapper thread grinding, single flank grinding, dual pressure angle grinding, plug thread gage, rolling die, crusher roller, etc.Matrix has developed its own Windows-based software program for THW-2080/3080. Using an advanced Windows-based, user-oriented interface, THW-2080/3080 can generate and archive practically infinite number of different profiles and grind/ dressing cycles easily by data input. The flexible dresser can profile the grinding wheels for standard worms, as well as profile the multi-rib grinding wheels for thread grinding with tip and root modifications. THW-2080/3080 can also grind pump rotors. We highly recommend THW-2080/3080 for your worm and thread grinding applications.
GHP-3540 is designed and developed based on Matrix’s experience of many years in gear cutting tool manufacturing. GHP-3540 is built on a base of highly rigid, high quality cast iron to perform with pin point accuracy. GHP-3540 applies the most advanced technologies available around the globe. With FANUC CNC controller, a direct drive motor, a linear motor and servo motors, GHP-3540 is able to deliver the accuracy, reliability and precision a gear expert is looking for.Matrix has developed its own Windows-based software program for GHP-3540. Using an advanced Windows-based, user-oriented interface, this software requires only the final gear data and all other CNC data is calculated automatically. GHP-3540 is a highly technical and highly precise gear grinder that gear grade of DIN 4 (AGMA 14 or JIS 0) can be achieved for standard gear profile at ease.
The GVP-8040 is built with some of the most modern technology available, such as an advanced 8-axis CNC controller with a closed loop servo control system, integrated with an industry computer, and a direct drive motor, all of which Matrix utilizes to achieve very high precision over long periods of use. The GVP-8040 includes Matrix’s most technologically advanced smart Windows-based and user-oriented interface to date. This software provides the user the ability of design flexibility for modifying gear profiles and specifying grinding conditions. Matrix has developed this software so that the operator just needs to key in the required gear data in an easy step-by-step process on our Windows-based user-oriented interface. No other numerical control programming knowledge is required since the entire program is generated automatically within the software.
The ZHS-3040 is an extremely versatile machine. With Matrix’s available software and fixtures, the ZHS-3040 can sharpen straight or helical gashed hobs, shaper cutters and can even grind gears achieving AGMA class 14 (DIN 4) accuracy. The ZHS-3040’s base is constructed of a highly rigid, high quality cast iron. Matrix manufactures every machine to perform with pin point accuracy and it all starts with a very stable base. Matrix builds the ZHS-3040 using the finest technology in the world. With seven axes, a CNC Fanuc controller, a personal computer, direct drive motors, servo motors and a linear motor, Matrix is able to deliver the accuracy, reliability and precision a gear expert is looking for.Matrix has developed its own Windows-based software programs for the 3040. Using an advanced Windows-based, user-oriented interface, this software requires only the final hob, shaper cutter dimensions and all other CNC data is calculated automatically by Matrix’s smart grinding software program.Matrix’s ZHS-3040 CNC hob sharpening machine is a highly technical, highly precise hob sharpener with the option of becoming an impressive shaper sharpener
DSA provides turnkey for machining automation, which is fully experienced, also, we offer complete integration solutions for hardware & software to build up a smart factory. Please refer to：www.dsa-automation.com
Labor in high-risk environments can be replaced by integrating several die-casting processes with robots. Please refer to：www.dsa-automation.com
Yao Sheng Machinery Industrial Co. is committed to developing and manufacturing shot blasting machines. We have accumulated rich experience in the field over the four decades. This blasting machine equipped with rails, hangers and hooks, by special design-ensures an even shot blasting and satisfactory treatment in a shorter time. Widely applied in surface treatment in various industrial sectors includes casting, forging, die-casting parts, automobile parts and paint industry, etc.We set up a R&D division and provide more varieties and customized machines to various industrial sectors. Manufacturing of all products is conformed to ISO standard, and we hold quite a few patents for the machine. Our product is high-functioning. This machine features the mechanism of rotation and spinning, by the special design can greatly reduces blasting time and cost. For all materials that require surface treatment.
Spindle housing diameter ： 120mmTool interface ： Quill D22/38 M22XP2.0Maximum speed ： 42,000 RPMLubrication ： Oil-AirMotor power ： 11.5/17 Kw
Spindle housing diameter ： 100mmTool interface ： HSK-E32Maximum speed (rpm) ： 30,000 RPMLubrication ： GreaseMotor power ： 3.5/5.5 Kw
Spindle housing diameter ： 210mmTool interface ： HSK-A63Maximum speed (rpm) ： 20,000 RPMLubrication ： Oil-AirMotor power ： 18/22.5 KW
Spindle housing diameter ： 170mmTool interface ： HSK-A63Maximum speed (rpm) ： 24,000 RPMLubrication ： Oil-AirMotor power ： 18/23 KW
Spindle housing diameter ： 45mmTool interface ： SD6Maximum speed (rpm) ： 50000 RPMLubrication ： GreaseMotor power ： 0.45/0.54 Kw
Matrix (Formed as Luren) was established in 1994. In these years, it developed the designing software, machine tools, gear cutters, such as, hobs, carbide hobs and shaving cutters, master gears and maintenance for the cutters.Matrix (Formed as Luren) has integrated a producing system to provide the high quality products because offer a 100% perfection products is our goal. We are not only strict control the production line, but also every product is inspected tightly. We keep to improve the producing system to face more challenges and various requests from the customers. For instance, Matrix (Formed as Luren) has developed many kinds of grinding and resharpening machines to enhance the producing efficiency.We always offer the best quality of gear cutters; widespread range of products, and fastest delivery date to satisfied the customer's needs.
40#-40T or 60T.Radiation angle design.Faster from disc to preparing-tool-change position, time-saving 60%.Extreme speed tool pot displacement, only 0.2 seconds/pot.Effectively reduce the side volume of the machine, save container space.Transmission structure heavy tool strengthening.Suitable for high-speed processing.
The tool magazine chain can be expanded and adjusted, 60T~120TFixed to the side of the machine, the lower effect of the processing accuracy.
The hydraulic pressure of the tool arm locks the tool, the overweight/long tool good performance.Fully hydraulic power.Optional vertical and horizontal tool change.Customized for various specifications of the gantry machine.
￭ Robust roller linear guideways applied on 3 axes.
￭ Rigid dual-wall castings on saddle and 6 blocks design on X-axis can easily support workpieces weighing up to 1,500 kg.
￭ 4-linear guideways on Y-axis with superior large span ensures the best dynamic balance.
￭ Large-diameter ball screws on X/Y/Z-axis directlydriven by servomotor, providing rapid feedrate up to 50 m/min.￭ 6 slide blocks on X-axis￭ High torque A/C-axis rotary table can holds a max. workpiece size of ø650 x 400 mm with 300 kg weight.￭ Complete thermal solutions against thermal
-Strong structure design of spindle: cross roller bearing is used as exclusive design of bearing for vertical lathes
-High rigidity column: Once piece column with wide span box structure design provide more stability and reduce vibration
-Excellent machining performance: Honor patented powerful clamping system - "Solid Lock" provides high accuracy for heavy-duty cutting and reduces tool vibration, and machine productivity as well
-For more information, please contact us.
honor@honorseiki.com
-Multiple turret types to fulfill various application
-High-Reliability Spindle: 100% spindle balancing process offers high durability. All spindles are made and tested by HONOR SEKEI and feature a precise one-to-one fit
-Excellent machining performance: High rigidity column with box in box machine bed design supports great stability during processing
-For more information, please contact:
honor@honorseiki.com
Save wrapping time and improve work efficiency !
1. Tight winding of high-density PTFE tape.
2. The user-machine interface is easy to operate.
3. High safety.
4. Suitable for workpieces of various materials/sizes.
High Rigid and High Precision Machine Structure
Add 4th & 5th rotary table to increase efficiency and productivity
．X / Y / Z axis linear guideway
．Arm type tool magazine : 24 tools (STD.) ; 30 tools (OPT.)
．X / Y / Z travel: 1050 x 600 x 610 mm
Click the link below for more information:
https://www.yidacnc.com/product_d.php?lang=en&tb=1&id=178
ER8 ER11 ER16 ER20 ER25 ER32 ER40 ER50
ER Collet / ER Collet Set
OZ Collet / OZ Collet Sets - Spring Collet
OZ25 OZ32
Product Description
1. Size: BT30 BT40 BT50 - ER8 ER16 ER20 ER25 ER32 ER40
3. Standard: JIS (MAS 403)
Product Name
CNC milling BT ER collet chuck tool holder Taiwan made
Standard JIS (MAS 403)
420X420 Enlarged flange interface + large-size clutch teeth,providing excellent rigidity and repeatability.
OZ Collet Chuck Holder
BT30-OZ25
BT40-OZ25
BT40-OZ32
BT50-OZ25
BT50-OZ32
Drill Re-sharpening Machine, Portable Drill Bit Sharpening Machine
YD-213 Re-sharpening drill 2mm ~ 13 mm
YD-320 Re-sharpening drill 3mm ~ 20 mm
Controller：FANUC 0i-T
Max. turning lengthSwing over bed：660mm
Swing over saddle：620mm
Max. Turning Diameter：300mm(UZ-1500T2Y) / 310mm(UA-1500T2Y)
Max. turning length：480mm(UZ-1500T2Y) / 500mm(UA-1500T2Y)
Guide way type：Linear + Box
X-axis Travel：X1/X2 : 200mm(UZ-1500T2Y)/185mm(UA-1500T2Y)
Z-axis Travel：Z1/Z2 : 600mm
Y-axis Travel：±50mm
B-axis Travel：700mm(UZ-1500T2Y)/600mm(UA-1500T2Y)
>click here to see more specifications<
Controller：FANUC 0i-M
Spindle speed：12000 /15000 rpm
Spindle nose taper：BT40
Bearing inner diameter：70mm
Drive system：Direct
X-axis travel：500mm
Y-axis travel：400mm
Z-axis travel：550mm
A-axis travel：-30 / +120 degree
C-axis travel：360 degree
>click here to see more specifications<
High Rigidity, High Precision, High Speed
Perfect for processing polyhedrons and curved parts
Five-axis simultaneous movement finishes complex processing with single setup.
Click the link below for more information:
https://www.yidacnc.com/product_d.php?lang=en&tb=1&id=142
ML-560 series is one of Yida's most popular models.
With high-precision, heavy-duty roller type linear guideways on X, Y & Z axes, allowing the axes to move at high rapid traverse rates with high positioning accuracy due to low stickslip and low coefficient of friction.
． High stability
． High Speed
． High Process Reliability
． Slant Bed Design
． Various turrets available
． CS-axis function applicable
． Automation equipment available
Click the link below for more information:
https://www.yidacnc.com/product_d.php?lang=en&tb=1&id=94
Controller： FANUC 0i-T
Swing over bed：660mm
Swing over saddle：620mm
Max. Turning Diameter (SP1)：320mm
Max. Turning Diameter (SP2)：320mm
Max. turning length：790mm
Guide way type：線軌+硬軌
X-axis Travel：X1/X2 : 210mm
Z-axis Travel：Z1/Z2 : 840mm
Y-axis Travel：-40/+60mm
B-axis Travel：920mm
>click here to see more specifications<
Controller：FANUC 0i-T
Swing over bed：380mm
Swing over saddle：320mm
Max. turning diameter：180mm
Max. turning length：175mm
Guide way type：Box
X-axis Travel：120mm
Z-axis Travel：230mm
>click here to see more specifications<
Controller：FANUC 0i-T
Swing over bed：505mm
Swing over saddle：318mm
Max. turning diameter：300mm(JT-150)；230mm(JT-150M)
Max. turning length：310mm(JT-150)；200mm(JT-150M)
Guide way type：Linear
X-axis Travel：195mm
Z-axis Travel：350mm
>click here to see more specifications<
Controller：FANUC 0i-T
Swing over bed：455mm
Swing over saddle：260mm
Max. turning diameter：280mm(UL-20)；180mm(UL-20M)
Max. turning length：600mm(UL-20)；500mm(UL-20M)
Guide way type：Box Way
X-axis travel：175mm
Z-axis travel：625mm
>click here to see more specifications<
Controller：FANUC 0i-T
Swing over bed：680mm
Swing over saddle：485mm
Max. turning diameter：240mm(UT-200Y)；155mm(UA-200Y)
Max. turning length：440 mm/ 365mm(UT-200Y)；500mm/425mm(UA-200Y)
Guide way type：Box Way
X-axis Travel：220mm
Z-axis Travel：600mm
Y-axis Travel ：±50mm
>click here to see more specifications<
Controller：FANUC 0i-T
Swing over bed： 850mm
Max. turning diameter： 750mm
Max. turning length： 700mm
Guide way type： Linear (Box way)
X-axis Travel：420mm
Z-axis Travel：800mm
>Click here to see more specifications<
1. IK milling heads can help you upgrade or replacement your original machine body, milling machine or special purpose machine.
2. Chrome quill with super precision preloaded bearing can bring the high quality cutting benefits for machine and we also offer P4 bearings for your optional.
3. Machining travel can up to 127mm (5").
4. This product of standard spindle type is NT30, we also offer R8 for you to optional.
5. There are 11 models in IK Turret Milling Machine Head Series.
🔥Specially designed for the high speed machining market.
🔥High-speed direct-drive spindle( #DDS) is the new trend in the future.
🔥Efficiency, precision, quality, rigidity and great price, all satisfactions in one machine
1. IK milling heads can help you upgrade or replacement your original machine body, milling machine or special purpose machine.
2. Chrome quill with super precision preloaded bearing can bring the high quality cutting benefits for machine and we also offer P4 bearings for your optional.
3. Machining travel can up to 127mm (5").
4. This product of standard spindle type is NT30, we also offer R8 for you to optional.
5. There are 11 models in IK Turret Milling Machine Head Series.
●Machine designed with finite element analysis to
ensure the high rigidity and best structural
optimization, also provided with high precision
machining performance and stability.
●Three axes are roller type linear guide way
(35/35/45 mm); the Z axis has no counter weight
needed in order to enhance the machine stability.
●Direct drive spindle with the speed of 15000rpm –
BBT.
●Automatic pneumatic magazine door, linear
guideway, precise and stable feed and prevents
coolant going into the magazine.
●Automatic lubrication on three axes ball screws,
effectively prevent oil deterioration, and reduce the
heat generation and thermal expansion during high
speed machining to achieve high speed and high
precision.
●Three axes federate can reach the maximum of
1.0G.
●Equipped linear scales in three axes, which can
make compensation for the thermal displacement
during high speed operation, effectively improving
the accuracy of three axes.
1. Improve tools life and cutting efficiency, especially ideal for particular process requirements of brittle or hard、 high-temperature superalloy and composite materials.
2. Increased precision and quality of the workpiece to achieve excellent cutting results. (smooth edge)
3. Perfected ultrasonic control technology for easy selection, automatic frequency, and power adjustment.
4. The strong chipping of chassis concentrates the chips into the path as ensures high efficiency.
5. Anti-scale cover + KEVLAR armor material, used in glasses, ceramics super hard metal processing which can preventing dust protection system effectively.。
Gantry Type Structure
-Designed with a gantry type structure, the Feeler U800-5AX 5-axis machining center has the feature of spacious machining space, allowing large workpiece to be loaded and unloaded with ease. It is also convenient for operator to check the current machining condition at any time.
U-shaped Construction of Base and Column
-The advanced U-Shape structure significantly increases structural rigidity and machining accuracy.
-X.Y.Z axis rapid traverse rate reach 48m/min.
- Suitable for equipping with a large diameter of rotary table.
Three Axes Overlap and Separated from Two Rotary Axes
-This design avoids a distance between the machining point and the intersection point of two rotating axes.
-Easy to compensate for the errors of radius on rotating axes and movement on three linear axes to ensure the machine's stability and accuracy.
Separated Design for Three Axes Moving Area and Machining Area
-This design feature not only makes chip removal more convenient, but also enables better chip-prevention capability of the machine.
-The rotaary shaft speed is increased by 800 rpm, which makes the turntable have a high-speed turning function.
Precision spacers and shims are mainly used in precision slitting machines, and can also be assembled on various machine components that require precise dimensions. Design and manufacturing can be discussed according to the dimensions required by customers.
Slitting line customized type could combine multiple ideal designs into a tailor-made line for each client.
TOA DR Made slitting lines could help clients slit copper well and other strips, such as stainless steel, silicon steel, Titanium, etc. which just need different kinds of slitter knives to use.
Bakelite fingers could be made to order for the best slitting quality.
1. This series is design for boxway guideway and high rigidity.
2. Equipping with powerful gear type spindle provides high performance heavy cutting.
3. This AA series machine's axes travel as
X axis: 900~2500mm
Y axis: 650~900mm
Z axis: 600~900mm
Specially designed cutting way : After the saw blade moves forward for cutting, table moves to right and left for retracting 2 mm.Then the saw blade return to its home position. This special design may avoid return-cutting, while ensuring fine surface of cut and cutting accuracy.
ST-3500 is an induction heating machine and water cooling station with high precision, high efficiency, energy-saving, and environmental protection.
According to the principle of thermal expansion and contraction, the tool and the tool holder are sintered seamlessly to obtain high-precision performance_ also, by using low-powered heating can prolong holder life, and the unique integrated design of heating and cooling can save space.
Based on the safety and convenience of use, the rail base design omits the need to move the holder after heating, thereby reducing the risk of burns to the user by the high-temperature holder. ST3500 uses a circulating cooling design, using the water-soluble and non-toxic coolant liquid not only to remove surface dirt but also to rust-proof. Moreover, it can re-use for green processing.
【Features】
1. Generate an alternating electromagnetic field by using 3.5KW high-frequency thermal coil. Refer to the heating timesheet, it's easy to load and unload tools just need to set the diameter and heating seconds.
2. Prolong holder life by using low-powered heating and water cooling.
3. By water-cooling with coolant, it can clean most of carbon deposits and prevent the chuck become rusty.
4. Use with Speed Tiger Shrink Fit Chucks and Power Tips Series, will show the maximum performance and economic benefits of shrink system.
5. Combine 2 functions in 1 machine: Operate heating and cooling process at one machine, i.e. no need to remove the base. Operating time within 1 minute and use friendly.
ST-3500 Full Panorama Photo
https://scankit.istaging.com/P1000266/P1000266.html
https://scankit.istaging.com/P1000268/P1000268.html
1. Double blade miter ±0º-45º Automatically.
2. Positioning cutting length automatically.
3. 3 Axis control by servo control.
4. X axis moving by lingering guide way ensure accuracy for positioning.
5. Mobile saw could be feeding and cutting automatically(optional).
2. Positioning cutting length automatically.
3. 3 Axis control by servo control.
4. X axis moving by lingering guide way ensure accuracy for positioning.
5. Mobile saw could be feeding and cutting automatically(optional).
X/Y/Z travel : 850(Opt.950)/426/400mm
Spindle taper : R8/NT30(Opt.NT40)(Ø85)
Spindle motor : 3HP
Hardened ground-X/Y
Square way-Y
X/Y/Z travel : 800(Opt.900)/426/470mm
Spindle taper : NT40(Ø105)
Spindle motor : 5HP
Hardened ground-X/Y/Z
Square way-Y/Z
X/Y/Z travel : 860(Opt.1000)/426/470mm
Spindle taper : NT40(Ø105)
Spindle motor : 5HP
Hardened ground-X/Y/Z
Square way-Y/Z
X/Y/Z travel : 750(Opt.850)/440/460 mm
Spindle taper : NT40(Ø110)
Spindle motor : 5HP (Opt.7.5HP)
X/Y/Z travel : 1000(Opt.800)/420/400 mm
Spindle taper : NT40(Ø110)
Spindle motor : 5HP (Opt.7.5HP)
X/Y axis servo motor
1. Saw Tilting 0 ~ 45˚ Degrees Automatically.
2. Worktable Rotary ±0 ~ 67.5˚ Degrees Automatically.
3. Positioning Cutting Length Automatically.
4. 5 Axis Control By Servomotor, Operation By Touch Screen.
5. X Axis Moving By Lingering Guide Way To Ensure Accuracy For Positioning.
6. Mobile Saw Could Be Feeding And Cutting Automatically.
＊Optional Auto 3000 Mobile saw could be feeding and cutting automatically.
2. Worktable Rotary ±0 ~ 67.5˚ Degrees Automatically.
3. Positioning Cutting Length Automatically.
4. 5 Axis Control By Servomotor, Operation By Touch Screen.
5. X Axis Moving By Lingering Guide Way To Ensure Accuracy For Positioning.
6. Mobile Saw Could Be Feeding And Cutting Automatically.
＊Optional Auto 3000 Mobile saw could be feeding and cutting automatically.
X/Y/Z travel : 1000(Opt.800)/400/470 mm
Spindle taper : NT40(Ø105)
Spindle motor : 5HP(Opt.7.5)
X/Y/Z travel : 1000(Opt.800)/400/440 mm
Spindle taper : NT40(Ø110)
Spindle motor : 5HP(Opt.7.5)
X/Y/Z travel : 1000(Opt. 1200,1400)/550/600 mm
Spindle taper : NT40
Spindle motor : 5HP (Opt.7.5HP)
X/Y/Z servo motor
X/Y/Z axis ball screw
X/Y/Z travel : 1000(Opt. 1200,1400) /550/600 mm
Spindle taper : NT40
Spindle motor : 5HP(Opt.7.5HP)
Controller system
The Bridgeport® GX-Series Performance Vertical Machining Centers and Drill/Tap centers are designed for flexibility and throughput and built for a production environment. Ideal for both job shops and OEMs, these high-quality, highly-specified and rugged machines were developed for applications that require speed as well as accuracy. The unique design allows the machines to literally overlap one another to better utilize valuable floor space and to promote cell manufacturing and perfect for automation. Add some robots or a gantry system and you can increase your productivity with virtually no labor costs.
The Bridgeport® V-Series Vertical Machining Centers are new generation machines. These machines are fully digital, high- quality machine tools, designed to achieve maximum capacity and performance in the Job Shop, OEM, Aerospace, Automotive energy and other demanding markets.
The Bridgeport® V-Series Vertical Machining Centers are new generation machines. These machines are fully digital, high- quality machine tools, designed to achieve maximum capacity and performance in the Job Shop, OEM, Aerospace, Automotive energy and other demanding markets.
The Bridgeport® V-Series Vertical Machining Centers are new generation machines. These machines are fully digital, high- quality machine tools, designed to achieve maximum capacity and performance in the Job Shop, OEM, Aerospace, Automotive energy and other demanding markets.
The Bridgeport® XT630 5AX CNC machining centers are designed for accuracy, speed and productivity. They are built to provide years of dependable machining on parts requiring consistent tolerances, tough to machine materials and fine surface finishes.has been designed to stand above all other machines in its class. With wide range of options to choose from, it’s the best in class against competitive machining centers worldwide. With high end features, it provides a very price competitive machine for the higher end market.The XT630 5AX features and robust traveling beam design on an extremely rigid cast iron base.
Performance. Precision. Reliability. Affordability.These are the driving forces behind the design of our new Traveling Column High-Efficiency Profile Grinding Machine. They’re the standards required by the medical, automotive, mining, semiconductor, aerospace and job shop industries in order to meet current grinding demands and pave the way to smart manufacturing.Chevalier achieved greater precision by placing the high waist traveling column on the same level as the spindle, creating a solid, rigid machine structure that minimizes vibration, movement, and displacement. Axial movements are programmable in increments of 0.001 mm (0.0001") with little effort.Our grinding machines are designed to be user friendly. Now, our exclusive next generation SMART iControl incorporates production efficiency, which simplifies operation procedures and greatly enhances the performance of Chevalier CNC grinders. Combined with TaskLink, it allows operators to create their own programs for generating complex grinding tasks in a single cycle—without an engineering degree.
X/Y/Z travel : 800 (Opt.1000)/400/420mm
Spindle taper : NT40
Spindle motor : 5HP(Opt.7.5)
Hardened ground-X/Y/Z
Square way-Y/Z
Easy Setup, Flexible and Sealed for Grinding
The FVGC Series of vertical grinding machines is another prime example of Chevalier’s position as the global leader in grinding technology. The series seamlessly increases efficiency and productivity for such industries as semiconductor, punch and aerospace, as well as other sectors for which these machines can be equipped. Workpieces in these fields primarily are a composite, single crystal silicon or brittle, along with other materials that present process challenges.
The FVGC series is completely sealed for process filtration. The filter bag, telecentric process or integrated filter application effectively separates cutting chips, impurities and powder during machining. The machine’s filtration system, which increases the longevity of the cutting fluid, improves workpiece grinding accuracy.
The FVGC Series also includes Chevalier’s exclusive iMachine Communications SystemTM (iMCS) software, which features remote machine monitoring, data analysis, alarm history records and maintenance updates to improve overall equipment efficiency (OEE), meets today’s market requirements.
1. The base is fabricated from heavy gauge steel plates and scientifically reinforced, allowing for solid support for the column and work pieces.
2. Travelling column design features increased machining efficiency and accuracy.
3. The oversized box-type column is manufactured from high quality cast iron.
4. Large diameter ball screw on x-axis is firmly supported to eliminate self-deflection problems.
5. 3 axis adopt 45 mm P class high precision linear guide ways; X axis features 8 blocks, Y and Z axis are 6 blocks.
6. Automatic lubricator delivers lubrication oil to all linear ways and ball screws.
7. 3 axis ball screws are direct coupled with drive motors, featuring no backlash, high transmission efficiency and high accuracy.
2. Travelling column design features increased machining efficiency and accuracy.
3. The oversized box-type column is manufactured from high quality cast iron.
4. Large diameter ball screw on x-axis is firmly supported to eliminate self-deflection problems.
5. 3 axis adopt 45 mm P class high precision linear guide ways; X axis features 8 blocks, Y and Z axis are 6 blocks.
6. Automatic lubricator delivers lubrication oil to all linear ways and ball screws.
7. 3 axis ball screws are direct coupled with drive motors, featuring no backlash, high transmission efficiency and high accuracy.
Features :
1. IK milling heads can help you upgrade or replacement your original machine body, milling machine or special purpose machine.
2. Chrome quill with super precision preloaded bearing can bring the high quality cutting benefits for machine and we also offer P4 bearings for your optional.
3. Machining travel can up to 127mm (5").
4. This product is variable turret milling machine head.
5. This product variable turret milling machine head of standard spindle type is NT30, we also offer R8 for you to optional.
6. There are 11 models in IK Turret Milling Machine Head Series.
Features :
1. We provide milling heads for turret milling machine factory and turret milling machine repair and replacement.
2. Check the connection interface size. Installing turret milling head is convenient and easy.
3. Machining travel can up to 127mm (5").
4. Offer air operated brake for you to optional.
5. This type milling head the maximum speed is 5440 rpm.
Intelligent. Dynamic. Affordable.These words describe the driving forces behind the new design of our SMART-IV CNC surface grinders. These are the benchmarks required by the medical, energy, semiconductor, aerospace, mold and processing industries in order to meet current and future market demands.This series is capable of producing complicated shapes for highly accurate workpieces along with finer finishes. The heavy-duty slide rails, one-piece base casting and hardened wheelhead guideways create a solid, rigid machine structure that minimizes vibration, movement and displacement.Our grinding machines are designed to be user friendly. Now, our exclusive next generation SMART iControl incorporates production efficiency, which simplifies operation procedures and greatly enhances the performance of Chevalier CNC grinders. Combined with TaskLink, it allows operators to create their own programs for generating complex grinding tasks in a single cycle—without anengineering degree.
1. To operate the machine, simply treadle on the foot switch, the machine will automatically perform clamping and cutting for convenient operation.
2. Concealed saw blade performs upward cutting. Single or multiple work pieces can be cut simultaneously.
3. While cutting, the oil mist splashes automatically for cooling and lubrication.
4. Cutting feed is driven by a hydraulic pneumatic combination cylinder for extremely stable cutting speed.
5. The machine cabinet painting is baked by high temperature of 200 degree ( Powder coating ) for resisting bumping without paint peeling off.
6. The machine permits ± 0 ~ 45 degree cutting.
Optional :
Automatic Rotary Angle, JIH-16R, JIH-20R, JIH20 24R, JIH-20 30R, JIH-20 36R.
•CE Standard•Infeed, Outfeed Roller Table•Chip Collector•Horizontal Clamp•Horizontal Feeding•Automatic Rotary Angle.
•With Auto3000 for Automatic Positioning, Automatic Feeding(Push), Automatic Rotary Angle, Automatic Cutting • Saw Blade.
2. Concealed saw blade performs upward cutting. Single or multiple work pieces can be cut simultaneously.
3. While cutting, the oil mist splashes automatically for cooling and lubrication.
4. Cutting feed is driven by a hydraulic pneumatic combination cylinder for extremely stable cutting speed.
5. The machine cabinet painting is baked by high temperature of 200 degree ( Powder coating ) for resisting bumping without paint peeling off.
6. The machine permits ± 0 ~ 45 degree cutting.
Optional :
Automatic Rotary Angle, JIH-16R, JIH-20R, JIH20 24R, JIH-20 30R, JIH-20 36R.
•CE Standard•Infeed, Outfeed Roller Table•Chip Collector•Horizontal Clamp•Horizontal Feeding•Automatic Rotary Angle.
•With Auto3000 for Automatic Positioning, Automatic Feeding(Push), Automatic Rotary Angle, Automatic Cutting • Saw Blade.
The UNi5X-400 five-axis vertical machining center can provide the required stability, speed and accuracy when machining complex workpieces. The machine’s high rigidity achieves the best stability, and the BIG-PLUS double-sided restraint spindle design can achieve excellent speed and accuracy.This machine type can be widely used in aerospace, automotive, medical treatment, mold, pneumatic and hydraulic components, electronics, semiconductor, and job shop industries.Our exclusive iMachine Communications System™ (iMCS) software includes remote machine monitoring, data analysis, alarm history and maintenance updates to improve overall equipment efficiency (OEE) and is the equipment required for the construction of smart factories.
Chevalier’s FSG-ADIV Series of surface grinders have several design features to shorten your processing and non-processing preparation while delivering high-precision workpieces year after year—functions you might not expect on such affordable machines: iSurface control, variable speed spindle, constant surface speed, smart grinding path and in-machine manual dynamic balancing.
FSG-ADIV Series grinders also feature tools to secure Big Data with Chevalier’s exclusive iMachine Communications System TM (iMCS). This software package, combined with data analysis, enhances machine efficiency in the factory while enabling remote monitoring and diagnostics to track machine performance and identify potential problems before they begin.
Chevalier’s new FSG-2048ADIV and FSG-2064ADIV machines join our ADIV Series of surface grinders offering two additional machine sizes, along with several newly designed features, including: a traveling column structure to further reduce vibration and achieve higher accuracy, a spindle that can withstand heavy load grinding and a double-V guideway for smooth, stable longitudinal movements.
These two new sizes, along with the entire ADIV Series, offer several design features to shorten processing and non-processing preparation while delivering high-precision workpieces: iSurface control, variable speed spindle, constant surface speed, smart grinding path and in-machine manual dynamic balancing.
The driving forces behind this series pave the way to smart manufacturing by meeting the current grinding demands and standards required by the automotive, electric vehicle, mining, aerospace and job shop industries.
This series of grinders also features tools to secure Big Data with Chevalier’s exclusive iMachine Communications SystemTM (iMCS).
Combined with data analysis, this software package enhances machine efficiency in the factory while enabling remote monitoring and diagnostics to track machine performance and identify potential problems before they begin.
Equipped with the latest technology, Chevalier’s FDG-700 is loaded with features that make the innovative double-sided grinder the ideal machine for a variety of flat, hard and brittle materials.The FDG-700 is perfect for mass production of small- and medium-sized workpieces that demand high-precision and high efficiency with an eight-stage pressure control. This fine grinding process offers several advantages in flatness, parallelism, surface finish and size tolerances.The FDG-700 features Chevalier's iSurfaceDS, a PC-based control that makes it possible to intuitively operate the grinder entirely by conversational graphic control.The machine features a high-precision, digitally controlled pneumatic system that automatically adjusts according to the selected pressure. The high-precision, contact-measuring system includes grinding height control and dressing monitoring.
The Bridgeport® V-Series Vertical Machining Centers are new generation machines. These machines are fully digital, high- quality machine tools, designed to achieve maximum capacity and performance in the Job Shop, OEM, Aerospace, Automotive energy and other demanding markets.
1. IK milling heads can help you upgrade or replacement your original machine body, milling machine or special purpose machine.
2. Chrome quill with super precision preloaded bearing can bring the high quality cutting benefits for machine and we also offer P4 bearings for your optional.
3. Machining travel can up to 127mm (5").
4. This product is steel type of turret milling machine head.
5. Offer air operated brake for you to optional.
6. There are 11 models in IK Turret Milling Machine Head Series.
1. IK milling heads can help you upgrade or replacement your original machine body, milling machine or special purpose machine.
2. Chrome quill with super precision preloaded bearing can bring the high quality cutting benefits for machine and we also offer P4 bearings for your optional.
3. Machining travel can up to 150mm (6").
4. Offer air operated brake for you to optional.
5. There are 11 models in IK Turret Milling Machine Head Series.
1. IK milling heads can help you upgrade or replacement your original machine body, milling machine or special purpose machine.
2. Chrome quill with super precision preloaded bearing can bring the high quality cutting benefits for machine and we also offer P4 bearings for your optional.
3. Machining travel can up to 150mm (6").
4. This product is variable turret milling machine head.
5. Offer air operated brake for you to optional.
6. There are 11 models in IK Turret Milling Machine Head Series.
1. IK milling heads can help you upgrade or replacement your original machine body, milling machine or special purpose machine.
2. Chrome quill with super precision preloaded bearing can bring the high quality cutting benefits for machine and we also offer P4 bearings for your optional.
3. Machining travel can up to 127mm (5").
4. This product is variable turret milling machine head.
5. Offer air operated brake for you to optional.
6. There are 11 models in IK Turret Milling Machine Head Series.
The Hardinge® Talent® Series multi-tasking CNC lathes are designed to work with a number of different types of workholding systems providing a high level of functionality and accuracy to dramatically increase your manufacturing capabilities. These machines are ruggedly built and offer an exceptional combination of features for accuracy, flexibility and durability in a compact design. Its unique collet-ready main and sub-spindle design increases part accuracy and improves surface finish. With specifications and standard features often found only in much higher price machine tools, Hardinge Talent® Series machines are an exceptional addition to any machining facility seeking increased levels of productivity.
．Max. Swing: Φ540 mm
．Max. Machining Diameter: Φ350 mm
．Max. Machining Length: 700 mm
．Powerful 20hp Spindle Motor
．5,000 rpm Max. Spindle Speed
．6", 8" or 10" Chuck System
．Orthogonal Moving Column Structure
．Linear Guideway
．±110° B-axis Design
．Multi-Tasking Table
Click the link below for more information:
https://www.yidacnc.com/product_d.php?lang=en&tb=1&id=394
Features :
1. Install the head of the milling machine needs to be fixed stably and placed on a flat ground to avoid tilting.
2. Turret milling machine is flexible in operation but not suitable for heavy cutting.
3. Machining travel can up to 140mm (2#).
4. This product is steel type of turret milling machine head.
5. Offer air operated brake for you to optional.
6. Idling and warming up the machine before use can increase its service life.
Features :
1. Compare with the other type, IK-6FS2-2# is variable milling head. It must be used with VFD.
2. Chrome quill with super precision preloaded bearing can bring the high quality cutting benefits for machine and we also offer P4 bearings for your optional.
3. Machining travel can up to 140mm (2#).
4. Offer air operated brake for you to option
5. This type milling machine head is oil circulation.
6. It used with a new milling machine. It also provide maintenance and replacement of the existing turret milling machine.
7. Please check the connect interface size.
Features :
1. IK milling heads can help you upgrade or replacement your original machine body, milling machine or special purpose machine.
2. Chrome quill with super precision preloaded bearing can bring the high quality cutting benefits for machine and we also offer P4 bearings for your optional.
3. Machining travel can up to 140mm (2#).
4. Offer air operated brake for you to optional.
5. This type milling machine head is oil circulation.
6. If you have any other question, please email to us.
Features :
1. IK milling heads can upgrade or replacement your existing milling machine. The cutting effect is better.
2. It is used for mold manufacturing or precision processing.
3. The machine processing for travel is 320 mm. We also provide “No slide” format.
4. This product is used on Gantry (Plano) Milling Machine (vertical / horizontal), suitable for heavy metal cutting.
5. Plano milling head series offer accessory head for you to option.It will apply for multi-angle machining to upgrade efficiency and longer machining range.
6. This product of standard motor is 10HP. We also offer 12.5HP.
7. Offer pneumatic blade locking device, bearing guide screw for you to option.
8. Please check the voltage, 50Hz or 60 Hz.
Features :
1. There are many types of milling head for you to option. We provide milling heads with the best cutting benefit for milling machines.
2. Gantry milling machines are used to mold manufacturing and metal heavy cutting .
3. The machine processing for travel is 398 mm. We also provide “No slide” format.
4. This product is used in Gantry (Plano) Milling Machine (vertical / horizontal).
5. Plano milling head series offer angle heads for you to optional. It will apply for multi-angle machining.
6. There are two options for your reference.(10HP and 12.5 HP)
7. Offer pneumatic blade locking device, bearing guide screw for you to optional.
8. The standard color of the product is green. If you need to specify the color, please provide the international color number.
Features :
1. In order to make the milling machine achieve better cutting efficiency, IK milling head can upgrade or replace the milling head of your milling machine or special machine.
2. It is used for mold manufacturing It is suitable for heavy cutting.
3. The machine processing for travel is 600 mm. We also provide “No slide” format.
4. This product is used on Gantry (Plano) Milling Machine (vertical / horizontal).
5. Plano milling head series offer accessory head for you to optional.
It will apply for multi-angle machining to upgrade efficiency and longer machining range.
6. This product of standard motor is 10HP. We also offer 12.5HP/15HP for you to optional.
7. Offer pneumatic blade locking device, bearing guide screw for you to optional.
8. IK-610L-RV has been applied through the structure patents, patents number are M354483 and M354484.
Features :
1. IK milling heads can upgrade or replacement your existing machine body, milling machine or special machine and also it can bring more stable and high-quality machining benefits for work piece cutting.
2. It is used for mold manufacturing or precision processing.
3. The machine processing for travel is 600 mm. We also provide “No slide” format.
4. This product is used in Gantry (Plano) Milling Machine (vertical / horizontal), suitable for heavy metal cutting, excavation frame and boring.
5. Plano milling head series offer accessory head for you to optional.
It will apply for multi-angle machining to upgrade efficiency and longer machining range.
6. This product of standard is variable frequency motor. Randomly matched with Taiwanese inverter and oil cooler.
Features :
1. IK milling heads can upgrade or replacement your existing machine body, milling machine or special machine and also it can bring more stable and high-quality machining benefits for work piece cutting.
2. It is used for mold manufacturing or precision processing.
3. The machine processing for travel is 480 mm.
4. This product is used in Gantry (Plano) Milling Machine (vertical / horizontal), suitable for heavy metal cutting.
5. Plano milling head series offer angle heads for you to optional. Ganrty milling machine combined with angle head could achieve high processing efficiency.
It will apply for multi-angle machining to upgrade efficiency and longer machining range.
6. This product of standard motor is 15HP.
7. Offer pneumatic blade locking device, bearing guide screw for you to optional.
8. IK-615-LV has been applied through the structure patents, patents number are M354483 and M354484.
Features :
1. IK milling heads can upgrade or replacement your existing machine body, milling machine or special machine and also it can bring more stable and high-quality machining benefits for work piece cutting.
2. It is used for mold manufacturing or precision processing.
3. The machine processing for travel is 700 mm.
4. This product is suitable for heavy metal cutting.
5. Plano milling head series offer accessory head for you to optional.
It will apply for multi-angle machining to upgrade efficiency and longer machining range.
6. This product of standard motor is 15HP. We also offer 20HP for you to optional.
7. Offer pneumatic blade locking device, bearing guide screw, pneumatic leveler for you to optional.
8. IK-618-LV has been applied through the structure patents, patents number are M417975 and M419629.
9. Vertical type or Horizontal type.
The FVL-8, 12, 20 and 24 Series meets the need to integrate automation or cell manufacturing into the market. This series is widely used in the automotive parts, engines and compressor industries by using a simplified fixture design and is excellent for turning irregular shaped workpieces. The automotive industry's lightweight and environmental restrictions and the popularity of alternative energy vehicles are driving a substantial increase in the demand of forged aluminum wheels.With our steel-inlaid guideway technology, this series adopts the dual-turret dual-system configuration that simultaneously handles the inner and outer diameter of the aluminum wheels. The machining range can reach 26" aluminum wheels, which greatly reduces machining time. The 6+6 turret provides additional flexibly for tool selection.Our exclusive iMachine Communications System™ (iMCS) software includes remote machine monitoring, data analysis, alarm history and maintenance updates to improve overall equipment efficiency (OEE). Working with Chevalier’s software, an operator easily controls the machine with simple procedures to increase productivity.
Features :
1. IK milling heads can upgrade or replacement your existing machine body, milling machine or special machine and also it can bring more stable and high-quality machining benefits for work piece cutting.
2. It is used for mold manufacturing or precision processing.
3. The machine processing for travel is 650 mm.
4. This product is used in Gantry (Plano) Milling Machine (vertical / horizontal), suitable for heavy metal cutting.
5. Plano milling head series offer accessory head for you to optional.
It will apply for multi-angle machining to upgrade efficiency and longer machining range.
6. This product of standard motor is 12.5HP. We also offer 15HP for you to optional.
7. Offer pneumatic blade locking device, bearing guide screw, pneumatic leveler for you to optional.
8. IK-618S-LV has been applied through the structure patents, patents number are M417975 and M419629.
9. 618 Series can be used to process deeper holes.
Features :
1. The gantry milling head can be used with your original machine body for machine upgrade or maintenance.
2. It is used for mold manufacturing or precision processing.
3. The machine processing for travel is 700 mm.
4. This product is used in Gantry (Plano) Milling Machine (vertical / horizontal), suitable for heavy metal cutting.
5. Plano milling head series can be used with angle heads. It will apply for different angle machining to upgrade efficiency and longer machining range.
6. This product of standard motor is 15HP. We also offer 20HP for you to optional.
7. Offer pneumatic blade locking device, bearing guide screw, pneumatic leveler for you to optional.
．X / Y / Z axis linear guideway (MV-1500)
．X / Y / Z axis box guideway (BMV-1500)
．Arm type tool magazine: 24 tools (STD.) ; 30 tools (OPT.)
．X / Y / Z travel: 1,500 x 680 x 680 mm
Click the link below for more information:
https://www.yidacnc.com/product_d.php?lang=en&tb=1&id=460
．X / Y / Z axis linear guideway (MV-1100)
．X / Y / Z axis box guideway (BMV-1100)
．Arm type tool magazine: 24 tools (STD.) ; 30 tools (OPT.)
．X / Y / Z travel: 1,100 x 650 x 620 mm
Click the link below for more information:
https://www.yidacnc.com/product_d.php?lang=en&tb=1&id=436
．X / Y / Z axis linear guideway (MV-1300)
．X / Y / Z axis box guideway (BMV-1300)
．Arm type tool magazine: 24 tools (STD.) ; 30 tools (OPT.)
．X / Y / Z travel: 1,300 x 680 x 680 mm
Click the link below for more information:
https://www.yidacnc.com/product_d.php?lang=en&tb=1&id=448
‧ X / Y / Z axis linear guideway
‧ Arm type tool magazine: 24 tools (STD.) ; 30 tools (OPT.)
‧ X/Y/Z travel: 860 x 600 x 610 mm
Click the link below for more information:
https://www.yidacnc.com/product_d.php?lang=en&tb=1&id=418
· X / Y / Z axis linear guideway
· Automatic pallet changer
· Arm type tool magazine: 24 tools (STD.) ; 30 tools (OPT.)
· X / Y / Z travel: 860 x 500 x 500 mm
Click the link below for more information:
https://www.yidacnc.com/product_d.php?lang=en&tb=1&id=424
．Max. Machining diameter: Φ360 mm
．Max. Machining length: 300 mm
．X-axis Travels: 195 (175+20) mm
．Z-axis Travels: 330 mm
．Spindle Nose: A2-5
．Chuck diameter: 6"
Click the link below for more information:
https://www.yidacnc.com/product_d.php?lang=en&tb=1&id=526
BML-560S
．Max. Machining diameter: Φ320 mm
．Max. Machining length: 320 mm
．X-axis Travels: 190 (160+30) mm
．Z-axis Travels: 360 mm
．Spindle Nose: A2-6 (STD.) ; A2-5 (OPT.)
．Chuck Diameter: 8" (STD.) ; 6" (OPT.)
．CS- axis function
BML-560M
．Max. Machining diameter: Φ320 mm
．Max. Machining length: 570 mm
．X-axis Travels: 190 (160+30) mm
．Z-axis Travels: 610mm
．Spindle Nose: A2-6 (STD.) ; A2-5 (OPT.)
．Chuck Diameter: 8" (STD.) ; 6" (OPT.)
．CS- axis function
Click the link below for more information:
https://www.yidacnc.com/product_d.php?lang=en&tb=1&id=538
BML-600L
．Max. Machining diameter: Φ420 mm
．Max. Machining length: (STD.) 1,280 mm (10")；(OPT.) 1,260 mm (12")
．X-axis Travels: 230 (210+20) mm
．Z-axis Travels: 1,330 mm (10") ; 1,320 mm (12")
．Spindle Nose: A2-8 (STD.)
．Chuck Diameter: Φ10" (STD.) ; Φ12" (OPT.)
．CS- axis function (OPT.)
Click the link below for more information:
https://www.yidacnc.com/product_d.php?lang=en&tb=1&id=562
BML-600M
．Max. Machining diameter: Φ420 mm
．Max. Machining length: (STD.) 780 mm (10")；(OPT.) 760 mm (12")
．X-axis Travels: 230 (210+20) mm
．Z-axis Travels: 830 mm (10") ; 820 mm (12")
．Spindle Nose: A2-8 (STD.)
．Chuck Diameter: Φ10" (STD.) ; Φ12" (OPT.)
．CS- axis function (OPT.)
Click the link below for more information:
https://www.yidacnc.com/product_d.php?lang=en&tb=1&id=550
BML-600S
．Max. Machining diameter: Φ420 mm
．Max. Machining length:(STD.) 560 mm (8")；(OPT.) 540 mm (10")
．X-axis Travels: 230 (210+20) mm
．Z-axis Travels: 590 mm (10") ; 600 mm (8")
．Spindle Nose: A2-6 (STD.) ; A2-8 (OPT.)
．Chuck Diameter: 8" (STD.) ; 10" (OPT.)
．CS- axis function (OPT.)
Click the link below for more information:
https://www.yidacnc.com/product_d.php?lang=en&tb=1&id=538
．Tool Magazine: 40 Tools; 60 Tools (OPT.)
．Tool Change Time (T-T): 3.7 sec.
．Pallet Change Time (P-P): 10 sec.
．BT40 Spindle Speed: 10,000 rpm (belt driven)
．Twin screws+ link type chip conveyor
．Fanuc/ Heidenhain/ Siemens controllers
Click the link below for more information:
https://www.yidacnc.com/product_d.php?lang=en&tb=1&id=196
．Tool Magazine: 40 Tools; 60, 120, 180 Tools (OPT.)
．Tool Change Time (T-T): 3.5 sec.
．Pallet Change Time (P-P): 6.8 sec.
．1G acceleration 60 m /min rapid feedrate (OPT.)
．BT50 direct coupling spindle
．Box-in-Box Structure
．Dual ball screw (X-axis)
．Fanuc/ Heidenhain/ Siemens controllers
Click the link below for more information:
https://www.yidacnc.com/product_d.php?lang=en&tb=1&id=310
．Tool Magazine: 60 Tools; 120, 180 Tools (OPT.)
．Tool Change Time (T-T): 3.5 sec.
．Pallet Change Time (P-P): 16 sec.
．Box-in-Box solid structure
．BT50 direct driven spindle: 10,000 rpm
．Dual ball screw (X/Z axis) and dual motor design
．Fanuc/ Heidenhain / Siemens controllers
Click the link below for more information :
https://www.yidacnc.com/product_d.php?lang=en&tb=1&id=298
．Tool Magazine: 40 Tools
．Tool Change Time (T-T): 2.1 sec.
．Pallet Change Time (P-P): 10 sec.
．BT40 Spindle: 12,000 rpm direct driven
．Acceleration: 1 G
．Central Removal System
Click the link below for more information:
https://www.yidacnc.com/product_d.php?lang=en&tb=1&id=130
．Max. Machining diameter: Φ360 mm
．Max. Machining length: (STD.) 470 mm (A2-6)；(OPT.) 460 mm (A2-8)
．X-axis Travels: 215 (180+35) mm
．Z-axis Travels: 500 mm (8") ; 500 mm (10")
．Spindle Nose: A2-6 (STD.) ; A2-8 (OPT.)
．Chuck Diameter: 8" (STD.) ; 10" (OPT.)
．CS- axis function (OPT.)
Click the link below for more information:
https://www.yidacnc.com/product_d.php?lang=en&tb=1&id=382
ML-600S
．Max. Machining diameter: Φ420 mm
．Max. Machining length:(STD.) 560 mm (8")；(OPT.) 540 mm (10")
．X-axis Travels: 230 (210+20) mm
．Z-axis Travels: 600 mm (8") ; 590 mm (10")
．Spindle Nose: A2-6 (STD.) ; A2-8 (OPT.)
．Chuck Diameter: Φ8" (STD.) ; Φ10" (OPT.)
．CS- axis function (OPT.)
ML-600M
．Max. Machining diameter: Φ420 mm
．Max. Machining length: (STD.) 780 mm (10")；(OPT.) 720 mm (12")
．X-axis Travels: 230 (210+20) mm
．Z-axis Travels: 830 mm (10") ; 820 mm (12")
．Spindle Nose: A2-8 (STD.)
．Chuck Diameter: Φ10" (STD.) ; Φ12" (OPT.)
．CS- axis function (OPT.)
ML-600L
．Max. Machining diameter: Φ420 mm
．Max. Machining length: (STD.) 1,280 mm (10")；(OPT.) 1,260 mm (12")
．X-axis Travels: 230 (210+20) mm
．Z-axis Travels: 1,330 mm (10") ; 1,320 mm (12")
．Spindle Nose: A2-8 (STD.)
．Chuck Diameter: Φ10" (STD.) ; Φ12" (OPT.)
．CS- axis function (OPT.)
Click the link below for more information:
https://www.yidacnc.com/product_d.php?lang=en&tb=1&id=238
．Max. Machining diameter: Φ720/ Φ600 mm
．Max. Machining length: Φ720 x 150 + Φ600 x 1,110 mm
．X-axis Travels: 1,330 mm
．Z-axis Travels: 590 mm (10") ; 600 mm (8")
．Spindle Nose: A2-11
．Chuck Diameter: 15" (STD.) ; 18" (OPT.)
．CS- axis function (OPT.)
Click the link below for more information:
https://www.yidacnc.com/product_d.php?lang=en&tb=1&id=262
ML-430
．Max. Machining diameter: Φ430 mm
．Max. Machining length: 240 mm
．X-axis Travels: 350 mm
．Z-axis Travels: 320 mm
．Spindle Nose: A2-5
．Chuck Diameter: 8"
．CS- axis function (OPT.)
Click the link below for more information:
https://www.yidacnc.com/product_d.php?lang=en&tb=1&id=250
VISE CAN SIDE-LOCK TO WORK
1.Pressure Constant. Clamping force can presetting, repeat use the same clamping force.
2.Vise body is made of ductile iron FCD-60.
3.Vise bed hardened to HRC45° and maintain accuracy for long.
4.Vise bed height-size and the guide block side are all made with full control, can 2, 3, or 4 vises to perform a job at a time.
5.The length of vise body is very short, but the clamping range is very big. It works with every kind of milling machine, CNC machine center.
Features :
1. It can be installed on a new gantry milling machine or repair and replace your original gantry milling machine
2. It is used for metal cutting, let metal to achieve a flat effect.
3. The machine processing for travel is 600 mm. We also provide “No slide” format.
4. This product is suitable for heavy metal cutting.
5. Plano milling head series offer angle heads for you to optional. It will upgrade efficiency and longer machining range.
6. This product of standard motor is 15HP. We also offer 20HP for you to optional.
7. Offer pneumatic blade locking device, bearing guide screw for you to optional.
8. Vertical type or Horizontal type.
Features :
1. IK milling heads can be matched with milling machines of various brands. Please confirm the connection size before ordering and whether each size meets your needs.
2. Traditional gantry milling machine is used for mold making or metal heavy cutting .
3. The machine processing for travel is 600 mm. We also provide “No slide” format.
4. This product is used in Gantry (Plano) Milling Machine (vertical / horizontal).
5. It can be matched with angle head, which can complete more angle processing and improve processing efficiency
6. This product of standard motor is 15HP. We also offer 20HP for you to optional.
7. Offer pneumatic blade locking device, bearing guide screw for you to option.
8. If you need a more detailed information of the product, please email to us.
Features :
1. Customer can choose this type to install on their own traditional gantry machine to achieve better cutting results.
2. Main for light cutting. The cutting effect is like mirror.
3. The machine processing for travel is 460 mm. We also provide “No slide” format.
4. YIH KUAN gantry milling head is suitable for vertical and horizontal boring and milling machines.
5. This gantry series products can be matched with accessory heads to do more angle processing and improve the efficiency and scope of processing.
6. This product of standard motor is 12.5HP. We also offer 15HP for you to option.
7. Offer pneumatic blade locking device, bearing guide screw for you to optional.
8. I K-916-LV has been applied through the structure patents, patents number are D172465 and D174766.
IK-A90 characteristics
1. It uses precision grinding gears made in Taiwan. It can be used machining with high torque.(800 rmp)
2. It is always linked to vertical machining center, gantry type machine, boring and milling machine and vertical lathe.
3. A wide range of machine tools and machining fields such as automobiles, molds, aerospace, energy...etc.
4. 90-degree head allows large workpieces to be processed on the side without turning or repeated loading and unloading, which improves the processing efficiency.
5. There are 2 models in 90 degree processing IK Angle Head series.(the other one is IK-N90)
1. Complete new mill head for your old machine body or special machinery.
2. All products can be used for metal milling and boring.
3. One of IK top selling Deep Head series.
4. The weight of this product is 98 kg.
5. Deep processing accessory head.
6. At 300mm of the front testing bar , the standard data is 0.02mm.
7. The milling length is 505mm.
8. There are 2 models in IK Deep Head series.
1. Complete new mill head for your old machine body or special machinery.
2. All products can be used for metal milling and boring.
3. The weight of this product is 131 kg.
4. Deep processing accessory head.
5. At 300mm of the front testing bar , the standard data is 0.02mm.
6. The milling length is 675mm.
7. There are 2 models in IK Deep Head series.
IK-N90 characteristics
1. It uses precision grinding gears made in Japan. It can be used machining with high speed.(2000 RMP)
2. It is always linked to traditional plano milling machine, gantry type machine, CNC machine center and special functions milling machine…etc.
3. It is a processing accessory for machinery manufacturing, molds, aerospace, energy, automobiles, motorcycles and other industries.
4. 90 degree processing angle heads is suitable for all types of milling heads and it can change the processing angle and direction. It help you save equipment investment costs.
5. There are 2 models in 90 degree processing IK Angle Head series. (the other one is IK-A90)
Besides these characteristics.IK-N90 could be used with IK-N95 semi-automatic hydraulic table.IK-N90+IK-N95 are applied for auto-rotating multi-angle machining.
(Accessory Milling Head / Semi-Automatic Angular Head)
IK-N90+N95 characteristics
1. Semiautomatic processing angle head can change the processing angle and direction.
It is also suitable for all type of milling heads.
2. IK-N90+N95 uses Japanese gear grinding. The spindle speed can up to 2000rpm and also can bring the powerful and high-quality cutting benefits for machine.
3. This product offers manual or semiautomatic two types for your optional.
4. This product offers one degree or five degree for your optional.
5. IK-N90+N95 has been applied through the structure patents, the patents number are M446037 and ZL 2012 2 0450246.5.
IK-U45 characteristics
1. Universal processing angle heads are suitable for all type of milling heads. Its design is mainly to meet the needs of vertical and horizontal angle processing.
2. IK-U45 uses Japanese gear grinding, so the spindle speed can up to 2000rpm and also can bring the powerful and high-quality cutting benefits for machine.
3. Its structure is sturdy, suitable for heavy cutting.
IK-U90 characteristics
1. It uses precision grinding gears made in Taiwan. It can be used machining with high torque.(800 RPM)
2. It is always linked to traditional plano milling machine, gantry type machine, CNC milling machine and special functions milling machine…etc. The universal milling head is a commonly used accessory of machine tools, and one of the most core parts of machine tools with the highest technical content.
3. It is widely used in high-speed processing in mold manufacturing, aviation industry…
etc.
4. Universal milling head refers to a milling head whose output axis of the machine tool can rotate in both horizontal and vertical planes.
5. There are 2 models in 90 degree processing IK Angle Head series.(the other one is IK-N90)
IK-E93A 2000 characteristics
1. Extend head, its function is to extend spindle and increase rigidity. The working stroke is increase.
2. Extend head is used to extend machining process 305mm.
3. Used on gantry milling machine, special machine, CNC milling machine, it need to be combined with flange.(Flange is optional)
4. It is used for mold, like aluminum for light cutting and drilling.
IK-E95A 2000 characteristics
1. Extend head is used to provide longer machining range. If you don't want to move or raise the workpiece, you can choose to use an extended milling head.
2. Extend head is used to extend machining process 505mm.
3. It is always linked to gantry milling machine, CNC machine center, boring and special machine. It need to combined with customize flange.(Customize flange is optional)
4. It is used for mold, like aluminum for light cutting and drilling.
Features :
1. IK milling heads can help you upgrade or replacement your original machine body, milling machine or special purpose machine.
2. This product uses for gear type structure can bring the powerful and high-quality cutting benefits for machine.
3. This product can be configured in CNC horizontal milling machine or special machine for milling machine.
4. This products didn't offer servo motor and servo controller.
5. There are 3 models in IK CNC Milling Machine Head Series.
Features :
1. IK milling heads can help you upgrade or replacement your original machine body, milling machine or special purpose machine.
2. This product uses for gear type structure can bring the powerful and high-quality cutting benefits for machine.
3. This product can be configured in CNC vertical milling machine or special machine for milling machine.
4. This products didn't offer servo motor and servo controller.
5. There are 3 models in IK CNC Milling Machine Head Series.
6. Offer IK-N90 and IK-N90+N95 milling head accessory for you to optional.
Features :
1. IK milling heads can help you upgrade or replacement your original machine body, milling machine or special purpose machine.
2. This product uses for gear type structure can bring the powerful and high-quality cutting benefits for machine.
3. Spindle speed change has high and low two stage.
4. This product can be configured in CNC vertical milling machine or special machine for milling machine.
5. This products didn't offer servo motor and servo controller.
6. There are 3 models in IK CNC Milling Machine Head Series.
The high rigidity model is mainly used for extremely large double column machine center or horizontal machine tools. The planetary gearboxes will not be distorted or shaken under high torque and emergency stop condition. The turret can be edited instantly without waiting. This rugged gearbox is not only able to withstand the challenges of harsh, high and low temperature environments, but also retains the original low backlash, low noise and other properties of the servo planetary gearbox.
High Radial Load Capacity
The PUR series of output shaft right angle helical gearbox provide a wide range of performance levels to high positioning accuracy and motion control applications, particularly when high precision and high torsional rigidity are required. Frame sizes 60-220 mm with the best level of backlash ≦ 2 arcmin. Taper roller bearings with maximum radial load capacity up to 27800 N, and axial load capacity up to 16200 N. The PUR is specially well suited to work with pinion and rack for linear operation. Commonly adapted in metal cutting machines, wood processing equipment, machine centers and highly dynamic motion control systems. Inline configuration (PUL series) is also available with max. frame size 220 mm.
-Worktable diameter Ø125, Ø170, Ø210, Ø255
-Exclusive patented dual pneumatic piston braking system.(P.19)
-Higher rotation speed.
-Equipped with high precision cross roller.
-Full gear depth transmitted by dual lead worm drive, resulting in higher efficiency and lower backlash.(P.20)
-Worktable diameter Ø255, Ø320, Ø400.
-Big spindle bore allow the more complex parts clamping and fixture.
-Ultra high clamping force by drum brake system.(P.19)
-Consolidated spindle with radial-Axial bearing built-in. (P.18)
-Full gear depth transmitted by dual lead worm drive,resulting in higher efficiency and lower backlash.(P.20)
Rotary Flange Right Angle Planetary Gearboxes
The PHFR Precision Round mounting flange, caged precision class helical planetary speed reducer in a right-angle housing through sizes 255. ISO-9409 flange output, high torque capacity, quiet operation with backlash as low as <2 arcmin. This gearbox provide a wide range of performance levels to high positioning accuracy and motion control applications, particularly when high precision and high torsional rigidity are required. Taper roller bearings with bending moment load capacity up to 6500 N.m, and axial load capacity up to 21850 N. The PHFR is specially well suited to work with pinion and rack for linear operation. Commonly adapted in metal cutting machines, wood processing equipment, machine centers and highly dynamic motion control systems. Inline configuration (PHF series) is also available with max. frame size 255 mm.
-Worktable diameter Ø500, Ø630, Ø800.
-Equipped with extra large bearings, preloaded in radial and axial directions.(P.18)
-Motor is mounted at right side(vertical and horizontal application).
-Full gear depth transmitted by dual lead worm drive, resulting in higher efficiency and lower backlash.(P.20)
The PGFR series of flange type right angle helical gearbox provide a wide range of performance levels to high positioning accuracy and motion control applications, particularly when high precision and high torsional rigidity are required. Frame sizes 42-142 mm with the best level of backlash ≦ 2 arcmin. Nominal input speed up to 10000 rpm. The PGFR is specially well suited to work with pinion and rack for linear operation. Commonly adapted in metal cutting machines, wood processing equipment, machine centers and highly dynamic motion control systems. Inline configuration (PGF series) is also available with max. frame size 142 mm.
-Worktable diameter Ø170, Ø210, Ø255.
-Motor mounted at left side of table
-Full gear depth transmitted by dual lead worm drive, resulting in higher efficiency and lower backlash. (P.20)
-Worktable diameter Ø170, Ø210 ,Ø255.
-GVA-SB series is new "super multiple brake"mechanism for pneumatic clamp.(P.19)
-Full gear depth transmitted by dual lead worm drive, resulting in higher efficiency and lower backlash.(P.20)
-Worktable diameter Ø255, Ø320, Ø400, Ø500.
-Motor is mounted at right side (vertical and horizontal applications).
-Equipped with three pieces type coupling with worm gear to achieve positioning. It is suitable for heavy cutting.
-The minimum degree is 1°.
-Worktable diameter Ø100, Ø125, Ø170, Ø210.
-Exclusive patented dual pneumatic piston braking system.(P.19)
-Enlarged the high precision cross roller bearing.
-Transmitted by dual lead worm with high efficiency and full depth gear teeth.(P.20)
-Worktable diameter Ø255, Ø320.
-The hydraulic brake equipped with radial and axial bearings.(P.18)
-Full gear depth transmitted by dual lead worm drive,resulting in higher efficiency and lower backlash.(P.20)
-Worktable diameter Ø210, Ø320, Ø410, Ø500.
-The hydraulic brake equipped with radial and axial bearings.(P.18)
-Full gear depth transmitted by dual lead worm drive, resulting in higher efficiency and lower backlash.(P.20)
-Built-in air-booster for appointed models.
Torque Motors Characteristics
Torque motors are designed to provide high starting torque and stable operation, especially in the low speed range or under a locked rotor condition. The torque is highest at zero speed and decreases steadily with increasing speed to keep motor and loading balanced. Motor rotation speed change is available by adjusting supply voltage when loading torque is constant.
The design of the torque motors is significantly different from that of the general motors. Suitable and typical application is to hold down the loading by static torque or constrained force is required at the end after a high-speed operation. The voltage for continuous operation is 60V; rated short time in the occasions for voltages above 60V; the rated time is 5 minutes for voltage 100V.
Torque motors are suitable for continuous winding and winding of articles at a certain speed with a certain tension. They are used commonly in situations where forced static torque is required during or after operation. Torque motors are widely used in applications where the product needs to be wound onto a reel, such as textiles, paper, rubber, plastic (round wire, flat wire, plastic bags, cling film), metal wire, cable and printing machinery.
*Available output power of 3 W up to 40 W
*Built-in thermo switch
*GN type (pinion) output shaft models available for gearhead
Types Torque Motor
The motors torque adjustment is available by changing applied voltage or built-in voltage regulator in the terminal box.
1.Standard Type:
Exterior voltage regulator is required to adjust motor speed.
2.Regulator Built-in Type:
The voltage regulator is installed in the terminal box to adjust motor speed.
Torque Motors Characteristics
Torque motors are designed to provide high starting torque and stable operation, especially in the low speed range or under a locked rotor condition. The torque is highest at zero speed and decreases steadily with increasing speed to keep motor and loading balanced. Motor rotation speed change is available by adjusting supply voltage when loading torque is constant.
The design of the torque motors is significantly different from that of the general motors. Suitable and typical application is to hold down the loading by static torque or constrained force is required at the end after a high-speed operation. The voltage for continuous operation is 60V; rated short time in the occasions for voltages above 60V; the rated time is 5 minutes for voltage 100V.
Torque motors are suitable for continuous winding and winding of articles at a certain speed with a certain tension. They are used commonly in situations where forced static torque is required during or after operation. Torque motors are widely used in applications where the product needs to be wound onto a reel, such as textiles, paper, rubber, plastic (round wire, flat wire, plastic bags, cling film), metal wire, cable and printing machinery.
*Available output power of 3 W up to 40 W
*Built-in thermo switch
*GN type (pinion) output shaft models available for gearhead
Types Torque Motor
The motors torque adjustment is available by changing applied voltage or built-in voltage regulator in the terminal box.
1.Standard Type:
Exterior voltage regulator is required to adjust motor speed.
2.Regulator Built-in Type:
The voltage regulator is installed in the terminal box to adjust motor speed.
-Worktable diameter, Ø255, Ø320, Ø410,Ø500.
-The hydraulic brake equipped with radial and
axial bearings.(P.18)
-Full gear depth transmitted by dual lead worm
drive, resulting in higher efficiency and lower
backlash.(P.20)
-Enlarged swing to allow more working envelope.
- Sub- table available as "S" model.
-Worktable diameter Ø125, Ø170
-Multiple rotary axis allow high volume production and automation integration.
-Worktable diameter Ø125, Ø210, Ø255
-Multiple rotary axis allow high volume production and automation integration.
-EASY INSTALLATION: The pallet change device is directly mounted on the base. Easy to install and space saving.
-FLEXIBLE PRODUCTION: Available to equip with several tables to meet small lot flexible production requirements.
-GREAT LOADING CAPACITY: Hydraulic drive.
Workpiece loading capacity up to 300kg x 2 pcs.
-HIGH REPEATABILITY: Employs high precision conical positioning blocks to ensure stability of table and repeatability in ± 0.005mm.
-Rolling contact reserves high rigidity, high speed and long endurance.
-Least drive energy wear- out and more than 90% transmission rate.
-Backlash-free from rolling motion achieves high accuracy.
-RGX170/210X built-in air booster system assures more superior clamping force (additional hydraulic tank not required).
-Rotation speed exceeds 250 min-1, excellent speed and efficiency for mass production.
-Low inertia- no gears or belts drive in direct drive system, resulting in lower inertia and greater acceleration / deceleration.
-Equipped with high precision encoder to achieve high precision positioning.
-Backlash-free transmission improves workpiece accuracy and surface roughness.
-Direct drive features reach zero-wear.
-High Speed – The average rotation speed of a normal rotary table is 22.2 RPM. Whereas DDM Rotary Table runs at speeds exceeding 100RPM. Hence this is suitable for high speed turning and cutting applications.
-High Precision – Direct drive design is without the normal worm gear transmission. Hence, there is no backlash and mechanical errors. This guarantees very high positional accuracy and repeatability.
-Superior Surface Finish - No Backlash, No Abrasion & Low Inertia – No gears or belts in direct drive system ensures superior surface finish.
Controller：FANUC 0i-T
Swing over bed：455mm
Swing over saddle：260mm
Max. turning diameter：280mm(UL-15)；180mm(UL-15M)
Max. turning length：300mm(UL-15)；210mm(UL-15M)
Guide way type：Box Way
X-axis travel：175mm
Z-axis travel：350mm
>click here to see more specifications<
Controller：FANUC 0i-T
Max. Turning Diameter(SP1)：70mm
Max. Turning Diameter(SP2)：70mm
Max. Turning Length：mm 55
Guide way type：Linear
X-axis Travel： 160(145+15)mm
Z-axis Travel： 310(±155)mm
>click here to see more specifications<
Controller：FANUC 0i-T
Swing over bed：660mm
Swing over saddle：620mm
Max. Turning Diameter：340mm
Max. turning length：510mm(UA-2000T2M) / 400mm(UA-2000T2MB)
Guide way type：Linear + Box
X-axis Travel：X1/X2: 210mm
Z-axis Travel：Z1/Z2: 550mm(UA-2000T2M)/Z1/Z2: 450mm(UA-2000T2MB)
B-axis Travel：1400mm(UA-2000T2M) /1200mm(UA-2000T2MB)
>click here to see more specifications<
Controller：FANUC 0i-M
Spindle speed：10000/12000rpm
Spindle nose taper：BT40
Bearing inner diameter：70mm
Drive system：Belt/Direct
X-axis travel：1100mm
Y-axis travel：550mm
Z-axis travel：550mm
Spindle nose to table：150~700mm
>click here to see more specifications<
420X420 Enlarged flange interface + large-size clutch teeth,providing excellent rigidity and repeatability.
420X420 Enlarged flange interface + large-size clutch teeth,providing excellent rigidity and repeatability.
With a highly experienced design and manufacturing background in centerless grinders, PALMARY present the new bearing type CNC centerless grinder.
Differ from PALMARY traditional model, PCB, bearing type to meet the awareness of eco-friendly, there’s no oil tank for spindle lubrication. Both wheel head spindle filled with oil grease which can do oil mist auto lubrication while needed. Maintenance is much easier. G.W. is hold by bearing in single side which is convenient for replacement. R.W. is hold by bearing at double side to reduce backlash.
The model has had great performance on automobile industry, take hydraulic spool for instance. Roundness can be controlled under 1 um.
To maintain such stable result, the dressing attachment is also key point. It is equipped with cylinder to avoid backlash. Besides, in addition to single point diamond dresser, roller dresser is optional for customer for better durability.
Automation design is always available with the machine. Gantry type loader is equipped on GW side which is easier to do grinding adjustment.
In addition to that, the graphic interface integrates auto loader and unloader as well as measuring data, which is much easier to take necessary action while notice the change.
The base structure is upgraded with square slide with roller bearing and shorten the machine layout at the same time.
Super rigid structure, stable without deformation. Double support grinding wheel spindle design features high speed operation to boost grinding performance. The double support bearing type spindles offer even grinding force on the contact surface. During grinding process, the stress is even on both ends of spindle to avoid taper shaped workpieces.
The one "V" & one flat feeding slide design reinforces the feeding stability. The entire feeding slide is hand scrapped to reduce friction and to increase accuracy of jog movement. Computer numerical control from 1 ~ 6 axes satisfy requests for customized specification. Fitted with wider wheel, suitable for efficient mass production.
CNC Cylindrical Grinder, Plunge grinding with wpecial wider grinding wheel series, the machine structure is strengthened with same design of heavy duty cylindrical grinder. The enlarge hydrostatic wheel spindle construction could equip max. 125 mm width grinding wheel for plunge grinding application.The enlarge hydrostatic wheel spindle construction could equip max. 125 mm width grinding wheel for plunge grinding application. The variable frequency grinding wheel speed control could reach max. 60 M/s cutting speed. The large fully splash guard is designed for more interior space use. All the slides are hydrostatic designed for smooth move while grinding process. The taper fine adjustment tailstock is standard accessory and easy to adjust the taper if required. The CNC conversational controller is ease of operation. The optional accessories such as O.D. measuring system is possible to equip for clients use.
CNC cylindrical grinder special designed for spindle grinding. The advanced machine structure with a special grinding wheel spindle design, enhances the whole rigidity of the machine, and makes the grinding workpiece of spindle faster, more accurate and more stable. High precision and high rigidity machine structure design.
Advance the machine design structure. The lower center of gravity of the bed reinforces the machine rigidity.
The rigidity of the grinding wheel spindle is comprehensively improved. Fully enhance the cutting force and grinding efficiency.
(a) The grinding wheel spindle with hydro-static bearing. No friction between metals, maximum wear resistance and enhance the lifetime.
(b) Enlarge the spindle pitch and grinding wheel motor, enhance the grinding efficiency and shorten cycle time.
Fully-closed hydrostatic slide advances the loading capacity.
The slide is widened and thickened designed with fully-closed hydrostatic. The maximum loading weight of the workpiece is 500KGS.
The stroke of each axis is increased to meet the requirement of large-angle grinding.
(a) The X&Z axis strokes are increased to improve the grinding efficiency of the wheel.
(b) The swiveling angle of the worktable is enlarged, providing the operator with their diversified processing demands.
The new and miniaturized CNC internal Grinding Machine from PALMARY features build-in spindles design, man-made mineral machine bed for more stability, minimize its space, and an elegant appearance combined with advanced CNC control and interactive screen operation. The all new series will bring internal grinding technology into a new era.
The high rigidity and stable man-made mineral machine bed could provide the smooth machining requirement and being the basic of accuracy.
The clients’ factory land capacity was increased for the machine has small machine bed design which only same as B1 paper size. Further, it’s easy to equip the automatic loading system.
The high efficiency bearing built-in spindles are used on both grinding wheel spindle & work spindle which offer the high accuracies grinding performance.
Both X & Z axes equip with linear servo motors which provide high-speed grinding activity and shorten the cycle time. Further, the digital readouts put on both axes for high-speed precision efficiency.
The new CNC internal Grinding Machine from PALMARY features optimal structural design, and an elegant appearance combined with advanced CNC control. The all new series will bring internal grinding technology into a new era.
The structural parts of the machine are manufactured from high quality cast iron for deformation-free performance year after year. The entire machine is precision built throughout to guarantee the best possible grinding accuracy you can find anywhere.
Two internal wheel spindles model for your different application requirement. It's capable of grinding internal hole, end face and outer diameter at one time setting. To meet mass production requirements, automatic loading and unloading equipment is available to provide a fully automatic operation. The slides move on roller type linear guideways for increasing smoothness & stable movement. The feed axis is equipped with optical scale to upgrade positioning accuracy.
Based on PALMARY's tradition of "Pursuing Quality Perfection", combined with human engineering design and peak performance concepts, each machine fully reflects PALMARY's unmatched design and technique.
Honeycomb type machine structure assures the best possible rigidity and stability. The machine bed is manufactured from high-quality Meehanite cast iron, heat treated and stress relieved for outstanding stability and without deformaiton. The design of honeycomb Tubular type machine bed and cross guideway structure for improving the higher rigidity and stability. For end face grinding application, the wheel spindle can swivel to 22.5 degrees for easy grinding.
Auto. tool change system (ATC). Equipped with max. 6 no. grinding wheels for different diameter or accuracy requirement. The coolant flow has an isolation design from the machine bed and can reduce the heat deformation and dirt contamination on the bed.
Based on PALMARY's tradition of "Pursuing Quality Perfection", combined with human engineering design and peak performance concepts, each machine fully reflects PALMARY's unmatched design and technique. Honeycomb type machine structure assures the best possible rigidity and stability. The machine bed is manufactured from high-quality Meehanite cast iron, heat treated and stress relieved for outstanding stability and without deformaiton. The design of honeycomb Tubular type machine bed and cross guideway structure for improving the higher rigidity and stability. For end face grinding application, the wheel spindle can swivel to 22.5 degrees for easy grinding. Auto. tool change system (ATC). Equipped with max. 6 no. grinding wheels for different diameter or accuracy requirement. The coolant flow has an isolation design from the machine bed and can reduce the heat deformation and dirt contamination on the bed.
Contact Information
www.palmary.com
No. 77, Gongye Rd., Dali Dist., Taichung City 412037, Taiwan
+886-4-24929799
+886-4-24929499
![Products|OCD-32100CAM - CNC Cylindrical Grinding Machine [CAM series] - special shaped workpiece]( https://www.mtb2b.tw/storage/customer/330f9c32862e.jpg )
For various eccentric circle or non-round shape workpieces grinding purpose, PALMARY develop CNC Cylindrical Grinder Cam Type with CAD/CAM software for easily transfer from workpiece drawing to grinding program. The workhead could offer precise angle control upto 0.1 micron resolution due to the C axis has accurate angle encoder. The infeed axis is driven by linear motor with linear guideway & close loop linear scale, it could avoid the backlash in order to reach high machining precision. Also, it could prevent the reaction force causing by linear motor under the large acceleration and deceleration motion, it could stabilize the grinding process.This machine has high-speed algorithm controller execute under PC Based + Windows XP, allowing the 3rd party application and Flash Drive for prompt transfer, its single section processing time could be ≦ 1ms.
The Internal Grinder for bearing inner dia. and groove is specially applied for bearing grinding. The workpiece loading, unloading and the workhead movement could operate at the same time in order to shorten the time for setting & adjustment. Machine could equip with vibration feeder or workpiece arranging device in order to have auto loading control.
Machine equipped with Palmary developed conversational control panel (Mitsubishi PLC) for easy operation. The customer could choose to use CNC controller as optional.
Machine with magnetic workhead centerless support device which allows the loading and unloading workpiece process move quickly and increase work efficiency.
Machine supplied the high precision roller type dressing device to make sure the dressing accuracy.
The customer could use optional accessory CBN grinding wheel for having better grinding results.
According to the workpiece accuracies required, it's optional to add the digital linear or in-process ID measuring device.
-High Speed – The average rotation speed of a normal rotary table is 22.2 RPM. Whereas DDM Rotary Table runs at speeds exceeding 100RPM. Hence this is suitable for high speed turning and cutting applications.
-High Precision – Direct drive design is without the normal worm gear transmission. Hence, there is no backlash and mechanical errors. This guarantees very high positional accuracy and repeatability.
-Superior Surface Finish - No Backlash, No Abrasion & Low Inertia – No gears or belts in direct drive system ensures superior surface finish.
https://www.tmts.tw/en
5 AXES SIMULTANEOUS CONTROL CNC MACHINING CENTER
Features:
-Moving column construction
-X/Y/Z box ways or X/Z Linear ways+Y box way
-X,Y,Z-axis are equipped with linear scales
-Gear-drivn type spindle head is excellent for heavy cutting
-0,001-degree servo-driven rotary table
-Table rotation is transmitted through double worm/ double worm gear units to eliminate gear-backlash problem
-W axis extension is free of deformation
-Go tools chain type magazine
-During machine assembly, all foundation bolts have been locked into the foundation to ensure the consistency of leveling accuracy
Features:
-30 degree slant bed design for easy operation and easy chip removal
-Cast iron bed with optimally designed ribs with integral stiffness provides an very strong rigidity
-Big diameter bearing provides high rigidity
-High-resolution encoder mounted on spindle to provide accurate C axis positioning
-C axis with continuous indexing
-Double supported ball screws direct-driven servo motors are used for axial movements
-Servo turret or hydraulic turret is offered for users as an alternative choice
-Large disc is equipped for easy tool set up
-Special spindle motor location design reduces machine floor space
-One-piece structure on the machine structure to provide massive rigidity
-Programmable tailstock available as an option
-Large coolant tank
-Internal coolant supply through turret disc
-High pressure pump
-PLC controlled chip conveyor
￭ The unique IDD spindle design provides power, speed, and stiffness required for the most adverse machining applications while providing long spindle life.
￭ Ceramic bearings help to minimize heat and provide thermal stability improving overall machining accuracy.
￭ High precision rotary encoders in the B and C
axes as a standard feature, allowing for the most demanding machining accuracies.
￭ ø650 mm table provides stable machining performance with a wide machining area and trunnion support.
Features:
-High precision and rigidity spindle
-Top quality gears
-Optical linear scale
-4th and 5th axis rotary table
-Circular inspection
-Inspection by laser unit
-Spindle dynamic balancing testing
￭One-piece 30° slant bed design made from high quality MEEHANITE® cast iron to reduce the effects of vibration and
minimize thermal deformation.￭The spindle driven by a 35 kW 47 HP motor can generate rotation speed up to 3,500 rpm which is well-suited for heavy duty
machining.￭Packed with sub spindle, Y-axis, live tool turret and C-axis, these turn-mill features allow complex finished parts machining in
just one setup, while also improving efficiency and accuracy.￭The BMT65 turret ensures a fast and stable rotation.
For 2mm-13mm Twist Drill
Re-sharpening , Angle 90°-140°
------------------------------------------------------------------
Precise Grinding Results , Precision Assurance within 0.02mm
Easy to Operate , grinding a drill within 10 seconds.
Special Design High Accuracy Alloy Steel Collets
Accurate Grinding consumption 0.2mm
High Efficiency DC motor
Stable Quality Diamond Dust Grinding Wheel
Considerable Design, Invisible Tool Box, Delicate & Friendly Use
Portable Design with only weight 7 kgs.
1. The grinding wheel head spindle is equipped with a self-made hydrostatic spindle, which has excellent characteristics such as high precision, high rigidity, high shock resistance, high bearing capacity and long life.
2. High rigidity hydrostatic rotary table, static rigidity>400kgf/μm, Ø600 worktable load can reach 10000kg
3. The base of the bed adopts an integrated cast iron design, which not only increases the structural strength, but also makes the center of gravity of the machine more stable, and provides the best support and ensures the bearing rigidity of the machine.
4. Equipped with CNC Mitsubishi controller, graphical dialogue human-machine interactive interface, and visual application.
* There are 4 Stations, 1 station is for loading/ unloading; the other 3 stations can machine the parts at the same time.
* Each station equips with spindle, ATC and B axis.
Process program is separated, in other words, one machine is equivalent three horizontal milling machines.
* Max. rotary speed of built-in spindle can reach to 16,000RPM, and rated torque is 55N.m.
* It can equip BT40 or HSK63A ATC, the capacity of ATC is 24 tools.
* The stroke of sliding table is X:400; Y:350; Z:400
* Design of B axis is used toothed clutch.
Depends on customer's request, one indexing can be set up for 1∘or 5∘, Repeatability is within 4”.
* Machine is suitable for processing special shape part, e.g. drilling, tapping, and milling
Description
▶Reliable ▶Diversity ▶Customization ▶Cost-effective
1. European DELEM multi-axial controller.
2. The ram repeat accuracy is guaranteed by 2 sets of linear scales.
3. The controller stores up to 999 programs, each contains 17 bend. All programs can be interconnected.
Description
▶Reliable ▶Diversity ▶Customization ▶Cost-effective
1. Hydraulic guillotine shear acts in a vertical up and down manner, which is enables by synchronized hydraulic cylinders and direct fixing mechanism of the upper blade. The sheared edge is burr free and precise.
2. Unique hydraulic control adjusts automatically the output of hold-down cylinders according to the magnitude of the load. Shearing thickness ranges from 0.1mm to 25mm.
3. Overload protection ensures the safety of the shear and operators.
4. Special design of blade offers easy adjustment of blade’s clearance. It can remain the shearing section and machine’s safety by pushing buttons or Controllers calculate.
5. Pre-retreat of back gauge to thick sheet cutting.
Description
▶Reliable ▶Diversity ▶Customization ▶Cost-effective
These hydraulic press are specially designed for precision deep drawing of metal plates. Available in 100 to 2000 tons, they offer high efficiency and accuracy.
Our design adopt special loop control system in order to meet the modern industrial requirement of high speed production and extremely safety.
Description
1. The machine structure is C-frame. All the parts are included in machine body, the operation is safe and simple.
2. Design is simple and free of trouble.
3. The machine is multiple purpose, we are ale to modify the design and enhance functions to meet customer’s special requirements.
Description
▶Reliable ▶Diversity ▶Customization ▶Cost-effective
1. European DELEM multi-axial controller.
2. The ram repeat accuracy is guaranteed by 2 sets of linear scales.
3. The controller stores up to 999 programs, each contains 17 bend. All programs can be interconnected.
4. Graphic display of punch and die. Data about die sets up to 2 MB can be stored.
5. Multi=language controller, with English, Japanese, Korean, Chinese (traditional & simplified) available.
6. Basic functions of windows.
1. Grinding wheel has been carried out, and one-time feed is adopted in a straight-forward mode, which greatly improves the overall processing efficiency and stability.2. The maximum width of the grinding wheel can reach 300mm, and the grinding of workpieces with 15 steps can be completed by one-time operation.3. Equipped with hydrostatic spindle, it has excellent features such as high precision, high rigidity, high shock resistance, high bearing capacity and long life.4. The headstock and tailstock are driven by dual servo motors, which can avoid the interference problem of traditional driving rings.
FEATURE
Slide table reverse 180° system.
Pneumatic slide TDC lock.
Slide table hydraulic lock.
Bolster hydraulic positioning lock system.
Bolster automatic hub device.
Optical scale precision positioning device.
Automatic Human-machine interface operation system.
Ratio valve, pressure and flow system.
Ratio electric valve precision die spotting system.
Slide dust proof expansion sheath.
Slide glide-path automatic lubrication system.
Description
▶Reliable ▶Diversity ▶Customization ▶Cost-effective
1. After planning the V slots on sheets, it can use small tonnage hydraulic press brake to bend the sheet.
2. Processing length depends on working piece length. Planer tool's stroke is adjustable. Planer working speed is stable and fast.
3. CNC 3 axes control, with semi-auto/auto processing function.
4. Be able to clamp and hold the working piece in semi-auto/auto function. All operation can be done in once.
5. The distance between planer tool and pressing plate is very small (3mm). The planned V slots are even.
MAIN PURPOSES
Air conditioning duct
Refrigerator body and truck body
Modular furniture panels
Description
Applicably in cutting angles and edges of soft steel and stainless steel plates.
Angular Rotator enables varied cutting angle (90°,105°,120°,135°,150°)
1. The grinding wheel head seat is equipped with a hydrostatic spindle, which has the characteristics of high precision, high rigidity, high shock resistance, high bearing capacity and long life, and the spindle rotation accuracy can reach within 1.0μm.
2. The tailstock is designed with high rigidity. The telescopic sleeve is controlled by hydraulic pressure, which is convenient for fixing and replacing the workpiece.
3. The workpiece headstock is equipped with a servo motor with automatic speed regulation function to maintain the machining accuracy and efficiency during the grinding process.
4.4. Graphical dialogue human-machine interface, visualization application.
1. The grinding wheel head seat is equipped with a hydrostatic spindle, which has the characteristics of high precision, high rigidity, high shock resistance, high bearing capacity and long life, and the spindle rotation accuracy can reach within 1.0μm.
2. Graphical dialogue human-machine interface, visualization application.
3. Stable mechanical structure, special grinding wheel spindle design, suitable for grinding outer surface, tapered surface, forming outer surface, radius, groove and end surface, with excellent precision.
4.The X-axis feed slideway adopts double V design, which presents the best balanced support and stable leveling accuracy. When grinding, the feed accuracy can reach μm level.
CONTINUOUS OPTIMIZATION OF PRODUCTION LINE NARROW FACE WIDTH. FLEXIBLE LAYOUT. YOUR BEST PARTNER IN INTELLIGENT MANUFACTURING.
- 1000mm supper narrow face width
- Flexible Layout to Suit Various Production Requirements.
- Patented Complex Tool Turret.
- Automatic Workpiece Changer (optional)
- Intelligent Production through Human-Machine Interface.
The WVT series CNC Vertical Lath features highly rigid structure. The series of machine is designed specifically for extra hard workpiece machining, and exhibits outstanding stability and dependability.
High reliability
PMI has accumulated many years experience in production managing. It covers the whole production sequence, from receiving the order, designing, material preparation, machining, heat treating, grinding, assembling, inspection, packaging and delivery. The systemized managing ensures high reliability of PMI Ballscrews.
High accuracy
PMI Ballscrews are machined, ground, assembled and Q.C. inspected under the constant temperature control (20℃) to ensure high precision of Ballscrews. accuracy inspection certifi cate.
Long durability
PMI Ballscrews are made of German Alloy steels, which are well quenching and tempering treated for good rigidity, along with suitable surface hardening to ensure long durability.
High working efficiency
Balls are rotating inside the Ballscrew nut to offer high working efficiency. Comparing with the traditional ACME screws, which work by friction sliding between the nut and screw, the Ballscrews needs only 1/3 of driving torque. It is easy to transmit linear motion into rotation motion.
No backlash and with high rigidity
The Gothic profile is applied by PMI Ballscrews. It offers best contact between balls and the grooves. If suitable preload is exerted on Ballscrew hence to eliminate clearance between the ball nut and screw and to reduce elastic deformation, the ballscrew shall get much better rigidity and accuracy.
High positioning accuracy, high repeatability
The PMI linear guideway is a design of rolling motion with a low friction coeffi cient, and the diff erence between dynamic and static friction is very small. Therefore, the stick-slip will not occur when submicron feeding is making.
Low frictional resistance, high precision maintained for long period
The frictional resistance of a linear guideway is only 1/20th to 1/40th of that in a slide guide. With a linear guideway, a well lubrication can be easily achieved by supplying grease through the grease nipple on carriage or utilizing a centralized oil pumping system, thus the frictional resistance is decreased and the accuracy could be maintained for long period.
High rigidity with four-way load design
The optimum design of geometric mechanics makes the linear guideway to bear the load in all four directions, radial, reversed radial, and two lateral directions. Furthermore, the rigidity of linear guideway could be easily achieved by preloading carriage and by adding the number of carriages.
Suitable for high speed operation
Due to the characteristic of low frictional resistance, the required driving force is much lower than in other systems, thus the power consumption is small. Moreover, the temperature rising effect is small even under high speed operation.
Easy installation with interchangeability
Compared with the high-skill required scrapping process of conventional slide guide, the linear guideway can offer high precision even if the mounting surface is machined by milling or grinding. Moreover the interchangeability of linear guideway gives a convenience for installation and future maintenance.
Features:
-Best cost & performance ratio machine
-Cutting speed is superior to other competitors
-Y-axis is located on the base; X-axis is located on the top of Y-axis,which is suitable for precise mold cuttings with small/medium stroke.
-Machine structure was designed via Finite Element Analysis(FEA) with high rigidity.
-Direct motor drive in X/Y axes with high servo response.
One-piece-formed base: The base is made as 60-degree one-piece-formed, which decreases the negative influence from the casting combination and also ameliorates the chip transferring.
Customized turret: The specialized turret, designed from MYLAS and SAUTER, mainly reduces the interference of each turret while triple system movement.
High-level end controller: For simultaneous machining, all three programs can be monitored in one shot, which maximizes the convenience of the tool control.
Multi-axes linear guideway: For better accuracy and speed, X and Z-axis are equipped with linear guideways.
Boxy way on dual Y axes: The machine is equipped double BMT-55 turret that increases the loading of each Y-axis. To meliorate the stability and rigid, double Y axes design with boxy way.
Features:
-Best cost & performance ratio machine
-Cutting speed is superior to other competitors
-Y-axis is located on the base; X-axis is located on the top of Y-axis,which is suitable for precise mold cuttings with small/medium stroke.
-Machine structure was designed via Finite Element Analysis(FEA) with high rigidity.
-Direct motor drive in X/Y axes with high servo response.
Features:
-Best cost & performance ratio machine
-Cutting speed is superior to other competitors
-Y-axis is located on the base; X-axis is located on the top of Y-axis,which is suitable for precise mold cuttings with small/medium stroke.
-Machine structure was designed via Finite Element Analysis(FEA) with high rigidity.
-Direct motor drive in X/Y axes with high servo response.
Features:
-Best cost & performance ratio machine
-Cutting speed is superior to other competitors
-Y-axis is located on the base; X-axis is located on the top of Y-axis,which is suitable for precise mold cuttings with small/medium stroke.
-Machine structure was designed via Finite Element Analysis(FEA) with high rigidity.
-Direct motor drive in X/Y axes with high servo response.
GA series has "Direct Force" design on the concept of X/Y axes linear guidewayblocks keep staying in straight line.
Working tabe is supported by casting bases. GA series is suitable for theprecision mold cutting within small / medium stroke.
AccuteX controller is 100% self-developed by core-technologies of R&D team. We can provide the best support in any modifications.
AccuteX controller is based on Windows CE system. It features “Precise Motion Control” with rapid servo response.
Also, Windows CE system is virus free environment to assure system stability.
AccuteX has simplified the generator and electric circuits to eliminate unnecessary power loss and improve the cutting efficiency.
Speed comparison table with other brands in different thickness of workpieces.
According to different wire diameters, corner angles, arc radius and thicknesses,AccuteX controller optimizes parameters for the best cutting efficiency with high accuracy.
Especially on the small path and continuous corners, machines can meet the corneraccuracy demand.
New generation of Lead-In / Lead-Out function is available for Tungsten Carbide.
The wire mark is 2μm after 3 cuts by 40mm thickness which improving mold qualityand saving second time polishing hours.
GA series has "Direct Force" design on the concept of X/Y axes linear guidewayblocks keep staying in straight line.
Working tabe is supported by casting bases. GA series is suitable for theprecision mold cutting within small / medium stroke.
AccuteX controller is 100% self-developed by core-technologies of R&D team. We can provide the best support in any modifications.
AccuteX controller is based on Windows CE system. It features “Precise Motion Control” with rapid servo response.
Also, Windows CE system is virus free environment to assure system stability.
AccuteX has simplified the generator and electric circuits to eliminate unnecessary power loss and improve the cutting efficiency.
Speed comparison table with other brands in different thickness of workpieces.
According to different wire diameters, corner angles, arc radius and thicknesses,AccuteX controller optimizes parameters for the best cutting efficiency with high accuracy.
Especially on the small path and continuous corners, machines can meet the corneraccuracy demand.
New generation of Lead-In / Lead-Out function is available for Tungsten Carbide.
The wire mark is 2μm after 3 cuts by 40mm thickness which improving mold qualityand saving second time polishing hours.
High-Rigidity Structures
The machine body is designed by finite Element Analysis (FEA) to assure optimized mechanical structure.Features include: honeycomb-type base, high-rigidity column mounted with oversized UVZ axes and reinforced low-arm by melting alloy to increase stiffness; these considerations assure superior geometric accuracy even under high pressure flushing while the machine is operated at first cutting.
EF (Electrolysis free) Discharging
High speed EF (Electrolysis Free) discharge method, it minimizes the possibility of workpiece cracking or electrolyze problems. It also increases the lift of the mold and saves brass wire consumption.By using EF (Electrolysis Free) power from rough to fine cut which can reach the average gap voltage to zero, during electrolysis free discharge power, the cation will not move to the cathode and also reducing the elements released like iron, carbon, cobalt, molybdenum to cause the soften surface and shorten the life cycle of moulds; it will increase the life cycle for 5 or 6 times comparing with traditional cutting with electrolysis free power cutting of making press moulds.
AWT SYSTEM
The Accutex unique intelligent servo-control wire-threading technology, together with multi-detectors, makes the threading system possess high speed and good reliability. Also achieves highly efficient auto-machining.
With The unique Straightened and Melted Way
Using impulse circuit makes the wire annealed to straighten. Then, with discharging way, make the end of the wire melted and become a bullet shape about 0.8mm. It can be easy to thread through the guide. Moreover, when encountering the block, the end of the wire wouldn’t be too peaked to curl. As for the workpiece of 300mm, it can directly thread the wire (above 0.25mm) from break point. Even for the wire of 0.1 mm, it also can use this way to thread.
Threading At Wire Break Point
In case of broken wire during machining, there’s no need to return to start point before threading, it is able to thread wire just at break point with nearly 100% possibility. If wire threading fails after several attempts, the intelligent system will return to star point and threads wire again (for workpiece thickness < 120mm,∮0.25/ ∮0.2 brass wire) No limits on taper machining as the system doesn't use high pressure to assist threading and no need to change special small-diameter flushing nozzles.
Precision Servo and transmission System
Using 32, C1 class ball screw with sub-zero and super-finish ground process for maximum smoothness and minimum pitch error. Built in high-response AC servomotor and option with linear scale is mounted close-loop feedback control. The linear scale is mounted close to the ball screw to minimize the slant. Each axis is compensated by laser interferometer to approve the high accuracy and repeatability. By adopting the latest generation Ball-Retainer type linear guide of which the patented structure reduces 90% of frictional variation compared to conventional ones. The movement will be similar to a magnetic levitation, even under complicated routes
High compatibility NC Program Design
Well-designed to be NC-coded for multi brand machines compatibility is without the need of modification. It is highly recommended for NC program circulation and management due to its user friendly feature.The operational screen provides large quantities go graphic icons, on-line HELP, warning descriptions, detailed operational instructions and messages. These enable the operator to understand the current machine condition and to easily control machining results.
High-Rigidity Structures
The machine body is designed by finite Element Analysis (FEA) to assure optimized mechanical structure.Features include: honeycomb-type base, high-rigidity column mounted with oversized UVZ axes and reinforced low-arm by melting alloy to increase stiffness; these considerations assure superior geometric accuracy even under high pressure flushing while the machine is operated at first cutting.
EF (Electrolysis free) Discharging
High speed EF (Electrolysis Free) discharge method, it minimizes the possibility of workpiece cracking or electrolyze problems. It also increases the lift of the mold and saves brass wire consumption.By using EF (Electrolysis Free) power from rough to fine cut which can reach the average gap voltage to zero, during electrolysis free discharge power, the cation will not move to the cathode and also reducing the elements released like iron, carbon, cobalt, molybdenum to cause the soften surface and shorten the life cycle of moulds; it will increase the life cycle for 5 or 6 times comparing with traditional cutting with electrolysis free power cutting of making press moulds.
AWT SYSTEM
The Accutex unique intelligent servo-control wire-threading technology, together with multi-detectors, makes the threading system possess high speed and good reliability. Also achieves highly efficient auto-machining.
With The unique Straightened and Melted Way
Using impulse circuit makes the wire annealed to straighten. Then, with discharging way, make the end of the wire melted and become a bullet shape about 0.8mm. It can be easy to thread through the guide. Moreover, when encountering the block, the end of the wire wouldn’t be too peaked to curl. As for the workpiece of 300mm, it can directly thread the wire (above 0.25mm) from break point. Even for the wire of 0.1 mm, it also can use this way to thread.
Threading At Wire Break Point
In case of broken wire during machining, there’s no need to return to start point before threading, it is able to thread wire just at break point with nearly 100% possibility. If wire threading fails after several attempts, the intelligent system will return to star point and threads wire again (for workpiece thickness < 120mm,∮0.25/ ∮0.2 brass wire) No limits on taper machining as the system doesn't use high pressure to assist threading and no need to change special small-diameter flushing nozzles.
Precision Servo and transmission System
Using 32, C1 class ball screw with sub-zero and super-finish ground process for maximum smoothness and minimum pitch error. Built in high-response AC servomotor and option with linear scale is mounted close-loop feedback control. The linear scale is mounted close to the ball screw to minimize the slant. Each axis is compensated by laser interferometer to approve the high accuracy and repeatability. By adopting the latest generation Ball-Retainer type linear guide of which the patented structure reduces 90% of frictional variation compared to conventional ones. The movement will be similar to a magnetic levitation, even under complicated routes
High compatibility NC Program Design
Well-designed to be NC-coded for multi brand machines compatibility is without the need of modification. It is highly recommended for NC program circulation and management due to its user friendly feature.The operational screen provides large quantities go graphic icons, on-line HELP, warning descriptions, detailed operational instructions and messages. These enable the operator to understand the current machine condition and to easily control machining results.
High-Rigidity Structures
The machine body is designed by finite Element Analysis (FEA) to assure optimized mechanical structure.Features include: honeycomb-type base, high-rigidity column mounted with oversized UVZ axes and reinforced low-arm by melting alloy to increase stiffness; these considerations assure superior geometric accuracy even under high pressure flushing while the machine is operated at first cutting.
EF (Electrolysis free) Discharging
High speed EF (Electrolysis Free) discharge method, it minimizes the possibility of workpiece cracking or electrolyze problems. It also increases the lift of the mold and saves brass wire consumption.By using EF (Electrolysis Free) power from rough to fine cut which can reach the average gap voltage to zero, during electrolysis free discharge power, the cation will not move to the cathode and also reducing the elements released like iron, carbon, cobalt, molybdenum to cause the soften surface and shorten the life cycle of moulds; it will increase the life cycle for 5 or 6 times comparing with traditional cutting with electrolysis free power cutting of making press moulds.
AWT SYSTEM
The Accutex unique intelligent servo-control wire-threading technology, together with multi-detectors, makes the threading system possess high speed and good reliability. Also achieves highly efficient auto-machining.
With The unique Straightened and Melted Way
Using impulse circuit makes the wire annealed to straighten. Then, with discharging way, make the end of the wire melted and become a bullet shape about 0.8mm. It can be easy to thread through the guide. Moreover, when encountering the block, the end of the wire wouldn’t be too peaked to curl. As for the workpiece of 300mm, it can directly thread the wire (above 0.25mm) from break point. Even for the wire of 0.1 mm, it also can use this way to thread.
Threading At Wire Break Point
In case of broken wire during machining, there’s no need to return to start point before threading, it is able to thread wire just at break point with nearly 100% possibility. If wire threading fails after several attempts, the intelligent system will return to star point and threads wire again (for workpiece thickness < 120mm,∮0.25/ ∮0.2 brass wire) No limits on taper machining as the system doesn't use high pressure to assist threading and no need to change special small-diameter flushing nozzles.
Precision Servo and transmission System
Using 32, C1 class ball screw with sub-zero and super-finish ground process for maximum smoothness and minimum pitch error. Built in high-response AC servomotor and option with linear scale is mounted close-loop feedback control. The linear scale is mounted close to the ball screw to minimize the slant. Each axis is compensated by laser interferometer to approve the high accuracy and repeatability. By adopting the latest generation Ball-Retainer type linear guide of which the patented structure reduces 90% of frictional variation compared to conventional ones. The movement will be similar to a magnetic levitation, even under complicated routes
High compatibility NC Program Design
Well-designed to be NC-coded for multi brand machines compatibility is without the need of modification. It is highly recommended for NC program circulation and management due to its user friendly feature.The operational screen provides large quantities go graphic icons, on-line HELP, warning descriptions, detailed operational instructions and messages. These enable the operator to understand the current machine condition and to easily control machining results.
High-Rigidity Structures
The machine body is designed by finite Element Analysis (FEA) to assure optimized mechanical structure.Features include: honeycomb-type base, high-rigidity column mounted with oversized UVZ axes and reinforced low-arm by melting alloy to increase stiffness; these considerations assure superior geometric accuracy even under high pressure flushing while the machine is operated at first cutting.
EF (Electrolysis free) Discharging
High speed EF (Electrolysis Free) discharge method, it minimizes the possibility of workpiece cracking or electrolyze problems. It also increases the lift of the mold and saves brass wire consumption.By using EF (Electrolysis Free) power from rough to fine cut which can reach the average gap voltage to zero, during electrolysis free discharge power, the cation will not move to the cathode and also reducing the elements released like iron, carbon, cobalt, molybdenum to cause the soften surface and shorten the life cycle of moulds; it will increase the life cycle for 5 or 6 times comparing with traditional cutting with electrolysis free power cutting of making press moulds.
AWT SYSTEM
The Accutex unique intelligent servo-control wire-threading technology, together with multi-detectors, makes the threading system possess high speed and good reliability. Also achieves highly efficient auto-machining.
With The unique Straightened and Melted Way
Using impulse circuit makes the wire annealed to straighten. Then, with discharging way, make the end of the wire melted and become a bullet shape about 0.8mm. It can be easy to thread through the guide. Moreover, when encountering the block, the end of the wire wouldn’t be too peaked to curl. As for the workpiece of 300mm, it can directly thread the wire (above 0.25mm) from break point. Even for the wire of 0.1 mm, it also can use this way to thread.
Threading At Wire Break Point
In case of broken wire during machining, there’s no need to return to start point before threading, it is able to thread wire just at break point with nearly 100% possibility. If wire threading fails after several attempts, the intelligent system will return to star point and threads wire again (for workpiece thickness < 120mm,∮0.25/ ∮0.2 brass wire) No limits on taper machining as the system doesn't use high pressure to assist threading and no need to change special small-diameter flushing nozzles.
Precision Servo and transmission System
Using 32, C1 class ball screw with sub-zero and super-finish ground process for maximum smoothness and minimum pitch error. Built in high-response AC servomotor and option with linear scale is mounted close-loop feedback control. The linear scale is mounted close to the ball screw to minimize the slant. Each axis is compensated by laser interferometer to approve the high accuracy and repeatability. By adopting the latest generation Ball-Retainer type linear guide of which the patented structure reduces 90% of frictional variation compared to conventional ones. The movement will be similar to a magnetic levitation, even under complicated routes
High compatibility NC Program Design
Well-designed to be NC-coded for multi brand machines compatibility is without the need of modification. It is highly recommended for NC program circulation and management due to its user friendly feature.The operational screen provides large quantities go graphic icons, on-line HELP, warning descriptions, detailed operational instructions and messages. These enable the operator to understand the current machine condition and to easily control machining results.
High-Rigidity Structures
The machine body is designed by finite Element Analysis (FEA) to assure optimized mechanical structure.Features include: honeycomb-type base, high-rigidity column mounted with oversized UVZ axes and reinforced low-arm by melting alloy to increase stiffness; these considerations assure superior geometric accuracy even under high pressure flushing while the machine is operated at first cutting.
EF (Electrolysis free) Discharging
High speed EF (Electrolysis Free) discharge method, it minimizes the possibility of workpiece cracking or electrolyze problems. It also increases the lift of the mold and saves brass wire consumption.By using EF (Electrolysis Free) power from rough to fine cut which can reach the average gap voltage to zero, during electrolysis free discharge power, the cation will not move to the cathode and also reducing the elements released like iron, carbon, cobalt, molybdenum to cause the soften surface and shorten the life cycle of moulds; it will increase the life cycle for 5 or 6 times comparing with traditional cutting with electrolysis free power cutting of making press moulds.
AWT SYSTEM
The Accutex unique intelligent servo-control wire-threading technology, together with multi-detectors, makes the threading system possess high speed and good reliability. Also achieves highly efficient auto-machining.
With The unique Straightened and Melted Way
Using impulse circuit makes the wire annealed to straighten. Then, with discharging way, make the end of the wire melted and become a bullet shape about 0.8mm. It can be easy to thread through the guide. Moreover, when encountering the block, the end of the wire wouldn’t be too peaked to curl. As for the workpiece of 300mm, it can directly thread the wire (above 0.25mm) from break point. Even for the wire of 0.1 mm, it also can use this way to thread.
Threading At Wire Break Point
In case of broken wire during machining, there’s no need to return to start point before threading, it is able to thread wire just at break point with nearly 100% possibility. If wire threading fails after several attempts, the intelligent system will return to star point and threads wire again (for workpiece thickness < 120mm,∮0.25/ ∮0.2 brass wire) No limits on taper machining as the system doesn't use high pressure to assist threading and no need to change special small-diameter flushing nozzles.
Precision Servo and transmission System
Using 32, C1 class ball screw with sub-zero and super-finish ground process for maximum smoothness and minimum pitch error. Built in high-response AC servomotor and option with linear scale is mounted close-loop feedback control. The linear scale is mounted close to the ball screw to minimize the slant. Each axis is compensated by laser interferometer to approve the high accuracy and repeatability. By adopting the latest generation Ball-Retainer type linear guide of which the patented structure reduces 90% of frictional variation compared to conventional ones. The movement will be similar to a magnetic levitation, even under complicated routes
High compatibility NC Program Design
Well-designed to be NC-coded for multi brand machines compatibility is without the need of modification. It is highly recommended for NC program circulation and management due to its user friendly feature.The operational screen provides large quantities go graphic icons, on-line HELP, warning descriptions, detailed operational instructions and messages. These enable the operator to understand the current machine condition and to easily control machining results.
High-Rigidity Structures
The machine body is designed by finite Element Analysis (FEA) to assure optimized mechanical structure.Features include: honeycomb-type base, high-rigidity column mounted with oversized UVZ axes and reinforced low-arm by melting alloy to increase stiffness; these considerations assure superior geometric accuracy even under high pressure flushing while the machine is operated at first cutting.
EF (Electrolysis free) Discharging
High speed EF (Electrolysis Free) discharge method, it minimizes the possibility of workpiece cracking or electrolyze problems. It also increases the lift of the mold and saves brass wire consumption.By using EF (Electrolysis Free) power from rough to fine cut which can reach the average gap voltage to zero, during electrolysis free discharge power, the cation will not move to the cathode and also reducing the elements released like iron, carbon, cobalt, molybdenum to cause the soften surface and shorten the life cycle of moulds; it will increase the life cycle for 5 or 6 times comparing with traditional cutting with electrolysis free power cutting of making press moulds.
AWT SYSTEM
The Accutex unique intelligent servo-control wire-threading technology, together with multi-detectors, makes the threading system possess high speed and good reliability. Also achieves highly efficient auto-machining.
With The unique Straightened and Melted Way
Using impulse circuit makes the wire annealed to straighten. Then, with discharging way, make the end of the wire melted and become a bullet shape about 0.8mm. It can be easy to thread through the guide. Moreover, when encountering the block, the end of the wire wouldn’t be too peaked to curl. As for the workpiece of 300mm, it can directly thread the wire (above 0.25mm) from break point. Even for the wire of 0.1 mm, it also can use this way to thread.
Threading At Wire Break Point
In case of broken wire during machining, there’s no need to return to start point before threading, it is able to thread wire just at break point with nearly 100% possibility. If wire threading fails after several attempts, the intelligent system will return to star point and threads wire again (for workpiece thickness < 120mm,∮0.25/ ∮0.2 brass wire) No limits on taper machining as the system doesn't use high pressure to assist threading and no need to change special small-diameter flushing nozzles.
Precision Servo and transmission System
Using 32, C1 class ball screw with sub-zero and super-finish ground process for maximum smoothness and minimum pitch error. Built in high-response AC servomotor and option with linear scale is mounted close-loop feedback control. The linear scale is mounted close to the ball screw to minimize the slant. Each axis is compensated by laser interferometer to approve the high accuracy and repeatability. By adopting the latest generation Ball-Retainer type linear guide of which the patented structure reduces 90% of frictional variation compared to conventional ones. The movement will be similar to a magnetic levitation, even under complicated routes
High compatibility NC Program Design
Well-designed to be NC-coded for multi brand machines compatibility is without the need of modification. It is highly recommended for NC program circulation and management due to its user friendly feature.The operational screen provides large quantities go graphic icons, on-line HELP, warning descriptions, detailed operational instructions and messages. These enable the operator to understand the current machine condition and to easily control machining results.
High-Rigidity Structures
The machine body is designed by finite Element Analysis (FEA) to assure optimized mechanical structure.Features include: honeycomb-type base, high-rigidity column mounted with oversized UVZ axes and reinforced low-arm by melting alloy to increase stiffness; these considerations assure superior geometric accuracy even under high pressure flushing while the machine is operated at first cutting.
EF (Electrolysis free) Discharging
High speed EF (Electrolysis Free) discharge method, it minimizes the possibility of workpiece cracking or electrolyze problems. It also increases the lift of the mold and saves brass wire consumption.By using EF (Electrolysis Free) power from rough to fine cut which can reach the average gap voltage to zero, during electrolysis free discharge power, the cation will not move to the cathode and also reducing the elements released like iron, carbon, cobalt, molybdenum to cause the soften surface and shorten the life cycle of moulds; it will increase the life cycle for 5 or 6 times comparing with traditional cutting with electrolysis free power cutting of making press moulds.
AWT SYSTEM
The Accutex unique intelligent servo-control wire-threading technology, together with multi-detectors, makes the threading system possess high speed and good reliability. Also achieves highly efficient auto-machining.
With The unique Straightened and Melted Way
Using impulse circuit makes the wire annealed to straighten. Then, with discharging way, make the end of the wire melted and become a bullet shape about 0.8mm. It can be easy to thread through the guide. Moreover, when encountering the block, the end of the wire wouldn’t be too peaked to curl. As for the workpiece of 300mm, it can directly thread the wire (above 0.25mm) from break point. Even for the wire of 0.1 mm, it also can use this way to thread.
Threading At Wire Break Point
In case of broken wire during machining, there’s no need to return to start point before threading, it is able to thread wire just at break point with nearly 100% possibility. If wire threading fails after several attempts, the intelligent system will return to star point and threads wire again (for workpiece thickness < 120mm,∮0.25/ ∮0.2 brass wire) No limits on taper machining as the system doesn't use high pressure to assist threading and no need to change special small-diameter flushing nozzles.
Precision Servo and transmission System
Using 32, C1 class ball screw with sub-zero and super-finish ground process for maximum smoothness and minimum pitch error. Built in high-response AC servomotor and option with linear scale is mounted close-loop feedback control. The linear scale is mounted close to the ball screw to minimize the slant. Each axis is compensated by laser interferometer to approve the high accuracy and repeatability. By adopting the latest generation Ball-Retainer type linear guide of which the patented structure reduces 90% of frictional variation compared to conventional ones. The movement will be similar to a magnetic levitation, even under complicated routes
High compatibility NC Program Design
Well-designed to be NC-coded for multi brand machines compatibility is without the need of modification. It is highly recommended for NC program circulation and management due to its user friendly feature.The operational screen provides large quantities go graphic icons, on-line HELP, warning descriptions, detailed operational instructions and messages. These enable the operator to understand the current machine condition and to easily control machining results.
High-Rigidity Structures
The machine body is designed by finite Element Analysis (FEA) to assure optimized mechanical structure.Features include: honeycomb-type base, high-rigidity column mounted with oversized UVZ axes and reinforced low-arm by melting alloy to increase stiffness; these considerations assure superior geometric accuracy even under high pressure flushing while the machine is operated at first cutting.
EF (Electrolysis free) Discharging
High speed EF (Electrolysis Free) discharge method, it minimizes the possibility of workpiece cracking or electrolyze problems. It also increases the lift of the mold and saves brass wire consumption.By using EF (Electrolysis Free) power from rough to fine cut which can reach the average gap voltage to zero, during electrolysis free discharge power, the cation will not move to the cathode and also reducing the elements released like iron, carbon, cobalt, molybdenum to cause the soften surface and shorten the life cycle of moulds; it will increase the life cycle for 5 or 6 times comparing with traditional cutting with electrolysis free power cutting of making press moulds.
AWT SYSTEM
The Accutex unique intelligent servo-control wire-threading technology, together with multi-detectors, makes the threading system possess high speed and good reliability. Also achieves highly efficient auto-machining.
With The unique Straightened and Melted Way
Using impulse circuit makes the wire annealed to straighten. Then, with discharging way, make the end of the wire melted and become a bullet shape about 0.8mm. It can be easy to thread through the guide. Moreover, when encountering the block, the end of the wire wouldn’t be too peaked to curl. As for the workpiece of 300mm, it can directly thread the wire (above 0.25mm) from break point. Even for the wire of 0.1 mm, it also can use this way to thread.
Threading At Wire Break Point
In case of broken wire during machining, there’s no need to return to start point before threading, it is able to thread wire just at break point with nearly 100% possibility. If wire threading fails after several attempts, the intelligent system will return to star point and threads wire again (for workpiece thickness < 120mm,∮0.25/ ∮0.2 brass wire) No limits on taper machining as the system doesn't use high pressure to assist threading and no need to change special small-diameter flushing nozzles.
Precision Servo and transmission System
Using 32, C1 class ball screw with sub-zero and super-finish ground process for maximum smoothness and minimum pitch error. Built in high-response AC servomotor and option with linear scale is mounted close-loop feedback control. The linear scale is mounted close to the ball screw to minimize the slant. Each axis is compensated by laser interferometer to approve the high accuracy and repeatability. By adopting the latest generation Ball-Retainer type linear guide of which the patented structure reduces 90% of frictional variation compared to conventional ones. The movement will be similar to a magnetic levitation, even under complicated routes
High compatibility NC Program Design
Well-designed to be NC-coded for multi brand machines compatibility is without the need of modification. It is highly recommended for NC program circulation and management due to its user friendly feature.The operational screen provides large quantities go graphic icons, on-line HELP, warning descriptions, detailed operational instructions and messages. These enable the operator to understand the current machine condition and to easily control machining results.
High-Rigidity Structures
The machine body is designed by finite Element Analysis (FEA) to assure optimized mechanical structure.Features include: honeycomb-type base, high-rigidity column mounted with oversized UVZ axes and reinforced low-arm by melting alloy to increase stiffness; these considerations assure superior geometric accuracy even under high pressure flushing while the machine is operated at first cutting.
EF (Electrolysis free) Discharging
High speed EF (Electrolysis Free) discharge method, it minimizes the possibility of workpiece cracking or electrolyze problems. It also increases the lift of the mold and saves brass wire consumption.By using EF (Electrolysis Free) power from rough to fine cut which can reach the average gap voltage to zero, during electrolysis free discharge power, the cation will not move to the cathode and also reducing the elements released like iron, carbon, cobalt, molybdenum to cause the soften surface and shorten the life cycle of moulds; it will increase the life cycle for 5 or 6 times comparing with traditional cutting with electrolysis free power cutting of making press moulds.
AWT SYSTEM
The Accutex unique intelligent servo-control wire-threading technology, together with multi-detectors, makes the threading system possess high speed and good reliability. Also achieves highly efficient auto-machining.
With The unique Straightened and Melted Way
Using impulse circuit makes the wire annealed to straighten. Then, with discharging way, make the end of the wire melted and become a bullet shape about 0.8mm. It can be easy to thread through the guide. Moreover, when encountering the block, the end of the wire wouldn’t be too peaked to curl. As for the workpiece of 300mm, it can directly thread the wire (above 0.25mm) from break point. Even for the wire of 0.1 mm, it also can use this way to thread.
Threading At Wire Break Point
In case of broken wire during machining, there’s no need to return to start point before threading, it is able to thread wire just at break point with nearly 100% possibility. If wire threading fails after several attempts, the intelligent system will return to star point and threads wire again (for workpiece thickness < 120mm,∮0.25/ ∮0.2 brass wire) No limits on taper machining as the system doesn't use high pressure to assist threading and no need to change special small-diameter flushing nozzles.
Precision Servo and transmission System
Using 32, C1 class ball screw with sub-zero and super-finish ground process for maximum smoothness and minimum pitch error. Built in high-response AC servomotor and option with linear scale is mounted close-loop feedback control. The linear scale is mounted close to the ball screw to minimize the slant. Each axis is compensated by laser interferometer to approve the high accuracy and repeatability. By adopting the latest generation Ball-Retainer type linear guide of which the patented structure reduces 90% of frictional variation compared to conventional ones. The movement will be similar to a magnetic levitation, even under complicated routes
High compatibility NC Program Design
Well-designed to be NC-coded for multi brand machines compatibility is without the need of modification. It is highly recommended for NC program circulation and management due to its user friendly feature.The operational screen provides large quantities go graphic icons, on-line HELP, warning descriptions, detailed operational instructions and messages. These enable the operator to understand the current machine condition and to easily control machining results.
High-Rigidity Structures
The machine body is designed by finite Element Analysis (FEA) to assure optimized mechanical structure.Features include: honeycomb-type base, high-rigidity column mounted with oversized UVZ axes and reinforced low-arm by melting alloy to increase stiffness; these considerations assure superior geometric accuracy even under high pressure flushing while the machine is operated at first cutting.
EF (Electrolysis free) Discharging
High speed EF (Electrolysis Free) discharge method, it minimizes the possibility of workpiece cracking or electrolyze problems. It also increases the lift of the mold and saves brass wire consumption.By using EF (Electrolysis Free) power from rough to fine cut which can reach the average gap voltage to zero, during electrolysis free discharge power, the cation will not move to the cathode and also reducing the elements released like iron, carbon, cobalt, molybdenum to cause the soften surface and shorten the life cycle of moulds; it will increase the life cycle for 5 or 6 times comparing with traditional cutting with electrolysis free power cutting of making press moulds.
AWT SYSTEM
The Accutex unique intelligent servo-control wire-threading technology, together with multi-detectors, makes the threading system possess high speed and good reliability. Also achieves highly efficient auto-machining.
With The unique Straightened and Melted Way
Using impulse circuit makes the wire annealed to straighten. Then, with discharging way, make the end of the wire melted and become a bullet shape about 0.8mm. It can be easy to thread through the guide. Moreover, when encountering the block, the end of the wire wouldn’t be too peaked to curl. As for the workpiece of 300mm, it can directly thread the wire (above 0.25mm) from break point. Even for the wire of 0.1 mm, it also can use this way to thread.
Threading At Wire Break Point
In case of broken wire during machining, there’s no need to return to start point before threading, it is able to thread wire just at break point with nearly 100% possibility. If wire threading fails after several attempts, the intelligent system will return to star point and threads wire again (for workpiece thickness < 120mm,∮0.25/ ∮0.2 brass wire) No limits on taper machining as the system doesn't use high pressure to assist threading and no need to change special small-diameter flushing nozzles.
Precision Servo and transmission System
Using 32, C1 class ball screw with sub-zero and super-finish ground process for maximum smoothness and minimum pitch error. Built in high-response AC servomotor and option with linear scale is mounted close-loop feedback control. The linear scale is mounted close to the ball screw to minimize the slant. Each axis is compensated by laser interferometer to approve the high accuracy and repeatability. By adopting the latest generation Ball-Retainer type linear guide of which the patented structure reduces 90% of frictional variation compared to conventional ones. The movement will be similar to a magnetic levitation, even under complicated routes
High compatibility NC Program Design
Well-designed to be NC-coded for multi brand machines compatibility is without the need of modification. It is highly recommended for NC program circulation and management due to its user friendly feature.The operational screen provides large quantities go graphic icons, on-line HELP, warning descriptions, detailed operational instructions and messages. These enable the operator to understand the current machine condition and to easily control machining results.
High-Rigidity Structures
The machine body is designed by finite Element Analysis (FEA) to assure optimized mechanical structure.Features include: honeycomb-type base, high-rigidity column mounted with oversized UVZ axes and reinforced low-arm by melting alloy to increase stiffness; these considerations assure superior geometric accuracy even under high pressure flushing while the machine is operated at first cutting.
EF (Electrolysis free) Discharging
High speed EF (Electrolysis Free) discharge method, it minimizes the possibility of workpiece cracking or electrolyze problems. It also increases the lift of the mold and saves brass wire consumption.By using EF (Electrolysis Free) power from rough to fine cut which can reach the average gap voltage to zero, during electrolysis free discharge power, the cation will not move to the cathode and also reducing the elements released like iron, carbon, cobalt, molybdenum to cause the soften surface and shorten the life cycle of moulds; it will increase the life cycle for 5 or 6 times comparing with traditional cutting with electrolysis free power cutting of making press moulds.
AWT SYSTEM
The Accutex unique intelligent servo-control wire-threading technology, together with multi-detectors, makes the threading system possess high speed and good reliability. Also achieves highly efficient auto-machining.
With The unique Straightened and Melted Way
Using impulse circuit makes the wire annealed to straighten. Then, with discharging way, make the end of the wire melted and become a bullet shape about 0.8mm. It can be easy to thread through the guide. Moreover, when encountering the block, the end of the wire wouldn’t be too peaked to curl. As for the workpiece of 300mm, it can directly thread the wire (above 0.25mm) from break point. Even for the wire of 0.1 mm, it also can use this way to thread.
Threading At Wire Break Point
In case of broken wire during machining, there’s no need to return to start point before threading, it is able to thread wire just at break point with nearly 100% possibility. If wire threading fails after several attempts, the intelligent system will return to star point and threads wire again (for workpiece thickness < 120mm,∮0.25/ ∮0.2 brass wire) No limits on taper machining as the system doesn't use high pressure to assist threading and no need to change special small-diameter flushing nozzles.
Precision Servo and transmission System
Using 32, C1 class ball screw with sub-zero and super-finish ground process for maximum smoothness and minimum pitch error. Built in high-response AC servomotor and option with linear scale is mounted close-loop feedback control. The linear scale is mounted close to the ball screw to minimize the slant. Each axis is compensated by laser interferometer to approve the high accuracy and repeatability. By adopting the latest generation Ball-Retainer type linear guide of which the patented structure reduces 90% of frictional variation compared to conventional ones. The movement will be similar to a magnetic levitation, even under complicated routes
High compatibility NC Program Design
Well-designed to be NC-coded for multi brand machines compatibility is without the need of modification. It is highly recommended for NC program circulation and management due to its user friendly feature.The operational screen provides large quantities go graphic icons, on-line HELP, warning descriptions, detailed operational instructions and messages. These enable the operator to understand the current machine condition and to easily control machining results.
The machine structure is constructed from high quality Meehanite cast iron and stress released to ensure great rigidity and prolonged precision.
All axes with high precision linear guideway ensure rapid movement and accurate positioning.
The column bottom is specially designed with A-shaped structure to increase machine stability while machining.
High-Rigidity Structures
The machine body is designed by finite Element Analysis (FEA) to assure optimized mechanical structure.Features include: honeycomb-type base, high-rigidity column mounted with oversized UVZ axes and reinforced low-arm by melting alloy to increase stiffness; these considerations assure superior geometric accuracy even under high pressure flushing while the machine is operated at first cutting.
EF (Electrolysis free) Discharging
High speed EF (Electrolysis Free) discharge method, it minimizes the possibility of workpiece cracking or electrolyze problems. It also increases the lift of the mold and saves brass wire consumption.By using EF (Electrolysis Free) power from rough to fine cut which can reach the average gap voltage to zero, during electrolysis free discharge power, the cation will not move to the cathode and also reducing the elements released like iron, carbon, cobalt, molybdenum to cause the soften surface and shorten the life cycle of moulds; it will increase the life cycle for 5 or 6 times comparing with traditional cutting with electrolysis free power cutting of making press moulds.
AWT SYSTEM
The Accutex unique intelligent servo-control wire-threading technology, together with multi-detectors, makes the threading system possess high speed and good reliability. Also achieves highly efficient auto-machining.
With The unique Straightened and Melted Way
Using impulse circuit makes the wire annealed to straighten. Then, with discharging way, make the end of the wire melted and become a bullet shape about 0.8mm. It can be easy to thread through the guide. Moreover, when encountering the block, the end of the wire wouldn’t be too peaked to curl. As for the workpiece of 300mm, it can directly thread the wire (above 0.25mm) from break point. Even for the wire of 0.1 mm, it also can use this way to thread.
Threading At Wire Break Point
In case of broken wire during machining, there’s no need to return to start point before threading, it is able to thread wire just at break point with nearly 100% possibility. If wire threading fails after several attempts, the intelligent system will return to star point and threads wire again (for workpiece thickness < 120mm,∮0.25/ ∮0.2 brass wire) No limits on taper machining as the system doesn't use high pressure to assist threading and no need to change special small-diameter flushing nozzles.
Precision Servo and transmission System
Using 32, C1 class ball screw with sub-zero and super-finish ground process for maximum smoothness and minimum pitch error. Built in high-response AC servomotor and option with linear scale is mounted close-loop feedback control. The linear scale is mounted close to the ball screw to minimize the slant. Each axis is compensated by laser interferometer to approve the high accuracy and repeatability. By adopting the latest generation Ball-Retainer type linear guide of which the patented structure reduces 90% of frictional variation compared to conventional ones. The movement will be similar to a magnetic levitation, even under complicated routes
High compatibility NC Program Design
Well-designed to be NC-coded for multi brand machines compatibility is without the need of modification. It is highly recommended for NC program circulation and management due to its user friendly feature.The operational screen provides large quantities go graphic icons, on-line HELP, warning descriptions, detailed operational instructions and messages. These enable the operator to understand the current machine condition and to easily control machining results.
FMD155 Built-in asynchronous motor spindle unit is designed for drilling and tapping applications. The feeding is transmitted by a C5 class ball screw and servo motor for accurate positioning. This product design provides space saving and increasing your efficiency and productivity. The spindle nose accuracy is under 0.003mm and maximum drilling capacity up to 30mm (S45C).
High-Rigidity Structures
The machine body is designed by finite Element Analysis (FEA) to assure optimized mechanical structure.Features include: honeycomb-type base, high-rigidity column mounted with oversized UVZ axes and reinforced low-arm by melting alloy to increase stiffness; these considerations assure superior geometric accuracy even under high pressure flushing while the machine is operated at first cutting.
EF (Electrolysis free) Discharging
High speed EF (Electrolysis Free) discharge method, it minimizes the possibility of workpiece cracking or electrolyze problems. It also increases the lift of the mold and saves brass wire consumption.By using EF (Electrolysis Free) power from rough to fine cut which can reach the average gap voltage to zero, during electrolysis free discharge power, the cation will not move to the cathode and also reducing the elements released like iron, carbon, cobalt, molybdenum to cause the soften surface and shorten the life cycle of moulds; it will increase the life cycle for 5 or 6 times comparing with traditional cutting with electrolysis free power cutting of making press moulds.
AWT SYSTEM
The Accutex unique intelligent servo-control wire-threading technology, together with multi-detectors, makes the threading system possess high speed and good reliability. Also achieves highly efficient auto-machining.
With The unique Straightened and Melted Way
Using impulse circuit makes the wire annealed to straighten. Then, with discharging way, make the end of the wire melted and become a bullet shape about 0.8mm. It can be easy to thread through the guide. Moreover, when encountering the block, the end of the wire wouldn’t be too peaked to curl. As for the workpiece of 300mm, it can directly thread the wire (above 0.25mm) from break point. Even for the wire of 0.1 mm, it also can use this way to thread.
Threading At Wire Break Point
In case of broken wire during machining, there’s no need to return to start point before threading, it is able to thread wire just at break point with nearly 100% possibility. If wire threading fails after several attempts, the intelligent system will return to star point and threads wire again (for workpiece thickness < 120mm,∮0.25/ ∮0.2 brass wire) No limits on taper machining as the system doesn't use high pressure to assist threading and no need to change special small-diameter flushing nozzles.
Precision Servo and transmission System
Using 32, C1 class ball screw with sub-zero and super-finish ground process for maximum smoothness and minimum pitch error. Built in high-response AC servomotor and option with linear scale is mounted close-loop feedback control. The linear scale is mounted close to the ball screw to minimize the slant. Each axis is compensated by laser interferometer to approve the high accuracy and repeatability. By adopting the latest generation Ball-Retainer type linear guide of which the patented structure reduces 90% of frictional variation compared to conventional ones. The movement will be similar to a magnetic levitation, even under complicated routes
High compatibility NC Program Design
Well-designed to be NC-coded for multi brand machines compatibility is without the need of modification. It is highly recommended for NC program circulation and management due to its user friendly feature.The operational screen provides large quantities go graphic icons, on-line HELP, warning descriptions, detailed operational instructions and messages. These enable the operator to understand the current machine condition and to easily control machining results.
AP series casting has compound table design by Y axis column moving. The center of gravity is always located between 2 linear guideways of X axis table. X and Y axes are independent without accumulation error for less deformation by FEA (Finite Element Analysis). Improved maximum loading weight is up to 1000kgs. The Bi-repeatability is less than 2.5μm after 5 times
laser calibration.
Machine structure was designed via Finite Element Analysis (FEA) with high rigidity.
AccuteX machine is capable with industry 4.0 who has M2M (machine to machine) protocol to collaborate with Robots and other machines. Flexible Real-time production can be made by Intelligent Manufacturing Integration System to meet full-automation demand.
AP series casting has compound table design by Y axis column moving. The center of gravity is always located between 2 linear guideways of X axis table. X and Y axes are independent without accumulation error for less deformation by FEA (Finite Element Analysis). Improved maximum loading weight is up to 1000kgs. The Bi-repeatability is less than 2.5μm after 5 times
laser calibration.
Machine structure was designed via Finite Element Analysis (FEA) with high rigidity.
AccuteX machine is capable with industry 4.0 who has M2M (machine to machine) protocol to collaborate with Robots and other machines. Flexible Real-time production can be made by Intelligent Manufacturing Integration System to meet full-automation demand.
Universal Arm Magnetic Base for indicators, it can be set at any point in 360˚, very quick and convenient for operation.
S-TYPE Special heavy duty model #122
Extremely high accuracy and precision design, suitable for CNC machining and machining center. All parts are ground, heat treated, surface treated and under specific QC condition.
H-TYPE Heavy duty model #123
Industrial design especially for milling machines and drilling machines.
All hardened parts ensure long life and safety while in operation.
YL-M308
Easy, portable, light weight
Applicable tapping for small diameter
Under less effort, can be impact tapping
Choose any five Tap Collect (M3~M8)
YL-312A
Replace Collets easily
Without motor, keep the cost down
Handle can rotate for 360°
Choose any seven Safety clutch Tapping Adapters (M3~M12)
The machine structure is constructed from high quality Meehanite cast iron and stress released to ensure great rigidity and prolonged precision.
All axes with high precision linear guideway ensure rapid movement and accurate positioning.
The column bottom is specially designed with A-shaped structure to increase machine stability while machining.
*With excellent thermal balance with a rigid case base construction.
*Double-column design to secure high levels of machining accuracy and heavy loading with long-life durability and machining stability.
SD-32 is one of our compact CNC lathe that designed especially for small and high precision parts, as well as provides powerful processing capacity, stable quality, and accuracy. It could be mounted a turret, gang type tool holders, and/or cross-drilling device to meet the requirements in any kind of precision machining.
Features
The structures of major components for DMCB machining centers have been designed with the finite element method (FEM). We refine our design and improve product quality.
The ECOM DMCB provides stability, and power requiring to deliver super-sized precision for meticulous industries such as aerospace, electronics, and automotive.
The solid double-column construction ensures greater rigidity and closer tolerances, making this machine well-suited for the efficient machining of general parts and rapid die & mold jobs. ECOM double-column machines deliver repeatedly.
Features
1.The ECOM HMC-Series is a horizontal machining center designed specifically for a No. 50 taper spindle, and is ideal for mass production of large workpieces. The machine meets a wide range of machining needs, mainly from the automotive and construction machinery fields. The ECOM HMC-Series accommodates workpieces up to a maximum part capacity of 400~1200kg. All HMC-Series are with an integrated 4th-axis rotary table.
Features
1.ECOM Precision VL-i Series is a combination of speed, rigidity, and precision. It eliminates vibration, ensuring excellent surface finishes and long cutting tool life. Adhering to our outstanding quality and development experience on the vertical machining centers for many years, the series of vertical high-speed machining centers can provide your customers a faster processing efficiency and more machining quality.
2.The VL-i model comes with a high-performance roller linear guideway for all 3-axis. It provides fast & accurate rapid feed, and also the allowance of heavy workpiece Z-axis.
3.The 3-axis C3 class high precision ballscrews all has been well pre-extension, and directly coupled to A/C servo motors. It significantly eliminates backlash and ensures the highest rigidity.
4.The large-diameter ultra precision ballscrews directly coupled to the feed motor and are arranged in the center of each guideway and close to the cutting point.
*Max. turning diameter 20mm.
*With guide bush holder and long parts catcher, it can make long and complicated components.
*With non guide bush holder, the length of rest bar can be reduced up to 50mm.
*Seven axes simultaneously movement (X1/Y1/Z1/X2/Z2/C1/C2).
*Main / Sub spindle C axis movement.
*Sub tooling system can make eccentric drilling, milling and grooving function.
*With FANUC 32i-A controller, most of the complicated components can be finished by this machine in one cycle time.
Features
1.5-Axis VX-14i, the most efficient & intelligent machining concept for multi-sided high-performance machining, increase productivity, flexibility and repeatability.
2.B-axis Continuous Swivel Milling Head, by roller cam system, it assures the maximum dynamic moment and linearity. The B-axis changes from vertical to horizontal machining in just seconds.
3.C-axis Rotary Table, the fully automatic 0.001° indexing from vertical to horizontal positions through a torque motor. Multi-Sided machining without resetting the workpiece.
4.3+2 Advantages: Offers an extra flexibility. Manufacture of complex components with a single set-up. Reduce the chance at scrap of making mistake and wasting time. 5-sided machining without additional fixture. Increased accuracy and shorter cycle time.
Features
1.Simplifying Processes: Each pallet is hydraulically locked with four taper cones for high accuracy positioning.
2.Improve Productivities: The VL-850/1000 APC allows customers to process complex machinings such as milling, drilling, boring, and more. Ideal for mass production applications on two individual pallets.
Features
1.VL-V8 comes with a high-performance roller linear guideway for all 3-axis. It provides fast & accurate rapid feed, and also the allowance of heavy workpiece Z-axis.
2.The 3-axis pre-loaded C3 class high precision ballscrews all has been well pre-extension, and directly coupled to A/C servo motors. It significantly eliminates backlash and ensures the highest rigidity.
3.The large-diameter ultra precision ballscrews directly coupled to the feed motor and are arranged in the center of each guideway and close to the cutting point.
Features
1.The VLB i Series offers optimum alignment of the motor and gearbox ensures no offset and guarantees steady smooth movement of the headstock along the Z-axis. This design significantly reduces torsion on the headstock and ensures optimum rigidity, long term accuracy, and repeatability. Large diameter pre-tensioned ballscrews have a double-nut preloaded design eliminating the potential thermal growth and promote high accuracy and high-speed positioning.
2.The X&Y roller linear guideways fully support the machine’s saddle and worktable, delivering outstanding X&Y-axis accuracy over the full travel range of the machine. This is critical during machining heavy workpieces. It can avoid deflection and is a key factor in maintaining part accuracy and precision. The Z sliding surface areas and gibs are coated with Turcite-B and hand-scraped for perfect fit and alignment.
●Significantly upgrade CNC 5-Axis Machines
●Special 45° dovetail structure with teeth
●The patented calibration system can regulate clamping center easily and rapidly
1) Vise body is made of High quality Steel (S50C) and its slideways gone through high-frequency hardening to achieve HRC50, which makes the whole part durable.
2) Detachable jaws are made of High quality Tool Steel (SCM440) and gone through carburizing to achieve HRC55. Since both sides are fixed size and able to be used as a datum, users can reverse them to increase clamping range.
3) The vise's clamping force can achieve 1300KG, the repeatability positioning precision of its clamping center is within 0.015mm.
4) Users can calibrate the clamping center of vise by adjusting the screws on both ends.
5) The 45° dovetail structure with teeth on the upper jaw ensures the bottom of the workpiece to be firmly clamped.
●Shortest Length with Big Jaw Opening
●Extremely High Accuracy and Repeatability
●Special MULTI-POWER design enhances clamping force of 5000KG
●Suitable for CNC 5-Axis Machining Centers, horizontal and vertical CNC Machining Centers
1) Compact design with big jaw opening, which enhances machine space utilization.
2) Vise jaws are made of High quality Tool Steel (SCM440) and Hardened to achieve HRC 55, which makes vise clamp the workpieces easily and firmly.
3) Vise body is made of Ductile lron above FCD 60 grade and its slideways are hardened to HRC 52 , which makes the vise tensile strength with high precision accuracy.
4) The patented MULTI-POWER SYSTEM is built of high grade BEARING STEEL which doubles the clamping force. Adjustable clamping force 5000kg. With this special patented system the pressure is more consistent and eliminates oil leakage and maintenance problems associated with Hydraulic Vises.
5) Special Leadscrew Covers protect Leadscrew from swarf and avoid any possible damage to internal parts.
●Electro-Permanent Magnetic Chuck structure design, use the natures of different permanent magnetic materials, through electronic control system control and convert the distibution of internal magnetic circuit, magnetic disk (i.e. in tight clamping state), and demagnetize (i.e. in loosing state).
●Magnetization and demagneticzation time is only 3-12 seconds. After completion, it does not need to continuously supply power to produce safe and strong magnetic force. It does not have the problem with temperature rise. It can last for a long time. The maintenance is easy. It is both economic and environment friendly.
●Shorten workpiece installation time, fast mold change, save work time, increase productivity.
●Strong and stable magnetic force, assure tight fastening of workpiece, high processing precision.
●Use and Applicable Areas:
General cutting and processing for all kinds of iron parts, rapid mold change, suitable for CNC vertical computer milling machine and horizontal computer milling machine, general milling machine precision machining; the Electro-Permanent Magnetic Chuck is highly mobile, suitable for any machine.
Workpiece thickness requirement
ECMC-A Series: above 15mm
ECMC-B Series: above 25mm
ECMC-C Series: above 40mm
ECMC-D Series: above 50mm
●As workpiece is clamped, strongest magnetic force is achieved when the contact is from more than 4 magnetic poles.
●Magnetic pole dimensions 50x50 mm, suitable for general cutting and processing for small and medium workpiece.
●Magnetic pole dimensions 70x70 mm, suitable for general cutting and processing for medium and large workpiece.
●Work with various magnetic soft jaws and movable spring pads, flexible adjustment and configuration according to processing needs.
1) Suitable for the magnetic material processing
2) Quick clamping the workpiece and provide five-sided processing
3) Work with various magnetic Soft jaws, flexible adjustment and configuration according to processing needs
Use and Applicable Areas:
●Milling, Grinding, Turning, Drilling, Automation, etc.
●Suitable for medium and large size of workpiece machining on milling machine and CNC machining center
●Users can array several magnetic vises in one set-up on a working table or a tooling tombstones to custom their own workholding solutions
●Mechanical vise (powerful clamping)
●Shortest Length with Big Jaw Opening
●Extremely High Accuracy and Repeatability
●Special MULTI-POWER design enhances clamping force of 0~8000KG (adjustable)
●Suitable for Gantry-Type machining centers
1.Vise Fixed Jaw is made of high quality steel and HARDENED to HRC 55. Vise body is made of Ductile Iron above FCD 60 grade for high precision and durability. With a force of 4500kg, the shape will deflect less than 0.005mm.
2.Slide ways are HARDENED to HRC 50 to further increase durability and maintain positioning height over long use.
3.The Special ANGLE-LOCK SYSTEM with compact design and high-grade iron of over FCD 60 grade for high rigidity automatically pulls the work-piece down to the accurate position of within 0.005mm under 4500kg of pressure. This vise is most suitable for precision mould making on Machining Centers.
4.Vise can be mounted horizontally or vertically.
5.The patented MULTI-POWER SYSTEM built of HIGH GRADE BEARING STEEL doubles the clamping force.
The pressure is more consistent and eliminates all leakage and maintenance problems associated with Hydraulic Vices.
With the first half a turn the vise will clamp with 2500kg pressure. With a second half turn it will apply 4500kg of clamping force.
This special patented system makes the clamping force constant.
6.Adjusting stop ring: This simple and effective presetting device enables to preset each desired clamping force and it guarantees to repeat each clamping operation at the same clamping force.
Mechanical Vise
Shortest Length with Big Jaw Opening
Extremely High Accuracy and Repeatability
Special MULTI-POWER design enhances clamping force of 0~6000KG
1.The patented MULTI-POWER SYSTEM is built of HIGH GRADE BEARING STEEL which doubles the clamping force. Adjustable clamping force of 0~6000kg. With this special patented system the pressure is more consistent and eliminates oil leakage and maintenance problems associated with Hydraulic Vices.
2.Slide ways are HARDENED to HRC 50º to further increase durability and maintain positioning height over long use.
3.Using high-grade iron of over FCD 60 grade for high rigidity and also ANGLE-LOCK SYSTEM, which automatically pulls the work-piece down to the accurate position of within 0.01mm under 4500kg of pressure, this vise is most suitable for precision mould making on Machining Centers.
4.Vise body is made of Ductile lron above FCD 60 grade for high precision and durability.
It is made in one solid piece and has very high rigidity with a force of 4500kg, the shape will deflect less than 0.01mm.
5.Vise can be mounted horizontally or vertically.
6.Adjusting stop ring: this simple and effective presetting device enables to preset each desired clamping force and it guarantees to repeat each clamping operation at the same clamping force.
Jig Grinder with superstructure fabricated by granite, which is well-known by its excellent damping, low heat conductivity, rust-proof, and corrosion resistance, is capable of stabilizing the machine accuracy and enhancing the roughness on workpiece. Stiffness and accuracy is also enhanced with the motors on three axis(X,Y,W) direct-driven design transmission. C1 grade ballscrew was adopted, pre-tension by 3°c in temperature increment, which is effectively upgrading stiffness and preventing from deformation during operation.
Feature:
1. Hydrostatic rotary tgable adopted in C axis; Roundness: approximate 1um.
2.HEIDENHAIN linear encoder equipped in X and Y axis; resolution:0.05um
3.Minimum setting unit 0.0001mm in X and Z axis
4.Automatic tool changer ATC, model No. 4T/4T(with DD motor) type of spindle tapping:HSK-A63, model No. 8CT/12CT type of tapping: HSK-A100
5.Auto-dressing and auto-compensation feature
6.C-axis for CVG-4TD is using built-in motor design with angle control in order to work for profile or eccentric circle.
7.Conversational format interface: diagram demonstration to edit grinding program. It is easy and faster setting grinding parameter for any new operator.
Variable Displacement Vane Pump With Gerotor, Cooling Gerotor
Variable Displacement Vane Pump with Cooling circulation pump is CML Unique and patented design. First, improve machining accuracy. By sucks in heated oil from the tank and delivers it to the radiator. It effectively reduced oil temperature under a continuous process of circulation which stabilize operation conditions. Second, saving cost. Proven by tests, to combine with proper cooler, it performs a lot better cooling efficiency than cooling only from the drain port. By reducing the size of the tank (reservoir), it could save the machine space and the volume of hydraulic oil, eventually saving cost.
http://www.cml-motion.com/en/product/VCM-SF_SM_DF-CG.html
1.Feature:
options of centering Microscope, CCD camera, Laser and other projection system depends on the different workpiece. Further application, manual, motorized with joystick or the CNC model can be optional by your demands.
2.Application:
IC electronics, Lead Frame and the related manufacturers in the fields of LCD, Semiconductor, PCB Screen printing WireCut. E.D.M. Rubber.Plastic, Precise Mold & Dies and other 2D workpiece machining.
3.Measuring Functions:
The multi-function MSU 3DPRO effects the 2D geometric measurement of Point, Line, Circle, Arc, Angle, Distance, Pitching, Alignment, and is accompanied with RS232 port.
UCC universal CMM controller is a sophisticated integrated motion control system, which is available with three levels of operating capability: Touch-trigger probing. Digitizing and Full scanning capability including Renishaw's patented RENSCAN DC
Software AAT-CAPPS:
The click-N-Measure CAN based inspection effect the CAD Alignment off-line simulation Probe Collision Avoidance Free From Scanning... and son on functions of intelligent measurement.
ASM is the first 5-axis CNC turning and milling machining center of Vision Wide, and it is particularly designed for delicate cylindrical components machining featuring high acceleration, rapid feed-rate and synchronized axes machining, especially for aerospace components, tire molds, turbine blades and aluminum parts.
ASM accessorizes with 5-axis universal head and rotary shafts built-in D.D motor. Through topology analysis, ASM realizes the best distance between tool center point and B-axis transmission
XM series moving column machining center is a product developed for the machining needs of large-scale precision machinery, electric power, wind power, energy, petrochemical, transportation... and other equipment. It has:
● Huge workpiece machining space: For precision machining of various types of structural parts, it can provide super large XYZ axis machining space.
● High-precise positioning: The high-standard geometric accuracy and positioning accuracy capabilities of the whole machine enable large-scale precision machining
● Heavy cutting capacity: Provide a variety of high rated torque spindles to meet the processing and cutting capabilities of various materials.
● Fully automatic multi-face machining: It can be matched with various automatic attachment heads for high tangential speed mold surface machining and various types of precision parts complex angle machining, with excellent tool tip point error automatic correction function, and automatic additional head and tool exchange function, it can realize fully automatic machining performance.
● Milling and turning compound multitask: This machine can be equipped with a high-torque and high-speed vertical turning table to realize milling and turning compound automatic machining.
NF series machines, with typical VW products features of rigid structure and high precision, are designed with 5-face function of multi-angle cutting and X-Y roller ways structure. It speeds up 3 axes rapid traverse and increases the machine’s efficiency of utilization.
UC Series, ultrasonic machining center, is mainly designed for aerospace honeycomb structure processing and it can efficiently perform honeycomb structure cutting with different inclinations, and output various structural shapes that meet customer needs.
● Composite paper honeycomb angle processing – triangle cutter processing and disc cutter processing
● With lightweight and dynamic column structure, combined with precision gears and racks, the movement is fast, ensuring the best feed speed.
● Oil-free pollution processing of advanced materials, and the three-axis slide rail adopts full grease lubrication device.
● Using European standard precision gear transmission on feeding axis to be provided with high feed rigidity position accuracy.
● Feeding axis with high accuracy linear scale feedback to use low thermal deformation coefficient to control positioning accuracy on linear scale.
● Feeding axes are using roller type linear guideway to keep accuracy for a long term.
● Vacuum chuck is clamping device under vacuum table to make workpiece adsorb stably on table.
● Two axis head self-monitoring protection system.
Spindle cooling system.
● Auto workpiece coordinate measurement / Contacting auto tool length measurement / Triangular tool angle deviation measurement.
XM series moving column machining center is a product developed for the machining needs of large-scale precision machinery, electric power, wind power, energy, petrochemical, transportation... and other equipment. It has:
● Huge workpiece machining space: For precision machining of various types of structural parts, it can provide super large XYZ axis machining space.
● High-precise positioning: The high-standard geometric accuracy and positioning accuracy capabilities of the whole machine enable large-scale precision machining
● Heavy cutting capacity: Provide a variety of high rated torque spindles to meet the processing and cutting capabilities of various materials.
● Fully automatic multi-face machining: It can be matched with various automatic attachment heads for high tangential speed mold surface machining and various types of precision parts complex angle machining, with excellent tool tip point error automatic correction function, and automatic additional head and tool exchange function, it can realize fully automatic machining performance.
● Milling and turning compound multitask: This machine can be equipped with a high-torque and high-speed vertical turning table to realize milling and turning compound automatic machining.
HFM series is Vision Wide designed for ultra large workpieces machining, which fulfills automatic 5-face machining with super rigidity structure and high positioning accuracy, satisfies demands in heavy cutting ability, angles cutting , 3D mold cutting, and precise contour finishing.
We developed tool center point compensation, auto multi-angle head attachment, and auto tool change system to complete auto 5-face machining.
● Cross beam design with box-in-box structure can reduce deformation caused by Z-axis loaded on unilateral cross beam.
● The gravity center of head is located on the centerline of symmetric structure , the design can reduce the influence from ambient temperature.
● Head adopts hydrostatic transmission design which provides better rigidity, low friction and stability for large Z-axis travel machine.
● 1,500~2,000Nm Spindle Torque output.
● Three axes movement is fully supported by Harden box way with low friction.
● Box ways was heat treated to HRC 50 hardness, and was precisely hand scrapping, then assemble and tune to best accuracy to ensure smooth and precise feeding performance.
● Box-shape with ribs design , main casting structure parts are made of Meehanite grade casting iron with stress- relief heat treatment provide durable, rigid support of the machine.
● Large size Guide ways are designed with optimal span to carry the table, box-shape bed with strong V-shape enforced ribs allows heavy work piece load.
● The best center-line layout of spindle system, spindle is close to the Y box way reduce the unbalanced cutting moment and offset of thermal expansion to minimum.
VHM series construction high performance machining via high feed design and multi-table capability.
● With various high-torque and high-speed spindle, it is widely used in valve, turret, crankcase, precision mold and differential machining.
● With dual workstations APC and 6-pallet change APC system, it enhances the machine’s utilization and realizes fully automatic processing.
● Cutting Speed 1~10,000mm/min
Bed swing diameter: 450mm (17.7")
Saddle swing diameter: 280mm (11.0")
Maximum turning diameter: 260mm (10.2")
Maximum turning length: 300mm (11.8")
Bar capacity: 42mm (1.7")
Power chuck diameter: 6"
Spindle motor power: 7.5/11kw
Spindle speed: 5000rpm
Spindle nose taper: A2-5
X-axis travel: 125+20mm (4.9"+0.8")
Z-axis travel: 300mm (11.8")
X-axis rapid feed rate: 24m/min
Z-axis rapid feed rate: 30m/min
Slide way type: Linear
Tool capacity: 8T
Floor space: 2790x1542x1713mm
Machine weight: 3300kg
www.keepwaycnc.com
Unique design of sloping beam enabled the center of Z axis close to the beam, and s
● Three axes movement is fully supported by Harden box way with low friction.
● Box ways was heat treated to HRC 50 hardness, and was precisely hand scrapping, then assemble and tune to best accuracy to ensure smooth and precise feeding performance.
● Box-shape with ribs design , main casting structure parts are made of Meehanite grade casting iron with stress- relief heat treatment provide durable, rigid support of the machine.
● Large size Guide ways are designed with optimal span to carry the table, box-shape bed with strong V-shape enforced ribs allows heavy work piece load.
● The best center-line layout of spindle system, spindle is close to the Y box way reduce the unbalanced cutting moment and offset of thermal expansion to minimum.
The structural analysis and optimization of the SM machine model stabilizes the structure of the fuselage and provides the best high dynamic rigidity when the machine moves at high speed.
High-precision positioning and emphasis on positioning accuracy provide the best choice for precision machining of auto parts, small car molds, mold bases, mechanical hardware parts and so on.
● Large table clamping area
● Optimized positioning accuracy
● Y axis increases machining stroke
● 15m / min high-speed cutting feed
● Structural design of machine tools for high-torque high-speed cutting applications
● Torque output of full tooth spindle 1,163Nm (15 / 18.5kW)
● Spindle housing is one piece cast to handle long run times with little deformation.
● Large worktable, greatly meet the machining applications of energy petroleum, shipbuilding, large structural parts, construction machinery, diesel engine body etc.
● The enclosed box ram and the gear box are one-piece casting with greatly improves the rigidity and stability of the Z and W axis, and enhances the cutting ability and precision.
Bed swing diameter: 450mm (17.7")
Saddle swing diameter: 280mm (11.0")
Maximum turning diameter: 260mm (10.2")
Maximum turning length: 300mm (11.8")
Bar capacity: 52mm (2.0")
Power chuck diameter: 8T
Spindle motor power: 7.5/11kw
Spindle speed: 5000rpm
Spindle nose taper: A2-6
X-axis travel: 125+20mm (4.9"+0.8")
Z-axis travel: 300mm (11.81")
X-axis rapid feed rate: 24m/min
Z-axis rapid feed rate: 30m/min
Slide way type: Linear
Tool capacity: 8T
Floor space: 2790x1542x1713mm
Machine weight: 3300kg
BM series machines, with typical VW products features of rigid structure and high precision, is unique by the features of movable cross rail and W-axis feed cutting synchronic with other axial feeding. The max. height for work piece & machining is 2,450mm & 2,400mm.
Bed swing diameter: 530mm (20.9")
Saddle swing diameter: 380mm (15.0")
Maximum turning diameter: 360mm (14.2")
Maximum turning length: 500mm / 750mm (19.7" / 29.5" )
Bar capacity: 52mm (2.0") (OPT: 65mm)
Power chuck diameter: 8"
Spindle motor power: 11/15kw
Spindle speed: 4500rpm
Spindle nose taper: A2-6
X-axis travel: 180+20mm (7.1"+0.8")
Z-axis travel: 500mm (19.7")
X-axis rapid feed rate: 24m/min
Z-axis rapid feed rat: 24m/min
Slide way type: Linear
Tool capacity: 8T
Floor space: 3318x1675x1727mm / 4070x1705x1844mm
Machine weight: 4000kg / 5000kg
Bed swing diameter: 530mm (20.9")
Saddle swing diameter: 380mm (15.0")
Maximum turning diamteter: 360mm (14.2")
Maximum turning length: 500mm / 750mm (19.7" / 29.5")
Bar capacity: 75mm (3.0")
Power chuck diameter: 10"
Spindle motor power: 15/18.5kw
Spindle speed: 3500rpm
Spindle nose taper: A2-8
X-axis travel: 180+30mm (7.1+1.2")
Z-axis travel: 500mm / 750mm (19.7" / 29.5")
X-axis rapid feed rate: 20m/min
Z-axis rapid feed rate: 20m/min
Slide way type: Box
Tool capacity: 10T
Floor space: 3508x1658x1854mm / 4070x1705x1844mm
Machine weight: 4500kg / 5200kg
Bed swing diameter: 600mm (23.6")
Saddle swing diameter: 400mm (15.7")
Maximum turning diameter: 500mm (19.7")
Maximum turning length: 750mm (29.5")
Bar capacity: 85mm (3.3")
Power chuck diameter: 12"
Spindle motor power: 15/18.5kw
Spindle speed: 3000rpm
Spindle nose taper: A2-8
X-axis travel: 250+25mm (9.8+1.0")
Z-axis travel: 750mm (29.5")
X-axis rapid feed rate: 20m/min
Z-axis rapid feed rate: 20m/min
Slide way type: Box
Tool capacity: 10T
Floor space: 4307x1770x1942mm
Machine weight: 5700kg
Bed swing diameter: 600mm (23.6'')
Saddle swing diameter: 400mm (15.7")
Maximum turning diameter: 500mm (19.7")
Maximum turning length: 1200mm / 1600mm (47.2" / 63.0")
Bar capacity: 85mm (3.3")
Power chuck diameter: 12"
Spindle motor power: 15/18.5kw
Spindle speed: 3000rpm
Spindle nose taper: A2-8
X-axis travel: 250+25mm (9.8+1.0")
Z-axis travel: 1200mm / 1600mm (47.2" / 63.0")
X-axis rapid feed rate: 20m/min
Z-axis rapid feed rate: 20m/min
Slide way type: Box
Tool capacity: 10T
Floor space: 4786x1932x1941mm
Machine weight: 5900mm
1) Gantry type automatic parts feeding system (pick and place robot)
2) Simple design and straightforward operation with better postioning accuracy and efficiency
3) Suitable for light to heavy hanging loads
4) Easy to program
5) Less limited by floor space constraints
WEB IoT Software for CNC Machines
●Machine monitoring
●Machine Activation rate (visualization)
●Employee work performance KPI
●System function
Gantry type rigid structure
• 40% less floor space required compared to other bridge type machines with similar travel ranges.
• All axial movements are executed by the cutting tool instead of the work-piece, causing less load on the axes and thus improving dynamic accuracy.
High performance B/C two axes head
• Italian-made two axes head designed for high performance & high stability.
• A variety of milling heads are available optionally – high rotation speed / high torque / compact structure.
Advanced cooling technology
• Milling head, spindle, and the X / Y axes drive systems are equipped with advanced cooling systems developed by TECHNAI, THK, and AWEA. These systems keep thermal deformation to a minimum during high speed or heavy cutting operations and thus assure high accuracy.
Superior machine dynamics
• Superior dynamic response with 0.3G acceleration on all linear axes, supported by rigid structural design and advanced drive systems.
Moving Column Bridge Type Multi-face Machining Center, the MCP series, was designed for machining of large work piece as required by aerospace, automotive, and marine industries. The MCP series is also employed by LCD and semiconductor manufacturers. It features an abundant range of motion and a very low profile that makes loading and unloading of work piece very convenient. Key components are either made in-house or sourced from Europe and Japan. With the automatic multi-face machining function part of the standard package, the machining capabilities of the MCP series easily exceeds those of similar machines available on the market, thus ensuring not only your current but also your future needs and demands are met
High-grade moving column structure
• Moving column type machines use 40 % less space than fixed
column type machines.
• The tool magazine is attached to the column which eliminates
the need to move the X-axis for tool changes and substantially
improves tool exchange efficiency.
• The X-axis features dual linear scales which in combination
with the Simultaneous Control Technology effectively prevents
misalignment of the moving columns and ensures optimal
dynamic accuracy.
Strong headstock support structure
• The headstock sits in a U-shaped saddle with reinforced front
structures, fully surrounding it. Four linear guide ways and ten
sliding blocks further increase the rigidity of the structure. The
design effectively reduces distortion and offers excellent
accuracy, even when the headstock is fully extended.
Flexible multi-face machining capability
• An automatic head changer and a two positions ATC system are standardly equipped for improved multi-face machining.
• New generation of in-house made attachment heads is available now.
The VM25 is a modular fully programmable system designed for high performances
applications in grinding machines. It is able to provide solutions for:
- Automatic balancing of the grinding spindle on 1 and 2 plane
- Touch detection to control the contact grinding wheel-work piece and grinding
wheel-dresser, by using acoustic emission and/or power sensors
- In-process and post-process gauging (absolute or comparative)
Any imagination of processing can be achieved by GMT-2000 series
• Looking for advanced processing equipment, with both high productivity and processing capacity for complex workpieces, as well as excellent cost performance. The seemingly impossible task will be fully achieved by GOODWAY GMT-2000 series.
• The GMT-2000 series integrates the functional characteristics of turning centers and machining centers into one. It has the highest 9-axis control and 5-axis simultaneous machining capabilities. It can not only efficiently complete various complex shapes of workpieces, but also easily overcome the need for heavy cutting. This is a versatile model that can be used in all industries.
• In addition, the optional G.LINC smart operating system and various automation equipment can further improve production efficiency, reduce manufacturing costs, and fully meet all your processing needs today and tomorrow.
Packed with the latest machine tools technology and high precision turning capabilities, the Goodway GV-500 series high speed vertical CNC turning center combines a high rigidity structure and precision linear guideways with a servo indexing turret and powerful spindle ( max. torque up to 883 N-m ). These series features a compact machine size with heavy duty turning capabilities. In addition to the GV-500 series, the GV-500X series twin spindles & turrets equipped with loading & unloading systems can complete disk-shape work pieces that need multi-processing in one single setup which saves a great amount of time and increases production efficiency to meet your needs of today and tomorrow.
• Fully enclosed splashguard keep chips and coolant contained for a safe clean working environment.
• The low center of gravity design with 90 degree rotatable control panel provides easy access to load & unload parts and a user friendly operating interface.
• Super compact machine size ( 3.3m ) equipped with rear discharge chip conveyor increases factory space usage while providing you with a convenient conveyor system planning.
With the latest machine tools technology and high quality components, GOODWAY brings you the new GLS-2800 / GLS-3300 series high speed CNC turning center. This series is based on high precise linear guide ways and featured big bore, high power, fast cut and more to provide you machining solution with high efficiency cutting power. Besides, The GLS-2800 / GLS-3300 series equipped with an optional live tooling turret, C-axis, Y-axis and sub-spindle, G.LINC 350 intelligent control system and various automation equipment to reach a complete series and easily meet your machining needs of today and tomorrow.
Equipped with an optional live tooling turret, C-axis, Y-axis and sub-spindle and other advanced features allows GLS-2800/3300 can work on turning, milling, drilling, tapping and off-center milling tasks. The machining capability equals the integration of turning center and machining center, which significantly lowers machining cycle time and manpower, and also prevent accuracy error of switching work-piece to another machine.
he spindle and gears of the right angle milling head (90o milling head, angle head) are made of chrome molybdenum alloy steel and heat treated (carburization). Thus, the milling head is rigid and durable. Its quality is reliable. Such a milling head is suitable for conventional gantry milling machines, CNC gantry milling machines, single arm milling machines, special purpose machines and machining centers. The main body of bidirectional milling type right angle milling head is formed in one piece, so its machining precision is more accurate and stable. Besides, the V-shaped oil seal not only seals the hole tightly, but also has waterproof and dust proof functions. The bidirectional milling saves re-correction time, and enhances work efficiency. This type of milling head, you can select 800RPM (heavy duty cutting type), 2000RPM (moderate cutting type) or 3000RPM (light cutting type) for using depending on the nature of the work and machine spindle speeds. And can mill five sides of the work piece if they work together with our boring-milling heads.
The spindle and gears of the right angle milling head (90 degree milling head, angle head) are made of chrome molybdenum alloy steel and heat treated (carburization). Thus, the milling head is rigid and durable. Its quality is reliable.
Such a milling head is suitable for conventional gantry milling machines, CNC gantry milling machines, single arm milling machines, special purpose machines and machining centers.
The model N75-HSK is a special milling head for motorized spindle, you can select 2000RPM (moderate cutting type) or 3000RPM (light cutting type) for using depending on the nature of the work and machine spindle speeds.
The spindle and gears of the right angle milling head (90 degree milling head, angle head) are made of chrome molybdenum alloy steel and heat treated (carburization). Thus, the milling head is rigid and durable. Its quality is reliable.
Such a milling head is suitable for conventional gantry milling machines, CNC gantry milling machines, single arm milling machines, special purpose machines and machining centers.
The model N75-CV use curvic coupling, which can be positioned quickly, customer can select inside curvic coupling type or outside curvic coupling type for using according the adapter size. Also can select 2000RPM(moderate cutting type) or 3000RPM(light cutting type) for using depending on the nature of the work and machine spindle speeds.
1. This milling head is one of our conventional milling head series, and most suitable for installing to gantry milling machine, single arm milling machine and special purpose machine as heavy duty cutting.
2. Its inner wall is thicker, and its main body is rigid.
3. The spindle of the milling head is made of Japan material and NSK bearings. The inner driving system has passed strict quality inspection, and is sturdy and durable. It functions very well.
4. Travel: 400mm
5. It can work together with our Φ250 right angle milling head (angle head) to
proceed with five-side milling.
1. This milling head is one of our conventional milling head series, and most suitable for installing to gantry milling machine, single arm milling machine and special purpose machine as heavy duty cutting.
2. Its inner wall is thicker, and its main body is rigid.
3. The spindle of the milling head is made of Japan material and NSK bearings. The inner driving system has passed strict quality inspection, and is sturdy and durable. It functions very well.
4. Travel: 600mm
5. It can work together with our Φ250 right angle milling head (angle head) to
proceed with five-side milling.
1. This milling head is one of our CNC boring-milling head series, and most suitable for installing to gantry milling machine, single arm milling machine and special purpose machine as heavy milling.
2. The inner wall is thicker. The main body is rigid.
3. The spindle of the milling head is made of Japan material and NSK bearings. The inner driving system has passed strict quality inspection, and is sturdy and durable. It functions very well.
4. Travel: 600mm
5. It can work together with our Φ250 right angle milling head (angle head) to
proceed with five-side milling.
6. Temperature rises slowly.
1. This milling head is one of our conventional milling head series, and most suitable for installing to gantry milling machine, single arm milling machine and special purpose machine as heavy duty cutting.
2. Its inner wall is thicker, and its main body is rigid.
3. The spindle of the milling head is made of Japan material and NSK bearings. The inner driving system has passed strict quality inspection, and is sturdy and durable. It functions very well.
4. Travel: 350mm
5. It can work together with our Φ250 right angle milling head (angle head) to
proceed with five-side milling.
1. This milling head is one of our CNC boring-milling head series, and most suitable for installing to gantry milling machine, single arm milling machine and special purpose machine as heavy milling.
2. The whole machine uses Japan NSK bearings to ensure smooth operation and long service life.
3. 12-step speed satisfies a variety of machining needs.
4. Four hydraulic locks reduce vibration during heavy cutting, and make the
machining more stable.
5. 22kw permanent magnet synchronous motor or servo motor is employed to ensure big horse power, stable and smooth operation.
1. This milling head is one of our conventional milling head series, and most suitable for installing to gantry milling machine, single arm milling machine and special purpose machine as heavy duty cutting.
2. Its inner wall is thicker, and its main body is rigid.
3. The spindle of the milling head is made of Japan material and NSK bearings. The inner driving system has passed strict quality inspection, and is sturdy and durable. It functions very well.
4. Travel: 300mm
5. It can work together with our Φ250 right angle milling head (angle head) to
proceed with five-side milling.
The spindle and gears of the right angle milling head (90o milling head, angle head) are made of chrome molybdenum alloy steel and heat treated (carburization). Thus, the milling head is rigid and durable. Its quality is reliable. Such a milling head is suitable for conventional gantry milling machines, CNC gantry milling machines, single arm milling machines, special purpose machines and machining centers. Oh Young right angle milling heads provide customers with many choices depending on machine spindle speeds and the nature of the work. The super heavy duty type right angle milling heads with heavy load bearings are suitable for super heavy duty cutting. And can mill five sides of the work piece if they work together with our boring-milling heads.
The spindle and gears of the right angle milling head (90o milling head, angle head) are made of chrome molybdenum alloy steel and heat treated (carburization). Thus, the milling head is rigid and durable. Its quality is reliable. Such a milling head is suitable for conventional gantry milling machines, CNC gantry milling machines, single arm milling machines, special purpose machines and machining centers. Oh Young right angle milling heads provide customers with many choices depending on machine spindle speeds and the nature of the work. The heavy duty type right angle milling heads with heavy load bearings are suitable for heavy duty cutting at low speeds(0-800RPM), finish milling, drilling, boring at high speeds(800-1500RPM). And can mill five sides of the work piece if they work together with our boring-milling heads. We also welcome customer-made orders.
The spindle and gears of the right angle milling head (90o milling head, angle head) are made of chrome molybdenum alloy steel and heat treated (carburization). Thus, the milling head is rigid and durable. Its quality is reliable. Such a milling head is suitable for conventional gantry milling machines, CNC gantry milling machines, single arm milling machines, special purpose machines and machining centers. Oh Young right angle milling heads provide customers with many choices depending on machine spindle speeds and the nature of the work. The light cutting type right angle milling heads with angular contact ball bearings are suitable for light cutting at low speeds(0-800RPM), finish milling at high speeds(800-3000RPM). And can mill five sides of the work piece if they work together with our boring-milling heads. We also welcome customer-made orders.
The spindle and gears of the right angle milling head (90o milling head, angle head) are made of chrome molybdenum alloy steel and heat treated (carburization). Thus, the milling head is rigid and durable. Its quality is reliable. Such a milling head is suitable for conventional gantry milling machines, CNC gantry milling machines, single arm milling machines, special purpose machines and machining centers. Oh Young right angle milling heads provide customers with many choices depending on machine spindle speeds and the nature of the work. The moderate cutting type right angle milling heads with angular contact ball bearings are suitable for moderate cutting at low speeds(0-800RPM), finish milling, drilling, boring at high speeds(800-2000RPM). And can mill five sides of the work piece if they work together with our boring-milling heads.
The spindle and gears of the right
